DJ-Tech Mix Free User manual

MIX FREE
PC MEDIA CONTROLLER
USER MANUAL

Note-on message
BUTTONs MIDI Command IN
(Pushed) MIDI Command IN (Release)
MONITOR 09 90 10 7F 09 90 10 00
BEND - / FX
SELECT UP 09 90 11 7F 09 90 11 00
BEND + / FX
SELECT DOWN 09 90 12 7F 09 90 12 00
PLAYLIST
ENTER 09 90 13 7F 09 90 13 00
BEAT 1 09 90 14 7F 09 90 14 00
BEAT 2 09 90 15 7F 09 90 15 00
BEAT 3 09 90 16 7F 09 90 16 00
BEAT 4 09 90 17 7F 09 90 17 00
SYNC 09 90 18 7F 09 90 18 00
CUE 09 90 19 7F 09 90 19 00
PLAY SAMPLE/
AUTO LOOP 09 90 20 7F 09 90 20 00
SCRATCH 09 90 21 7F 09 90 21 00
MIX TO A 09 90 22 7F 09 90 22 00
PLAY 09 90 23 7F 09 90 23 00
HI KILL 09 90 24 7F 09 90 24 00
MID KILL 09 90 25 7F 09 90 25 00
LOW KILL 09 90 26 7F 09 90 26 00
LEDs MIDI Command
OUT (LED ON) MIDI Command OUT (LED OFF)
PLAYSAMPLE 09 90 20 7F 09 90 20 00
SCRATCH 09 90 21 7F 09 90 21 00
MIX TO A 09 90 22 7F 09 90 22 00
PLAY 09 90 23 7F 09 90 23 00
HI KILL 09 90 24 7F 09 90 24 00
MID KILL 09 90 25 7F 09 90 25 00
LOW KILL 09 90 26 7F 09 90 26 00
AUTO LOOP 09 90 27 7F 09 90 27 00
BEATMATCH A1 09 90 28 7F 09 90 28 00
BEATMATCH A2 09 90 29 7F 09 90 29 00
BEATMATCH A 3 09 90 2A 7F 09 90 2A 00
BEATMATCH A4 09 90 2B 7F 09 90 2B 00
MIXFREEMAP CHANNEL 1 (LEFT DECK)

Control change message
CTRL MIDI Command MIDI Command
PITCH / XFACTOR 0B B0 30 7F(Maximal) 0B B0 30 00(Minimal)
VOLUME FADER 0B B0 31 7F(Maximal) 0B B0 31 00(Minimal)
PLAYLIST 0B B0 40 41(Forward) 0B B0 40 3F(Reverse)
SEARCH 0B B0 41 41++(Forward) 0B B0 41 3F--(Reverse)
MIXFREEMAP CHANNEL 1 (LEFT DECK)

Note-on message
BUTTONs MIDI Command IN
(Pushed) MIDI Command IN (Release)
MONITOR 09 91 10 7F 09 91 10 00
BEND - / FX
SELECT UP 09 91 11 7F 09 91 11 00
BEND + / FX
SELECT DOWN 09 91 12 7F 09 91 12 00
PLAYLIST
ENTER 09 91 13 7F 09 91 13 00
BEAT 5 09 91 14 7F 09 91 14 00
BEAT 6 09 91 15 7F 09 91 15 00
BEAT 7 09 91 16 7F 09 91 16 00
BEAT 8 09 91 17 7F 09 91 17 00
SYNC 09 91 18 7F 09 91 18 00
CUE 09 91 19 7F 09 91 19 00
PLAY SAMPLE
/ AUTO LOOP 09 91 20 7F 09 91 20 00
SCRATCH 09 91 21 7F 09 91 21 00
MIX TO B 09 91 22 7F 09 91 22 00
PLAY 09 91 23 7F 09 91 23 00
HI KILL 09 91 24 7F 09 91 24 00
MID KILL 09 91 25 7F 09 91 25 00
LOW KILL 09 91 26 7F 09 91 26 00
LEDs MIDI Command OUT
(LED ON) MIDI Command OUT (LED OFF)
PLAY SAMPLE 09 91 20 7F 09 91 20 00
SCRATCH 09 91 21 7F 09 91 21 00
MIX TO B 09 91 22 7F 09 91 22 00
PLAY 09 91 23 7F 09 91 23 00
HI KILL 09 91 24 7F 09 91 24 00
MID KILL 09 91 25 7F 09 91 25 00
LOW KILL 09 91 26 7F 09 91 26 00
AUTO LOOP 09 91 27 7F 09 91 27 00
BEATMATCH B1 09 91 28 7F 09 91 28 00
BEATMATCH B2 09 91 29 7F 09 91 29 00
BEATMATCH B3 09 91 2A7F 09 91 2A00
BEATMATCH B4 09 91 2B 7F 09 91 2B 00
MIXFREEMAP CHANNEL 2 (RIGHT DECK)

Control change message
CTRL MIDI Command MIDI Command
PITCH / Y FACTOR 0B B1 30 7F(Maximal) 0B B1 30 00(Minimal)
VOLUME FADER 0B B1 31 7F(Maximal) 0B B1 31 00(Minimal)
PLAYLIST 0B B1 40 41(Forward) 0B B1 40 3F(Reverse)
SEARCH 0B B1 41 41++(Forward) 0B B1 41 3F--(Reverse)
MIXFREEMAP CHANNEL 2 (RIGHT DECK)
