IX-SW028 Power Pack Instruction
Manual
文件编号：
发行日期：2017/08/28
版本：
A2
Product Overview
This product is a portable power pack. Attractive appearance built in high quality and large
capacity Lithium polymer battery. Use for Nintendo Switch Console in emergency charging. With
LED Charging indicator
Special designed for Nintendo Switch Console battery life, with multiple protection:over
charging protection, discharge protection, over current protection, short circuit protection
Description
Built in 7000 mAh Lithium polymer battery，can charge up the Switch console for one time.
With fast charging circuit ，charging time about 3 hours.
Built-in high integration of TYPE C power bank all in one chip
With LED indicator for battery state
Output:2A
Discharge rate：80%
Automatically load testing, without switch
Multiple protection:over charging protection, discharge protection, over current protection,
short circuit protection
Use TYPE-C connector for charging
Sepecification
1）TYPE-C input：DC5.0V±0.25V /1.5A
2）TYPE-C output：DC5.0V±0.25V /2A
3）Battery: Lithium polymer battery ,3.7V 7000MAH
4）Four blue LED indicator，When charging the battery lights flashing, long bright on discharge
5）Automatic function of output
6）Shut off automatically when completed charging( shut off time is 25-44s when current is less
than 45Ma)
7）Self consumption：less than 100μA
8）Power pack charging time: 4 hours(input 2A)
1) Connector type
No.
Connector Funtion
namw
sepecification
Remark
1
input
TYPE-C
Female
2
output
TYPE-C
Male
2) Battery Specification
Name
Testing
Testing Parameters
Testing Condition
Remark

IX-SW028 Power Pack Instruction
Manual
文件编号：
发行日期：2017/08/28
版本：
A2
Specification
Lithium
polymer
battery
Battery dimension
9060100
Standard capacity
7000mAh
0.2C standard
discharge
internal
resistance
≤60mΩ
3) Protection
Testing Specification
Testing Parameters
Testing Condition
Remark
Over discharge detection
2.9V
Over discharge releasing
3.1V
Over charge releasing
4.08-4.13V
Over charge testing voltage
4.15V-4.24V
4) Charging Testing
Name
Testing Specification
Testing Parameters
Testing Condition
Remark
Battery
Chargin
g
Full charge voltage
4.15V～4.24V
Charging current
2400mA±200MA
3.7V
Turning light current
＜150mA
Full charge indication
LED long bright
Charging state
Four LED indicator，Corresponding battery charging
flashing
Blue LED
5）Discharge Testing Parameters
Name
Testing Specification
Testing Parameters
Testing Condition
Remark
Battery
single
discharg
e
Output voltage
5.0V±0.25V
Electronic load
ripple wave
<150mVp-p
oscilloscope
output load voltage
5.0V±0.25V
Electronic load
Inputp load current
2000mA±200mA
Electronic load
Over current
3.3A-4.2A
Discharge rate
>80％
PCB Conversion
efficiency
short circuit protection
Current more than 5A
150-200US
Discharge instructions
the current voltage in long bright
Instruction

IX-SW028 Power Pack Instruction
Manual
文件编号：
发行日期：2017/08/28
版本：
A2
Install Switch console to the power pack, press the lock button, then start to charging and stop when
completed charging automatically.
Remark：1. Don't support to charge up the switch when power pack is charging.
2.Charging time for power pack：4hours( use 5V,1.5A AC Adaptor, original Switch AC
Adaptor charging time need 4hours)
3.Charging time for Switch Console: 3hours
Product Specification
Product name
Power Pack
Model No.:
IX-SW028
Production dimension
161*111*65mm
Packaging dimentison
142*142*40mm
weight
0.25Kg
Charging indicator
4 LED
Charging port
TYPE C
Capacity
7000 mAh Lithium polymer battery
Life
Charging to recycle ≥300times
input
5V 1.5A MAX
output
5V 2A MAX
Charging time
4hours（1.5A input）
Support to
Switch Console only
Protection circuit
Yes
Charging cable
USB A TO TYPE C L=50CM
