DK Digital DVB-T237R User manual

CHANNEL

TO REDUCE THERISK OF FIREAND ELECTRIC SHOCK,DO NOT EXPOSETHIS UNIT TO
RAIN OR MOISTURE.
IMPORTANT SAFEGUARDS
Read and Follow Instructions- Allthe safety and operation instructions
should be read beforethe video product is operated. Follow all
operating instructions.
Retain Instructions- The safety andoperating instructions should be
retained for future reference.
Heed all Warnings-Comply with allwarnings on the video product and in
the operating instructions.
Polarization- This video product isequipped with a polarized alternating
-current line plug. This plugwill fit into the poweroutlet, try reversing
the plug. If the plug still fails to fit,contact your electrician to replace
your obsolete outlet. To preventelectric shock, do not usethis polarized
plug with an extension cord,receptacle, or other outlet unlessthe
blades can be fully insertedwithout blade exposure. If youneed an
extension cord, use a polarizedcord.
Power Sources- This video productshould be operated only fromthe
type of power source indicatedon the marking label. Ifyou are not sure
of the type of powersupply to your home, consultyour video dealer or
local power company. For videoproducts intended to operate from
battery power, or other sources,refer to the operating instructions.
Overloading- Do not overloadwall outlets or extensioncords as this can
result in a risk offire or electric shock. OverloadedAC outlets, extension
cords, frayed power cords, damagedor cracked wire insulation, and
broken plugs are dangerous, Theymay result in a shockor fire hazard.
Periodically examine the cord, andif its appearance indicated damageor
deteriorated insulation, have it replacedby your service technician.
Power-Cord Protection- Power-supply cords shouldbe routed so that
they are not likely tobe walked on or pinchedby items placed upon or
against them, paying particularattention to cords at plugs,convenience
receptacles, and the point where they exit fromthe video product.
Ventilation- Slots and openings inthe case are provided forventilation
to ensure reliable operation ofthe video product and toprotect it from
overheating. These openings must notthe blocked or covered. The
openings should never be blockedby placing the video producton a
bed, sofa, rug, or heatregister. This video product shouldnot be placed
in a built-in installation suchas a book case orrack, unless proper
ventilation is provided or thevideo product manufacturer's instructions
have been followed.
Attachments- Do not use attachmentsunless recommended by the video
product manufacturer as they maycause hazards.
: To reduce the
risk of fire andelectric shock, do
not remove the cover(or back) of
the unit. Refer servicingonly to qualified servicepersonnel.
The lightning flash with arrowheadsymbol, within an equilateral
triangle, is intended to alertthe user to the presence of uninsulated
"dangerous voltage" within product's enclosure that may be of
sufficient magnitude to constitute arisk of electric shock.
The exclamation point within anequilateral triangle is intended to
alert the user to thepresence of important operationand servicing
instructions in the literature accompanyingthe appliance.
WARNING: TO REDUCE THE RISKOF FIRE OR ELECTRIC SHOCK,DO
NOT EXPOSE THIS APPLIANCE TORAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK,MATCH WIDE BLADE OF
PLUG TO WIDE SLOT ANDFULLY INSERT.
In addition to thecareful attention devoted toquality standards
in the manufacture ofyour video product, safetyis a major factor
in the design ofevery instrument. However, safetyis your
responsibility, too. This sheetlists important information thatwill
help to assure yourenjoyment and proper useof the video
product and accessory equipment.Please read them carefully
before operation and usingyour video product.
Installation
Water and Moisture- do notuse this video product nearwater for example,
near a bath tub, washbowl, kitchen sink or laundry tub, in a wet basement,or
near a swimming pool andthe like. Caution: Maintain electricalsafety.
Powerline operated equipment oraccessories connected to thisunit should
bear safety certification mark onthe accessory itself and shouldnot be
modified so as to defeatthe safety features. Thiswill help avoid any andshould
not be modified so asto defeat the safety features.This will help avoid any
potential hazard from electrical shockor fire. If in doubt,contact qualified
service personnel.
Accessories- Do not place thisvideo product on an unstablecart, stand, tripod,
bracket, or table. The videoproduct may fall, causing seriousinjury to a child or
adult as well as seriousdamage to the video product. Use this video product
only with a cart, stand,tripod, bracket, or table recommendedby the
manufacturer's or sold withthe video product. Any mounting of the product
should follow the manufacturer's instructionsand use of a mountingaccessory
recommended by the manufacturer.
A video product and cartcombination should be moved withcare. Quick stops,
excessive force, and uneven surfacesmay cause the video productand cart
combination to overturn.
Note to CATV system installer
This reminder is provided tocall the CATV system installer'sattention to
Section 820-40 of the NECwhich provides guidelines for propergrounding
and, in particular, specifies thatthe cable ground shall beconnected to the
grounding system of the building,as close to the pointof cable entry as
practical.
Outdoor Antenna Grounding- Ifan outside antenna or cablesystem is
connected to the video product,be sure the antenna orcable system is
grounded so as to providesome protection against voltage surgesand built-up
static charges. Section 810 ofthe National Electrical Code, ANSI/NFPA No.70-
1984 (Section 54 of CanadianElectrical Code, Part1) providesinformation with
respect to proper grounding ofthe mast and supporting structure,grounding
of the lead-in wire toan antenna-discharge unit, connection togrounding
electrodes, and requirements for thegrounding electrode.
Power Lines-An outside antenna systemshould not be located inthe vicinity of
overhead power lines, otherelectric light or powercircuits, or where itcan fall
into such power lines orcircuits. When installing an outsideantenna system,
extreme care should betaken to keep fromtouching or approaching such
power lines or circuits, ascontact with them might befatal. Installing an
outdoor antenna can be hazardousand should be left toa professional
antenna installer.
Use
Cleaning- Unplug this video product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Objects that may touch dangerous voltage points or "short-out" parts could result in
a fire or electric shock. Never spill liquid of any kind on the video product.
Lightning-For added protection for this video product during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna or cable system. This will prevent damage to
the video product due to lightning and power line surges.
Service
Servicing-Do not attempt to service this video product yourself, as opening or
removing covers may expose you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
Conditions Requiring Service-Unplug this video product from the wall outlet and
refer servicing to qualified service personnel under the following conditions:
A. When the power-supply cord or plug is damaged.
B. If liquid has been spilled, or objects have fallen into the video product.
C. If the video product has been exposed to rain or water.
D. If the video does not operate normally by following the operating instructions.
Adjust only those controls that are covered by operating instructions.
Improper adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore the video product
to its normal operation.
E. If the video product has been dropped or cabinet has been damaged.
F. When the video product exhibits a distinct change in performance-this
indicates a need for service.
Replacement Parts-When replacement parts are required, have the service
technician verify that the replacements he uses have the same safety characteristics
as the original parts. Use of replacements specified by the video product
manufacturer can prevent fire, electric shock, or other hazards.
Safety Check-Upon completion of any service or repairs to this video product, ask the
service technician to perform safety checks recommended by the manufacturer to
determine that the video product is in safe operating condition.
Wall or Ceiling Mounting- The product should be mounted to a wall or ceiling only
as recommended by the manufacturer.
Heat-The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifiers) that products heat.
10.
11.
11a.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
CAUTION
The apparatus shall not beexposed to dripping or splashing,and that no
objects filled with liquids, suchas vases, shall be placeon the apparatus.
SAFETY INSTRUCTIONS
1.
2.
3.
4.
5.
6.
7.
8.
9.

SAFTY IMFORMATION
This STB hasbeen manufactured tosatisfy international safetystandards.
Please read thefollowing recommended safetyprecautions carefully.
MAINS SUPPLY:
OVERLOADING:
LIQUIDS:
CLEANING:
VENTILATION:
ATTACHMENTS:
CONNECTION TO
THE CABLE TV
SIGNAL AND TV:
SERVICING:
LIGHTNING:
GROUNDING:
AC220-240V ~50Hz
Do not overloadwall outlets, extensioncords or adapters
as this canresult in fireor electrical shock.
Before cleaning, disconnectthe STB fromthe wall socket.
Use a clothlightly dampened withwater(no solvents) to
clean the exterior.
Do not blockthe STB ventilationholes. Ensure thatfree airflow
is maintained aroundthe STB. Neverstore the STBwhere it is
exposed to directsunlight or nearheating euipment e.g.a
radiator.
Never stack otherelectronic equipment ontop of theSTB.
Place the STBat least 30mmfrom the wall.
Keep liquids awayfrom the STB.
Do not useany attachment thatis not recommendedby the
manufacturer; it maycause a hazardor damage theequipment.
Connect all components before plugging any power cords into the wall
outlet. Always turn off the STB, TV and other components before you
connect or disconnect any cables.
Do not attemptto service thisproduct yourself.
Any attempt todo so willmake the warrantyinvalid.
Refer all servicingto a qualifiedservice agent.
If the STBis installed inan area subjectto intense lightning
activity, protection devicesfor the STBmains connector and
modem telephone lineare essential.
The individual manufacturer'sinstruction for safeguardingother
equipment, such asTV set, Hi-Fi,etc., connected tothe STB must
also be followedduring lightning storms.
CATV cable MUSTBE EARTHED.
The grounding systemmust comply withSABS 061.
NOTE
Dispose the used batteries at designated place for environment protection

SAFETY INFORMATION
INTRODUCTION
About STB
Front panel
Rear panel
Remote control
SYSTEM CONNECTION
General about connections
Connecting to theTV aerial
Connecting to theTV with scart
Connecting a HiFisystem
Connecting a videorecorder with scart
GETTING STARTED
Switching on
WELCOME PAGE
System setup
INSTALLATION
Automatic channel scan
Manual channel scan
Aerial Adjustment
OPERATION
Subtitle,Page up /Page down,Volume Control,Audilcontrol,Soundtrack language
Accessing the favoritechannels,Teletext,Displaying program information
Pausing the currentpicture,DTV/VCR
EPG,TV/Radio
CHANNEL
Channel list
Channel list menu
TV Channel list
Radio Channel list
Delete All Favorites
Delete All Channels
SYSTEM SET UP
System setup mainmenu
OSD Language
TV System
Start up Service
Region and Time
Timer Setting
OSD Setting
Parental Lock
TOOLS
Tools main menu
Information
Game
Load Factory Default
Software Upgrade
Remote Control Help
WELCOME PAGE
TROUBLESHOOTING
SPECIFICATION
1
1
2-3
4
4
5
6
7
8
8
8
9
9
10
19
19
20
21
21
22
23
24
25
25
26
26
26
27
27
28
29
CONTENTS
11
12
12
13
14
14
15-17
17
18
18

CHANNEL
DVB-T237R
AC 220-240V
~50Hz
Model:DVB-T237R
DK digital GmbH
M heimer Strasse 49
D-40878 Ratingen
Germany
ü
Power Source: AC 220V -240V 50Hz
Power Consumption: 15 Watt
Made in China
Front panel
Rear panel
About the STB
INTRODUCTION
Coaxial Digital Audio
TV Scart
for connection tothe TV
Serial port
(for connection toPC)
AUX Scart
for connection toa VCR
or a satellitereceiver
TV aerial
Loop though
for an externalTV aerial
RF
AC Mains
Remote sensor
Main Power button Channel up
Channel down
Power indicator
1

123
564
89
7
0
MENUMENU
OKOK
DTV/VCRDTV/VCR
EXITEXIT
CH+CH+
CHCH
-
VOLVOL
--
VOL
+
VOL
+
PAUSEPAUSE FAVORITEFAVORITE
LANGLANG INFOINFO
RECALLRECALL
MUTEMUTE
TV/RADIOTV/RADIO AUDIOAUDIO
EPGEPG
XX
TTXTTX SUBTITLESUBTITLE
DVB-T237R
CH-CH-
CHANNEL
DVB-T237R
Remove the batterycompartment cover.
Load two AAA(UM-4 or R03) batteries into the
battery compartment.
Make sure thatthe batteries have been inserted
in the correctpolarities matching to the symbols
+, - markedin the battery compartment. Close
the battery compartmentcover.
When replacing batteries,replace both batteries.
Do not mixnew and used batteries operating
together, otherwise, theoperation lifetime will
be much shorterthan normal.
Remove the batteriesif the unit will not beused
for a prolongedperiod of time.
Remote control
The remote controltransmits a directional
infrared beam. Besure to aimthe remote
control directly atthe infrared sensor of the
unit during operation.
If the sensorhas been coveredor there isa
large object betweenthe remote controland
the sensor, thesensor will notrespond.
The sensor maynot able toreceive the
remote signal whenit is exposedto direct
sunlight or astrong artificial light (fluorescent
or strobe light).In this case, change the
direction of thelight or repositionthe unit to
avoid direct lighting.
30
o
30
o
Within approximately
6 meter (20 feet)
Remote
sensor
2
BE ENVIRONMENTALLY FRIENDLY
Do not disposebatteries as normalrubbish. Be environmentally friendly,
dispose batteries followingthe Government's regulation.
INTRODUCTION
2

123
564
89
7
0
MENUMENU
OKOK
DTV/ VCRDTV/ VCR
EXITEXIT
CH+CH+
CHCH
-
VOLVOL
--
VOL
+
VOL
+
PAUSEPAUSE FAVORITEFAVORITE
LANGLANG INFOINFO
RECALLRECALL
MUTEMUTE
TV/RADIOTV/RADIO AUDIOAUDIO
EPGEPG
XX
TTXTTX SUBTITLESUBTITLE
DVB-T237R
CH-CH-
Power On/Standby
(Switch the STBON/STANDBY mode)
Numeric entry
(Enter numeric valuesand to select the
channel directly byentering its number)
Menu
(Open up menu)
Red Button (Forteletext function)
Page up
Cursor/ Enter
( to selectsub-menu from the
main menu andchannel +/-,
( to selectmenu and sub-menu
from the menu and volume +/-,
( Press toenter.)
Yellow Button
(For teletext function)
Mute
RECALL
(switch to previouschannel)
EPG
(Open up Electronic Program Guide
menu)
TTX
(Open Teletext function)
DTV/VCR
(Switch between TVand external input
through AUX scart)
EXIT
(Exit from menu)
Green Button (Forteletext function)
Page down
Blue Button
(For teletext function)
FAVORITE
(Open up Favouritelist)
PAUSE
INFO
(Press for currentchannel information)
LANG
(Select language)
AUDIO
(Select audio: Left/ Right /Stereo / Mono)
TV/RADIO
(Switch between TVand Radio)
SUBTITLE
(On/Off Subtitle)
8
9
11
10
12
13
15
14
1
2
3
4
5
6
7
1
2
3
4
7
5
6
11
12
13
14
15
10
8
9
16
17
18
19
20
21
16
17
18
19
20
21
INTRODUCTION
3

Connecting to the TV aerial
There are manydifferent types ofTV/VCR and otherequipment that youcan
connect to theSTB.In this manual you will see some of the most common
ways to connectyour equipment.
General
You can connectthe STB tothe following typeof aerials:
Standard outdoor aerial
Please note thefollowing:
In some blockof flats, the roof-mounted aerial systemincludes a filter and
channel selector. Ifso, the aerial may not workwith the STB. Please consult
the landlord.
Many older roof-mountedaerials may onlyreceive a limitednumber of chan
nels. As aresult, digital channelstransmitted on higher frequencies are
difficult or evenimpossible to receive.The problem canbe solved by
replacing the roofaerial.
Some outdoor aerialsare directed towardsan analogue transmitter.
The aerial mustbe directed towardsa digital TV transmitter.
It is notalways advisable toposition the aerialas high aspossible. If
problems arise, experimentwith different aerialheights.
Indoor and windowmounted aerials
It is notadvisable to use indoor or windowmounted aerials, as digital channels
will be difficultor even impossible to receive.
1
2
SYSTEM CONNECTION
4

AC 220-240V
~50Hz
Model:DVB-T237R
DK digital GmbH
M heimer Strasse 49
D-40878 Ratingen
Germany
ü
Power Source: AC 220V -240V 50Hz
Power Consumption: 15 Watt
Made in China
Connecting to the TV with SCART
Scart cable
Antenna
Remove the aerial lead from your TV and connect this to the TV AERIAL input socket on the STB.
Connect a SCART cable between the main SCART socket on the TV and the TV SCART
socket on the STB.
Switch on your TV, plug in and switch on your STB.
You may need to select the AV ( SCART ) channel on your TV to watch Digital TV. In some cases your
TV will automatically select this channel when the STB is switched on.
RF cable
NOTE
RF Loop Through connectoris used for asecond DVB-T receiver.
The digital signal fromRF In will belooped through via thisconnection.
SYSTEM CONNECTION
5

AC 220-240V
~50Hz
Model:DVB-T237R
DK digital GmbH
M heimer Strasse 49
D-40878 Ratingen
Germany
ü
Power Source: AC 220V -240V 50Hz
Power Consumption: 15 Watt
Made in China
Connecting a HiFi system
You can connectan RCA/Cinch single cable from theDIGITAL AUDIO socket on the
STB to aHiFi system equipped with digital audioinput. This output is also usedfor
connection to anexternal Dolby digital decoder.
Hi-Fi
Coaxial cable
NOTE
To avoid interference youmust use screened audiocables.
Never connect digital outputto any analogue input.
It is always advisableto consult your HiFiinstruction book.
SYSTEM CONNECTION
6

AC 220-240V
~50Hz
Model:DVB-T237R
DK digital GmbH
M heimer Strasse 49
D-40878 Ratingen
Germany
ü
Power Source: AC 220V -240V 50Hz
Power Consumption: 15 Watt
Made in China
Remove the aerial lead from your TV and connect this to the TV AERIAL input socket on the STB.
Connect a SCART cable between the TV SCART socket on the video and the AUX SCART socket on
the STB.
Connect a SCART cable between the main SCART socket on the TV and the TV SCART socket on
the STB.
Switch on your TV, plug in and switch on your STB.
On your VCR there should be an A/V select button. This should be selected to record Digital TV.
You may need to select the AV ( SCART ) channel on your TV. In some cases your TV will not automatically select
this channel when the STB is switched on. Press "DTV/VCR" button on the remote control can switch to VCR
signal.
Connecting a video recorder
with SCART
NOTE
To record a digitalchannel you will needto select the AV( SCART ) channelon your video.
It is always advisableto consult your videoand TV instruction books.
SYSTEM CONNECTION
Video Cassette Recorder
VCR
TV
Scart cable
Scart cable
Antenna
R cable
F
7

GETTING STARTED
WELCOME PAGE
Switching on
Turn on your TV set and select the SCART input (with the AV key, or simular, on the television
remote control).
Turn on the main power supply to the STB, the indicator on the front of the unit will turn
red and then green. In standby mode, the indicator light will be red. In working mode,
the indicator light will be green.
If you use the STB the first time or after you delete all channel information in the STB,the
"WELCOMOE PAGE" picture for quick shortcut menu will display .
WELCOME PAGE
OSD Language
Country
Tuner Power
Auto Scan
Main Menu
1
2
3
4
5
Press "1~5" numeric button to enter OSD Language,Country,tuner
Power,Auto Scan and Main Menu quickly.
Press "MENU" button to return.
System setup
Press the "MENU" button to enter the setup menu of the STB.
Press the "UP" or" DOWN" cursor button to select "Setup" .
Press the "OK" Button to enter the sub-menu.
Press "UP" or "Down" cursor button to select the desired
item and press "OK" Button to comfirm.
Press "EXIT" button to return the upper menu.
Press"MENU" button to quit.
1
2
3
4
5
6
Main Menu
Select Enter Exit
Channel
Tools
Installation
Setup
OK MENU
System Setup
Select Enter Exit OK MENU
OSD Language
TV System
Start up Service
Region and Time
Timer Setting
OSD Setting
Parental Lock
8

Automatic channel scan
Manual channel scan
Installation
Select Enter Exit OK MENU
Auto Scan
Channel Scan
Aerial Adjustment
Auto Scan
MENU
UHF 470.0~862.0 MHz Ch No.
Frequency 858.00 MHz FFT
Modulation GI
Exit
40%
TV Service Radio Service
The automatic search will start and the picture shown right is displayed.
Press the "MENU" button to enter the setup menu of the STB.
Press "UP" or "DOWN" cursor button to select "Installation".
Press the "OK" Button to enter the sub-menu.
Select the "Channel Scan" and press "OK" button ,Channel
Scan menu appears
Press "LEFT" or "RIGHT" cursor button to select Scan mode,
Scan Band and Channel No. and highlight "Search",then press
the "OK" button to confirm .
1
2
3
4
5
Installation
Select Enter Exit OK MENU
Auto Scan
Aerial Adjustment
Channel Scan
Channel Scan
MENU
UHF 470.0~478.0 MHz
Frequency FFT
Modulation GI
Exit
40%
TV Service Radio Service
Your STB will start to scan the desired service or Frequency
and the picture shown right is displayed.
Press the "MENU" button to enter the setup menu of the STB.
Press "UP" or "DOWN" cursor button to select "Installation".
Press the "OK" Button to enter the sub-menu.
Select the "Auto Scan" press "OK" button ,Auto Scan menu
appears
Press "LEFT" or "RIGHT" cursor button to select Scan mode
and highlight "Search",then press the "OK" button to confirm .
11
2
3
4
5
Channel Scan mode: By channel
By frequency
Installation
9
Main Menu
Channel
Tools
Setup
Installation
Select Enter Exit OK MENU
Auto Scan
Select MENU
Scan Mode
Search
All
Change Exit OK Enter
Main Menu
Channel
Tools
Setup
Installation
Select Enter Exit OK MENU
Channel Scan
Select MENU
Mode
Scan Band
Ch No.
Search
Frequency
BandWidth
By Channel
UHF
21
000.000MHz
8 MHz
Change Exit 0-9 Input
Signal Intensity
Signal Quality
65%
90%

Installation
Press the "MENU" button to enter the main menu of the STB.
Press "UP" or "DOWN" cursor button to select "Installation".
Press the "OK" Button to enter the sub-menu.
Select the "Aerial Adjustment" ,press "OK" button ,Aerial
Adjustment appears.
Press "LEFT" or "RIGHT" cursor button to select the desired
channel No.
1
2
3
4
5
Aerial Adjustment
Installation
Select Enter Exit OK MENU
Auto Scan
Channel Scan
Aerial Adjustment
The signal intensity and quality for the desired channel will display as above.
When you adjust the location of aerial,use this menu to check signal intensity and quality of the
selected channel.
Aerial Adjustment
Change MENU
21
On
Exit
Signal Intensity
Signal Quality
65%
90%
Ch No.
Tuner Power
10
Main Menu
Channel
Tools
Setup
Installation
Select Enter Exit OK MENU

OPERATION
Subtitle
Press Subtitle button to switch subtitleOn/Off.
SUBTITLE
Page up / Page down
Press to page up for the picture ,channel list ,favorite list and other text information.
Press to page down for the picture ,channel list ,favorite list and other text information.
The volume level of the STB can be altered with the "Left" or "Right" cursor button on the
remote control.
Volume Control
NOTE
The volume level selected will remain set, even when the receiver is turned off and on again,
until it's altered.
You can silence the sound from the receiver by pressing the "MUTE" button . The
sound remain muted until the "MUTE" button is pressed again, the "LEFT" or "Right"
cursor button is
pressed, or until the receiver is turned off and on again.
Audio control
Soundtrack language
You can press the "AUDIO" button to select different audio modes among STEREO,
LEFT, RIGHT, MONO.
Some Programmes are broadcast in two or more language simultaneously. The soundtrack
language can be selected or by pressing the "LANG" button on the remote control.
11

OPERATION
Accessing the favorite channels
Press the "FAVOURITE" button to open up the "FAVOURITE LIST".
Press "LEFT" or "RIGHT" cursor button to select the desired favourite
group.
Select the favourite channels and press "OK" button to view the
selected channel.
1
2
3
Teletext
Press TTX button to Open/Close teletext .
TTX
Displaying program information
You can read the current program information by pressing "INFO" button on the remote
control. Press the button again to hide the program information table.
Channel
Tools
Installation
System Setup
Favorite Group 1
0001 HN Radio2
0002 BBC NEWS 24
0003 BBC Text
0004 BBC Two
Pausing the current picture
You can pausethe current picture by pressing "PAUSE"button on the remote control.
Press the keyagain to keep switching the program.
NOTE
The broadcast betweentwo pauses will be skipped.
NOTE
You can switch between Digital TV mode and VCR mode by pressing "DTV/VCR" button .
Switching between DTV
and VCR mode
When STB is in standby mode(turned off), DTV/VCR button will not activate.
When the power is off, it will automatically change to VCR
DTV/ VCR
12

OPERATION
Accessing the Electronic Program
Guide (EPG)
Accessing the EPG of all channels:
1
2
3
4
Press the "EPG" button to enter EPG menu .
Press "OK" button to view the current selected in full screen.
Press the numeric button"1" to display all programs schedule
information of the selected channel as right.
Press the numeric button"2" to display the detail informations of
current channel.
EPG
EPG
Schedule
Detail 2
15/02/2006 14:29
Select Page Enter
OK
Exit MENU
1
14:05-14:55
BBC News
Theme: News
Rate:00
15:00-16:00
BBC News
Theme: News
Rate:00
0001 HN Radio2
0003 BBC Text
0004 BBC Two
0005 BBC CHOICE
0002 BBC NEWS 2
Detail 15/02/2006 14:29
Page Extend
Timer 2
BBC NEWS 24
13:00-15:00 BBC News
Bill Turnbull and Valerie Sanderson present
the news,with live reports from around the
world. Widescreen.
Exit MENU 1
Schedule
Detail 1
15/02/2006 14:29
Select Page
Enter
Exit MENU
OK
0002 BBC NEWS 24
15/02/2006
Timer 2
Date
55In schedule and detail menu,press numeric button "2" can open the timer menu directly. This
operation can add the highlighted program to a timer quickly.
Switching between TV
and Radio mode
You can switch between Digital TV mode and Radio mode by pressing "TV/RADIO" button .
NOTE
Radio function is not available in Germany.
From the technical point of view it is possible to receive radio via DVB-T.
The german government decided to keep the standard DAB Signal.
13

Channel
Channel list
There are four ways of channel selection - stepping through the channel list,
selection by number, from the on-screen channel list, and using the electronic
programme guide(EPG).
Stepping through the channel list:
To move through the channel list, press the upward arrow or downward arrow
key on the remote control.
Selection by number:
Enter the channel list number directly by remote control to select desired channel.
auto scan will clean the channels that stored first.
manual scan don't clean the channels,but it will not add the repeated channels that
have stored.
Selection by on-screen channels list:
You can also select the required channel directly from on-screen channel list. This is
displayed using the STB's main menu.
1
2
3
4Selection by EPG:
You can also select the required channel directly from electronic program guide (EPG).
Like the channel list, the EPG screen displays a list of the stored channels along with
information on what programmes are being broadcast.
For EPG details ,see page 13
Channel list menu
Channel
Select Enter Exit OK MENU
TV Channel List
Radio Channel List
Delete All Favorites
Delete All Channels
Press the "MENU" button to enter the main menu of the STB.
Press "UP" or "DOWN" cursor button to highlight channel.
Press the "OK" button to enter the sub-menu.
Press "UP" or "DOWN" cursor button to highlight the desired item and press "OK"
button to confirm .
Press "MENU" button to exit.
1
2
3
4
5
14
Main Menu
Select Enter Exit
Tools
Installation
Setup
OK MENU
Channel

CHANNEL
TV Channel list
Enter Channel menu.
Press "UP" or "DOWN" cursor button to highlight TV
channel list.
Press the "OK" button ,TV channel list appears.
Press "LEFT" or "RIGHT" cursor button to select channel group.
Press "UP" or "DOWN" cursor button to preview the desired
channel
Press "OK" button to view the selected channel in full screen.
1
2
3
4
5
6
Favorite
2
OK
MENU
1
TV Channel List
FAV Group 2
0001 BBC CHOICE
0002 BBC NEWS 2
Preview
Move
3
Find
Select Page Enter Exit
4
Sort
5
Edit
Group
Favorite
Favorite
2
OK
MENU
1
TV Channel List
FAV Group 2
0001 BBC CHOICE
0002 BBC NEWS 2
Preview
Move
3
Find
Select Page Enter Exit
4
Sort
5
Edit
Group
Favorite
Favorite 1
Favorite 2
Favorite 3
Favorite 4
Favorite 5
Favorite 6
Favorite 7
Favorite 8
In channel list menu, press numeric button "1" to setup Favorite
item.
Press "UP" or "DOWN" cursor button to move highlight
between 8 favorite groups ,you can setup the desired channelto
the selected favorite group.
Press "OK" button to confirm,a favorite mark will be added.
Press "OK" button on the marked favorite group to cancel
favorite group,the mark will be cancel too.
Press "EXIT" button to quit Favorite setup and return to Channel list menu.
1
2
3
4
EXIT
Move
In channel list menu, press numeric button "2" , there will show a
"moving mark" in the right side of the selected channel.
Press "UP" or "DOWN" cursor button to move the selected
channel to the position that you want to place
1
2
5
Favorite
2
OK
MENU
1
TV Channel List
FAV Group 2
Preview
Move
3
Find
Select Page Enter Exit
4
Sort
5
Edit
Group
0001 BBC CHOICE
0002 BBC NEWS 2
Find
In channel list menu, press numeric button "3" to open Find menu.
Press "UP" , "DOWN" or "LEFT","RIGHT" cursor button to
highlight the letter or numeric and press "OK" button to
input one by one.
After input each character, the program list on the left will search
the channel according your input, and list the matched channel.
Press "Exit" button can close "Find" window and you can select
channel from the channels list directly.
1
2
3
4
EXIT
Favorite
2
OK
MENU
1
TV Channel List
FAV Group 2
0001 BBC CHOICE
0002 BBC NEWS 2
Preview
Move
3
Find
Select Page Enter Exit
4
Sort
5
Edit
Group
Find
ABCDEFG
HIJKLMN
OPQRSTU
VWXYZ12
3456789
0()@&-+
/
SP
?DEL OK
Use this menu to find a desired channel.
15

Delete
21
Edit channel
Grouo - 1
No Signal!
Skip
3
Lock
Select Page
4
Edit
5
Del All
Group
0679 SZTV-M
MENU
Exit
CHANNEL
TV Channel list (Continued)
Sort
Favorite
2
OK
MENU
1
TV Channel List
FAV Group 2
0001 BBC CHOICE
0002 BBC NEWS 2
Preview
Move
3
Find
Select Page Enter Exit
4
Sort
5
Edit
Group
Sort
Default
Name(A-Z)
Name(Z-A)
FTA
Lockd
In channel list menu, press numeric button "4" to open "Sort"
menu.
Press "UP" or "DOWN" cursor button to highlight sorting
way you want and Press "OK" button to confirm.
1
2
Default:
Name (A-Z):
Name (Z-A):
FTA:
Lock:
Sorting by scanning result.
Sorting in Alphabetical Orderl.
Sorting in Alphabetical Orderl.
Sieved out all free fare channels.
Accumulated all locked channels and list in the
last of TV Channel List.
Edit
In channel list menu, press numeric button "5" to open channel
list edit menu.You will be asked to enter the password.
Enter the password using the numeric buttons.Then the channel
list edit menu will be opened. The default password is "0000".
.
1
2
Use this menu to delete ,skip,lock and edit channel list.
Favorite
21
TV Channel List
Grouo - 1
No Signal!
Move
3
Find
Select Page
ok
Enter
4
Sort
5
Edit
Group
0679 SZTV-M
Input Password
----
Delete:
In "Edit Channel" menu, press numeric button "1" can make
a delete mark in the right side of the highlighted channel. After save
and exit "Edit Channel" menu, the marked channel will be
deleted.
Press "1" again to cancel delete channel.
Skip:
In "Edit Channel" menu, press numeric button "2" can make
a skip mark in the right side of the highlighted channel. After
save and exit "Edit Channel" menu, the marked channel will
be skip while you change the channel in full screen.
Press "2" button again to cancel the skip channel .
Lock:
In "Edit Channel" menu, press numeric button "3" can make a lock mark in the right
side of the highlighted channel. After save and exit "Edit Channel" menu, the marked
channel will be locked.STB will request you to input the password while you want to watch
the locked channel.
Press "3" button again to cancel the lock channel .
MENU
Exit
16
