Dometic GROUP BUTTNER PowerPack BASIC User manual

PowerPack BASIC, PowerPack CLASSIC I, PowerPack CLASSIC II, PowerPack CLASSIC
POWER I, PowerPack CLASSIC POWER II, PowerPack CLASSIC POWER PLUS I,
PowerPack CLASSIC POWER PLUS II
Accessory kit for power supply
Installation and Operating Manual. . . . . . . 13
Zubehörpaket für die
Energieversorgung
Montage- und Bedienungsanleitung . . . . . 19
Kit d’accessoires pour
l'alimentation électrique
Instructions de montage
et de service . . . . . . . . . . . . . . . . . . . . . . . . .26
Kit di accessori per l'alimentazione
Istruzioni di montaggio e d’uso . . . . . . . . .33
Accessoireset voor
stroomvoorziening
Montagehandleiding en
gebruiksaanwijzing. . . . . . . . . . . . . . . . . . . 40
Tilbehørssæt til strømforsyning
Monterings- og betjeningsvejledning. . . . 47
Tillbehörssats för strömförsörjning
Monterings- och bruksanvisning . . . . . . . . 54
Tilbehørssett for strømforsyning
Monterings- og bruksanvisning. . . . . . . . . 61
A
A
A
A
A
EN
DE
FR
IT
NL
DA
SV
NO
POWER & CONTROL
POWERPACK

© 2022 Dometic Group. The visual appearance of the contents of this manual is
protected by copyright and design law. The underlying technical design and the
products contained herein may be protected by design, patent or be patent
pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.
All rights are reserved.

4445103621 3
EN DE FR IT NL DA SV NO
rd Red Rot Rouge Rosso Rood Rød Röd Rød
bk Black Schwarz Noir Nero Zwart Sort Svart Svart
bu Blue Blau Bleu Blu Blauw Blå Blå Blå
rd
D+
t30 A
t40 A
rdbk
+- +-
800 mA
bu
rd
2
1
A
3
Netz D+ TR TT
Start BordCom.
1

4 4445103621
EN DE FR IT NL DA SV NO
rd Red Rot Rouge Rosso Rood Rød Röd Rød
bk Black Schwarz Noir Nero Zwart Sort Svart Svart
bu Blue Blau Bleu Blu Blauw Blå Blå Blå
rd
D+
t30 A
t40 A
rdbk
+- +-
2
1
B
800 mA
bu
rd
3
Netz D+ TR TT
Start BordCom.
2

4445103621 5
EN DE FR IT NL DA SV NO
rd Red Rot Rouge Rosso Rood Rød Röd Rød
bk Black Schwarz Noir Nero Zwart Sort Svart Svart
vt Violet Violett Violeta Violetto Paars Violet Violett Fiolett
ye Yellow Gelb Jaune Giallo Geel Gul Gul Gul
og Orange Orange Orange Arancione Oranje Orange Orange Oransje
bu Blue Blau Bleu Blu Blauw Blå Blå Blå
D+
+B1
+B2
D+ vt
+
t30 A
t40 A
-+-
rdbk
bk og
86
87
87a
85
30
bu ye
800 mA
bu rd
2
1
C
3
Netz D+ TR TT
Start BordCom.
3

6 4445103621
+
+
D+
–
–
40 A
A40
2 1
5A
25A
5A
5A
+-
+-
Netz D+ TR TT
Start BordCom.
2
3
5
6
7
7
8
1
4
9
A
4

4445103621 7
1
2
+
+
–
–
40 A
A40
5A
25A
5A
5A
D+
+-
+-
Netz D+ TR TT
Start BordCom.
2
3
5
6
7
7
8
1
B
4
9
5

8 4445103621
1
2
+
+
–
–
40 A
A40
5A
25A
5A
5A
D+
+B1
+B2
+-
+-
Netz D+ TR TT
Start BordCom.
5
2
3
6
7
7
8
1
C
4
9
6

4445103621 9
+
+
D+
–
–
+-
Start BordCom.
1
2
5A
5A
5A
5A
25A
+-
80 A
80 A
2
3
5
6
7
9
7
8
1
A
4
7

10 4445103621
+
+
D+
D+
–
–
+-
Start BordCom.
1
2
5A
5A
5A
5A
25A
+-
80 A
80 A
2
3
5
6
7
78
1
9
B
4
8

4445103621 11
+
+
D+
–
–
+-
D+
+B1 87a
87
8685
30
+B2
5A
5A
5A
5A
25A
+-
80 A
80 A
Start BordCom.
1
2
2
3
5
6
7
78
1
bk
bu
og
ye
C
4
9
9

12 4445103621
+
+
D+
–
–
+-
5A
5A
5A
5A
25A
+-
80 A
80 A
8685
3837
Start BordCom.
1
2
bk bu
buye
2
3
5
6
7
78
1
D
4
9
0

4445103621 13
EN
Please read these instructions carefully and follow all instructions, guide-
lines, and warnings included in this product manual in order to ensure that
you install, use, and maintain the product properly at all times. These instruc-
tions MUST stay with this product.
By using the product, you hereby confirm that you have read all instructions,
guidelines, and warnings carefully and that you understand and agree to
abide by the terms and conditions as set forth herein. You agree to use this
product only for the intended purpose and application and in accordance
with the instructions, guidelines, and warnings as set forth in this product
manual as well as in accordance with all applicable laws and regulations. A
failure to read and follow the instructions and warnings set forth herein may
result in an injury to yourself and others, damage to your product or damage
to other property in the vicinity. This product manual, including the instruc-
tions, guidelines, and warnings, and related documentation, may be subject
to changes and updates. For up-to-date product information, please visit
documents.dometic.com.
Content
Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . .13
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Technical description . . . . . . . . . . . . . . . . . . . . .15
Related documents . . . . . . . . . . . . . . . . . . . . . . .15
Installing the accessory kit . . . . . . . . . . . . . . . . . .16
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Scope of delivery
MT Power Pack BASIC
MT PowerPack CLASSIC I + II
MT Power Pack CLASSIC POWER I + II
Designation Quantity
Battery control booster
MT BCB 25/20 with accessories*
1
Battery monitor MT iQ Basic Pro
with accessories*
1
Cable connector 1
Installation and Operating Manual for the
battery control booster
1
Installation and Operating Manual for the
battery monitor
1
*Find the detailed scope of delivery in the respective installation and
operating manual (see chapter “Related documents” on page 15).
Designation Quantity
Battery control booster
MT BCB 25/20 with accessories*
1
MT PowerPack CLASSIC I:
Solar system MT 110 MC
with Solar charger MT 230 PP
and accessories*
MT PowerPack CLASSIC II:
Solar system MT 220-2 MC
with Solar charger MT 230 PP
and accessories*
1
Battery monitor MT 5000 iQ
with 200 A shunt and accessories*
1
Fuse holder ME with fuses (2 x 40 A) 1
Fuse holder FS-3 with fuses (5 A, 25 A) 1
Fuse holder FS-1 with fuse (5 A) 1
Installation and Operating Manual for the
battery control booster
1
Installation and Operating Manual for the
solar system
1
Installation and Operating Manual for the
solar charger
1
Installation and Operating Manual for the
battery monitor
1
*Find the detailed scope of delivery in the respective installation and
operating manual (see chapter “Related documents” on page 15).
Designation Quantity
Battery control booster
MT BCB 30/30 with accessories*
1
MT PowerPack CLASSIC POWER I:
Solar system MT 110 MC
with Solar charger MT 230 PP
and accessories*
MT PowerPack CLASSIC POWER II:
Solar system MT 220-2 MC
with Solar charger MT 230 PP
and accessories*
1

14 4445103621
MT Power Pack CLASSIC POWER PLUS
I+II
Accessories
Available as accessories (not included in the scope
of delivery):
Intended use
The accessory kit is intended to monitor and
charge 12 V house batteries in caravans and motor
homes while driving or on the mains. In addition,
the accessory kit can be used as a stable power
supply to operate DC powered devices to keep
the batteries fully charged. The accessory kit can
be installed as a stand-alone charging system or as
a supplement to the existing on-board electronics.
This product is only suitable for the intended pur-
pose and application in accordance with these
instructions.
This manual provides information that is necessary
for proper installation and/or operation of the
product. Poor installation and/or improper operat-
ing or maintenance will result in unsatisfactory per-
formance and a possible failure.
The manufacturer accepts no liability for any injury
or damage to the product resulting from:
• Incorrect assembly or connection, including
excess voltage
Battery monitor MT 5000 iQ
with 200 A shunt and accessories*
1
Fuse holder ME with fuses (2 x 40 A) 2
Fuse holder FS-3 with fuses (5 A, 25 A) 1
Fuse holder FS-1 with fuse (5 A) 2
Installation and Operating Manual for the
battery control booster
1
Installation and Operating Manual for the
solar system
1
Installation and Operating Manual for the
solar charger
1
Installation and Operating Manual for the
battery monitor
1
*Find the detailed scope of delivery in the respective installation and
operating manual (see chapter “Related documents” on page 15).
Designation Quantity
Battery control booster
MT BCB 40/40 with accessories
1
MT PowerPack CLASSIC POWER PLUS I:
Solar system MT 170 MC
with Solar charger MT 230 PP
and accessories*
MT PowerPack CLASSIC POWER PLUS II:
Solar system MT 340-2 MC
with Solar charger MT 350 PP
and accessories*
1
Battery monitor MT 5000 iQ
with 200 A shunt and accessories
1
Fuse holder ME with fuses (2 x 80 A) 2
Fuse holder FS-3 with fuses (5 A, 25 A) 1
Fuse holder FS-1 with fuse (5 A) 2
Installation and Operating Manual for the
battery control booster
1
Installation and Operating Manual for the
solar system
1
Designation Quantity
Installation and Operating Manual for the
solar charger
1
Installation and Operating Manual for the
battery monitor
1
*Find the detailed scope of delivery in the respective installation and
operating manual (see chapter “Related documents” on page 15).
Description Ref. no.
Combination kit 1500 W
with sine wave inverter MT PL 1500 SI
and mains switching unit MT NU 3600
9620001961
(PP 01500)
LiFePO4 battery 105 Ah,
MT LI 105
9620000237
(MT LI0105)
LiFePO4 battery 120 Ah,
MT LI 120
9620000187
(MT LI0120)
Designation Quantity

4445103621 15
• Incorrect maintenance or use of spare parts
other than original spare parts provided by the
manufacturer
• Alterations to the product without express per-
mission from the manufacturer
• Use for purposes other than those described in
this manual
Dometic reserves the right to change product
appearance and product specifications.
Tec hn ica l des cri ption
The accessory kit consists of several components
that are combined to provide a complete charging
system.
Battery control booster
The battery control booster enables charging
either on the 230 V mains or while driving via the
integrated 12 V charging booster. If neither of
these two charging sources is available, pulser
operation is activated to protect the battery from
sulfation.
The house battery type used can be set directly on
the device via DIP switches. With the temperature
sensor connected, the temperature of the house
battery is monitored during charging and adjusted
according to the measured temperature on the
battery.
Battery monitor
The battery monitor is the central monitoring unit
of the accessory kit. The battery monitor displays
the available battery capacity, voltage and the
actual amount of energy generated or consumed
andprovidesinformation about thetemperature of
the starting battery and the date and time.
Solar system (only MT PowerPack CLASSIC I + II,
MT PowerPack CLASSIC POWER I + II, MT Power-
Pack CLASSIC POWER PLUS I + II)
The solar system converts sunlight into direct cur-
rent (DC) to charge the house battery and supply
standard on-board consumers, especially when a
connection to the mains is not available.
The included solar charger is intended to ensure
the correct charging voltage of the vehicle batter-
ies using microprocessor controlled IU0U
charging programs and to protect the batteries
against over voltage and deep discharge.
Related documents
Find the detailed information on the respective
device in the enclosed installation and operating
manual or online at:
Battery control booster
(MT BCB 25/20)
Battery control booster
(MT BCB 30/30,
MT BCB 40/40)
https://documents.dometic.com/
?object_id=84709
https://documents.dometic.com/
?object_id=84710
Solar system
(MT 110 MC,
MT 220-2 MC)
Solar charger
(MT 230 PP,
MT 350 PP)
https://documents.dometic.com/
?object_id=83825
https://documents.dometic.com/
?object_id=83055
Battery monitor
(MT iQ Basic Pro)
Battery monitor
(MT 5000 iQ)
https://documents.dometic.com/
?object_id=83824
https://documents.dometic.com/
?object_id=84711

16 4445103621
Installing the accessory kit
!
I
MT PowerPack BASIC:
Legend for fig. 1, page 3 to fig. 3, page 5:
Connection variant A
Connection variant for vehicles that are to be
equipped with a house battery and a charging
device.
➤To connect the accessory kit proceed as shown
in fig. 1, page 3.
Connection variant B
Connection variant for vehicles with a cutoff relay
present.
➤To connect the accessory kit proceed as shown
in fig. 2, page 4.
Connection variant C
Connection variant for motor homes with existing
central electrical system.
➤To connect the accessory kit proceed as shown
in fig. 3, page 5.
MT PowerPack CLASSIC I + II:
Legend for fig. 4, page 6 to fig. 6, page 8:
1. Install the solar system.
2. Protect the positive cable of the solar charger
with a fuse (25 A) (6).
3. Select the appropriate connection variant and
install the battery control booster.
4. Protect the positive cable of the house battery
as close to the battery as possible with a fuse
(80 A) (7).
5. Protect the positive cable of the starting bat-
tery as close to the battery as possible with a
fuse (80 A) (7).
6. Install the battery monitor.
7. Protect the sense cables on the shunt with a
fuse (5 A) (8).
8. Optionally connect the battery monitor to the
battery control booster (9) (see chapter “Con-
necting the battery monitor to the battery con-
trol booster (optional)” on page 18).
WARNING!
Observe the instructions and safety pre-
cautions for all components used in the
accessory kit.
NOTE
Find the detailed information on mount-
ing the accessory kit in the respective
installation and operating manual (see
chapter “Related documents” on
page 15).
The electrical power supply must be
connectedby aqualifiedelectricianwho
has demonstrated skill and knowledge
related to the construction and opera-
tion of electrical equipment and installa-
tions and has received safety training to
identify and avoid the hazards involved.
No Description
1 Battery control booster
2Batterymonitor
3 Current sensor (Hall sensor)
No Description
1 Battery control booster
2 Solar panel with junction box
3 Solar charger
4Batterymonitor
5Shunt
6 Fuse holder FS-3 with fuses (5 A, 25 A)
7 Fuse holder ME with fuse (40 A)
8 Fuse holder FS-1 with fuse (5 A)
9 Control cable for connecting the battery
monitor to the battery control booster

4445103621 17
Connection variant A
Connection variant for vehicles that are to be
equipped with a house battery and charging
device.
➤To connect the accessory kit proceed as shown
in fig. 4, page 6.
Connection variant B
Connection variant for vehicles with a cutoff relay
present.
➤To connect the accessory kit proceed as shown
in fig. 5, page 7.
Connection variant C
Connection variant for motor homes with existing
central electrical system.
➤To connect the accessory kit proceed as shown
in fig. 6, page 8.
MT PowerPack CLASSIC POWER I + II,
MT PowerPack CLASSIC POWER PLUS
I + II:
Legend for fig. 7, page 9 to fig. 0, page 12:
1. Install the solar system.
2. Protect the positive cable of the solar charger
with a fuse (25 A) (6).
3. Select the appropriate connection variant and
install the battery control booster.
4. Protect the positive cable of the house battery
as close to the battery as possible with a fuse
(80 A) (7).
5. Protect the positive cable of the starting bat-
tery as close to the battery as possible with a
fuse (80 A) (7).
6. Install the battery monitor.
7. Protect the sense cables on the shunt with a
fuse (5 A) (8).
8. Optionally connect the battery monitor to the
battery control booster (9) (see chapter “Con-
necting the battery monitor to the battery con-
trol booster (optional)” on page 18).
Connection variant A
Connection variant for vehicles that are to be
equipped with a house battery and charging
device.
➤To connect the accessory kit proceed as shown
in fig. 7, page 9.
Connection variant B
Connection variant for vehicles with an existing
cutoff relay.
➤To connect the accessory kit proceed as shown
in fig. 8, page 10.
Connection variant C
Connection variant for motor homes with existing
central electrical system equipped with integrated
cutoff relay and integrated charger.
➤To connect the accessory kit proceed as shown
in fig. 9, page 11.
Connection variant D
Connection variant if the power consumption in
driving operation is higher than the charging
power.
➤To connect the accessory kit proceed as shown
in fig. 0, page 12.
No Description
1 Battery control booster
2 Solar panel with junction box
3 Solar charger
4Batterymonitor
5Shunt
6 Fuse holder FS-3 with fuses (5 A, 25 A)
7 Fuse holder ME with fuse (80 A)
8 Fuse holder FS-1 with fuse (5 A)
9 Control cable for connecting the battery
monitor to the battery control booster

18 4445103621
Connecting the battery monitor to the
battery control booster (optional)
➤Connect terminal 1 of the battery monitor to the
TR terminal of the battery control booster using a
control cable (9) with a cable cross-section of
0.75 mm².
Activating the connection to the battery
control booster
I
1. Press and hold the button on the battery
monitor for at least 3 seconds to open the set-
tings menu.
2. Press the button until “bcb” is displayed.
3. Press the button to set “ON”.
4. Press the button to save the setting.
✔The settings menu is closed and the start screen
appears.
✔An arrow symbol is displayed at the bottom of
the battery monitor display between "Start" and
"Bord". When the arrow symbol flashes, the
relay is controlled by the battery monitor.
Warranty
The statutory warranty period applies. If the prod-
uct is defective, please contact your retailer or the
manufacturer's branch in your country (see
dometic.com/dealer).
For repair and warranty processing, pleaseinclude
the following documents when you send in the
product:
• A copy of the receipt with purchasing date
• A reason for the claim or description of the fault
Note that self-repair or nonprofessional repair can
have safety consequences and might void the war-
ranty.
Disposal
Recycling packaging material
Recycling products with non-replaceable
batteries, rechargeable batteries or light
sources
NOTE
Activating the connection to the battery
control booster deactivates the outdoor
temperature sensor.
➤Place the packaging material in the appro-
priate recycling waste bins wherever pos-
sible.
➤If the product contains any non-replace-
able batteries, rechargeable batteries or
light sources, you don't have to remove
them before disposal.
➤If you wish to finally dispose of the prod-
uct, ask your local recycling center or spe-
cialist dealer for details about how to do
this in accordance with the applicable dis-
posal regulations.
➤The product can be disposed free of
charge.

4445103621 19
DE
Lesen und befolgen Sie bitte alle Anweisungen, Richtlinien und Warnhin-
weise in diesem Produkthandbuch sorgfältig, um sicherzustellen, dass Sie
das Produkt ordnungsgemäß installieren und stets ordnungsgemäß betrei-
ben und warten. Diese Anleitung MUSS bei dem Produkt verbleiben.
Durch die Verwendung des Produktes bestätigen Sie hiermit, dass Sie alle
Anweisungen, Richtlinien und Warnhinweise sorgfältig gelesen haben und
dass Sie die hierin dargelegten Bestimmungen verstanden haben und ihnen
zustimmen. Sie erklären sich damit einverstanden, dieses Produkt nur für
den angegebenen Verwendungszweck und gemäß den Anweisungen,
Richtlinien und Warnhinweisen dieses Produkthandbuchs sowie gemäß
allen geltenden Gesetzen und Vorschriften zu verwenden. Eine Nichtbeach-
tung der hierin enthaltenen Anweisungen und Warnhinweise kann zu einer
Verletzung Ihrer selbst und anderer Personen, zu Schäden an Ihrem Produkt
oder zu Schäden an anderem Eigentum in der Umgebung führen. Dieses
Produkthandbuch, einschließlich der Anweisungen, Richtlinien und Warn-
hinweise, sowie die zugehörige Dokumentation können Änderungen und
Aktualisierungen unterliegen. Aktuelle Produktinformationen finden Sie
unter documents.dometic.com.
Inhalt
Lieferumfang. . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Zubehör . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Bestimmungsgemäßer Gebrauch. . . . . . . . . . . .21
Technische Beschreibung. . . . . . . . . . . . . . . . . .21
Zugehörige Dokumente . . . . . . . . . . . . . . . . . . 22
Zubehörkit installieren . . . . . . . . . . . . . . . . . . . . 22
Gewährleistung . . . . . . . . . . . . . . . . . . . . . . . . . 25
Entsorgung. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Lieferumfang
MT Power Pack BASIC
MT PowerPack CLASSIC I + II
Bezeichnung Anzahl
Batterie-Control-Booster
MT BCB 25/20 mit Zubehör*
1
Batterie-Computer MT iQ Basic Pro
mit Zubehör*
1
Kabel-Verbinder 1
Montage- und Bedienungsanleitung für
den Batterie-Control-Booster
1
Montage- und Bedienungsanleitung für
den Batterie-Computer
1
*Den detaillierten Lieferumfang finden Sie in der jeweiligen Montage-
und Bedienungsanleitung (siehe Kapitel „Zugehörige Dokumente“ auf
Seite 22).
Bezeichnung Anzahl
Batterie-Control-Booster
MT BCB 25/20 mit Zubehör*
1
MT PowerPack CLASSIC I:
Solaranlage MT 110 MC
mit Solarladeregler MT 230 PP
und Zubehör*
MT PowerPack CLASSIC II:
Solaranlage MT 220-2 MC
mit Solarladeregler MT 230 PP
und Zubehör*
1
Batterie-Computer MT 5000 iQ
mit 200-A-Shunt und Zubehör*
1
Sicherungshalter ME mit Sicherungen
(2 x 40 A)
1
Sicherungshalter FS-3 mit Sicherungen
(5 A, 25 A)
1
Sicherungshalter FS-1 mit Sicherung
(5 A)
1
Montage- und Bedienungsanleitung für
den Batterie-Control-Booster
1
Montage- und Bedienungsanleitung für
die Solaranlage
1
Montage- und Bedienungsanleitung für
den Solarladeregler
1
Montage- und Bedienungsanleitung für
den Batterie-Computer
1
*Den detaillierten Lieferumfang finden Sie in der jeweiligen Montage-
und Bedienungsanleitung (siehe Kapitel „Zugehörige Dokumente“ auf
Seite 22).
Bezeichnung Anzahl

20 4445103621
MT Power Pack CLASSIC POWER I + II
MT Power Pack CLASSIC POWER PLUS
I+II
Zubehör
Als Zubehör erhältlich (nicht im Lieferumfang ent-
halten):
Bezeichnung Anzahl
Batterie-Control-Booster
MT BCB 30/30 mit Zubehör*
1
MT PowerPack CLASSIC POWER I:
Solaranlage MT 110 MC
mit Solarladeregler MT 230 PP
und Zubehör*
MT PowerPack CLASSIC POWER II:
Solaranlage MT 220-2 MC
mit Solarladeregler MT 230 PP
und Zubehör*
1
Batterie-Computer MT 5000 iQ
mit 200-A-Shunt und Zubehör*
1
Sicherungshalter ME mit Sicherungen
(2 x 40 A)
2
Sicherungshalter FS-3 mit Sicherungen
(5 A, 25 A)
1
Sicherungshalter FS-1 mit Sicherung
(5 A)
2
Montage- und Bedienungsanleitung für
den Batterie-Control-Booster
1
Montage- und Bedienungsanleitung für
die Solaranlage
1
Montage- und Bedienungsanleitung für
den Solarladeregler
1
Montage- und Bedienungsanleitung für
den Batterie-Computer
1
*Den detaillierten Lieferumfang finden Sie in der jeweiligen Montage-
und Bedienungsanleitung (siehe Kapitel „Zugehörige Dokumente“ auf
Seite 22).
Bezeichnung Anzahl
Batterie-Control-Booster
MT BCB 40/40 mit Zubehör
1
MT PowerPack CLASSIC POWER PLUS I:
Solaranlage MT 170 MC
mit Solarladeregler MT 230 PP
und Zubehör*
MT PowerPack CLASSIC POWER PLUS II:
Solaranlage MT 340-2 MC
mit Solarladeregler MT 350 PP
und Zubehör*
1
Batterie-Computer MT 5000 iQ
mit 200-A-Shunt und Zubehör
1
Sicherungshalter ME mit Sicherungen
(2 x 80 A)
2
Sicherungshalter FS-3 mit Sicherungen
(5 A, 25 A)
1
Sicherungshalter FS-1 mit Sicherung
(5 A)
2
Montage- und Bedienungsanleitung für
den Batterie-Control-Booster
1
Montage- und Bedienungsanleitung für
die Solaranlage
1
Montage- und Bedienungsanleitung für
den Solarladeregler
1
Montage- und Bedienungsanleitung für
den Batterie-Computer
1
*Den detaillierten Lieferumfang finden Sie in der jeweiligen Montage-
und Bedienungsanleitung (siehe Kapitel „Zugehörige Dokumente“ auf
Seite 22).
Beschreibung Art.-Nr.
Kombinationskit 1.500 W
mit Sinus-Wechselrichter
MT PL 1500 SI und Netzschaltgerät
MT NU 3600
9620001961
(PP 01500)
LiFePO4-Batterie 105 Ah,
MT LI 105
9620000237
(MT LI0105)
LiFePO4-Batterie 120 Ah,
MT LI 120
9620000187
(MT LI0120)
Bezeichnung Anzahl
