Docomo N-01F User manual

2013.11 (1st Edition)
Manufacturer:
Sales: NTT DOCOMO, INC.
Don’t forget your mobile phone … or your manners!
When using your mobile phone in a public place, don't forget to show
common courtesy and consideration for others around you.
INSTRUCTION MANUAL ’13.11
N-01F(薄型英文1版)H1H4
KDIC2484
N-01F
0120-005-250 (toll free)
* Service available in: English, Portuguese, Chinese, Spanish.
* Unavailable from part of IP phones.
(Business hours : 9:00 a.m. to 8:00 p.m.)
■ From DOCOMO mobile phones (In Japanese only)
(No prex) 151 (toll free)
* Unavailable from land-line phones, etc.
■ From land-line phones (In Japanese only)
0120-800-000 (toll free)
* Unavailable from part of IP phones.
(Business hours : 9:00 a.m. to 8:00 p.m. (open all year round))
■ From DOCOMO mobile phones
-81-3-6832-6600* (toll free)
* You are charged a call fee to Japan when calling from a land-line phone, etc.
※If you use N-01F, you should dial the number [phone] (to enter '+', press and hold the '0' key for at least one second).
■From land-line phones <Universal number>
-8000120-0151*
* You might be charged a domestic call fee according to the call rate for the country you stay.
※For international call access codes for major countries and universal number international prefix, refer to DOCOMO International Services website.
For loss, theft, malfunction, and inquiries while overseas (24-hour reception)
<docomo Information Center>
● If you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the FOMA terminal.
● If the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO after
returning to Japan.
Repairs
International call access code
for the country you stay
Universal number international
prefix
●Please confirm the phone number before you dial.
●For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo Shop etc. near you on the
NTT DOCOMO website or the i-mode site.
NTT DOCOMO website http://www.nttdocomo.co.jp/english/
i-mode site iMenu ⇒お客様サポート (User support) ⇒ドコモショップ (docomo Shop) * In Japanese only
General Inquiries
<docomo Information Center>
■ From DOCOMO mobile phones (In Japanese only)
(No prex) 113 (toll free)
* Unavailable from land-line phones, etc.
■ From land-line phones (In Japanese only)
0120-800-000 (toll free)
* Unavailable from part of IP phones.
(Business hours : 24 hours (open all year round))

Make various applications or change your billing plan, check your charges and points, and more online.
i-mode access :
iMenu ⇒お客様サポート (User support) ⇒お申込・お手続き (Applications/
procedures) ⇒各種お申込・お手続き (Various applications/procedures)
(in Japanese only)
No packet communications charges apply
PC access: My docomo (http://www.mydocomo.com/) ⇒各種お申込・お手続き (Various
applications/procedures) (in Japanese only)
* You need your "Network security code" to use via i-mode.
* Packet communications charges do not apply to use via i-mode. Charges will apply if using the service
from overseas.
* "docomo ID/password" are required to use this site from a PC.
* Please contact "General Inquiries" For details, contact "General Inquiries" on the back cover if you
forget or do not have "Network security code" or "docomo ID/password".
* May not be available in some cases depending on the conditions of your subscription.
* There are cases where the site may not be available due to system maintenance, etc.
What DOCOMO does to be eco-friendly
Slimming down the manual
By describing only basic functions and operations,
we have succeeded in reducing paper usage and
slimming down the Japanese instruction manual.
For further explanations, see your 使いかたガイ
ド(Guide) (Japanese, available in your FOMA
terminal) or visit NTT DOCOMO's websites.
Collecting and recycling of mobile phones
We collect your unnecessary mobile
phones and other devices irrespective
of carrier. Bring them to a docomo
Shop near you.
* Intended devices: Mobile phone, PHS,
battery pack, charger and desktop
holder (irrespective of carrier)
Using mobile phone with your manners!
When using mobile phone in a public
place, don't forget to show courtesy and
consideration for others.
Turn the power o when you are:
■In places where use is prohibited
・In an airplane or hospital, follow the instructions
given by the respective airline or medical
institution.
Turn off the power in a location where use is
prohibited.
Always set Public mode when you are:
■Driving
・Using a handheld mobile phone while driving
will result in a penalty. Exceptions are made in
case of emergency, such as to safeguard injured
persons or to maintain public safety.
■ In places such as theaters, cinemas, and art galleries
Respect privacy
Ple ase b e co nsi der at e of th e pr i va c y of
individuals around you when taking and sending
photos using camera-equipped mobile phones.
Thank you for choosing "N-01F".
Before use, be sure to thoroughly read this manual to ensure that you use N-01F correctly.
About manual of N-01F
The operations of N-01F are also described in "使いかたガイド" (Guide) (available in this FOMA
terminal) and "Instruction Manual (Detailed version)" (Japanese) (PDF file) other than this manual.
■ "INSTRUCTION MANUAL" (this manual): Provides information about screens and basic operations.
■"使いかたガイド " (Guide) (available in this FOMA terminal): Provides information about the
outline of frequently-used functions and of operations (in Japanese only).
On the N-01F standby screen, Iis" 便利ツール " (Tool) s"使いかたガイド " (Guide)
* "使いかたガイド " (Guide) is not available when "English" is set for "Select language".
■"Instruction Manual (Detailed version)" (Japanese): Provides detailed information about
all functions and operations.
From PC: Download from NTT DOCOMO'S website
http://www.nttdocomo.co.jp/support/trouble/manual/download/index.html
* The URL and content may change without prior notice.
Accessories and major optional extras
■Basic package
N-01F (including written
warranty)
Battery Pack N30 N-01F INSTRUCTION MANUAL
(Japanese)
Desktop Holder N45
Back Cover N67
■Options and accessories compatible with this FOMA terminal→p.87
Before using this manual
・Note that "N-01F" is referred to as "FOMA terminal" in this manual.
・This manual uses the default settings and screen shots for "WHITE" to describe operations. To
read a screen easily in this manual, "Stand-by display" is set to "OFF", and the font color is black
while the background color is white.
・The screens shown as examples in this manual are displayed when "English" is set for "Select
language". Set "English" for "Select language" in advance. (→p.23)
・ The images or illustration used in this manual are examples. They may differ from the actual displays.
・Unauthorized copying of all or part of this manual is prohibited.

FOMA Terminal ..........................2
Part Names and Functions.......3
Precautions (Always follow
these directions)........................5
Waterproof/Dustproof Function... 16
Introduction
p.1
Before Using.............................20
Screen Explanation.................24
Character Entry........................31
Sound/Screen Setting ............33
Lock/Security ...........................38
Basic Operation
p.20
Call Telephone .........................43
Mail............................................51
Phonebook...............................55 Connect
p.43
i-mode/Full Browser ...............56
i-channel...................................59
Map............................................60 Search
p.56
Camera......................................61
1Seg...........................................64
Music .........................................66
i-αppli/i-Widget .......................68
i-motion/Movie........................69 Enjoy
p.61
Osaifu-Keitai ............................70
i-concier....................................72
Convenient Tools.....................73
Data Management ..................75
More Convenient
p.70
Support.....................................79
Appendix..................................88
Index ...................................... 101 Others
p.79
Contents
1

Introduction
・ N-01F supports W-CDMA and GSM/GPRS systems.
・ FOMA terminals use wireless communications and cannot be used in tunnels, underground
areas, buildings, and other areas without reception; in outdoor locations with weak reception; or
outside the service area. Reception may also be weak in even some unobstructed upper floors
of high-rise buildings and apartments. Please be aware that calls or communications may be
disconnected even under optimal conditions when reception is strong and all three antenna
icons are displayed, and when in a stationary position.
・ A third party may be able to use special equipment to listen in on your calls, as FOMA terminals
use radio waves. However, W-CDMA and GSM/GPRS systems automatically support privacy
protection with a scrambling function for all calls to make conversations incomprehensive to
third parties.
・ FOMA terminals convert voice into digital signals for wireless communications, and therefore
if you are in an area where radio reception is weak, these digital signals may not be properly
restored and this may result in distortion of the actual caller's voice.
・ Please keep a separate record of the information (Phonebook, Schedule, Memo, Record message,
Voice memo etc.) you have registered in your FOMA terminal. Please be aware that DOCOMO
bears no obligation or responsibility in the event that data is altered or lost.
・ It is recommended that you back up important data to a microSD card. If you own a PC, you can
also transfer and save data, such as Phonebook, Mail or Schedule, to your PC using DOCOMO
keitai datalink.
・ The user hereby agrees that the user shall be solely responsible for the result of the use of SSL/
TLS. Neither DOCOMO nor the certifier as listed herein makes any representation or warranty as
for security in the use of SSL/TLS. In the event that the user shall sustain damage or loss due to
the use of SSL/TLS, neither DOCOMO nor the certifier shall be responsible for any damage or loss.
Certifier: VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K., EMC Japan Corp., SECOM
Trust Systems Co., Ltd., Comodo CA Ltd., Entrust Limited and Go Daddy Group, Inc.
・ This FOMA terminal is available for use in the FOMA Plus-Area and FOMA HIGH-SPEED area.
・ The display is manufactured using high-precision technology but there may be some dots that
fail to light or remain permanently lit. Please note that this is a characteristic of displays and not a
malfunction.
FOMA Terminal
2

Introduction
<Using Earphone>
Connect an external-connector-terminal-
compatible earphone (optional). To use
an incompatible earphone, connect an
adapter converter (optional).
Stereo Earphone/Microphone 01 for External
connector terminal (optional) connection example
The AC adapter (for charging) and the Stereo Earphone/Microphone 01
(earphone/microphone terminal) use the same slot.
Stereo Earphone/
Microphone 01
AC adapter
* The 1Seg antenna is built-in and the FOMA
terminal itself works as an antenna.
1
8
e
g
9
3
b
4
2
i
h
6
c
d
a
f
7
5
k
j
s
r
v
u
o
n
p
q
t
l
m
Part Names and Functions
3

Introduction
1Earpiece
Hear other party's voice from here.
2Display
3Illuminance sensor
Detect brightness. Do not cover with hand or
put sticker on it.
4Multi-function keys
f/g: Up/Down key
・Move the cursor or contents etc. upward or
downward.
・Display the Search phonebook menu screen.
・Activate shortcut.
h/j: Left/Right key
・Move the cursor to the left or right.
・Activate MyFACE.
d: OK key
・Perform the function displayed on this key.
5ikey
Display the main menu.
6ukey
Display the still image shooting screen.
7okey
Display the mail menu.
8pkey
Display the iMenu.
9tBack (Clear)/i-channel key
・Return to the previous step or delete the
entered characters.
・Display i-channel.
arStart key
Make calls.
byPower/End/Hold key
cDial keys
Enter phone numbers or characters.
dw/Public mode (Drive mode) key
Set Public mode (Drive mode).
eq/Manner key
fQQuick key
Activate a function selected in "Quick button
set".
gmMulti key
Display the TASK MENU screen.
hMouthpiece/Microphone
iCharging terminal
jStrap hole
kExternal connector terminal
Multi-terminal for charging, connecting an
earphone, etc.
Connect AC Adapter (optional), DC Adapter
(optional), FOMA USB Cable with Charge
Function 02 (optional) or Stereo Earphone/
Microphone 01 (optional), etc.
laVolume up key
Raise the earpiece volume or set Manner
mode.
msVolume down key
Lower the earpiece volume.
nIllumination/Charge lamp/Recording
indicator
oSub-display
Display the clock or FOMA terminal status.
pemark
Read the IC card and make iC transmissions.
qFOMA antenna
The antenna is built-in. Covering the antenna
part with your hand may affect the quality.
rCamera
sInfrared data port
tSpeaker (monaural)
umicroSD card slot (inside)
vBack cover
4

n
To ensure that you use your FOMA terminal
correctly, read "Precautions" carefully before use.
Keep this manual after reading for future reference.
n
The precautions must be observed at all times
since they contain information intended to
prevent the bodily injury or damage to property.
n
The following symbols indicate the different
degrees of injury and damage that may occur if
the information provided is not observed and
the FOMA terminal is used incorrectly:
DANGER
Indicates that death or serious
bodily injury may result directly and
immediately from improper use.
WARNING
Indicates that death or serious
bodily injury may result from
improper use.
CAUTION
Indicates that slight bodily injury
and/or damage to the property
may result from improper use.
nThe following symbols indicate specific
directions:
Don't
Indicates that it is prohibited.
No disassembly
Indica tes that it m us t no t be
disassembled.
No liquids
Indicates that it must not be used
near water, which means that you
must not let it become wet.
No wet hands
Indicates that you must not touch
it with wet hands.
Do
Indicates that it is an instruction-
based compulsory conduct (must
be acted).
Unplug
Indicates that you must unplug
the power cord from the outlet.
nSafety precautions are explained in the
following categories:
1. Precautions for the FOMA terminal, Battery Pack,
Adapter, Desktop Holder and miniUIM
(Common)････････････････････････････････ p.5
2. Precautions for the FOMA terminal
･････････ p.7
3. Precautions for the Battery Pack ･･･････････ p.8
4. Precautions for the Adapter and Desktop
Holder ･･･････････････････････････････････ p.9
5. Precautions for the miniUIM ･･････････････ p.10
6. Precautions for Use Near Electronic Medical
Devices ･････････････････････････････････ p.11
7. Material List ･････････････････････････････ p.11
1. Precautions for the FOMA terminal,
Battery Pack, Adapter, Desktop
Holder and miniUIM (Common)
Don't
Do not use, keep or leave the devices in locations
subject to high temperatures (near a fire or
heating unit, in a kotatsu, under direct sunlight,
inside a car on a hot day, etc.).
Doing so may cause fire, burns, or injury.
Don't
Do not put the devices in a microwave
oven or pressurized container.
Doing so may cause fire, burns, injury or
electric shock.
No disassembly
Do not disassemble or modify the equipment.
Doing so may cause fire, burns, injury or
electric shock.
Introduction
Precautions (Always follow these directions)
5

Do
If something unusual happens, such as
unusual odor, overheating, discoloration
or deformation during use, charge or
storage, be sure to:
・ Unplug the power cord from the power
outlet or the cigarette lighter socket.
・Turn off the power.
・Remove the battery pack from the
FOMA terminal.
Failure to observe these precautions may
cause fire, burns, injury or electric shock.
CAUTION
Don't
Do not leave the devices on a slope or
unstable surface.
The devices may fall and cause injury.
Don't
Do not leave the devices in humid, dusty
or hot places.
Doing so may cause fire, burns or electric shock.
Do
If your child uses the FOMA terminal, instruct
him/her on how to use it. Check if he/she always
uses the FOMA terminal correctly as you instruct.
Improper usage could result in bodily injury.
Do
Keep the FOMA terminal out of young
children's reach.
A young child may try to swallow it or suffer injury.
Do
Pay special attention when you use the
FOMA terminal connected to the adapter
for a long period.
If you use i-αppli or videophone or watch 1Seg
programs for a long time while charging, the
temperature of the FOMA terminal, battery
pack or adapter may rise.
If you touch the warm part of these devices for a
long period of time, it may cause redness, itch, skin
irritation or low temperature burns depending on
your constitution or physical condition.
No liquids
Do not allow the devices to become wet
with liquids, such as drinking water or
other water, pet urine or sweat.
Doing so may cause fire, burns, injury or electric shock.
For waterproof function, refer to the following:
→p.16 "Waterproof/Dustproof Function"
No liquids
Do not allow liquids (drinking water or
other water, pet urine, sweat, etc.) to
enter the charging terminal or external
connector terminal.
Doing so may cause fire, burns, injury or
electric shock.
Do
Use theoptionsspecified byNTT DOCOMO
for the FOMA terminal.
Failure to observe this precaution may cause
fire, burns, injury or electric shock.
WARNING
Don't
Do not apply excessive force to the FOMA
terminal, throw it or expose it to strong shocks.
Doing so may cause fire, burns, injury or
electric shock.
Don't
Do not place electrically conductive objects
(wires, pencil leads, etc.) in contact with the
charging terminals or external connector
terminal. Do not insert those materials
inside the terminal.
Doing so may cause fire, burns, injury or
electric shock.
Don't
Do not cover or wrap the devices with
bedding, etc. while in use or charging.
Doing so may cause fire or burns.
Do
Make sure to turn off the FOMA terminal
and stop charging before you get close
to the places like a gas station where a
flammable gas is generated.
Failure to observe this precaution may cause
the gas to ignite.
Turn off the power, when you use Osaifu-
Keitai at a gas station (if the IC card lock is set,
turn the power off after the lock is released).
Introduction
6

Do
Make sure to hold the FOMA terminal at a
safe distance from your ear when you use
the handsfree mode or the ring tone
sounds. Also, when you play games or
music, etc. with an earphone/microphone
etc. connected to the FOMA terminal,
adjust the volume properly.
Too large a volume may lead to defective
hearing. Also, hearing difficulties may cause
an accident.
Do
If you have a weak heart, take precautions
when setting theVibrator or Ring volume.
Failure to observe this precaution may affect
your heart.
Do
If you are wearing electronic medical devices,
ask the manufacturer or sales agent whether
the devices can be affected by radio waves
before using your FOMA terminal.
The terminal may adversely affect electronic
medical devices.
Do
Please turn off the power near electronic
equipment that contains high-precision
mechanisms or handles delicate signals.
The terminal may interfere with the operation
of sensitive electronic equipment.
* Electronic equipment to watch out for:
Hearing aids, implanted pacemakers, ICDs and
other electronic medical devices; fire alarms,
automatic doors, and other automatically
controlled apparatus.
Users of implanted pacemakers, ICDs, and other
electronic medical devices are advised to ask
the manufacturer or sales agent whether or not
these devices can be affected by radio waves.
Do
If the display or camera lens is broken, be
careful with the broken glass and any
exposed FOMA terminal parts.
A plastic panel is used for the display or the
surface of the camera lens to prevent glass
from shattering. However, touching broken or
exposed parts may cause injury.
2. Precautions for the FOMA terminal
WARNING
Don't
Do not direct the infrared data port
towards your or another person's eyes.
Doing so may cause eye injury.
Don't
Do not direct the infrared data port towards
consumer equipment with infrared devices
during infrared communication.
Doing so may cause malfunction of the
infrared devices and result in an accident.
Don't
Do not put fluids such as water or substances
such as pieces of metal or flammable
materials into the miniUIM slot or microSD
card slot inside of the FOMA terminal.
Doing so may cause fire, burns, injury or
electric shock.
Do
Please turn off your FOMA terminal when
inside an airplane, hospital, or other area
where use is prohibited.
The terminal may adversely affect electronic
or medical equipment. If the Auto power
function is set, make sure to disable the
function before turning off the power.
Follow the instructions provided by the
medical facility for the use of mobile phones.
You will be punished if you take activity
prohibited by law such as use of mobile
phones in airplanes. However, use of the
FOMA terminal may be permitted by turning
off transmissions using radio waves, etc., but
follow airline instructions for proper use.
Introduction
7

CAUTION
Don't
Do not swing the FOMA terminal by its
strap or other parts.
The terminal may strike you or others around
you, resulting bodily injury.
Don't
Do not use the damaged FOMA terminal.
Doing so may cause fire, burns, injury or
electric shock.
Don't
If the display is broken and the inner
substance such as liquid crystal leaks, do
not allow it to come in contact with your
face, hands, etc.
Failure to observe this precaution may cause
loss of eyesight or damage to your skin. If the
inner substance such as liquid crystal comes
into your eyes or mouth, immediately rinse
with clean water and see a doctor.
If the liquid crystal adheres to your skin or
clothing, immediately wipe it off with alcohol
and wash with soap and water.
Do
Before using your FOMA terminal in a
vehicle, ask the manufacturer or sales
agent whether the operation of the
vehicle can be affected by radio waves.
In some types of vehicle, using the FOMA
terminal may interfere with the operation of
the vehicle's electronic equipment. In this case,
stop using the FOMA terminal immediately.
Do
There may be cases where the customer's
physical condition or predisposition
leads to itchiness, rashes, or sores. If this
occurs, immediately stop using the
FOMA terminal and see a doctor.
Material used in each part→p.11 "7. Material List"
Do
Take care not to pinch your fingers or the
strap when opening/folding the display
of the FOMA terminal.
Such pinching may cause injury.
Do
When viewing the display, keep a proper
distance between your eyes and it in a
bright place.
Failure to observe this precaution may impair
your vision.
3. Precautions for the Battery Pack
n
Refer to the information shown on the battery
pack label to check the type of battery.
Display Battery type
Li-ion00 Lithium-ion
Don't
Do not place metal items such as wires in contact with
the charging terminals. Also, do not carry or store the
battery pack with metal items such as necklaces.
Doing so may cause the battery pack to ignite,
explode, overheat or leak.
Don't
Check the orientation of the battery pack
before attaching it. If you have difficulty
attaching it to the FOMA terminal, do not
put excessive pressure on the battery pack.
Failure to observe this precaution may cause
the battery pack to ignite, explode, overheat
or leak.
Don't
Do not throw the battery pack into fire.
Doing so may cause the battery pack to ignite,
explode, overheat or leak.
Don't
Do not puncture the battery pack, hit it
with a hammer or step on it.
Doing so may cause the battery pack to ignite,
explode, overheat or leak.
Introduction
8
