Dometic 5 Series User manual

RM5310, RM5330, RM5380
Absorber refrigerator
Installation Manual. . . . . . . . . . . . . . . . . . . . 15
Absorber-Kühlschrank
Montageanleitung. . . . . . . . . . . . . . . . . . . .30
Réfrigérateur à absorption
Instructions de montage . . . . . . . . . . . . . . .45
Absorptiekoelkast
Montagehandleiding . . . . . . . . . . . . . . . . .60
EN
DE
FR
NL
REFRIGERATION
5 SERIES
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 1 Dienstag, 30. März 2021 10:54 10

© 2021 Dometic Group. The visual appearance of the contents of this manual is
protected by copyright and design law. The underlying technical design and the
products contained herein may be protected by design, patent or be patent
pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.
All rights are reserved.
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 2 Dienstag, 30. März 2021 10:54 10

RM5310, RM5330, RM5380
3
486 mm 474 mm
618 mm
486 mm
821 mm
474 mm
486 mm
821 mm
474 mm
118 mm
216 mm218 mm
RM 5310
RM 5330
RM 5380
1
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 3 Dienstag, 30. März 2021 10:54 10

RM5310, RM5330, RM5380
4
> 660 mm
> 660 mm
> 660 mm
3
5
4
RM 5310 RM 5330
5
5
4
4
RM 5380
3
3
2
2
1
1
2
1
2
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 4 Dienstag, 30. März 2021 10:54 10

RM5310, RM5330, RM5380
5
15 – 25 mm
> 25 mm > 25 mm
3
1
4
5
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 5 Dienstag, 30. März 2021 10:54 10

RM5310, RM5330, RM5380
6
1
4
3
2
6
1
32
7
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 6 Dienstag, 30. März 2021 10:54 10

RM5310, RM5330, RM5380
7
1.
2.
AB
CD
8
9
≥15 mm 1
2
3
4
5
678910
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 7 Dienstag, 30. März 2021 10:54 10

RM5310, RM5330, RM5380
8
0
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 8 Dienstag, 30. März 2021 10:54 10

RM5310, RM5330, RM5380
9
A B
CD
EF
GH
IJ
1.
1.
2.
2.
a
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 9 Dienstag, 30. März 2021 10:54 10

RM5310, RM5330, RM5380
10
A B
DC
FE
GH
IJ
1.
2.
1.
2.
2.
1.
3.
3.
3.
b
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 10 Dienstag, 30. März 2021 10:54 10

RM5310, RM5330, RM5380
11
AB
C
2.
1.
c
SW 17
SW 14
d
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 11 Dienstag, 30. März 2021 10:54 10

RM5310, RM5330, RM5380
12
bl br ge gn rt sw
EN Blue Brown Yellow Green Red Black
DE Blau Braun Gelb Grün Rot Schwarz
FR Bleu Marron Jaune Vert Rouge Noir
NL Blauw Bruin Geel Groen Rood Zwart
1
2
34
8
10
10
12
13
13
13
NL
G
ge/gn
ge/gn
V85
bl
bl
1a
1b
3a
3b
5a
5b
2b
2a
4b
4a
6b
6a
br
–+
br
br
bl
rt
ge/gn
br
br
bl
br
br
sw
sw
br
br
br
F
E
11
e
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 12 Dienstag, 30. März 2021 10:54 10

RM5310, RM5330, RM5380
13
bl br ge gn rt sw ws
EN Blue Brown Yellow Green Red Black White
DE Blau Braun Gelb Grün Rot Schwarz Weiß
FR Bleu Marron Jaune Vert Rouge Noir Blanc
NL Blauw Bruin Geel Groen Rood Zwart Wit
1
2
7
9
34 56
8
10
10
12
13
13
NL
G
ge/gn
ge/gn
V85
bl
bl
1a
1b
3a
3b
5a
5b
2b
2a
4b
4a
6b
6a
br
––
++
br
br
bl
rt
ge/gn
br
br
bl
br
br
sw
sw
br
br
ws
ws
ws
ws
sw sw
–
+
br
F
E
11
13
f
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 13 Dienstag, 30. März 2021 10:54 10

RM5310, RM5330, RM5380
14
RM 5310
RM 5330
RM 5380
RM 5385
g
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 14 Dienstag, 30. März 2021 10:54 10

EN
RM5310, RM5330, RM5380 Explanation of symbols
15
Please read these instructions carefully and follow all instructions,guidelines, and warnings included in this product manual in order to ensure
that you install, use, and maintain the product properly at all times. These instructions MUST stay with this product.
By using the product, you hereby confirm that you have read all instructions, guidelines, and warnings carefully and thatyou understand and
agree to abide by the terms and conditions as set forth herein. You agree to use this product only for the intended purpose and application
and in accordance with the instructions, guidelines, and warnings as set forth in this product manual as well as in accordance with all appli-
cable laws and regulations. A failure to read and follow the instructions and warnings set forth herein may result in an injury to yourself and
others, damage to your product or damage to other property in the vicinity. This product manual, including the instructions, guidelines, and
warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit
documents.dometic.com, dometic.com.
Table of contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
6 Installing the refrigerator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
7 Reversing the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8 Put on the door panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
9 Connecting the refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
10 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
11 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
12 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
1 Explanation of symbols
!
!
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
CAUTION!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 15 Dienstag, 30. März 2021 10:54 10

EN
Safety instructions RM5310, RM5330, RM5380
16
A
I
2 Safety instructions
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Explosion hazard
• Never open the absorber unit. It is under high pressure and can cause
injury if it is opened.
•Only operate the device at the pressure shown on the type plate.
Only use pressure controllers with a fixed setting which comply with
the national regulations (in Europe EN 12864).
Fire hazard
• Ensure clean and residue-free handling if silicon sealant or similar is
used. There is a risk of fire if silicone filaments come into contact with
hot parts or naked flames.
• Never use a naked flame to check the device for leaks.
• Only use propane or butane gas (not natural gas).
Health hazard
• Do not operate the device if it is visibly damaged.
• If the AC power cable for this device is damaged, it must be replaced
by the manufacturer, a service agent or a similarly qualified person in
order to prevent safety hazards.
• This device may only be repaired by qualified personnel. Inadequate
repairs may cause serious hazards.
Risk of asphyxiation
• Dismantle all device doors for the disposal of the old device and leave
the shelves in the device to prevent accidental enclosure and suffoca-
tion.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE
Supplementary information for operating the product.
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 16 Dienstag, 30. März 2021 10:54 10

EN
RM5310, RM5330, RM5380 Safety instructions
17
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Electrical shock
• Before starting the device, ensure that the power supply line and the
plug are dry.
Risk of crushing
• Do not put your fingers into the hinge.
ANOTICE! Damage hazard
• Only hold the device at the body of the device during transport. Never
hold the device at the absorber unit, the cooling fins, the gas pipes,
the door or the control panel.
• Make sure that the device circuit is not damaged during
transportation. The refrigerant in the device circuit is highly
flammable.
In the event of any damage to the device circuit (smell of ammonia):
– Switch off the device if applicable.
– Avoid naked flames and sparks.
– Air the room well.
• Do not install the device near naked flames or other heat sources (heat-
ers, direct sunlight, gas ovens etc.).
•Danger of overheating!
Always ensure sufficient ventilation so that the heat generated during
operation can dissipate. Make sure that the device is sufficiently far
away from walls and other objects so that the air can circulate.
• Check that the voltage specification on the type plate is the same as
that of the power supply.
• Do not open the refrigerant circuit under any circumstances.
• Only use the AC connection cable supplied to connect the device to
the AC mains.
• Only use cables with a suitable size.
• Never pull the plug out of the socket by the connection cable.
• The device may not be exposed to rain.
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 17 Dienstag, 30. März 2021 10:54 10

EN
Scope of delivery RM5310, RM5330, RM5380
18
3Scopeofdelivery
• Refrigerator
•Caps
•Ice-cubetray
• Operating manual
• Installation manual
4Accessories
Available as accessories (not included in the scope of delivery):
If you have questions regarding the accessories, please contact your local service
partner.
Description Ref. no.
Fan kit 9105900007
LS100 ventilation grille
with flue duct and winter cover
White 9105900012
Beige 9105900011
LS200 ventilation grille
without flue duct and winter cover
White 9105900014
Beige 9105900013
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 18 Dienstag, 30. März 2021 10:54 10

EN
RM5310, RM5330, RM5380 Intended use
19
5 Intended use
The refrigerator is designed for installation in caravans or motorhomes. It is only suit-
able for cooling, freezing and storing foodstuffs. The refrigerator is not intended for
the proper storage of medicine.
The refrigerator is designed to be operated on a DC power supply and an AC socket
and can be powered by liquid gas (propane or butane). The refrigerator may not be
run on natural gas or city gas. The RM5385 refrigerator also always requires a perma-
nent DC supply.
This product is only suitable for the intended purpose and application in accordance
with these instructions.
This manual provides information that is necessary for proper installation and/or
operation of the product. Poor installation and/or improper operating or mainte-
nance will result in unsatisfactory performance and a possible failure.
The manufacturer accepts no liability for any injury or damage to the product
resulting from:
• Incorrect assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts
provided by the manufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product
specifications.
6 Installing the refrigerator
6.1 Preparing the installation
When installing the refrigerator, note the following:
• To enable the refrigerant to circulate properly, the refrigerator may not exceed an
angle of 3°.
Park the vehicle on a level surface with the help of a spirit level.
• The refrigerator must be installed so that it is easily accessible for service work,
easy to de-install and install and can be easily removed from the vehicle.
• The distance between the refrigerator and the rear wall must be min. 15 mm –
max. 25 mm (fig. 3, page 5).
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 19 Dienstag, 30. März 2021 10:54 10

EN
Installing the refrigerator RM5310, RM5330, RM5380
20
• The refrigerator must be installed in a recess so that it stands firm when the vehicle
is in motion. Note the following dimensions here (H x W x D in mm, fig. 1,
page 3):
–RM5310: 618 x 486 x 474
–RM5330: 821 x 486 x 474
–RM5380: 821 x 486 x 474
• The outer wall must be fitted with an air inletvent (fig. 22, page 4)and an outlet
vent (fig. 23, page 4) with ventilation grilles so that the heat generated can be
easily released to the outside:
– Air inlet vent: Fit the ventilation grille as flush as possible underneath the
burner lid (fig. 21, page 4) with a minimum cross-section of 250 cm2.
– Outlet vent: fit above the refrigerator as far as possible. A ventilation grille
with integrated flue duct can also be used here.
• If the ventilation grille of the air inlet vent cannot be installed flush to the ground,
an additional inlet vent (fig. 25, page 4) must be provided in the floor for
releasing leaked gas.
• For the RM5380 refrigerators, an air inlet vent (fig. 25, page 4) must always be
installed in the floor.
• The air vents must not be covered by vehicle parts (such as an open door or by
installing accessories such as bicycle racks) while operating.
• There must be sufficient space at the back of the refrigerator for the air to be able
to circulate around the cooling element.
• Fit a heat conduction plate (fig. 24, page 4) above the refrigerator so that the
heat does not accumulate in the vehicle.
• Install the refrigerator so that it is protected from excessive heat, as this leads to
poor performance and increases the power consumption of the refrigerator.
• The electrical installation must comply with national and local regulations.
European standards: EN 60335-1, EN 60335-2-24, EN 1648-1 and EN 1648-2.
• The gas installation must comply with national and local regulations.
European standard: EN 1949.
• The refrigerator must be installed in a draught-proof location in accordance with
EN 1949, see chapter “Installing the refrigerator in a draught-proof location” on
page 21.
DometicRM53xx_INM_4445102229_EMEA(en-de-fr-nl)_20xx-xx-xx.book Seite 20 Dienstag, 30. März 2021 10:54 10
