  9. dobue MOVELARIA Monaco 301480 User manual

dobue MOVELARIA Monaco 301480 User manual

GARANTIA
- A garantia dos produtos fabricados, abrange
eventuais defeitos/vícios de fabricação, no prazo
estabelecido pelo Código de Defesa do Consumidor, em
seu artigo 26, II, o qual
prevê a legal de 90 (noventa) dias.
CUIDADOS ESPECIAIS
- Leia com atenção as instruções do manual de
montagem que acompanha o produto
- Evitar umidade excessiva a exposição prolongada a luz
solar.
- Para limpeza usar pano limpo e úmido, não devendo
utilizar produtos de limpeza.
-Produto para uso doméstico.
EXCLUSÃO DA GARANTIA LEGAL
- A falta de observância das instruções contidas no Manual
de Montagem, que eventualmente poderá causar danos
à mercadoria, tais como, adequação do local para
instalação do produto, uso correto dos parafusos e demais
componentes, nivelamento, correta distribuição dos
objetos no produto (conforme peso / tamanho).
indicado no manual), dentre outros, bem como transporte
inadequado tanto pela Loja, como pelo consumidor.
- Defeitos ou danos causados em qualquer componente
do produto pela utilização inadequada ou provocado
por acidentes, negligência, má condições estruturais da
residência, tempo de uso, caso fortuito ou força maior
(por exemplo umidade, inltrações, mofo, cupins, raios
maresia, chuvas, etc.
INSTRUÇÃO
DE MONTAGEM
Assembly instruction
Instrucciones de ensamblaje
WARRANTY
- The warranty of manufactured products, covers
any manufacturing defects / defects, within the period
established
by the Consumer Protection Code, in its article 26, II, which
provides the legal 90 (ninety) days.
SPECIAL CARES
- Read with attention the instructions in the assembly
manual accompanying the product.
- Avoid excessive humidity and prolonged exposure to
sunlight.
- For cleaning use a clean, damp cloth, and cleaning
products should not be used.
DISCLAIMER OF LEGAL WARRANTY
- Failure to observe the instructions contained in the
Assembly Manual, which may eventually cause
damage to the product, such as, adequacy of the
location for installing the product, correct use of screws
and other components, leveling, correct distribution of
objects in the product (according to weight / size
indicated in the manual), among others, as well as
inadequate transport by both the Store and the consumer.
- Defects or damage caused to any component of the
product due to improper or provoked use
due to accidents, negligence, poor structural conditions of
the residence, time of use, or force majeurefortuity
(for example humidity, inltrations, mold, termites, sea rays,
rain, etc.
GARANTÍA
- La garantía de productos fabricados, cubre
cualquier defecto / defecto de fabricación, dentro del plazo
establecido
por el Código de Protección al Consumidor, en su artículo 26,
II, que
proporciona los 90 (noventa) días legales.
CUIDADOS ESPECIALES
- Leer atentamente las instrucciones del manual de montaje
que acompaña al producto
- Evite la humedad excesiva y la exposición prolongada a la
luz solar.
- Para la limpieza utilice un paño limpio y húmedo y no se
deben utilizar productos de limpieza.
RENUNCIA DE GARANTÍA LEGAL
- El incumplimiento de las instrucciones contenidas en el
Manual de Montaje, que eventualmente puede provocar
Daños a la mercancía, tales como, adecuación del lugar
para la instalación del producto, uso correcto de tornillos y
otros componentes, nivelación, distribución correcta de
objetos en el producto (según peso / tamaño
indicado en el manual), entre otros, así como el transporte
inadecuado tanto por parte de la Tienda como del
consumidor.
- Defectos o daños ocasionados a cualquier componente del
producto por uso indebido o provocado
por accidentes, negligencia, malas condiciones estructurales
de la residencia, tiempo de uso, caso fortuito o fuerza mayor
(por ejemplo, humedad, inltraciones,etc.
07/11/2022
Atualizado em:
Revisão - 03
Dobuê Movelaria LTDA.
Rua: Campos Sales, Nº 45 Parque Industrial Novo CEP: 86720-000 Sabáudia - PR
Fone (55) (0**43) 3151-1611 - E-mail: [email protected] Site: www.dobue.com.br
Utilize o QR Code ao lado
para baixar o arquivo
Instrução de Montagem.
Use the QR Code beside
to download the le
Assembly Instruction.
Utilice el código QR al lado
para descargar el archivo
Instrucciones de ensamblaje.
MESA / Table / Mesa
Mônaco 1800 mm / Mônaco 1600 mm
301480 301460
10
060
20 11070 120 130 140 150 160 170 180
30 80
40 9050 100 190 270260250240230220210200
Nº
Nº
FIBRA
FIBRA
QTD
QTD
COD
COD
PEÇAS
PEÇAS
(mm)
(mm)
PIECES
PIECES
PIEZAS
PIEZAS
01
01
02
02
04
03
04
03
05
05
02 01
02
01
01
02
03
04
05
06
Fechamento Maior
Fechamento Menor
Apoio
Travessa Maior
Travessa Menor
Tampo Chanfrado
Closure Bigger
Closure Smaller
Support
Bigger Crosspiece
Smaller Crosspiece
Closure Bigger
Closure Smaller
Support
Bigger Crosspiece
Smaller Crosspiece
Cover
Cierre Grande
Cierre Pequeño
Apoyo
Grande Cruceta
PequeñoCruceta
Cubrir
Cierre Grande
Cierre Pequeño
Apoyo
Grande Cruceta
PequeñoCruceta
600x340x15
464x351x15
469x264x12
440x90x15
230x90x15
1350x900x25
MDF
MDF
MDP
MDP
MDF
MDF
04
04
02
02
02
01
00000000
00000000
00000000
00000000
00000000
3003402
Mônaco 1350 mm
Mônaco 1600 mm / Mônaco 1800 mm
000000
301460 301480
30146001
30146002
30146003
30146004
30146005
3003602
3003002
04
04
02
02
02
01
01
02
03
04
05
06
Fechamento Maior
Fechamento Menor
Apoio
Travessa Maior
Travessa Menor
Tampo Chanfrado Cover Cubrir
851x340x15
466x340x15
712x264x12
682x90x15
230x90x15
1600x900x25
1800x900x25
MDF
MDF
MDP
MDP
MDF
MDF
4,0 x 40 mm = 24
AE
Parafuso Cabeça Chata
Flat Head Screw
Tornillo de cabeza
3,5 x 12 mm = 40
BF
CG
D
H
L
Parafuso Cabeça Chata
Flat Head Screw
Tornillo de cabeza
= 20
Cantoneira Metálica
Corner Brace
Angulo del Metálico
Parafusos / Pregos em Tamanho Real 1x1 /
1x1 Full Size Screws / Tornillos de Tamaño 1x1 Acessórios / Accessories / Accesorios
= 08
= 08
Tambor Minix 15 mm
Minix drum 15 mm
Tambor Minix 15 mm
Parafuso Minix
Minix Screw
Tornillo Minix
6 x 30 mm = 08
8 x 20 mm = 04
Parafuso Cabeça Chata
Flat Head Screw
Tornillo de cabeza
Cavilha
Peg
Clave
Cavilha
Peg
Clave
= 06
Sapata Deslizadora Plástica Preta 15x10x03 mm
Slider
Zapata Deslizante
8 x 8 mm = 06
Prego
Nail
Clavo
É recomendável duas pessoa para montar o produto.
It’s necessary two person to assembly the product.
Se requiere dos persona para montar el producto.
Chave Philips
Philips Key
Llave Philips
Parafusadeira
Electric Screwdriver
Tornillo Eléctrico
Martelo
Hammer
Martillo
1º
3º
2º
C
C
C
C
C
C
C
C
C
8x
G
G
G
G
G
G
G
G
G
G
8x 8x
F
FFF
F
FFF
F
F
A
A
A
A
A
A
A
AA
A
A
AA
A
A
AA
A
A
A
A
AA
A
A
A
8x
16x
04 04
04
04 03
03
04
05
05
05
05
05
4º 5º
01
01
01
01
01
01
02
02 02 02
02
02
03
D H
6x 6x
EB
10x
20x
L
L
L
2x
Acessório Cavilha (L)
serve de guia apenas
facilitando a montagem.
Peg Accessory (L)
serves as a guide only
facilitating assembly.
Accesorio de clavija (L)
sirve solo como guia
facilitando el montaje.
B+E D+H
D+H
D+H
D+H D+H
D+H
D+H
B+E
B+E B+E
B+EB+E B+E
B+E
B+E
B+E
B+E
6º 7º
B+E
B+E
B+E
B+E
B+E
B+E
B+E
MESA / Table / Mesa
Mônaco 1600 mm
301460
B
8x
E
4x
B+E
1600 mm
1800 mm
B+E
B+E
B+E
465 mm
247 mm
30
kg
800 mm
MESA / Table / Mesa
Mônaco 1800 mm
301480
06
B
B
8x
12x
E
E
4x
6x
B+E
B+E
B+E B+E
B+E
B+E
224 mm
365 mm
01
01 02
02
03
06
L
L
Acessório Cavilha (L)
serve de guia apenas
facilitando a montagem.
Peg Accessory (L)
serves as a guide only
facilitating assembly.
Accesorio de clavija (L)
sirve solo como guia
facilitando el montaje.
L
2x

This manual suits for next models

1

Other dobue MOVELARIA Indoor Furnishing manuals

dobue MOVELARIA 100140 User manual

dobue MOVELARIA

dobue MOVELARIA 100140 User manual

dobue MOVELARIA Bruxelas 300890 User manual

dobue MOVELARIA

dobue MOVELARIA Bruxelas 300890 User manual

dobue MOVELARIA Athenas 200520 User manual

dobue MOVELARIA

dobue MOVELARIA Athenas 200520 User manual

dobue MOVELARIA DUBAI 200200 User manual

dobue MOVELARIA

dobue MOVELARIA DUBAI 200200 User manual

dobue MOVELARIA 2001101 User manual

dobue MOVELARIA

dobue MOVELARIA 2001101 User manual

dobue MOVELARIA RUBI 1360 User manual

dobue MOVELARIA

dobue MOVELARIA RUBI 1360 User manual

dobue MOVELARIA TOPAZIO 1360 User manual

dobue MOVELARIA

dobue MOVELARIA TOPAZIO 1360 User manual

dobue MOVELARIA 3000239 User manual

dobue MOVELARIA

dobue MOVELARIA 3000239 User manual

dobue MOVELARIA Topazio 200574 User manual

dobue MOVELARIA

dobue MOVELARIA Topazio 200574 User manual

dobue MOVELARIA IMOLA 300052 User manual

dobue MOVELARIA

dobue MOVELARIA IMOLA 300052 User manual

dobue MOVELARIA 980140 User manual

dobue MOVELARIA

dobue MOVELARIA 980140 User manual

dobue MOVELARIA 100145 User manual

dobue MOVELARIA

dobue MOVELARIA 100145 User manual

dobue MOVELARIA 200570 User manual

dobue MOVELARIA

dobue MOVELARIA 200570 User manual

dobue MOVELARIA Pádua 1600 mm 3008821 User manual

dobue MOVELARIA

dobue MOVELARIA Pádua 1600 mm 3008821 User manual

dobue MOVELARIA PARIS 300045 User manual

dobue MOVELARIA

dobue MOVELARIA PARIS 300045 User manual

dobue MOVELARIA Amsterdan 300800 User manual

dobue MOVELARIA

dobue MOVELARIA Amsterdan 300800 User manual

dobue MOVELARIA TURIM PLUS 300016 User manual

dobue MOVELARIA

dobue MOVELARIA TURIM PLUS 300016 User manual

dobue MOVELARIA JACARTA 1360 User manual

dobue MOVELARIA

dobue MOVELARIA JACARTA 1360 User manual

dobue MOVELARIA ATLANTA 1480 User manual

dobue MOVELARIA

dobue MOVELARIA ATLANTA 1480 User manual

dobue MOVELARIA 1.03 TURIM 200500 User manual

dobue MOVELARIA

dobue MOVELARIA 1.03 TURIM 200500 User manual

dobue MOVELARIA Turim Light 200510 User manual

dobue MOVELARIA

dobue MOVELARIA Turim Light 200510 User manual

dobue MOVELARIA Dublin 301240 User manual

dobue MOVELARIA

dobue MOVELARIA Dublin 301240 User manual

dobue MOVELARIA Martinelli 300892 User manual

dobue MOVELARIA

dobue MOVELARIA Martinelli 300892 User manual

dobue MOVELARIA Bilbao 301040 User manual

dobue MOVELARIA

dobue MOVELARIA Bilbao 301040 User manual

Popular Indoor Furnishing manuals by other brands

OfficeSource 600MMFBK Assembly instructions

OfficeSource

OfficeSource 600MMFBK Assembly instructions

KETCHAM ELLIPSE Series installation guide

KETCHAM

KETCHAM ELLIPSE Series installation guide

Milano RDCVPW780 installation guide

Milano

Milano RDCVPW780 installation guide

Powell 149-534A Assembly instructions

Powell

Powell 149-534A Assembly instructions

Fores Deco LMX222 Assembling instructions

Fores

Fores Deco LMX222 Assembling instructions

Furniture of America Bridgewater FOA7490PL Assembly instructions

Furniture of America

Furniture of America Bridgewater FOA7490PL Assembly instructions

Linon SPC-20372 Assembly instructions

Linon

Linon SPC-20372 Assembly instructions

Lorell Managerial Mid-Back Chair LLR86209 instructions

Lorell

Lorell Managerial Mid-Back Chair LLR86209 instructions

Moree STUDIO Series instruction manual

Moree

Moree STUDIO Series instruction manual

ADS N4 installation manual

ADS

ADS N4 installation manual

BLACK RED WHITE NFD 713/420 PG Assembly manual

BLACK RED WHITE

BLACK RED WHITE NFD 713/420 PG Assembly manual

Forte Hoyvik HVKS953 Assembling Instruction

Forte

Forte Hoyvik HVKS953 Assembling Instruction

Donco kids 1200T Assembly instructions

Donco kids

Donco kids 1200T Assembly instructions

Work Smart KCM1420 operating instructions

Work Smart

Work Smart KCM1420 operating instructions

Konig + Neurath CONTAINER PEDESTAL operating instructions

Konig + Neurath

Konig + Neurath CONTAINER PEDESTAL operating instructions

Happy Beds Prince Assembly instructions

Happy Beds

Happy Beds Prince Assembly instructions

LOWE'S 1922VA-60-267-900-SR Assembly instructions

LOWE'S

LOWE'S 1922VA-60-267-900-SR Assembly instructions

FMD Furniture MANHATTAN 1 Assembly instructions

FMD Furniture

FMD Furniture MANHATTAN 1 Assembly instructions

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
