Dometic POWER AWNING PRO User manual

AWNINGS
POWER AWNING PRO
Form No. 3317636.000 09/20 | ©2020 Dometic Corporation
WARNING
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
Model # 3317114
EN Wireless Receiver
Installation Manual.....................2

2EN
Contents Wireless Receiver
1 Explanation of Symbols and Safety
Instructions ............................ 2
1.1 Recognize Safety Information .............2
1.2 Understand Signal Words................2
1.3 Supplemental Directives .................2
1.4 General Safety Messages ................3
2 Intended Use ........................... 3
3 General Information ..................... 3
3.1 Compatibility ..........................3
3.2 Recommended Tools ...................3
3.3 Specifications .........................4
3.4 Receiver Control Range .................4
4 Wiring Diagram......................... 4
5 Installation ............................. 4
6 Pairing the Remote Control ............... 5
6.1 Pairing the 9200 and 9500 Remote Control . 5
6.2 Pairing the 9100 Power Awning Remote
Control...............................5
6.3 Verifying the Remote Control .............6
7 Pairing the Wind Sensor.................. 6
8 Vehicle Ignition Lock-out ................. 7
9 Troubleshooting ........................ 7
10 Disposal ............................... 7
11 Limited Warranty ....................... 7
Contents
Service Center & Dealer Locations
Visit: www.dometic.com/support
Read these instructions carefully. These instructions
MUST stay with this product.
1 Explanation of Symbols and
Safety Instructions
This manual has safety information and instructions to
help you eliminate or reduce the risk of accidents and
injuries.
1.1 Recognize Safety Information
This is the safety alert symbol. It is used to alert
you to potential physical injury hazards. Obey all
safety messages that follow this symbol to avoid
possible injury or death.
1.2 Understand Signal Words
A signal word will identify safety messages and property
damage messages, and also will indicate the degree or
level of hazard seriousness.
DANGER!
Indicates a hazardous situation that, if not avoided,
will result in death or serious injury.
WARNING
Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
CAUTION
Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
NOTICE: Used to address practices not related to
physical injury.
IIndicates additional information that is not related
to physical injury.
1.3 Supplemental Directives
To reduce the risk of accidents and injuries, please
observe the following directives before proceeding to
install this product:
• Read and follow all safety information and
instructions.
• Read and understand these instructions before
installing this product.

3
EN
Wireless Receiver Intended Use
• The installation must comply with all applicable local
or national codes, including the latest edition of the
following standards:
U.S.A.
– ANSI/NFPA70, National Electrical Code (NEC)
– ANSI/NFPA 1192, Recreational Vehicles Code
– ANSI Z21.57, Recreational Vehicles Code
Canada
– CSA C22.1, Parts l & ll, Canadian Electrical Code
– CSA Z240 RV Series, Recreational Vehicles
1.4 General Safety Messages
WARNING: IMPACT OR CRUSH HAZARD.
Failure to obey the following warnings could
result in death or serious injury:
• This product should be installed in a controlled
environment (inside). Do not install product during
windy conditions, or when wind is expected.
Otherwise, product could move unpredictably,
become unstable, and could detach, bend, or
collapse.
• Make sure the awning retract button and the awning
extend button operate the awning in the intended
direction.
• Keep your hands, arms, head or torso clear of the
awning hardware during periods of rain, wind, etc.
These conditions may cause the wind sensor to
unexpectedly activate and retract the awning.
WARNING: FIRE OR ELECTRICAL SHOCK
HAZARD. Failure to obey the following
warnings could result in death or serious
injury:
• For all wire connections, use only NEC-approved
connectors and terminals that are appropriately sized
for the wire gauge.
• Disconnect 120 VAC power from RV. Failure to do so
could result in death or serious injury.
2 Intended Use
The Wireless Receiver is intended for use in recreational
vehicles. Pair devices with the receiver to allow
communication between the device and the awning.
The manufacturer accepts no liability for damage in the
following cases:
• Faulty assembly or connection
• Damage to the product resulting from mechanical
influences and excess voltage
• Alterations to the product without express permission
from the manufacturer
• Use for purposes other than those described in the
operating manual
Dometic Corporation reserves the right to modify
appearances and specifications without notice.
3 General Information
This section describes the awning series compatibility
and the recommended tools to install the wireless
receiver.
IThe images used in this document are for reference
purposes only. Components and component
locations may vary according to specific product
models. Measurements may vary ±0.38 in. (10 mm).
3.1 Compatibility
The wireless receiver is compatible with the following
power awning pro series:
• 9100
• 9200
• 9500
3.2 Recommended Tools
The following are the recommended tools for
installation:
Recommended Tools
Phillips Screwdriver Flat-Blade Screwdriver

4EN
Wiring Diagram Wireless Receiver
3.3 Specifications
The following are the technical specifications for the
wireless receiver.
Voltage 12 V
Emission Frequency 433.92 MHz
Maximum Power Load for Motor 180 W
Maximum Power Load for Light 30 W
3.4 Receiver Control Range
For the awning remote control to communicate with
the wireless receiver, it must be within the specified
transmission distance.
IEffective transmitting distance may be affected by
actual environment.
q
w
1 Remote Control Transmission Distances
qUnobstructed
656  (200 m)
wConcrete Obstruction
115  (35 m)
4 Wiring Diagram
q
u
y
t
r
e
w
2 Wiring Diagram
qPower+ (Red) tLED+ (Red)
wPower- (Black) yLED- (White)
eMotor (Brown) uIgnition (Orange)
rMotor (Blue)
5 Installation
Follow the steps in this section to install the wireless
receiver.
IThe receiver shall be installed inside the
recreational vehicle.
1. Determine the receiver location inside the
recreational vehicle and secure the receiver to the
wall or cabinet using the installer supplied screws.
w
q
3 Installing the Receiver
qReceiver wWiring
2. Route the wiring. Make the electrical connections
according to the “Wiring Diagram” on page 4.

5
EN
Wireless Receiver Pairing the Remote Control
6 Pairing the Remote Control
The power awning remote control must be paired with
the receiver to communicate. The pairing steps may vary
depending on the awning model. Follow the pairing
instructions for your awning model.
6.1 Pairing the 9200 and 9500
Remote Control
Follow the steps below for the 9200 and 9500 awning
series only.
IComplete each pairing step within four seconds
of the previous step to keep the receiver in pairing
mode. If the receiver resets, restart the pairing
process.
Step Operation Audible
Alert
Awning
Movement
1
Remove battery
cover from back of
remote
None None
2
Turn the receiver
Power button ON
Beep x1
None
3
Press Le P2
button two times
Beep x2
None
4
Press Up1button
one time
Beep x4 Awning jogs
5 Proceed immediately to “Verifying the Remote
Control” on page 6.
1 For the 9500 power awning, press the Down button at step 4
instead of the Up button.
6.2 Pairing the 9100 Power Awning
Remote Control
Follow the steps below for the 9100 awning series only.
IComplete each pairing step within four seconds
of the previous step to keep the receiver in pairing
mode. If the receiver resets, restart the pairing
process.
Step Operation Audible
Alert
Awning
Movement
1
Remove battery
cover from back of
remote
None None
2
Turn the receiver
Power button ON
Beep x1
None
3
Press Le P2
button two times Beep x2
None
4
Press Up button
one time
Beep x4 Awning jogs
5
Press Le P2
button one time Beep x1 Awning jogs
6
Press Up button
one time
Beep x1
None

6EN
Pairing the Wind Sensor Wireless Receiver
Step Operation Audible
Alert
Awning
Movement
7
Press Down button
one time
None None
8
Press the Le P2
button one time Beep x1 Awning jogs
9 Proceed immediately to “Verifying the Remote
Control” on page 6.
6.3 Verifying the Remote Control
Aer pairing the remote control and the receiver, verify
remote control functionality by doing the following:
1. Press the Down button. The awning should extend.
2. Press the Up button. The awning should retract.
– If either button does not perform as expected,
see“Pairing the Remote Control” on page 5
and restart the pairing process.
3. Upon successful verification, proceed to “Pairing the
Wind Sensor” on page 6 (if applicable).
7 Pairing the Wind Sensor
NOTICE: Do not rely on the wind sensor to prevent
damage to the awning. The awning should always be
closed when unattended or when strong rain, wind, etc.
is expected.
The wind sensor is a key component to protect your
awning from the wind. This section describes how to
pair the wind sensor to the receiver and program the
sensitivity level. The information below applies to all
compatible power awning pro models.
IComplete each pairing step within four seconds
of the previous step to keep the receiver in pairing
mode. If the receiver resets, restart the pairing
process.
Step Operation Audible
Alert
Awning
Movement
1
Remove the front
cover of the Wind
Sensor
None None
2
Set Sensor Dial
to 0
None None
3
Press Remote Le
P2 button one time Beep x1 Awning jogs
4
Press Remote Le
P2 button one time
None None
5
Press Sensor
Programming
button one time
Sensor
Beep x1
Receiver
Beep x5
Awning jogs
6
Set Sensor Dial
to 5
None None
7
Press Sensor
Programming
button one time
Sensor Beep
x1
Awning
retracts
8
Set Sensor Dial to
desired level
None None

7
EN
Wireless Receiver Vehicle Ignition Lock-out
Once programmed, the sensitivity can be adjusted at
any time without reprogramming. The sensitivity of the
wind sensor can be set from 1 (most sensitive) to 9 (least
sensitive). Settings 0 and 5 are for programming only
and are not active settings.
IFor safety purposes, the wind sensor sends a
signal to the receiver every 60 minutes to confirm
functionality. If for any reason (removal, low battery,
etc.) the signal is not received aer 60 minutes, the
awning will retract automatically.
8 Vehicle Ignition Lock-out
When the vehicle ignition is in the ACC, ON, or START
position, the receiver has the ability to retract/lock/cut
power to the awning.
When the vehicle ignition is in the OFF position, the
awning is unlocked and will operate normally.
START
OFF OFF
ACC
ON
START
ACC
ON
q
w
4 Vehicle Ignition Lock-out
qIgnition ON wIgnition OFF
9 Troubleshooting
Problem Possible Cause Recommended
Solution
Unable to pair the
remote control or
wind sensor
The receiver
has reset before
initiating the next
step in the pairing
process.
Restart the pairing
process and
complete each
step within four
seconds of the
previous step.
Wind sensor
keeps beeping;
awning
automatically
retracts every 30
minutes
The wind sensor
battery may be
low. (The receiver
will retract the
awning every 30
minutes to protect
the awning.)
Replace the wind
sensor battery.
Awning
automatically
retracts every 60
minutes
The wind sensor
is out of place.
(The receiver will
retract the awning
every 60 minutes
to protect the
awning.)
Locate the wind
sensor and put it
back in place.
10 Disposal
MPlace the packaging material in the appropriate
recycling waste bins, whenever possible. Consult
a local recycling center or specialist dealer for
details about how to dispose of the product in
accordance with all applicable national and local
regulations.
11 LIMITED WARRANTY
LIMITED WARRANTY AVAILABLE AT
WWW.DOMETIC.COM/WARRANTY.
IF YOU HAVE QUESTIONS, OR TO OBTAIN A COPY
OF THE LIMITED WARRANTY FREE OF CHARGE,
CONTACT:
DOMETIC CORPORATION
CUSTOMER SUPPORT CENTER
5155 VERDANT DRIVE
ELKHART, INDIANA 46516
1-800-544-4881 OPT 1

Mobile living made easy.
dometic.com
YOUR LOCAL
DEALER
dometic.com/dealer
YOUR LOCAL
SUPPORT
dometic.com/contact
YOUR LOCAL
SALES OFFICE
dometic.com/sales-offices
