Dodge 2010 Challenger SRT8 Installation and operation manual

CHALLENGER SRT8®C|41
CHALLENGER SRT8®
2010 D DGE CHALLENGER SRT8®SPECIFICATI NS
Dimensions are in inches (millimeters) unless otherwise noted.
GENERAL INF RMATI N
Body Style Two-door coupe
Assembly Plant Brampton, Ontario, Canada
EPA Vehicle Class Intermediate car
Introduction Date May 2008 as 2008 model
ENGINE: 6.1-LITER HEMI®V-8
Availability Standard
Type and Description 90-degree V-type, liquid-cooled
Displacement 370 cu. in. (6059 cu. cm)
Bore x Stroke 4.06 x 3.58 (103.0 x 90.9)
Valve System Pushrod-operated overhead valves, 16 valves, eight conventional hydraulic
lifters, all with roller followers
Fuel Injection Sequential, multi-port, electronic, returnless
Construction Deep-skirt cast-iron block with cross-bolted main bearing caps, aluminum
alloy heads with hemispherical combustion chambers
Compression Ratio 10.3:1
Power (estimated SAE net) 425 bhp (317 kW) @ 6,200 rpm (69.8 bhp/L)
Torque (estimated SAE net) 420 lb.-ft. (569 N•m) @ 4,800 rpm
Max. Engine Speed 6,400 rpm (electronically limited)
Fuel Requirement Premium 91 octane (R+M)/2—recommended
Oil Capacity 7 qt. (6.6L)
Factory Oil Fill 5W-40 Synthetic
Coolant Capacity 14 qt. (13.25L)
Emission Controls Dual close-coupled three-way catalytic converters, quad-heated
oxygen sensors and internal engine features(a)
Max. Gross Trailer Weight Not rated for trailer-tow
EPA Fuel Economy mpg (City/Hwy) Automatic—13/19
Manual—14/22
(a) Meets Federal Tier 2, Bin 5 emissions requirements; marketed in California as an LEV II (Low Emission Vehicle) under cleanest vehicle rules.
TRANSMISSI N: W5A580 FIVE-SPEED AUT MATIC
Availability Standard
Description Adaptive electronic control, performance-tuned Auto Stick driver-interactive
manual control and electronically modulated torque converter clutch
Gear Ratios
1st 3.59
2nd 2.19
3rd 1.41
4th 1.00
5th 0.83
Reverse 3.16
Final-drive Ratio 3.06 – Getrag axle with limited-slip differential
Overall Top-gear 2.54
CHALLENGER SRT8®
42 |C
CHALLENGER SRT8®
2010 D DGE CHALLENGER SRT8®SPECIFICATI NS
TRANSMISSI N: SIX-SPEED MANUAL TREMEC TR-6060 WITH ZF-SACHS 250 MM TWIN-DISC CLUTCH
Availability Optional
Description Triple cone / double cone synchronizer design; 1-4 skip shift and
reverse inhibit solenoids; 5:1 remote shifter
Gear Ratios
1st 2.97
2nd 2.10
3rd 1.46
4th 1.00
5th 0.74
6th 0.50
Reverse 2.90
Final-drive Ratio 3.91 – Getrag limited-slip differential
ELECTRICAL SYSTEM
Alternator 160-amp
Battery H7 case, 730 CCA, maintenance-free
DIMENSI NS AND CAPACITIES(b)
Wheelbase 116.0 (2946)
Track, Front 63.0 (1603)
Track, Rear 63.1 (1604)
Overall Length 197.7 (5023)
Overall Width 75.7 (1923)
Overall Height 57.1 (1449)
Ground Clearance 4.8 (122.2)
Frontal Area, sq. ft. (sq. m) 25.3 (2.35)
Drag Coefficient 0.353
Curb Weight, lb. (kg)—Est. 4,132 (automatic)
4,144 (manual)
Weight Distribution, percent F/R 54.5/45.5 (automatic)
54.7/45.3 (manual)
Fuel Tank Capacity, gal. (L) 19 (71.9)
(b) All dimensions measured at curb weight with standard tires.
ACC MM DATI NS
Seating Capacity, F/R 2/3
Front Seat
Head Room 39.3 (999)
Leg Room 42.0 (1067)
Shoulder Room 58.2 (1477)
Hip Room 54.6 (1387)
Seat Travel Driver—10.6 (270), passenger—8.7 (220)
Recliner Angle Range, deg. Driver—64, passenger—63
SAE Front Volume Index, cu. ft. (cu. m) 55.8 (1.58)
CHALLENGER SRT8®C|43
CHALLENGER SRT8®
2010 D DGE CHALLENGER SRT8®SPECIFICATI NS
Rear Seat
Head Room 37.4 (950)
Leg Room 32.6 (829)
nee Clearance 1.2 (31.1)
Shoulder Room 53.9 (1368)
Hip Room 48.6 (1236)
SAE Rear Seat Volume Index, cu. ft. (cu. m) 38.1 (1.08)
Total Interior Volume, cu. ft. (cu. m) 91.5 (2.59)
SAE Cargo Volume, cu. ft. (cu. m) 16.2 (0.46)
EPA Interior Volume Index, cu. ft. (cu. m) 107.7 (3.05)
Trunk Lift-over Height 33.0 (839)
B DY
Layout Longitudinal front engine, rear-wheel drive
Construction Unitized steel body
EXHAUST
Type Dual 2.75-inch with rectangular chromed tip and image-tuned exhaust note
SUSPENSI N
SRT-tuned Front and Rear Suspension
Front Independent SLA with high upper “A” arm, coil spring over gas-charged
monotube Bilstein shock absorbers and stabilizer bar, lateral and diagonal
lower links
Rear Five-link independent with coil springs, link-type stabilizer bar, gas-charged
monotube Bilstein shock absorbers and isolated suspension cradle
STEERING
Type Rack-and-pinion with hydraulic power assist
Overall Ratio 16.1:1
Turning Diameter (curb-to-curb) 37.5 ft. (11.48 m)
Steering Turns (lock-to-lock) 2.75
P/S Pump Fixed displacement
TIRES(c)
Front and Rear Standard on Challenger SRT8
Size and Type 245/45ZR20 all-season
Mfr. and Model Goodyear Eagle RSA
Revs per Mile (km) 731 (456) front and rear
Front Optional on Challenger SRT8
Size and Type P245/45ZR20 three-season
Mfr. and Model Goodyear F1 Supercar
Revs per Mile (km) 726 (450)
CHALLENGER SRT8®
44 |C
CHALLENGER SRT8®
2010 D DGE CHALLENGER SRT8®SPECIFICATI NS
Rear Optional on Challenger SRT8
Size and Type P255/45ZR20 three-season
Mfr. and Model Goodyear F1 Supercar
Revs per Mile (km) 718 (445)
(c) Other sizes and brands may also be used.
WHEELS
Standard
Type and Material Fully forged aluminum
Size 20 x 9 in.
BRAKES
Front
Rotor Size and Type 14.2 x 1.26 (360 x 32.0) vented and slotted
Caliper Size and Type 1.73 (44) Brembo four-piston fixed with aluminum housing
Swept Area 351 sq. in. (2261 sq. cm)
Rear
Rotor Size and Type 13.8 x 1.10 (350 x 28) vented
Caliper Size and Type 1.26 (32) Brembo four-piston fixed with aluminum housing
Swept Area 316 sq. in. (2036 sq. cm)
Four-wheel Anti-lock Brake System (ABS)
and Traction Control Standard
Electronic Stability Program (ESP) and Brake Assist Standard
Brake nockback Mitigation Standard
Hill-start Assist (HSA) Standard with manual transmission
Three-position ESP/Traction Control Mode Selection Standard
Power-assist Type 8 + 9 (203 + 209) tandem-diaphragm vacuum booster
CHALLENGER SRT8®C|45
CHALLENGER SRT8®
2010 D DGE CHALLENGER SRT8®FEATURE AVAILABILITY
LEGEND: S = Standard, O = Optional, P = Pac age, — = Not available
Complete pac age information is listed at the end of the Feature Availability section.
NOTE: Information shown is correct at time of publication and is subject to change.
SRT8®
EXTERI R
Antenna—Integrated into rear window S
Badging—SRT8 and stripes
Deck-lid S
Grille Insert S
Dual-hood stripe S
Dual-hood stripe delete O
Colors:
High Performance Red Clear Coat
HEMI®Orange
Bright Silver Metallic Clear Coat
Brilliant Black Crystal Pearl Coat
Plum Crazy Pearl Coat (Special-edition, limited availability) O/P
Door Handles—Body-color S
Exhaust System
Stainless steel high-performance with dual chromed rectangular exhaust tips S
Fuel Filler Door
Bright, polished aluminum S
Grille—Satin chrome surrounded with black field S
Glass—Solar control, all windows S
Headlamps
Xenon, High-Intensity Discharge (HID) S
Automatic S
Fog lamps S
Hood—Dual air scoops, functional
Mirrors
Power, body-color, folding, heated S
Rear Spoiler, Functional
Black S
Sun Roof—Power with one-touch open/close and vent feature O
Windshield Wipers—Two-speed with variable-intermittent mode S
INTERI R
Air Conditioning—Manual temperature control S
Assist Handles—Passenger S
Cargo Compartment Dress-up—Trunk S
Color: Dark Slate Gray S
Console
Floor with fore-and-aft slide S
Cell-phone storage S
Front and rear climate control outlets S
12-volt power accessory delay S
Defroster—Rear window S
Door Locks—Power, speed-sensitive locking S
CHALLENGER SRT8®
46 |C
CHALLENGER SRT8®
2010 D DGE CHALLENGER SRT8®AVAILABILITY
SRT8®
Electronic Vehicle Information Center (EVIC) S
Reconfigurable Display with Performance Pages S
Performance Pages includes 0-60 mph, eighth-mile, quarter-mile, braking distance timers; G-force meter S
Floor Covering—Carpet S
Floor Mats
Luxury, front and rear S
HomeLink universal transceiver S
Interior Accents S
Satin-silver lock knobs S
Side-door accent S
SRT instrument-panel (IP) plaque S
SRT dash badge S
SRT serialized IP plaque (available on special-edition Plum Crazy Model) P
eyless Go—Push-button starter S
Lighting
Front map lamps for reading and rear courtesy lamps S
Trunk lamp S
LED-illuminated cup holders S
LED-illuminated map pockets S
Mirrors
Rearview, day/night S
Rearview, auto-dimming S
Sun Visor
Dual visor vanity, illuminated S
Pedals—Non-adjustable S
Power Accessory—12-volt auxiliary power outlet located in center console S
Remote keyless illuminated entry system—Includes two transmitters S
Remote start—Automatic transmission only S
Shift nob
Leather-wrapped S
Pistol grip (six-speed manual transmission only) O
Speedometer
180-mph with electroluminescent display and tachometer S
Steering Column—Tilt/telescoping, manual S
Steering Wheel
Leather-wrapped with accent stitching S
Steering wheel-mounted audio and EVIC controls S
Temperature Display—Outside, located in instrument cluster S
Seating
SRT performance seats with exclusive premium-leather trim and red stripe insert S
Plum leather accent seat-stripe insert (available on special-edition Plum Crazy Model) P
Front
Power-adjustable, performance S
Eight-way power driver’s S
Heated S
Manual driver/passenger adjustable lumbar S
Rear
60/40 split-folding bench with armrest and two cup holders S
CHALLENGER SRT8®C|47
CHALLENGER SRT8®
2010 D DGE CHALLENGER SRT8®FEATURE AVAILABILITY
SRT8®
Radios
AM/FM/CD/DVD/MP3 S
iPod Control®S
SIRIUS Satellite Radio S
Uconnect Navigation (requires SRT Option Group II) O
Uconnect Phone S
Sound Systems
Six Boston Acoustics®speakers with 276-watt digital amplifier S
Thirteen SRT high-performance IC ER®speakers (eight locations) with a 322-watt digital amplifier
and 200-watt subwoofer amplifier with Driver Selectable Surround (DSS) sound (included with SRT Group II) P
Windows—Power front one-touch auto down S
P WERTRAIN AND CHASSIS
6.1L SRT HEMI V-8 with five-speed automatic transmission with Auto Stick and limited-slip differential S
6.1L SRT HEMI V-8 with six-speed manual transmission with TRAC PA (Hill-start Assist, limited-slip differential,
bright pedal covers, performance steering, ESP full-off switch) O
Alternator—160-amp S
Battery—625-amp, maintenance-free S
Battery-saver Feature—Enhanced, programmable to turn headlamps and other switched and non-switched
interior lamps off after ignition is turned off S
Brakes
High-performance four-wheel disc anti-lock with vented 14-inch front and 13.8-inch rear discs;
includes Brembo Performance four-piston calipers and all-speed traction control S
Anti-lock Brake System (ABS) S
Brake Assist S
Engine Cooling
Severe-duty II S
Fuel Tank
19-gallon with tethered cap S
Speed Control—Electronic with steering column-mounted controls S
Steering
Performance-tuned S
Suspension
SRT-tuned dampers, specially tailored spring rates and suspension bushings S
Large-diameter anti-sway bars S
Modified front and rear knuckles S
Tip Start—Prevents ignition from over-cranking (N/A with manual transmission) S
Axle—Limited-slip differential S
Tires
Front and Rear—P245/45ZR20 Goodyear RSA four-season S
Front—P245/45ZR20 Goodyear F1 three-season O
Rear—P255/45ZR20 Goodyear F1 three-season O
TIREFIT System: tire sealant and electric compressor S
Wheels
20-inch SRT-exclusive, fully forged, polished aluminum S
CHALLENGER SRT8®
48 |C
CHALLENGER SRT8®
2010 D DGE CHALLENGER SRT8®AVAILABILITY
SRT8®
SAFETY AND SECURITY
Air Bags(a)
Advanced multi-stage for driver and front-passenger S
Supplemental side-curtain for front and rear outboard occupants S
LATCH Child Seat Anchor System—Mounts for two child seats in the rear help ease the installation of
compatible aftermarket child seats S
Electronic Stability Program (ESP)(b)—Three mode tuned for SRT performance with brake knockback mitigation software S
Seat Belts
Three-point driver and front-passenger with traveling buckles S
Seat-belt pretensioners S
Three-point lap/shoulder belts at all rear-seat positions S
Security Alarm S
Sentry ey®—Anti-theft engine immobilizer S
Tire-pressure Monitoring (TPM) Warning Lamp S
Tire-pressure Monitoring (TPM) Display S
Uconnect Phone S
(a) Certified to the federal regulation for automatic passenger occupant classification. Always use seat belts. Children 12 and under should
always be in a back seat correctly using an infant or child restraint system, or the seat belt positioned correctly for the child’s age and size.
The Occupant-classification System (OCS) determines the conditions for activation or deactivation of the passenger-side front air bag based
upon the weight of the occupant. It may not activate the air bag if the occupant has incorrect seating posture or is moving in the seat.
You should observe the air bag lamp to determine if the OCS is deciding properly. Passengers should sit properly in the seat with the seat belt
fastened at all times.
(b) No system, no matter how sophisticated, can repeal the laws of physics or overcome careless driving actions. Performance is limited by
available traction, which snow, ice and other conditions can affect. When the ESP warning lamp in the speedometer flashes, the driver needs
to use less throttle and adapt speed and driving behavior to prevailing road conditions. Always drive carefully, consistent with conditions.
Always wear your seat belt.
PACKAGES / EQUIPMENT GR UPS
SRT Option Group II—13 IC ER®SRT high-performance audio speakers, 322-watt IC ER®SRT amplifier and
200-watt IC ER®SRT subwoofer with Driver Selectable Surround (DSS) sound O
Uconnect Navigation—Requires SRT Option Group II O
Track Pak—Includes six-speed manual transmission, Hill-start Assist (HSA), (3.91 final-drive ratio with 20-inch wheels),
and bright pedals (packaged with the manual transmission) O
Plum Crazy Model—Includes unique Plum Crazy Pearl Coat exterior color, plum accent seat-stripe insert and
color-cued accent stitching in steering wheel and serialized dash plaque O
SRT Track Experience—Includes a one-day driving experience designed for SRT owners and performance enthusiasts
to maximize their driving knowledge and skills on the street or track. All SRT owners and enthusiasts are eligible to
participate in this day-long event held at selected tracks throughout the season with first-rate driving instruction
from the professionals at the Richard Petty Racing School S

Other manuals for 2010 Challenger SRT8

2

Other Dodge Automobile manuals

Dodge Challenger 2018 User manual

Dodge

Dodge Challenger 2018 User manual

Dodge Caliber 2012 User manual

Dodge

Dodge Caliber 2012 User manual

Dodge Dakota 2011 User manual

Dodge

Dodge Dakota 2011 User manual

Dodge DURANGO 2020 User manual

Dodge

Dodge DURANGO 2020 User manual

Dodge 2013 Durango User manual

Dodge

Dodge 2013 Durango User manual

Dodge 2010 Charger SRT User manual

Dodge

Dodge 2010 Charger SRT User manual

Dodge 2013 VIPER SRT User manual

Dodge

Dodge 2013 VIPER SRT User manual

Dodge Ram Truck 1500 Instruction Manual

Dodge

Dodge Ram Truck 1500 Instruction Manual

Dodge 2008 Charger User manual

Dodge

Dodge 2008 Charger User manual

Dodge 2006 Caravan User manual

Dodge

Dodge 2006 Caravan User manual

Dodge 2008 Durango User manual

Dodge

Dodge 2008 Durango User manual

Dodge charger 2017 Configuration guide

Dodge

Dodge charger 2017 Configuration guide

Dodge Caliber User manual

Dodge

Dodge Caliber User manual

Dodge 2012 Challenger User manual

Dodge

Dodge 2012 Challenger User manual

Dodge Challenger 2019 User manual

Dodge

Dodge Challenger 2019 User manual

Dodge 2004 Neon SX2 User manual

Dodge

Dodge 2004 Neon SX2 User manual

Dodge challenger 2017 User manual

Dodge

Dodge challenger 2017 User manual

Dodge 2010 Nitro User manual

Dodge

Dodge 2010 Nitro User manual

Dodge Neon 2005 User manual

Dodge

Dodge Neon 2005 User manual

Dodge journey 2017 User manual

Dodge

Dodge journey 2017 User manual

Dodge Viper2017 User manual

Dodge

Dodge Viper2017 User manual

Dodge Avenger Owner's manual

Dodge

Dodge Avenger Owner's manual

Dodge 2006 Grandcaravan User manual

Dodge

Dodge 2006 Grandcaravan User manual

Dodge 2013 RAM Chassis Cab 5500 User manual

Dodge

Dodge 2013 RAM Chassis Cab 5500 User manual

Popular Automobile manuals by other brands

Vauxhall MY15 INSIGNIA quick start guide

Vauxhall

Vauxhall MY15 INSIGNIA quick start guide

Fiat 500 ABARTH 2018 owner's manual

Fiat

Fiat 500 ABARTH 2018 owner's manual

Opel CASCADA owner's manual

Opel

Opel CASCADA owner's manual

GMC 2013 Sierra 1500 Quick facts

GMC

GMC 2013 Sierra 1500 Quick facts

Mahindra Genio DC BS-III Diagnostic manual

Mahindra

Mahindra Genio DC BS-III Diagnostic manual

Chevrolet Malibu 2016 owner's manual

Chevrolet

Chevrolet Malibu 2016 owner's manual

Chevrolet 1996 Astro manual

Chevrolet

Chevrolet 1996 Astro manual

Mercedes-Benz Mercedes-AMG SL Roadster 2021 owner's manual

Mercedes-Benz

Mercedes-Benz Mercedes-AMG SL Roadster 2021 owner's manual

Daewoo TACUMA Body repair manual

Daewoo

Daewoo TACUMA Body repair manual

Chevrolet Spark EV 2014 owner's manual

Chevrolet

Chevrolet Spark EV 2014 owner's manual

Chevrolet 2009 Silverado owner's manual

Chevrolet

Chevrolet 2009 Silverado owner's manual

Hudson Year 1947 owner's manual

Hudson

Hudson Year 1947 owner's manual

Hyundai Santro owner's manual

Hyundai

Hyundai Santro owner's manual

Volvo V90 - ACCESSORY PANEL owner's manual

Volvo

Volvo V90 - ACCESSORY PANEL owner's manual

Hudson Terraplane K 1934 Mechanical procedure manual

Hudson

Hudson Terraplane K 1934 Mechanical procedure manual

Cadillac 2012 Cadillac Escalade owner's manual

Cadillac

Cadillac 2012 Cadillac Escalade owner's manual

Renault 2013 Clio Cup Driver's handbook

Renault

Renault 2013 Clio Cup Driver's handbook

Mercedes-Benz 2003 S 430 Operator's manual

Mercedes-Benz

Mercedes-Benz 2003 S 430 Operator's manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
