MAGNUM OPUS®
ALL-CHINA GRAVITY DISCHARGE TOILET
OWNER’S MANUAL
Dometic Corporation • Sanitation Systems
13128 State Rt 226, PO Box 38
Big Prairie, OH 44611
SeaLand Product Customer Service: 1-800-321-9886
(8:00 a.m. - 5:00 p.m. ET)
This manual must be read and under-
stood before installation, adjustment,
service, or maintenance is performed.
Modification of this product can
result in property damage.
WARNING
!
3000 Series Toilets

2
TABLE OF CONTENTS
Toilet Model Identification . . . . . . . . . . . . . . . . 2
Ordering Parts . . . . . . . . . . . . . . . . . . . . . . . . 2
Important Information Before Operation . . . . . . 3
Toilet Controls . . . . . . . . . . . . . . . . . . . . . . . . 3
Operating Instructions . . . . . . . . . . . . . . . . . . 4
Automatic Flush Operation Timing Chart . . . . 5
Proper Cleaning and Maintenance . . . . . . . . . 5
Winterizing . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Deodorants and Special Tissue . . . . . . . . . . . 6
Flush Mechanism Components . . . . . . . . . . . 7
Troubleshooting . . . . . . . . . . . . . . . . . . . . 8 – 9
Manual Flush Operation . . . . . . . . . . . . . . . . . 9
Electrical Troubleshooting . . . . . . . . . . 10 – 12
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . 12
Customer Service . . . . . . . . . . . . . . . . . . . . . 13
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . 14 – 15
Limited Warranties . . . . . . . . . . . . . . . . . . . . 16
ORDERING PARTS
Dometic is ready to assist you in the event service is required. Before calling, please have the following information
available. Your cooperation in having this information ready is appreciated and allows us to better meet your needs.
Please refer to the Parts Distributor list in the Customer Service section.
1. Toilet Model Number
2. Serial Number
3. Part Number, Description and Quantity (see Parts List)
Read and understand the complete contents of this manual before operating or servicing the
toilet. Failure to follow these precautions may result in damage to the toilet.
WARNING – ELECTRICAL SYSTEM.
Turn off electrical power before servicing.
WARNING – MOTOR STARTS AUTOMATICALLY.
Turn off electrical power before servicing.
TOILET MODEL IDENTIFICATION
DOMETIC CORPORATION
P.O. BOX 38, 13128 STATE RT 226 [phone]
BIG PRAIRIE, OH 44611 USA
MODEL NO. 000
SERIAL NUMBER
000000
The model identification label is located on the inside
wall of the toilet under the access cover. It will show the
model number and serial number.
Magnum Opus, SeaLand and Flush and Forget are registered trademarks of
Dometic Corporation.

3
IMPORTANT INFORMATION BEFORE OPERATION
1. Fill freshwater tank and add deodorant to holding tank through toilet bowl.
2. Make sure all guests understand the operation of the toilet system and the
flushing instruction label is easy for guests to read. This label is located
under the seat, and is easily read when the seat is raised.
3. Shut off the toilet system before servicing and do not leave the vehicle with
toilet system circuit breaker on.
4. Never use drain openers, alcohol, solvents, etc. in the toilet.
5. If the toilet does not function properly, refer to the Troubleshooting
section of this manual and repair as necessary. If problem persists, contact your local SeaLand product dealer or
see the Customer Service section of this manual.
1. To add water to the toilet before
using (if necessary), raise flush
handle until desired water level
is reached. (Water flow will stop
automatically after a pre-
programmed period of time).
2. To flush toilet, press flush
handle down. Water will flow
into bowl for two seconds, then
flush ball will open. Toilet will not
flush again until water refill cycle
is complete.
3. Do not dispose of sanitary
napkins or other non-dissolving
items in toilet, such as facial
tissue or paper towels. These
items can cause plugging of the
system.
FLUSH and FORGET®OPERATION
®
TOILET CONTROLS
ACCESS COVER
OFF
FLUSH
ADD WATER
TO BOWL
OFF
FLUSH HANDLE
CONTROL SWITCHES
Figure 1

4
1. Adding More Water To Toilet Bowl
Pull up the handle until the desired water level is attained. To prevent overflowing the toilet, a timer inside the
control module limits the amount of water that can be added.
2. Flushing The Toilet
Push the handle down for a moment, then release it. Holding the handle down will not prolong the flush cycle nor
start a new flush cycle. The lever must be allowed to return to the OFF position before another flush can occur.
3. Selecting Automatic Water Levels
The Water Level switch is located under the access cover. Carefully lift up on the front of the cover to access the
Water Level switch. There are three water refill levels available. The microprocessor-controlled water valve will
refill the toilet bowl according to your Water Level selection (see Figure 1, page 3).
To reinstall the access cover, set the cover on top of the toilet and press down. This will lock the cover in place and
prevent it from coming loose during rough travel.
LOW Level
Use this setting to conserve water. This level also may be desirable to reduce the chance of water splashing out
of the bowl during sudden stops and starts or when traveling. If more water is needed for flushing, lift up on the
flush handle. Water flow will stop after nine seconds to prevent overflow.
MID Level
Use this position to keep the toilet bowl clean, especially when family and friends may be using the toilet. If more
water is still needed for flushing, raising the flush lever will provide up to six seconds of additional water refill time.
HIGH Level
Use this position if the MID level does not provide a clean toilet bowl. This position is not recommended while the
vehicle is underway. If more water is still desirable for flushing, raising the flush handle will provide up to three
seconds of additional water refill time.
4. Mode Switch
The Mode switch is located on the right side of the printed circuit board. It lets you switch between three function
settings:
NORMAL
Use this setting for flushing the toilet.
SERVICE
Use this position for cleaning the toilet bowl and flush ball seal. The flush ball will open automatically and remain
open in this position. Lifting up the flush handle provides water.
MANUAL OVERRIDE
Use this position to flush the toilet manually in the event of power or battery failure. This switch disconnects the
electronic brake in the flush valve motor, and allows manual flushing via the override access hole in the side of the
vitreous china base.
Note: The control module allows 15 seconds of water for cleaning. If more water is required, return
the switch to the NORMAL position, then back to the SERVICE position.
A safety circuit in the control module monitors flush ball operation. If foreign objects or low voltage prevent the
flush ball from closing, this circuit prevents personal injury or damage to the flush valve motor. If this condition
occurs, reset the control module by placing the Mode switch into the SERVICE position temporarily, then
returning it to the NORMAL position.
OPERATING INSTRUCTIONS

5
AUTOMATIC FLUSH OPERATION TIMING CHART
The Magnum Opus toilet should be cleaned regularly for maximum sanitation and
operational efficiency. You can clean it just as you would a household toilet.
Do not use caustic chemicals, such as drain-opening types, as they will
damage the seals.
BOWL CLEANING: For stubborn stains, use SeaLand Bowl and Seal Cleaner
(Fig. A). It’s manufactured especially for use with our Magnum Opus toilets. In
certain locations where water is hard, a build-up of lime may dull the toilet bowl
finish. Restore the shine with this cleaner. If you cannot find our brand in your area,
contact SeaLand Product Customer Service for your nearest dealer. If it is not
available, you can also use Bar Keepers Friend®cleanser. It is not necessary to
vigorously scrub with either product. Please follow label instructions.
SEAL CLEANING: After an extended time, mineral deposits from hard water can
build up under the edge of the rubber bowl seal, resulting in a slow leakdown of
water from the bowl. To prevent this mineral build-up, periodically clean under the
bowl seal with SeaLand Bowl and Seal Cleaner (Fig. B).
1. Put Mode switch in SERVICE position. Flush ball will open automatically.
2. Apply cleanser onto the seal cleaning tool (supplied with new toilet), and scrub
under the seal. Make sure to push bristles between bottom of seal and top of
flush ball surface to scrub all parts of seal that come into contact with flush
ball.
3. Wait 2-3 minutes.
4. Pull up on flush handle to let water flow into bowl. Use cleaning tool and water to rinse away cleanser and loosened
deposits. You can add water for up to 15 seconds in the SERVICE position.
5. Put Mode switch in NORMAL position. Water will flow for a few seconds, then flush ball will close automatically.
Water will continue flowing into bowl, making it ready for the next flush.
PROPER CLEANING AND MAINTENANCE
Fig. A
Fig. B
Magnum Opus "Add Water" Time Limits
Magnum Opus Flush and Forget®Cycle Time
“Add Water” Time In Seconds
512841711613159143102160
Water Valve
Low Position
High Position
Service Position
Mid Position
Flush Cycle In Seconds
165128417116131591431020
Water Valve
Flush Valve
Low Refill
Mid Refill
High Refill
Opening Time
Held Open
Closing Time
Additional “Add Water” Time Allowance

6
WINTERIZING
At the end of each traveling season, the Magnum Opus toilet system must be winterized for storage. The following
procedure should be used:
1. Pump out waste holding tank.
2. Thoroughly flush toilet system with fresh water.
3. Drain freshwater tank.
4. Add freshwater antifreeze to freshwater tank.
5. Flush freshwater antifreeze and water mixture through toilet and into the waste holding tank. Each installation is
different so amounts may vary. User discretion is required to assure adequate protection.
6. Turn off electrical power.
CAUTION: The use of freshwater antifreeze that contains alcohol will result in damage to your sanitation
system. Only use propylene glycol freshwater antifreeze that does not contain alcohol.
DEODORANTS AND SPECIAL TISSUE
Your Magnum Opus toilet requires the regular addition of a deodorant product to reduce malodors and to help break
down holding tank contents. Several factors should be considered in selecting a deodorant product.
Liquid or Dry: Liquid products obviously work more quickly by readily going into solution. Granulated powder formu-
lations, on the other hand, have the advantage of requiring less storage space and are less likely to leak if the package
is inadvertently damaged.
Formaldehyde versus Non-Formaldehyde: Dometic manufactures both types of deodorants. Generally speaking,
formaldehyde formulas control odor very effectively at all temperatures and with all degrees of water hardness. SeaLand
Environment-Friendly brand, which is formaldehyde free, is similarly effective.
How Much Deodorant and How to Add It: The deodorant is added directly into the toilet bowl, then flushed into the
holding tank. Follow bottle or package instructions. Conditions of extremely warm weather, longer waste holding time
and larger tank capacities may require more deodorant treatment. Also, to maintain optimum efficiency in odor control,
the waste holding tank should be cleaned thoroughly at least once or more each season, depending on use.
Why Not Use Household Toilet Paper in Your Magnum Opus Toilet? Household tissues often contain adhesives
which bond together the paper fibers from which the tissue is made. The adhesives prevent the tissue from breaking
apart, and their use in “ultra-low flow” systems can cause system clogging. SeaLand tissue is especially designed for
use in low water toilet systems. Its rapid dissolving properties minimize the amount of residual paper in the holding tank
and allow deodorizers to work more efficiently.
SeaLand versus Other Brands: SeaLand constantly strives to provide our system owners with effective products that
have minimal environmental impact and good value. Many deodorant products do not measure up to our standards of
performance and value.
SPARE PARTS
It is recommended that the following spare parts be kept available at all times:
Flush Ball Seal Kit
Flush Ball
Description Part Number Quantity
see parts list
see parts list
1
1
Water Valve
Vacuum Breaker Assembly
Description Part Number Quantity
see parts list
see parts list
1
1
SeaLand®Granulated
Deodorant
Six 2-oz.
pouches
Part No.
379626002
SeaLand®
Rapid-
Dissolving
Toilet Tissue
Four 400-sheet
rolls
Part No.
379441204
SeaLand®Liquid
Deodorant
Two 8-oz. bottles
Part No. 379224008
SeaLand®Liquid
Deodorant -
Environment
Friendly
32-oz. bottle
Part No.
379114032

7
FLUSH MECHANISM COMPONENTS
Base Assembly
Cable
BASE ASSEMBLY COMPONENTS
(under china toilet)
Water Valve Flush Ball
Closed Limit
Switch
Motor
Drive Arm
Rotor Arm
Flush Valve
Motor
Flexible Water Supply Hose
Open Limit
Switch
Mode
Switch
Water
Level Switch
Power
Cable
CONTROL
MODULE
Input
for
Flush
Handle
Cable
Input for
Base Assembly Cable
1. To access
base assembly
components,
remove
decorative
screw caps
and unscrew
four bolts that
hold china
toilet to floor.
2. Remove access cover.
Lift up control module.
Disconnect power cable
from control module.
Do not disconnect flush
handle cable or base
assembly cable.
3. Lift china toilet
straight up and set
it down close to
front of floor flange/
adapter assembly.
Turn off water to
toilet and discon-
nect flexible water
line at rear of base
assembly. The
toilet is completely
disconnected.
Flush
Switch
Flush
Handle
Cable
FLUSH HANDLE COMPONENTS
(under Access Cover)
Flush
Handle

8
TROUBLESHOOTING
1. Toilet emits odor (flush ball
open).
2. Water will not stay in bowl.
3. Water leaks onto floor.
4. Toilet will not flush and water
will not enter bowl.
5. Flush ball will not open, but
water enters toilet bowl.
6. Flush ball will not close.
7. Water will not enter bowl in
any Water Level setting
and when the flush handle
is raised to add water.
8. Water does not enter toilet
bowl properly.
a. Odor emitting from base of toilet.
b. Plugged holding tank vent line.
a. Dirt or debris on underside of flush
ball seal.
b. Worn or damaged flush ball
and seal.
a. Toilet loose.
b. Defective component under china
bowl: vacuum breaker assembly,
water hose/fittings, water valve
assembly, upper bowl seal, base
O-ring, rotor shaft, or plastic base.
c. Worn or defective floor flange seal.
d. Cracked china bowl.
a. Fuse is blown.
b. Loose electrical connections.
c. Defective Flush Switch.
a. Defective Flush Switch, limit switches
or loose connections.
b. Toilet bowl and base are
misaligned, causing drive arm to
contact inside wall of bowl.
a. Mode Switch is in "Service" position.
b. Safety circuit locked flush ball in open
position.
c. Closed or Open Limit Switch out of
adjustment or defective.
a. Loose electrical connections,
defective Water Valve or Control
Module.
b. No water pressure to toilet.
c. Water Valve filter screen is
clogged.
a. Insufficient water flow rate at toilet.
b. Water Valve clogged.
c. Plugged rim wash holes in toilet.
a. Use SeaLand brand deodorants.
b. Clear obstructions from vent line.
a. Put Mode Switch in "Service"
position and clean underside of
flush ball seal.
b. Remove toilet from floor,
disassemble bowl from base, and
replace flush ball and seal.
a. Tighten toilet mounting bolts.
b. Remove floor bolts and turn toilet
to one side as much as possible,
keeping telescoping base in floor
flange adapter. Flush toilet to find
source of leak. Tighten loose
connections or replace defective
component.
c. Replace seal.
d. Replace china toilet.
a. Replace fuse typically located in
fuse panel.
b. See Electrical Troubleshooting
section.
c. See Electrical Troubleshooting
section.
a. See Electrical Troubleshooting
section.
b. Adjust base-to-toilet bowl connec-
tion to eliminate interference.
a. Return Mode Switch to "Normal"
position.
b. Reset Control Module by putting
the Mode Switch in the "Service"
position for 3 seconds, then return
to "Normal" position.
c. See Electrical Troubleshooting
section.
a. See Electrical Troubleshooting
section.
b. Repair water system.
c. Remove water line from Water
Valve inlet and clean debris from
filter screen.
a. Check water flow rate at toilet.
Rate should be 2 gpm (7.6 lpm) at
toilet.
b. Remove and clean screen located
inlet of Water Valve.
c. Clean holes. If still a problem,
replace the toilet bowl.
Problem Possible Cause Service Instructions
Important: Always turn off electrical power and water to the toilet for disassembly.

9
TROUBLESHOOTING (cont’d)
9. Water leaking from Water
Valve.
10. Water will not enter toilet bowl
when the Flush Handle is
raised to add water.
11. Water Level Switch has no
effect on water level in low or
high positions.
12. Water will not shut off –
toilet overflows.
13. Flush ball will not open with
Mode Switch in "Service"
position.
a. Water Valve body cracked due to
freeze damage.
b. Water line connection is loose or
not seated properly.
c. Defective Water Valve.
d. Stripped threads.
a. Loose electrical connections or
defective Flush Switch.
a. Defective Water Level Switch or
Control Module.
a. Dirt or debris lodged in Water Valve
seal.
b. Defective Water Valve.
c. Defective Control Module.
a. Defective Mode Switch or Control
Module.
a. Replace Water Valve.
b. Insure that threads are not
cross-threaded and tighten.
c. Replace Water Valve.
d. Replace Water Valve.
a. See Electrical Troubleshooting
section.
a. Replace Control Module.
a. Disassemble and clean Water
Valve.
b. Replace Water Valve.
c. Replace Control Module.
a. Replace Control Module.
Problem Possible Cause Service Instructions
MANUAL FLUSH OPERATION
In the event of an electrical failure, the flush ball of the toilet can be manually opened to clear the bowl. We recommend
using a long-neck screwdriver or 7/16-in. socket for the operation shown below. NEVER PRY OPEN THE FLUSH BALL
FROM INSIDE THE TOILET BOWL. Damage to the flush ball and bowl seals may result.
1. Remove access cover from top of china toilet. Place
Mode Switch in the "Manual Override" position. This
disconnects flush valve motor brake from electrical
circuit.
2. Locate hole on side of china toilet. This allows access
to the flush valve motor drive arm.
3. Insert screwdriver or 7/16-in. socket through access
hole and onto hex head.
4. Turn screwdriver or socket counter-clockwise. This
will open flush ball and allow bowl contents to clear.
After bowl is clear, turn screwdriver or socket clockwise
to return flush ball to original position.
NOTES:
Water will not enter the toilet bowl during manual flush
operation.
Place Mode Switch in the "Normal" position before
returning to automatic operation.
Manual Override
position

10
ELECTRICAL TROUBLESHOOTING
A volt/ohmmeter (VOM) and the Magnum Opus Wiring schematic (page 12) may be required for this section.
Caution: Portions of this section will require that power be applied to the toilet. Keep hands away from
the flush ball, motor drive arm and rotor shaft to prevent personal injury during testing and troubleshooting.
The Magnum Opus control module uses a microprocessor to provide all the automatic and timing functions. The control
module is on the right side under the access cover on the top of the toilet. The control module has input and output
status lights that can be used in troubleshooting the toilet. The program inside the microprocessor is used for both
gravity discharge and vacuum-operated toilets.
The program in the microprocessor monitors the input and output signals during a normal flush cycle. If the inputs or
outputs do not follow the commands of the program, then the microprocessor may go into a "standby" mode and flash
an "error" code. The microprocessor is reset by placing the Mode switch in the "Service" position temporarily, then
returning the switch to the "Normal" position.
CONTROL MODULE STATUS LIGHTS
Status Light
1 Low Level
2 High Level
3 Valve Closed
4 Valve Open
5 Service Mode
6 Flush
7 Add Water
8 High Vac Switch
9 Holding Tank Full
10 OK to Flush
11 Do Not Flush
12 Water Valve
13 +5V
Function
Water Level Switch in "Low" position.
Water Level Switch in "High" position.
Flush valve Closed Limit Switch engaged.
Flush valve Open Limit Switch engaged.
Mode Switch in "Service" position.
Flush Handle in "Flush" position.
Flush Handle in "Add Water" position.
Always on (vacuum toilet only).
Always off (vacuum toilet only).
On when not in flush cycle.
On during flush cycle. Also provides error codes.
Electric water valve energized.
Input power
Color
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
VALVE CLOSED
VALVE OPEN
SERVICE MODE
FLUSH
ADD WATER
HI VAC SWITCH
HOLD TANK FULL
OK TO FLUSH
DO NOT FLUSH
HI LEVEL
LO LEVEL
WATER VALVE
+5V
LED 13 LED 12 LED 11 LED 10 LED 9 LED 8 LED 7 LED 6 LED 5 LED 4 LED 3 LED 2 LED 1
Status Light
10 OK to Flush
11 Do Not Flush
11 Do Not Flush
11 Do Not Flush
ERROR CODES
Condition
Mode Switch in SERVICE position
VALVE OPEN Limit Switch problem
VALVE CLOSED Limit Switch problem
Flush valve motor relay failure
No. of Flashes
1
1
2
4
Pause
.5 sec.
2 sec.
2 sec.
2 sec.

11
Symptom: Toilet will not flush and water will not enter toilet bowl.
• LED 13 (+5V) off :
Check toilet fuse or circuit breaker.
Check for loose or defective wiring between Control Module and DC power source.
Check for reverse polarity.
If all of above check OK, replace Control Module.
• LED 13 on:
Input voltage must be 10V DC or higher.
Check for error codes at LED 10 and LED 11. If showing error, reset Control Module using Mode
Switch. If not showing error or Control Module does not reset, go to next step.
• Check following status lights on Control Module:
LED 3 (Valve Closed): If not on, Closed Limit Switch is out of alignment or defective, or related wiring is
defective.
LED 9 (Hold Tank Full): If on, replace Control Module.
• Push Flush Handle down (in "Flush" position) – status light LED 6 (Flush) must light up. Then, release Flush
Handle, and status light LED 6 should turn off.
If LED 6 did not follow the commands of the Flush Handle, the Flush Switch or related wiring is
defective.
If LED 6 did follow the commands of the Flush Handle, go to the next step.
Symptom: Flush Ball will not close.
• Mode Switch in "Service" position. Return the switch to the "Normal" position.
• Foreign object prevented the Flush Ball from closing and safety circuit locked the Flush Ball in the open position.
Reset the Control Module by putting the Mode Switch in the "Service" position temporarily, then set in "Normal"
position. The Flush Ball should close after 2 seconds. If Flush Ball does not close, go to next step.
• Check for error code at LED 11 (Do Not Flush). If showing error, the Closed or Open Limit Switch is out of adjustment
or defective, or related wiring is loose or defective.
Symptom: Water will not enter the toilet bowl during a flush or when the Flush Handle is lifted.
• Place the Water Level Switch in "Low" position and flush toilet. Check status light LED 12 (Water Valve) while
lifting up the Flush Handle to add water.
If LED 12 comes on, the Water Valve filter screen may be plugged with debris, or the Water Valve and/
or its related wiring is defective.
If LED 12 remains off, replace the Control Module.
ELECTRICAL TROUBLESHOOTING (cont’d)
Condition
Mode Switch in SERVICE position.
Valve Open Limit Switch problem.
Valve Closed Limit Switch problem.
Flush valve motor relay failure.
Corrective Action
Return Mode Switch to NORMAL position.
With the flush valve fully open, check the “VALVE OPEN” status light. If
the light is off, then the Valve Open Limit Switch is out of alignment or
defective, or related wiring is defective.
With flush valve in the fully closed position check the “VALVE CLOSED”
status light. If the light is off, then the Valve Closed Limit Switch is out of
alignment or defective, or related wiring is defective.
Replace control module.
ERROR CODE CORRECTIVE PROCEDURES
TOILET OPERATION CORRECTIVE PROCEDURES

12
WIRING DIAGRAM
ELECTRICAL TROUBLESHOOTING (cont’d)
TOILET OPERATION CORRECTIVE PROCEDURES (cont’d)
Symptom: Water will not enter the bowl when the Flush Handle is raised to add water.
• Place the Water Level Switch in "Low" position and flush toilet. Check status light LED 7 (Add Water) while
lifting up the Flush Handle.
If LED 7 comes on, replace the Control Module.
If LED 7 remains off, the Flush Switch or its related wiring is defective.
Symptom: Water Level Switch has no effect on water level in "Low" or "High" position.
• Replace the Control Module.
Symptom: Flush Ball will not open when Mode Switch is in the "Service" position.
• Replace the Control Module.

13
CUSTOMER SERVICE
There is a strong, worldwide network to assist in servicing and
maintaining your sanitation system. For the Authorized Service
Center near you, please call from 8:00 a.m. to 5:00 p.m. (ET)
Monday through Friday. You may also write us at Dometic Corp.,
P.O. Box 38, Big Prairie Ohio 44611.
Telephone: [phone] U.S.A. and Canada
330-496-3211 International
You may also contact or have your local dealer contact the Parts
Distributor nearest you for quick response to your replacement
parts needs. They carry a complete inventory for the SeaLand
product line.
Fax: [phone] U.S.A. and Canada
330-496-3220 International
U.S.A.
MASTER SANITATION
DISTRIBUTORS
U.S.A. – North Central
(IL, IN, KY, MI, OH)
Midwest Marine Supply
24300 Jefferson Ave.
St. Clair Shores, MI 48080
Tel: [phone]
800-860-1540
Fax: [phone]
E-mail: [email protected]
Contact: Bob Kennedy
U.S.A. - Northeast
(CT, DE, DC, MA, MD, ME, NH, NJ, NY,
PA, RI, VA, VT, WV)
Northeast Marine Sanitation
69 Florida Street
Farmingdale, NY 11735
Tel: [phone]
800-352-4323
Fax: [phone]
888-283-7606
E-mail: [email protected]
Contact: Mike Starito
U.S.A. - Northwest
(AK, ID, MT, OR, WA, WY)
Marine Sanitation, Inc.
1900N.Northlake Way,Suite121
Seattle, WA 98103
Tel: [phone]
800-624-9111
Fax: [phone]
E-mail: [email protected]
Contact: Ric Kolb
U.S.A. - South Central
(AR, KS, LA, MO, MS, NM, OK, TX)
AER Supply
P.O. Box 349
2301 Nasa Road #1
Seabrook, TX 77586
Tel: [phone]
800-767-7606
Fax: [phone]
E-mail: [e-mail]
Contact: Richard Miller
U.S.A. - Southeast
(AL, FL, GA, NC, PR, SC, TN, VI)
Environmental Marine
111 S.W. 23rd Street, SuiteA
Fort Lauderdale, FL 33315
Tel: [phone]
800-522-2656
Fax: [phone]
E-mail: [email protected]
Contact: John or Jill Hopkins
U.S.A. - Southwest
(AZ, CO, NV, UT, CA-south)
Ardemco Marine Specialties
778 West 17th Street
Costa Mesa, CA 92627
Tel: [phone]
800-253-0115
Fax: [phone]
E-mail: [email protected]
Contact: Rick Glasser
U.S.A. – Upper Midwest
(IA, MN, NE, ND, SD, WI)
PowerHouse Marine
518 Logan
La Crosse, WI 54603
Tel: [phone]
888-752-4539
Fax: [phone]
E-mail: [email protected]
Contact: Dave Tucker
U.S.A. – Northern California
Fox Marine
2250 Zanker Road, Unit D
San Jose, CA 95131
Tel: [phone]
800-826-2873
E-mail: [email protected]
Contact: Charlie Barker
CANADA
MASTER SANITATION
DISTRIBUTORS
Canada - East
Eastern Marine Systems, Inc.
12-A Leslie Street
Toronto, Ontario M4M 3H7
Tel: [phone]
888-764-1111
Fax: [phone]
E-mail: [e-mail]
Contact: Paul Gales
Canada - West
Western Marine Company
1494 Powell Street
Vancouver, BC V5L 5B5
Tel: [phone]
800-663-0600
Fax: [phone]
800-663-6790
E-mail: [email protected]
Contact: Bill Falk
INTERNATIONAL
SEALAND SANITATION SYSTEM
DISTRIBUTORS
Call 1-800-321-9886, email us at
[email protected], or visit
www.dometic.com for the distributor
nearest you.

14
NOTES

15
NOTES

16
Dometic Corporation warrants, to the original purchaser only, that this Magnum Opus®gravity discharge toilet, if used for
personal, family or household-like purposes, is free from defects in material and workmanship for a period of three (3)
years from the date of purchase.
Dometic also warrants, to the original purchaser only, that the vitreous china toilet bowl will not discolor, stain, scratch
or craze for a period of ten (10) years if used for personal, family or household-like purposes, and is regularly cleaned as
described in the product’s owner’s manual.
If this Dometic product is placed in commercial or business use, it will be warranted, to the original purchaser only, to be
free of defects in material and workmanship for a period of ninety (90) days from the date of purchase.
Dometic reserves the right to replace or repair any part of this product that proves, upon inspection by Dometic, to be
defective in material or workmanship. All labor and transportation costs or charges incidental to warranty service are to
be borne by the purchaser-user.
EXCLUSIONS
IN NO EVENT SHALL DOMETIC BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, FOR DAMAGES
RESULTING FROM IMPROPER INSTALLATION, OR FOR DAMAGES CAUSED BY NEGLECT,ABUSE, ALTERATION,
OR USE OF UNAUTHORIZED COMPONENTS. THIS INCLUDES FAILURES WHICH MAY RESULT FROM NOT
FOLLOWING THE WINTERIZATION OR CLEANING PROCEDURES AS DESCRIBED IN THIS MANUAL. ALL IMPLIED
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE, ARE LIMITED TO A PERIOD OF ONE (1) YEAR FROM DATE OF PURCHASE.
IMPLIED WARRANTIES
No person is authorized to change, add to, or create any warranty or obligation other than that set forth herein.
Implied warranties, including those of merchantability and fitness for a particular purpose, are limited to one (1) year from
the date of purchase for products used for personal, family or household-like purposes, and ninety (90) days from the
date of purchase for products placed in commercial or business use.
OTHER RIGHTS
Some states do not allow limitations on the duration of an implied warranty, and some states do not allow exclusions
or limitations regarding incidental or consequential damages; so, the above limitations may not apply to you. This
warranty gives you specific legal rights, and you may have other rights which vary from state to state.
To obtain warranty service, first contact your local dealer from whom you purchased this product.
MANUFACTURER’S THREE-YEAR AND TEN-YEAR LIMITED WARRANTIES
® Registered; ™ Trademark of Dometic Corporation
® Bar Keepers Friend is a registered trademark of SerVaas Laboratories.
© 2004 Dometic Corporation
Dometic Corporation • Sanitation Systems
13128 State Rt 226, PO Box 38
Big Prairie, OH 44611
SeaLand Product Customer Service: 1-800-321-9886
(8:00 a.m. - 5:00 p.m. ET)
600344233 1/04
