Dometic SeaLand 711-M28 User manual

1
This manual must be read and understood
before adjustment, maintenance, or service
is performed. Modication of this product
can result in property damage.
WARNING
!
SeaLand®
GRAVITY DISCHARGE TOILET
OWNER’S MANUAL
SeaLand®711-M28 Toilet
Dometic Sanitation Corporation
13128 State Rt 226, PO Box 38
Big Prairie, OH 44611
SeaLand Product Customer Service: 1-800-321-9886
(8:00 a.m. - 5:00 p.m. ET)

2
RECOMMENDATIONS
SPECIFICATIONS
Product Name: 711-M28 SeaLand Marine Toilet
Shipping Information:
Carton Sizes:
Toilet 21" x 18-1/2" x 13-1/2"
(533mm x 470mm x 343mm)
Tank 19-1/4" x 17-1/2" x 11-1/2"
(489mm x 445mm x 292mm)
Weight Approx. 49 lbs. (22Kg)
System:
Average water consumption per ush 1 Qt. (.95 L)
Minimum water consumption per ush1 Pt. (.47L)
Holding tank capacity . . . . . . . . . . .9.5 Gal. (36L)
Fresh water supply pressure . . . . . . . . . 5-80 PSI
Water inlet size . . . . . . . . . . . . . . . . . . . .1/2" NPT
Holding tank discharge tting . . . . . . . 1-1/2" NPT
Vent tting....................... 5/8"Barb
Unit Weight. . . . . . . . . . . . . . . . . . 41 Lbs. (19Kg)
Dimensions:
1. Read the “Operating Instructions” section of the
manual carefully.
2. Make sure all guests understand the operation of
the SeaLand toilet.
3. Carry a few spare parts for the maintenance pur-
poses. Dometic has developed several repair kits
that will save you both time and expense should a
problem occur. See “Customer Service” section of
this manual.
4. Use only SeaLand brand®Tissue and SeaLand®
brand Holding Tank Deodorants to maintain a
trouble-free system.
5. Do not use chlorine or caustic chemicals, such as
laundry bleach or drain opening types, in the
system. These products damage the seals in
toilets.
6. Do not ush foreign objects through the toilet.
7. Do not allow small problems to go unsolved. As
soon as a problem is detected, correct it.
INSTALLATION INSTRUCTIONS
Tank:
1. Select position in bathroom where unit can operate
properly. Allow room for using the ush lever and
clearance for raising the seat and lid.
2. Position the tank 3/4" (19mm) away from the wall.
Mark four holes at mounts on tank base. After holes
are marked, remove tank, and drill pilot holes. Slide
tank back into position. Secure the tank with four
#14 x 2" long pan head screws and washers on all
tank mounts.
3. Run 5/8" (16mm) I.D. hose to vent tting and secure
with hose clamps.
Install thru-hull vent tting:
(not supplied with unit – SeaLand part number 346368)
4. Drill hole through the hull, well above water line
and directly above SeaLand toilet. Hole location is
determined by routing and length of hose.
TABLE OF CONTENTS
Specications .........................2
Recommendations . . . . . . . . . . . . . . . . . . . . . 2
Installation Instructions . . . . . . . . . . . . . . . 2 - 4
Operating Instructions . . . . . . . . . . . . . . . . . . . 4
Maintenance....................... 4-5
Preparing for Summer Use . . . . . . . . . . . . . . . 5
Model Identication . . . . . . . . . . . . . . . . . . . . . 5
Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CustomerService......................5
Troubleshooting Guide . . . . . . . . . . . . . . . . . . 6
Warranty .............................8

3
12. Route hose from tank to deck tting and secure with
hose clamp.
Note: The holding tank on the 711-M28 is designed
to withstand discharge by a properly operating
discharge pump.
Toilet Installation:
13. Push button on back of ush pedal, then pull ush
pedal cover away from pedal to expose water valve.
Remove plastic pedestal cover from toilet base.
14. Install the (4) 1/4-20 x 1-3/4" long studs in inserts on
the tank top.
15. Place oor ange seal on studs, aligning the studs
with bumps on seat. Note: “THIS SIDE UP” should
face upwards.
16. Place toilet on studs and secure with four washers
and four nuts.
5. Apply waterproof caulk around underside of thru-hull
vent tting.
6. Install thru-hull vent tting and secure snugly with
nut. Wipe off excess caulk with damp cloth.
7. Attach remaining end of vent hose to thru-hull
tting with hose clamp.
Dockside Discharge Fitting:
(not supplied by SeaLand)
8. Drill hole in deck directly above SeaLand toilet. Hole
location is determined by routing space and length
of hose.
9. Screw 1-1/2" FPT x 1-1/2" hose barb into bottom of
deck tting.
10. Apply waterproof caulk around deck hole and install
deck tting into 2-1/4" (57mm) hole with screws. Wipe
off excess caulk with a damp cloth.
11. Install 1-1/2" MPT x HUB adapter into discharge
tting on holding tank.If necessary, PVC cement
elbow and hose adapter or hose adapter only into
1-1/2" (38mm) adapter. Secure 1-1/2" (38mm) hose
to adapter with hose clamp.
INSTALLATION INSTRUCTIONS (cont’d)
or

4
INSTALLATION INSTRUCTIONS (cont'd)
Water line:
17. Locate water valve at rear of ush lever.
18. Attach water supply pipe or hose from water system
to inlet tting on back of water valve.
Pedestal cover:
19. Slide back side of pedestal cover around rear of
toilet base and snap in groove. Close front half of
pedestal cover and snap in groove.
Flush pedal cover:
20. Put ush pedal cover back in place.
Seat and lid:
21. Remove seat and lid from package. Secure to china
bowl using instructions from mounting pack.
OPERATING INSTRUCTIONS
To properly use the SeaLand toilet, follow these simple
instructions:
1. A good biodegradable tissue such as SeaLand®brand
is recommended.
2. To add water to the toilet before using, lift or raise
the ush pedal.
3. To ush toilet, push pedal all the way down until
sewage leaves the toilet bowl. Water ow pressures
vary at different locations and therefore, holding the
ush lever down 4-8 seconds may be required. We
recommend 2-4 GPM (8-15 Lpm) for proper rim and
bowl wash.
4. Release ush pedal by allowing it to snap back, which
permits positive sealing around the ush ball.
5. A small amount of water should remain in the bowl.
Note: Holding the ush pedal down longer than neces-
sary results in excessive water usage.
CAUTION: Do not dispose of sanitary napkins or other
non-dissolving items in the toilet.
MAINTENANCE
CLEANING
The SeaLand toilet should be cleaned regularly for maxi-
mum sanitation and operational efciency.
Clean the toilet bowl with a mild bathroom cleaner,
such as SeaLand®Bowl and Seal Cleaner. Do not use
chlorine or alcohol-based caustic chemicals such as
drain opening types, as they will damage the seals.
If an odor is apparent from the toilet:
1. Clean out system by ushing several gallons of fresh
water through with one cup of liquid laundry soap.
2. Add odor control deodorant in amount specied for
your holding tank capacity after cleaning and every
few days during use.
WINTERIZING
At the end of each season, the SeaLand toilet should be
winterized for storage by either draining or using potable
water safe antifreeze in the system.
To drain:
1. Thoroughly ush system with fresh water.
2. Empty holding tank.
3. Shut off water supply to toilet. Remove inlet
waterline.
4. Press flush lever until all water is drained from
toilet.

5
Your SeaLand 711-M28 toilet is designed for years of
dependable trouble free service. However, during the life
of the product certain parts may require replacement.
The following is a list of parts kits which may be required
for maintenance purposes.
Part Number Description
385310681 Ball, Shaft & Cartridge Kit
385310677 Seal Kit
385314349 Water Valve Kit
385316906 Vacuum Breaker Kit
MODEL IDENTIFICATION
SPARE PARTS
The model identication label is located on the inside of
the ush pedal cover.
DOMETIC CORPORATION
P.O. BOX 38, 13128 STATE RT 226 [phone]
BIG PRAIRIE, OH 44611 USA
MODEL NO. 000
SERIAL NUMBER
000000
To use antifreeze:
1. Thoroughly ush system with fresh water.
2. Empty holding tank.
3. Drain potable water tank.
4. Add freshwater antifreeze and water mixture
through toilet and into the waste holding tank. Each
installation is different, so amounts may vary. User
discretion is required to assure adequate protection.
5. Empty holding tank.
Note: Use nontoxic antifreeze designated for potable
water systems (see boat owner’s manual).
CAUTION: Never use automotive-type antifreeze in
freshwater systems.
PREPARING FOR SUMMER USE
To prepare the SeaLand toilet for summer use, turn on
water supply and check system for leaks. Flush toilet,
check for leaks and repair as necessary. Your SeaLand
toilet is now ready for use.
MAINTENANCE (cont’d)
Dometic has a strong, worldwide network to assist in
servicing and maintaining your SeaLand toilet if parts
or service are required. Before calling, please have the
following information available. Your cooperation in hav-
ing this information ready is appreciated and allows our
Customer Service Department to better meet your needs.
When you call, we will direct you to the nearest parts
distributor.
1. Toilet Model Number
2. Serial Number
3. Part Number, Description and Quantity (See Parts
List.)
When you have gathered all the required information,
call us at one of the following telephone numbers from
8:00 a.m. to 5:00 p.m. (Eastern Time) Monday through
Friday, or email us.
Telephone: [phone] USA and Canada
330-496-3211 International
Fax: [phone] USA and Canada
330-496-3220 International
Email: [email protected]
CUSTOMER SERVICE
U.S.A. - Southeast
(AL, FL, GA, NC, PR, SC, TN, VI)
Environmental Marine
111 S.W. 23rd Street, Suite A
Fort Lauderdale, FL 33315
Tel: [phone]
800-522-2656
E-mail: [email protected]
U.S.A. - Southwest
(AZ, CO, NV, UT, CA-south)
Ardemco Marine Specialties
778 West 17th Street
Costa Mesa, CA 92627
Tel: [phone]
800-253-0115
E-mail: [email protected]
U.S.A. – Upper Midwest
(IA, MN, NE, ND, WI, SD)
PowerHouse Marine
518 Logan
La Crosse, WI 54603
Tel: [phone]
888-752-4539
E-mail: [email protected]
U.S.A. – Northern California
Fox Marine
6545 Caballero
Buena Park, CA 90620
Tel: [phone]
E-mail: foxmarco@pacicsupplyco.com
Canada - East
Eastern Marine Systems, Inc.
12-A Leslie Street
Toronto, Ontario M4M 3H7
Tel: [phone]
888-764-1111
E-mail: [e-mail]
Canada - West
Western Marine Company
1494 Powell Street
Vancouver, BC V5L 5B5
Tel: [phone]
800-663-0600
E-mail: [email protected]
MASTER SANITATION
DISTRIBUTORS –
NORTH AMERICA
U.S.A. – North Central
(IL, IN, KY, MI, OH)
Midwest Marine Supply
24300 Jefferson Ave.
St. Clair Shores, MI 48080
Tel: [phone]
800-860-1540
E-mail: [email protected]
U.S.A. - Northeast
(CT, DE, DC, MA, MD, ME, NH, NJ, NY, PA,
RI, VA, VT, WV)
Northeast Marine Sanitation
69 Florida Street
Farmingdale, NY 11735
Tel: [phone]
800-352-4323
E-mail: [email protected]
U.S.A. - Northwest
(AK, ID, MT, OR, WA, WY)
Marine Sanitation, Inc.
1900 N. Northlake Way, Suite 121
Seattle, WA 98103
Tel: [phone]
800-624-9111
E-mail: [email protected]
U.S.A. - South Central
(AR, KS, LA, MO, MS, NM, OK, TX)
AER Supply
P.O. Box 349
2301 Nasa Road #1
Seabrook, TX 77586
Tel: [phone]
800-767-7606
E-mail: [e-mail]

6
TROUBLESHOOTING GUIDE
1. Water will not stay in bowl.
2. Plastic ush ball will not
close completely.
3. Water does not shut off in
toilet (toilet overows).
4. Water does not enter toilet
bowl properly.
5. Water leaking from water
valve.
6. Water leaking from rear of
toilet bowl.
a. Tighten clamp ring adjusting nut.
b. Inspect ush ball and underside of
Teon seal for foreign objects.
Clean if necessary.
c. Replace seal.
d. Replace ush ball.
a. Loosen clamp ring.
b. Check spring tension by letting up
on ush lever suddenly. If lever
does not snap back, replace spring
cartridge.
a. Disassemble and clean water
valve.
b. Bend front of cam strap up about
1/16" (1.6mm).
c. Replace valve assembly.
d. Replace spring cartridge.
a. Check incoming water pressure.
b. Remove and clean lter screen
located on inlet of water valve.
a. Tighten bottom cap, inlet tting
and outlet hose clamp.
b. Replace water valve.
c. Insure that threads are not cross-
threaded and tighten.
d. Replace water valve.
e. Replace water valve.
f. Replace water valve.
a. Tighten hose connections.
b. Tighten vacuum breaker-to-bowl
connection.
c. Replace vacuum breaker
assembly.
d. Replace toilet bowl.
Problem Possible Cause Service Instructions
a. Loose clamp.
b. Improper seal around ush ball due
to dirt or debris on underside of
Teon®ball seal.
c. Worn or damaged seal.
d. Worn or damaged ush ball.
a. Clamp ring is overtightened,
causing too much tension on seal
and ush ball.
b. Weak or defective spring cartridge.
a. Dirt lodged in water valve seal.
b. Cam strap is bent down, holding
water valve open.
c. Worn or defective water valve.
d. Worn or defective spring cartridge.
a. Low water pressure.
b. Water valve clogged.
a. Loose connection.
b. Worn or defective water valve.
c. Water line connection not seated
properly.
d. Stripped threads.
e. Seal worn or missing.
f. Valve body cracked.
a. Loose hose connection.
b. Loose vacuum breaker.
c. Worn or defective vacuum breaker.
d. Cracked or defective toilet bowl.

7
This page is intentionally left blank.

8
MANUFACTURER’S TWO-YEAR AND TEN-YEAR LIMITED WARRANTY
Dometic Corporation warrants, to the original purchaser only, that this SeaLand®gravity discharge toilet, if used for
personal, family or household-like purposes, is free from defects in material and workmanship for a period of two (2)
years from the date of purchase.
Dometic also warrants, to the original purchaser only, that the ceramic portion of the toilet bowl will not discolor, stain,
scratch or craze for a period of ten (10) years if used for personal, family or household-like purposes, and is regularly
cleaned as described in the product’s owner’s manual.
If this Dometic product is placed in commercial or business use, it will be warranted, to the original purchaser only, to be
free of defects in material and workmanship for a period of ninety (90) days from the date of purchase.
Dometic reserves the right to replace or repair any part of this product that proves, upon inspection by Dometic, to be
defective in material or workmanship. All labor and transportation costs or charges incidental to warranty service are
to be borne by the purchaser-user.
EXCLUSIONS
IN NO EVENT SHALL DOMETIC BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, FOR DAMAGES
RESULTING FROM IMPROPER INSTALLATION, OR FOR DAMAGES CAUSED BY NEGLECT, ABUSE, ALTERA-
TION, OR USE OF UNAUTHORIZED COMPONENTS. THIS INCLUDES FAILURES WHICH MAY RESULT FROM NOT
FOLLOWING THE WINTERIZATION OR CLEANING PROCEDURE AS DESCRIBED IN THIS OWNER’S MANUAL.
ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR
ANY PARTICULAR PURPOSE, ARE LIMITED TO A PERIOD OF ONE (1) YEAR FROM DATE OF PURCHASE.
IMPLIED WARRANTIES
No person is authorized to change, add to, or create any warranty or obligation other than that set forth herein.
Implied warranties, including those of merchantability and tness for a particular purpose, are limited to one (1) year
from the date of purchase for products used for personal, family or household-like purposes, and ninety (90) days from
the date of purchase for products placed in commercial or business use.
OTHER RIGHTS
Some states do not allow limitations on the duration of an implied warranty, and some states do not allow exclusions
or limitations regarding incidental or consequential damages; so, the above limitations may not apply to you. This
warranty gives you specic legal rights, and you may have other rights which vary from state to state.
To obtain warranty service, rst contact your local dealer from whom you purchased this product.
® Registered; ™ Trademark of Dometic Corporation
® Teon is a registered trademark of DuPont Co.
© Dometic Corporation
600342689 7/06
Dometic is a customer driven, world-leading provider of innovative leisure
products for the caravan, motorhome and marine markets. Dometic offers
a complete range of air conditioners, refrigerators, awnings, cookers,
sanitation systems, lighting, windows, doors and other equipment that
makes leisure life more comfortable away from home.
Dometic also provides refrigerators for specic use in hotel rooms,
ofces and for storage of medical products and wine. Dometic’s products
are sold in almost 100 countries and are produced mainly in Dometic’s
own production facilities around the world. Dometic has more than
4,400 employees.
Dometic Sanitation Corporation
13128 State Rt 226, PO Box 38
Big Prairie, OH 44611
SeaLand Product Customer Service: 1-800-321-9886
(8:00 a.m. - 5:00 p.m. ET)
Email: [email protected]
www.DometicSanitation.com
