1100T WIRELESS TRANSLATOR
Installation Guide
DESCRIPTION
The 1100T Wireless Translator allows
upgrades of non-DMP systems with
one-way, low frequency, wireless
transmitters to DMP. The 1100T is
compatible with transmitters that
operate at various MHz such as
Interlogix, Honeywell 5800, 2GIG, and
DSC. The translator operates with a
wireless connection to a DMP panel.
Transmitters that have been learned
into the 1100T are able to send
supervision and low battery messages
to the panel.
Compatibility
• All DMP XT Series panels and XR
Series panels with version 203 or
higher
• All 1100 Series Wireless Receivers
with version ???? or higher
• Interlogix 319.5 MHz
• Honeywell 5800 345 MHz
• 2GIG Series 345 MHz
• DSC 433 MHz
Note: The 1100T is not compatible
with life safety devices.
What is Included?
• 1100T Wireless Translator
• 12 VDC Power Supply
• Hardware Pack
1PROGRAM THE PANEL
Because the 1100T is a wireless device, all panel programming must
be completed in Device Setup and zones should be programmed in
Zone Information.
For XR Series Panels
Device Setup
1. Enter 6653 (PROG) at the keypad.
2. Press CMD and select DEVICE SETUP.
3. At DEVICE TYPE, press CMD to display options.
4. Press CMD again to open the extended options menu.
5. Select 1100T and press CMD to save.
6. Enter the Serial number.
7. At 1100T FREQ, select any select key or area to select the
non-DMP system. Default is HWL (Honeywell).
8. Press CMD.
Zone Information
1. In ZONE INFORMATION, enter the wireless zone number.
2. At *UNUSED*, enter the zone name.
3. Select a ZONE TYPE.
4. At DMP WIRELESS, select NO.
5. At COMP WLS, select YES.
6. At COMP WLS SRL #, you can manually enter the serial
number of the transmitter or transmit the serial number to
the panel:
Manually: Press top row key 1 and then begin typing the
transmitters serial number.
Transmit: To transmit the serial number, choose LRN at
prompt to display TRANSMIT NOW. Tamper the transmitter.
Once the panel has received the tamper signal, the serial
number will display.
7. Press CMD.
For XT Series Panels
Device Setup
1. Enter 6653 (PROG) at the keypad.
2. Press CMD and select DEVICE SETUP.
3. At 1100T? NO YES, select YES and press CMD.
4. Enter the Serial number.
5. At 1100T FREQ select any select key or area to select the
non-DMP system. Default is HWL.
6. Press CMD.
Zone Information
1. In ZONE INFORMATION, enter the wireless zone number.
2. At *UNUSED*, enter the zone name.
3. Select a ZONE TYPE.
4. At DMP WIRELESS select NO.
5. At COMP WLS select YES.
6. At COMP WLS SRL #, see Step 6 from the XR Zone
Information section above.
7. Press CMD.

2 1100T INSTALLATION GUIDE | DIGITAL MONITORING PRODUCTS
3The 1100T translator provides a Survey LED capability to allow one person to confirm communication with the
panel while the cover is removed.
1. With the cover removed, hold the translator in the exact desired location.
2. Press the tamper switch to send data to the panel and determine if communication is confirmed or
faulty.
Confirmed: If communication is confirmed, for each press or release of the tamper switch, the LED
blinks immediately on and immediately o. Repeat this test 5 times to confirm ten separate
consecutive LED blinks. Any indication otherwise means proper communication has not been
established.
Faulty: If communication is faulty, the LED remains on for about 8 seconds or flashes multiple times
in quick succession. Relocate the translator or receiver until the LED confirms clear communication.
SELECT A LOCATION
MOUNT THE TRANSLATOR
The translator must be mounted using the provided #6
screws in the four mounting holes. Mount the translator
in a secure, dry place away from metal objects to
protect the panel from damage due to tampering or the
elements. Mount the translator a minimum of 4 feet from
any wireless panels or repeaters. It is not necessary to
remove the PCB when installing the enclosure.
4
POWER THE TRANSLATOR
2Wire the Power Supply
The 1100T can be powered from a 12 VDC external
power supply. In addition to powering the 1100T, the
power supply also charges the back-up battery. If
the DC power source is removed, the power failure is
indicated as an open condition on the 1100T zone.
The 372-500-W must be located within 100 feet of
the panel using 22 AWG wire. Use the following steps
to connect the model 372-500-W plug-in DC power
supply to the 1100T:
1. Connect the positive wire to the positive
terminal on the 1100T.
2. Connect the negative wire to the negative terminal on the 1100T.
3. Plug the power supply into a wall outlet not controlled by a switch.
Mounting Hole Locations
+B AT- +12V-
-
+

1100T INSTALLATION GUIDE | DIGITAL MONITORING PRODUCTS 3
ADDITIONAL INFORMATION
Replace the Battery
1. Open the translator housing to expose the inside of the 1100T.
2. Remove the PCB board
3. Unplug the battery connector, then remove the old battery
4. Place the new battery in the holder.
5. Connect the battery connector
6. Snap the PCB Board back in place.
7. Snap the cover back on the 1100T.

Designed, engineered, and
manufactured in Springfield, MO
using U.S. and global components.
LT-2243 1.01 20XXX
1100T WIRELESS
TRANSLATOR
Specifications
Operating Voltage XXVDC, XX mA
Standby Battery
Voltage 3.7 VDC
Capacity 800 mAh
Type Lithium Polymer, rechargeable
Standby 24 hours
Frequency Range 905-924 MHz
Dimensions 5.50” W x 3.75” H x 1.00” D
13.97cm W x 9.53 cm H x 2.54 cm D
Ordering Information
1100T Wireless Translator
Patents
U.S Patent No. 7,239,236
Accessories
1100RBAT800/8 Replacement rechargable battery
(8 pack)
505-12 12 VDC Power Supply
372-500-W Plug-In DC Power Supply
Compatibility
All DMP XT Series panels and XR Series panels with version
203 or higher
All 1100 Series Wireless Receivers with version ????? or higher
Interlogix 319.5 MHz
Honeywell 5800 345 MHz
2GIG Series 345 MHz
DSC 433 MHz
Certifications
?????????????????????????
