Dixon Bayco FT390 Series Operating and maintenance manual

Maintenance & Operating
Instructions
For
Dixon Bayco
Trailer Mounted Dual Sockets
Canada:
Dixon Group Canada Limited
Innisfil (Barrie), Ontario
Phone: [phone]
Fax: [phone]
Toll Free: 877-963-4966
E-mail: [e-mail]
USA:
Dixon Bayco USA
Chestertown, Maryland
Phone: [phone]
Fax: [phone]
Toll Free: 800-355-1991
E-mail: [e-mail]
Mexico:
Dixva, S. de R.L. de C.V.
Monterrey, N.L
Phone: [phone]-DIXON (34966)
Fax: [phone]
E-mail: [e-mail]
Europe:
Dixon Group Europe Ltd
Preston, England
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
Asia Pacific:
Dixon (Asia Pacific) Pty Ltd Wingfield,
South Australia
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
dixonvalve.com
For Sales and Service Contact

FT390 Series Trailer Mounted Dual Sockets
2 877.582.3569 FT390 SERIES
PRODUCT DESCRIPTIONS:
These instructions cover the following FloTech products:
FT390 Basic Dual Socket
FT390G Dual Socket with Ground Bolt Installed
FT390GT Dual Socket with Ground Bolt and Trailer I.D. Module
Installed
FT390Pxx Plug & Play Version
FT390V Basic Dual Socket –Vertical Mounting
FT391 Dual Socket with 4J Slots on Optic & Thermistor
FT391G Dual Socket with 4J Slots on Optic & Thermistor & Ground
Bolt Installed
FT391GT Dual Socket with 4J Slots on Optic & Thermistor & Ground
Bolt & Trailer I.D. Module Installed
FT391V Dual Socket with 4J Slots on Optic & Thermistor –Vertical
Mounting
FT391VG Dual Socket with 4J Slots on Optic & Thermistor, Ground
Bolt Installed –Vertical Mounting
FloTech sockets are mechanically and functionally compatible with
API 1004 Cargo Tank Bottom Loading Recommended Practice.
INSTALLATION
Sockets are to be mounted on the same side of the trailer as the
bottom loading equipment. Sockets are normally located within 3 feet
of the bottom loading adapters so the rack plug and cord will reach the
socket without over stretching the cord. Use the socket body as a
template to drill four 5/16" holes as shown in Diagram 1. Mount the
socket body to the trailer using four 5/16" bolts and lock washers.
DIAGRAM 1

FT390 Series Trailer Mounted Dual Sockets
FT390 SERIES 877.582.3569 3
DIAGRAM 1V Vertical Mounting

FT390 Series Trailer Mounted Dual Sockets
4 877.582.3569 FT390 SERIES
WIRING INSTRUCTIONS
Wire the sockets to the on-board monitor according to Diagram
2 below. Double-check your wiring connection when complete.
If you are connecting a FT390Pxx Plug & Play version, apply
grease (supplied with each unit) to the plug. Connect the
connector on the FT390Pxx to the connection on the Onboard
Monitor; be sure to align the connector cut outs. The connector
should plug together easily. DO NOT FORCE. Attach the White
retaining clip to hold the connectors together.
PATENT PENDING
For Technical Assistance Call 877 582 3569
DIAGRAM 2

FT390 Series Trailer Mounted Dual Sockets
FT390 SERIES 877.582.3569 5
Dixon Bayco Warranty
For complete warranty information, please refer to the latest
Dixon catalog.
