Dixie Chopper 2014 Zee 2 Owner's manual

700375 08/2013
2014 Zee 2 Owner/Operator Manual
Serial numbers 14XXXXXX and higher

II
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Congratulations on the purchase of your new Dixie Chopper mower! When operated and main-
tained as directed in this manual, Dixie Chopper is condent that this mower will provide you with
years of excellent performance, durability, and trouble free service.
Should you ever have any questions regarding the operation, maintenance, or safety of your
mower, please contact your authorized Dixie Chopper dealer who has been specially trained in
the operation and service of Dixie Chopper mowers.
Please take time to record the information about your new Dixie Chopper mower in the space
below for future reference. Such information may be needed when you contact your authorized
Dixie Chopper dealer with questions.
The general operation, adjustment, and maintenance procedures contained in this manual are
meant for both the beginner and the experienced Dixie Chopper operator. Operating conditions
vary greatly, as do individual skill sets, so take time to learn how to safely operate this machine.
This owner’s manual is considered a permanent part of the mower. It must be available to all of
the operators and/or person(s) servicing the mower. Should the mower be resold, this manual
must remain with the mower.
Illustrations and photographs used in this manual were current as of date of print. Despite this
effort, production changes may have occurred after the time of the purchase of your Dixie Chop-
per; therefore, your unit may vary slightly from what is depicted in this manual.
All information, illustrations, and specications contained in this manual were in effect at the time
of publication. Dixie Chopper reserves the right to change, modify, and/or discontinue specica-
tions and/or design without notice. If there is a change that has been made to your mower which
is not shown or reected in this manual, please see your authorized Dixie Chopper dealer before
operating and/or servicing equipment.
Authorized Dealer:
About This Manual
Model #:
Serial #:
Date purchased:
Engine Model #:
Engine Serial #:

III
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Topic Page#
General Precautions.................................................1
Safety Information ...................................................3
Warranty....................................................................5
Routine Maintenance...............................................8
Maintenance Schedule...8
Maintenance Record...9
Maintenance Points...10
Start-up & Controls................................................11
Safety Interlock System...11
Starting the Mower...12
Controls...13
Operation................................................................14
Cut Height Setting...14
Mowing Speed...14
Mowing...15
Shutdown...............................................................15
Shutdown Procedures...15
Moving the Mower Without Power...15
Bypass Valve...15
Maintenance & Repair...........................................16
Blade Replacement...16
Under Deck Cleaning...16
Battery Maintenance...16
Mower Cleaning & Off-Season Storage...16
Drive Belt Adjustment...17
Drive Belt Replacement...17
Deck Adjustment...17
Preparation for Storage...18
Preparation for New Mowing Season...18
Belt Routing Diagram...19
Notes......................................................................20
Table of Contents

1
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
General Safety Precautions
PLEASE READ AND UNDERSTAND THIS OPERATION MANUAL AND THE INSTRUCTIONS
FURNISHED WITH ATTACHMENTS BEFORE ATTEMPTING TO OPERATE THIS MOWER.
1. Know the location and function of the controls and how to operate them. Know how to stop quickly.
2. Do not allow children under the age of 18 to operate machine.
3. Do not allow anyone to operate the machine without proper instruction.
4. Do not carry passengers.
5. Do not mow when children, pets, or others are present. The operator is responsible for the safety
of others within the vicinity of the operation of this mower.
6. While operating the machine, always:
• place roll over protection system in up position (if applicable)
• wear seat belt if roll over protection system is installed
• keep hands and feet inside of the machine.
7. Keep hands, feet, and clothing away from rotating blades or other rotating parts while engine is
running.
8. Clear the work area of objects (wire, rocks, toys, or debris of any kind).
9. Disengage all attachment clutches, set parking brake, and place steering speed control levers into
neutral-lock (open) position before attempting to start engine.
10. Disengage power to attachments, stop engine, engage parking brake and remove ignition key before
leaving the operator position or leaving machine unattended.
11. Do not attempt to adjust or repair the mower deck, the drive system, the mower blades, or any moving
parts of the machine while the engine is running. You must disengage power to attachments,
disengage PTO (Deck Engagement Switch), set steering speed control levers to neutral-lock, set
parking brake, shut off the engine, and remove key before making any repairs or adjustments or
attempting any of the following tasks:
• Adjusting deck pitch
• unclogging the mower deck chute
• checking blade mounting bolts for proper tightness at the specied intervals
• refueling (never add fuel while engine is running or hot)
Failure to comply with the above may result in personal injury or death.
12. Disengage power to attachments when transporting unit or when unit is not in use.
13. Never operate this mower on slopes exceeding 5O- 10O- 15O degrees in any specic direction.
NOTE: To operate on terrain that exceeds these limits constitutes misuse of the equipment
and as such, any and all injuries as a result of said use are expressly disclaimed.
14. Reduce speed and exercise extreme caution on slopes to prevent tipping and/or loss of control of
mower. Be especially cautious and slow down when changing directions on steep terrain.
15. DO NOT operate on slopes when grass is wet.
16. When mowing downhill, loss of traction and/or braking ability may occur. Use extreme caution and
good judgement before mowing sloped terrain.
17. Stay alert for holes, rocks, roots or other terrain features which may cause loss or sudden increase in
traction. Care must be taken to keep away from drop-offs.
18. Use care when pulling loads or using heavy attachments.
• Use only approved draw bar hitch points.
• Limit loads to those you can safely control.
• Do not turn sharply. Use care when reversing.
19. Watch out for trafc when near or crossing roads, and obey trafc laws. Disengage blades and wait for
them to stop completely before crossing gravel roads.
20. When using any attachments, never direct discharge of materials toward bystanders, nor allow anyone
near the machine while it is in operation.
21. Keep all nuts, bolts, and screws tight to be sure equipment is in safe working condition.

2
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
General Safety Precautions
22. Allow engine to cool before storing in any enclosure.
23. Never attempt to operate mower while under the inuence of alcohol or drugs.
24. Handle gasoline with care.
Follow these guidelines:
• Use approved gasoline container
• Place container out of reach of children
• Use gasoline only as a fuel, never as a cleaner
• Never remove fuel cap while engine is running or hot
• Never add fuel while engine is running or hot
• Never ll fuel tank indoors
• Wipe up spilled gasoline
• Do not smoke while refueling the machine
• Never store equipment with gasoline in the tank inside a building where fumes may reach an
open ame or spark
• Always have a re extinguisher present when using gasoline or other ammable substance.
25. Keep vehicle and attachments in good operating condition. Keep safety devices, such as guards,
shields, and covers, in place and in working condition.
26. Do not operate the mower or attachments if any guards are missing or are not functioning properly.
27. After striking a foreign object, stop and secure the mower, and then inspect for damage. Repair any
damage before restarting and operating the equipment.
28. The machine is calibrated at the factory. Do not change engine governor settings or overspeed the
engine.
29. Disengage power to mower deck before backing up. The mower is not designed to mow in reverse.
Dixie Chopper’s zero turning radius nearly eliminates the need for backing up. Simply turn the mower
around within its own dimension and proceed forward.
30. Do not mow with mower blades that are out of balance, have worn, or have been damaged.
31. Personal protection equipment such as safety goggles, hearing protection and other devices must be
worn while operating the machine. Do not operate or service the mower when barefoot or wearing
open-toed shoes.
32. Use caution when handling mower blades during replacement or maintenance. Wear appropriate
protective gloves and clothing. Failure to comply may result in personal injury.
33. Operate mower only in daylight or good articial light.
34. Do not operate when grass is wet.
35. Do not make sudden turns, stops, starts, reversals, or any other abrupt maneuvers, especially when
negotiating slopes. The steering speed control levers are very responsive to slight movement. Rapid,
rough, or jerky manipulation of the steering speed control levers may result in damage to equipment
and personal injury.
36. Do not run the engine in an enclosure without adequate ventilation. Exhaust fumes contain carbon
monoxide which is harmful to animals and humans. Failure to comply can result in personal injury or
death.
37. Do not work underneath the mower unless it is adequately supported by jack stands or similar type
devices that have a safe working load of at least 2000 lbs or more. Failure to adequately support the
machine in this manner may result in property damage, personal injury, or death.
38. Disconnect the negative battery terminal when setting up, adjusting, or doing repairs on your mower.
Failure to comply may result in personal injury or death.
39. Do not touch hot parts of the mower. Failure to comply can result in personal injury.
40. Give complete and undivided attention to the job at hand.
41. Obey all safety decals.

3
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Safety Information Decals

4
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Parking Brake - The parking brake should be engaged whenever the mower is stationary and
unoccupied.
Safety Interlock System - The mower has a system of safety interlock switches that will not
allow the mower to start unless the steering speed control levers are in the neutral lock position,
the parking brake is set and the deck engaging switch (PTO) is off. If the seat is vacated during
mowing without positioning the controls as previously outlined, the engine will be stopped by the
safety interlock system.
Seat
Switch
Parking
Brake
PTO
On/Off
Safety Features
Steering Neutral
Switches

5
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Warranty
Dixie Chopper Limited Warranty
General Warranty Conditions
Dixie Chopper warrants that it will, at its option, adjust, repair, or replace, any factory original part used
in the manufacturing of a Dixie Chopper complete unit, found to be defective in material or workmanship.
For the purposes of this Warranty, a Dixie Chopper complete unit is dened as a riding lawn mower
manufactured by Dixie Chopper. This warranty is non-transferable absent written authorization by Dixie
Chopper. Dixie Chopper is in no way liable for any special, incidental or consequential damages for
breach of any written or implied warranty on any product. Zee 2 units are designed with residential use in
mind. As such, commercial use of any Zee 2 unit will void this warranty. For the purposes of this warranty
commercial use is dened as any use of the Zee 2 machine to mow property that is not owned and/or
leased by the lawn mowers owner.
Purchaser/Operator’s Responsibilities under the Warranty
As a condition of the Dixie Chopper warranty, the purchaser and or the operator must have fully read
and understood the operator’s manual. This includes being familiar with how to operate the equipment
safely, as well as how to maintain the equipment properly prior to actually operating the equipment. This
Warranty applies only to equipment that is operated under normal conditions and maintained per the
service schedule specied in this owner’s manual. Maintenance of the unit is the sole responsibility of the
owner.
To obtain warranty service, the unit must be registered before obtaining any warranty work. This
information must be submitted to Dixie Chopper within ten (10) days of the original retail purchase date to
enable validation of the warranty period.
A Dixie Chopper mower requiring repair or warranty work must be returned to an authorized Dixie
Chopper service dealer within the warranty period. The expense of transporting the unit to and from the
authorized Dixie Chopper service dealer for warranty work will be the sole responsibility of the purchaser/
owner and in no way will be attributed to Dixie Chopper. All warranty work must be performed by an
authorized Dixie Chopper dealer using genuine Dixie Chopper parts. Failure to have warranty repair
performed by an authorized Dixie Chopper dealer will result in the denial by Dixie Chopper to pay for said
warranty repair work.
Should a Purchaser encounter problems with receiving warranty service from an authorized Dixie
Chopper dealer, or is in need of assistance or clarication of this warranty, contact us at:
Magic Circle Corp.
6302 E. CR. 100 North
Coatesville, IN 46121
NOTE: This warranty is void for any new products purchased through auction web sites. Warranty
is valid only for new products purchased through Authorized Dealer. Proof of purchase required
for all claims.

6
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Warranty (cont.)
Warranty Period & Limitations
The Zee 2 is warranted to be free of defects in material or workmanship for a period of three (3)
years from the retail purchase date by the original purchaser regardless of the amount of hours
of service on the machine. For the rst two years of the warranty period, Dixie Chopper will be
responsible for both parts and labor for all warrantable claims. During the third and nal year of
the warranty, Dixie Chopper will be responsible for the cost of parts only for warrantable claims.
Labor costs will be the sole responsibility of the owner of the machine during the third year of the
warranty period.
Dixie Chopper original equipment batteries are warranted against OEM factory defects in materials
or workmanship for a period of 1 year from the retail purchase date. If a battery failure occurs
before one (1) year has passed since the date of retail purchase, the battery will be replaced at the
cost of the standard replacement battery. Abuse or using the battery for purposes not associated
with its intended use voids the battery warranty.
Consumable wear items such as tires, blades, spark plugs, belts, etc. are warranted for a period
of ninety (90) days from the date of retail purchase for defects in materials or workmanship. This
warranty does not apply to damage or wear of such consumable components as a result of abuse
or normal wear and tear.
Warranty Exclusions & Remedies
Dixie Chopper does not warranty the following: 1) parts not manufactured or sold by Dixie
Chopper; 2) after market components or accessories for use on a Dixie Chopper brand mower; 3)
repairs, alterations or installation of accessories by non-authorized Dixie Chopper service dealers;
4) repairs or replacement resulting from the installation or use of unauthorized parts, accessories
or attachments; 5) damage to a Dixie Chopper unit that occurred as a result of it being used for
another purpose other than which it was designed; 6) damage or depreciation as a result of normal
wear and tear, or improper or inadequate maintenance of the mower as specied in this owner’s
manual 7) damage as a result of an act of God to include but not limited to hail, wind, rain, ood,
lightning, re, smoke, sun exposure, earthquake, etc..; 8) repairs or replacement as the result of
any alterations or modications, in the determination of Dixie Chopper, which adversely affects the
performance or operation of the mower; 9) costs associated with the routine maintenance of the
mower or costs of parts associated with such to include those specied by this owner’s manual to
include oil, grease, and consumable components; 10) repairs associated with improper fuel usage,
to include the use of gasoline containing an excess of 10% ethanol alcohol by volume.

7
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Warranty (cont.)
Dixie Chopper is in no way liable for consequential damages, negligence, strict liability in tort, or
any other legal theory. Likewise, Dixie Chopper is not responsible for damages associated with
these theories to include but not limited to: 1) lost prots or revenue; 2) loss of the use of any
equipment to include the equipment that is subject to this warranty; 3) any down time as a result
of warranty work being performed to include temporary replacement equipment; 4) cost of capital;
and 5) claims asserted by third parties, including customers. Some jurisdictions prohibit the
exclusion or limitation of incidental or consequential damages, so the above may not be applicable
to you.
DISCLAIMER
THE FOREGOING WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IN THE EVENT THAT
A DIXIE CHOPPER IS PURCHASED FOR CONSUMER USE, ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS LIMITED TO THE
DURATION OF THIS LIMITED WARRANTY. SOME JURISDICTIONS PROHIBIT LIMITATIONS
ON THE LENGTH OF TIME AN IMPLIED WARRANTY LASTS; AS SUCH THIS LIMITATION
MAY NOT APPLY TO YOU. THIS WARRANTY PROVIDES YOU WITH SPECIFIC LEGAL
RIGHTS, AND OTHER RIGHTS MAY BE PROVIDED IN YOUR JURISDICTION.
Complete Warranty
Absent a modication in writing signed by all the parties and approved by Magic Circle, this
agreement constitutes the complete and exclusive agreement between the parties. This
agreement is to replace and or supersede all other prior agreements written or oral.

8
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Routine Maintenance
Maintenance should be performed per the requirements in the chart below or as needed.
2IMPORTANT NOTE: CHANGE ENGINE OIL AND FILTER AFTER FIRST 8 HOURS OF USE AND
THEN EVERY 25 HOURS THEREAFTER. FAILURE TO DO SO WILL VOID THE ENGINE WARRANTY.
3IMPORTANT NOTE: CHANGE TRANSAXLE OIL AND FILTER AFTER FIRST 75 HOURS OF USE
AND THEN EVERY 400 HOURS THEREAFTER. FAILURE TO DO SO WILL VOID THE TRANSAXLE
WARRANTY.
NOTE: THE RECOMMENDED TRANSAXLE OIL FOR YOUR MOWER IS DIXIE CHOPPER PART #902353.
We strongly urge that you use this oil in the event that you should need to rell or add hydraulic reservoir. How-
ever if this is unavailable, you may substitute a motor oil of 89 SUS or better (at 212 degrees Fahrenheit) , such
as a high grade 10W50,15W40, 15W50, or 20W50
Engine Oil: Consult engine manual.
Lube Grease: Dixie Chopper Heavy Duty Grease part number 902373.
1Engine air lters should be cleaned/changed more frequently in dusty conditions or when airborne
debris is present.
Routine Maintenance Chart
Before
Each
Use
Every
25
Hours
Every
100
Hours or
Annually
Every
400
Hours
Check Safety Interlock System X
Inspect unit for loose hardware and/or damaged parts X
Inspect tires for wear and proper ination
(front 15 psi, rear 10psi)
X
Inspect fuel level X
Inspect for fuel and/or oil leaks X
Inspect engine oil coolers for build up X
Inspect and clean air intake screen X
Check engine oil level (See engine owner’s manual) X
Check blades for sharpness and wear X
Check hydraulic overow tank X
Change transaxle oil and lter3X
Inspect engine cooling ns under engine shroud
(See authorized Dixie Chopper dealer for cleaning if build-up
exists).
X
Check engine air cleaner. Replace if necessary1X
Change engine oil and lter
(See engine owner’s manual)2X
Change engine fuel lter X
Replace cutting blades X

9
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Routine Maintenance
Engine Oil/Filter
Change Air Cleaner Inspection/Change
Fuel Filter
Change
Record Service Dates

10
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Routine Maintenance
Engine Air
Filter Cover
Engine Oil
Fill/Dip-stick
Engine Oil
Filter Fuel Filter
Battery
under seat
Grease Zerk
(1 Each Side)

11
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Controls and Operation
Before Starting the Mower:
1. Ensure that all shields and the mower deck
discharge chute are in place. Never
attempt to clear discharge areas or the
mower deck blades without disengaging
mower deck, setting the parking brake,
shutting off the engine, and removing the
ignition key.
2. Conrm that mower deck blades are sharp
and balanced to ensure the optimum
quality of cut.
NOTE: Refer to blade replacement
procedures for detailed instructions
on how to safely and properly
maintain mower blades.
3. Check tires for wear and proper ination.
4. Check levels of fuel, engine oil and
hydraulic system oil.
Do not run the mower engine in
conned areas such as a closed
garage. Take care not to inhale
exhaust gases as they contain carbon monox-
ide, which is a colorless odorless gas, which can
cause unconsciousness and is potentially lethal.
Handle fuel with care. Use only
approved fuel containers. Never
add fuel while the engine is run-
ning or hot. Fill fuel tank outdoors, never indoors.
Replace the fuel tank cap securely and wipe up
all spilled fuel. Failure to comply may
result in damage to the equipment and/or injury
to persons
Before starting the engine, be-
come familiar with all controls.
Read and understand this Opera-
tion Manual thoroughly. Always check for proper
engine oil level before starting engine. Failure to
comply may result in damage to the equipment
and injury to persons.
CAUTION
WARNING
C UTI N
W NIN
AU N
WARN
Safety Interlock System
The mower has a system of safety interlock switch-
es that will not allow the mower to start
unless the following conditions are met:
• Steering speed control levers are in neutral
lock position.
• Parking brake is set.
• Deck engaging switch (PTO) is off.
If the seat is vacated during operation without posi-
tioning the controls as previously outlined, the en-
gine will be stopped by the safety interlock system.
Speed Control
Levers
PTO Switch
Parking
Brake

12
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
1. Place the steering speed control levers in
the neutral lock position.
2. Sit in the mower seat.
3. Pull the parking brake lever all the way up
to set parking brake.
4. Push the throttle lever forward to 3/4 power.
5. Pull choke knob until it stops.
6. Turn the ignition switch to the START
position. Release the key after the engine
starts. The Key will automatically return to
the RUN position.
7. After the engine has started, push in the
choke knob and allow engine to warm up.
NOTE: If the engine fails to start after
6-7 seconds of continuous cranking,
turn the key to the OFF position
and allow the starter motor to cool.
See below for location of controls
Throttle
Ignition
Switch
PTO
Switch
The pitch of the steering levers is adjustable to ac-
comodate the comfort of the mower operator. Each
lever is independently adjustable by manipulating
the bolts on the lower portion of the lever. To adjust
the lever:
1. Loosen the two bolts in the bracket which holds
the steering lever. Do not remove the bolts.
2. Adjust the angle of the steering lever by using
the upper bolt as a pivot point and moving the le-
ver either back or forth. The lower bolt will slide
through the opening in the lever.
3. Once the desired position is achieved, re-tighten
the steering lever bolts.
The height of the steering levers may also be adjust-
ed by moving the entire upper portion of the lever up
or down into the pre-drilled holes in the lower brack-
et (lever shown in the middle position).
Steering Level Adjustment To Start the Mower:
Controls
Choke
Steering
Lever Bolts

13
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Start-Up and Controls
Do not move the steering speed
control levers too rapidly or
start and stop the mower suddenly, especially on
grades. Failure to comply will result in personal
injury or death.
W RNING
The mower is equipped with a separate Transaxle
for each rear wheel and are controlled by the steer-
ing speed control levers. The left lever controls the
left rear wheel and the right lever controls the right
rear wheel.
To move forward, push both levers forward at the
same time, slowly and evenly. (See below)
To speed up the forward movement, push levers
farther forward. The farther they are pushed, the
faster the mower will travel.
To move in reverse, pull both levers backward at
the same time, slowly and evenly. (See below)
Steering Speed Control Levers:
ZERO
RIGHT TURN
REVERSE
RIGHT TURN
FORWARD
RIGHT TURN
REVERSEFORWARD
To speed up the backward movement, pull levers
toward you. The closer they are pulled, the faster
the mower will travel. NOTE: Never mow in re-
verse.
To turn, slow the mower’s ground speed, then
further slow the speed of the wheel. Slow the right
wheel for a right-hand turn or the left wheel for a
left-hand turn.
(See below)
To reduce the speed of the mower, move the
steering speed control levers forward or backward
toward the neutral position.
Refer to the illustrations of steering speed control
levers’ positions shown below.
To execute a Zero Radius turn, you must put one
wheel in reverse and one wheel in forward.
Refer to illustrations shown below of the steering
speed control levers’ position relative to the mower
wheels and the direction in which the levers turn
them.

14
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Operation
The mower is designed to operate most ef ciently at
maximum blade speed (engine 3600 rpm).
The speed of the mower should allow the mower
deck blades to maintain this maximum speed while
mowing across turf. Control the ground speed with
speed control levers. Slow the mower for cutting tall
grass, grass that is heavy with moisture, or when
moving uphill. If ground speed is too fast or blade
speed is too slow, mowing will be uneven because
the mower blades will not be able to lift grass into
cutting position as the mower passes over the
ground.
Set the mowing deck appropriately to achieve the
desired height of your cut. The recommended
cutting height is 2-3 inches (5-7 cm), though your
preference may be a higher or lower cut.
Tall grass or weeds should be cut with the mower
deck set to its highest position.
The  rst time you mow, set the cut height slightly
higher than normal, then adjust accordingly.
1. Refer to the deck height indicator decal
adjacent to the deck height pedal.
2. Determine the appropriate setting for your
desired cut height, starting with the
highest.
3. Adjust the setting by applying slight
pressure to the pedal handle towards the
middle of the mower and then raising or
lowering the pedal. Ensure the stop in
the lever settles into the appropriate notch
in the rail.
Setting the Cutting Height Mowing Speed
Deck Height
Adjustment
Pedal
Deck Height
Setting Indicator
*Each hole is approximately
1/2” change in cut height.
Fuel level Indicator
The fender on the trim side of the mower has a cut
out in the stainless steel allowing for easy fuel level
assessment.
Fuel Level Indicator
Handle fuel with care. Use only
approved fuel containers. Never
add fuel while the engine is run-
ning or hot. Fill fuel tank outdoors, never indoors.
Replace the fuel tank cap securely and wipe up
all spilled fuel. Failure to comply may
result in damage to the equipment and/or injury
to persons.
CAUTI N
WA N N

15
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
NOTE: Engine may be stopped at any time by
turning the ignition key to the OFF position.
1. Move the steering speed control levers to
neutral position to stop mower movement.
2. Push the deck engaging switch (PTO) down
to disengage mower deck blades.
3. Pull the parking brake lever all the way up.
4. Move the throttle to the idle position.
5. Allow the engine to idle for two minutes.
6. Turn the ignition key to the OFF position
and remove the key, even if leaving the
mower unattended for only a few minutes.
NOTE: Do not exceed a speed of 2 mph when
moving the mower without power.
In order to transport the mower without power, you
must  rst release the hydraulic pressure by using
the bypass lever located on each transaxle. Gain
access to the bypass levers under the main chassis,
behind the rear wheels. The levers are held in the
front locking notch under spring
pressure. Pull the lever toward the back of the mow-
er until detent is felt in handle, enabling the mower
to be moved without power.
Bypass Lever
(1 per transaxle, 2 total)
Under rear of mower, looking forward
NOTE: Always set engine speed at full- throttle
when mowing. This engine speed will provide
the necessary airfl ow to the engine cowling to
prevent overheating and will maintain blade
speed for a satisfactory quality of cut. If the
engine pulls below full throttle when under load,
slow down the ground speed and allow the en-
gine to recover to full throttle.
Slow the mower for cutting tall grass or when
mowing uphill. If ground speed is too
fast or blade speed is too slow, mowing will
be uneven because the mower blades will not be
able to lift the grass into cutting
position as the mower passes over the ground.
1. Set the mowing deck height to desired cut
height
2. To release the parking brake, push the
parking brake lever all the way down.
3. Set the throttle to full throttle position.
4. Engage the mower deck by pulling up on
the deck engaging switch (PTO).
5. Set the throttle at the full-throttle
position.
6. Steer and accelerate the mower using the
steering speed control levers as explained
in this manual.
To Mow
Mower Shutdown Procedure
To Tow
Operation

16
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Basic Mower Adjustments, Maintenance, and Repair
AUT ON
NEVER work with mower blades
while mower is running. Make
sure that ignition switch is off,
key is removed, PTO switch is disengaged, steer-
ing speed control levers are in neutral lock, and
parking brake is on. Failure to comply can result
in personal injury or death.
A N N While setting up, repairing, or
transporting your mower, dis-
connect the negative battery terminal. Failure to
comply can result in personal injury or death.
A N
WARN NG
Use caution when handling mow-
er blades during replacement or
maintenance. Wear appropriate protective gloves
and clothing. Cover the sharp cutting edges of the
blades. Failure to comply can result in personal
injury.
AU N Do not clean the underside of
the deck with a pressure wash-
er. Water can get in and under
seals and cause damage to equipment.
Clean the underside of the deck frequently.
Accumulation of debris seriously impairs the mow-
er’s ability to “lift” the grass into cutting position and
discharge the clippings evenly. Build up on the
underside of the mower deck often results in a poor
quality of cut.
Under Deck CleaningBlade Replacement
1. Chock rear tires.
2. Lift front end of mower and support it with a
jack or jack stands that have sufcient safe
working load capacities.
3. Wedge a short piece of lumber between the
mower blade and the mower deck to
immobilize the blade while removing and
reattaching hardware.
4. Remove bolts and washers attaching blade
to blade spindle shafts, before removing
blades.
5. Apply anti-seize compound to threads of
attaching bolts before installation of new or
sharpened blades.
6. In reverse order as removed, install new or
sharpened blade with spacer, washers, and
bolts. Make certain to keep the lift area
(turned-up section of the blade) facing the
underside of mower deck. Ensure that the
ber washer (which acts as a vibration
damper) is against the blade. (Replace ber
washer if damaged or degraded)
7. Tighten bolts to a torque of 115-130 ft-lbs.
During off-season storage, use a trickle charger to
maintain the battery.
Battery Maintenance
Mower Cleaning & Off-Season Storage
WA N N
Prior to performing any and all
maintenance, make sure that
the ignition switch is off and
key removed, PTO switch is disengaged, steering
speed control levers are in neutral lock, and park-
ing brake is on. Failure to comply may result in
personal injury or death.
Clean and store the mower at the end of the mowing
season as follows:
1. Perform steps as applicable under routine
maintenance.
2. Remove all grass, dirt, and debris from the
machine. Wash mower with an automotive
type detergent.
3. Thoroughly apply grease to grease zerks as
shown on page 10.
4. Check tires for proper ination.
5. Start mower and engage PTO for
approximately one minute to remove excess
water from belts and pulleys.

17
700375 08/2013
Dixie Chopper ▪ 6302 E. County Road 100 N. ▪ Coatesville, IN ▪ 46121 ▪ www.dixiechopper.com
Basic Mower Adjustments, Maintenance, and Repair
Replace the drive belts if they show signs of cuts,
tears, burns caused by slipping, or excessive wear.
Refer to the Routine Maintenance section of this
manual for a schedule of replacement.
1. Loosen the tension on the vertical/ horizon
tal idler pulley by pulling it away from belt.
2. Remove belt from pulley noting the routing of
belt.
3. Install new belt onto pulley, routing it in the
same con guration as the replaced belt.
The pulley can be moved as needed.
See belt routing on page 19.
Drive Belt Replacement
AU O
Never attempt to make any
adjustments to mower deck or
work under it while mower is
running. Make sure that ignition switch is off and
key removed, PTO switch is disengaged, steer-
ing speed control levers are in neutral lock, and
parking brake is on. Failure to comply will result in
personal injury or death.
Deck Drive Belt Tension (Non-Adjustable)
Engine to Deck
Idler Arm
Hour Meter
Functions:
1. Tachometer
2. Engine Hours
3. System Voltage
4. Initial Oil Change (Break in oil)
5. Scheduled Oil Service Alert
6. Air  lter service Alert
7. Fuel  lter service Alert
Operation:
Push and release mode button to toggle between
functions, the mode button will also be used to clear
alerts and/or timers.
The service alert timer counts down from a set
interval,when the hour meter reaches the GENTLE
ALERT INTERVAL for a qualifying function your meter
will begin to  ash messages such as CHG OIL, SVC
AIR FILTER and SVC FUEL FILTER. As the interval
countdown continues and 0 hours remain for service
intervals messages such as CHG OIL NOW, SVC
AIR FILTER NOW, SVC FUEL FILTER NOW will be
displayed.
Reset Procedure:
Select the alert or timer you would like to reset press
and HOLD the mode button for 3 to 7 seconds (an
alert or timer reset can be performed at any time).
Mode Button
