Dometic D50 User manual

D15,D50
Wine refrigerator
Operating manual . . . . . . . . . . . . . . . . . . . . .7
Weinkühlgerät
Bedienungsanleitung . . . . . . . . . . . . . . . . .27
Cave à vin réfrigérée
Notice d’utilisation . . . . . . . . . . . . . . . . . . .48
Enfriador de vino
Instrucciones de uso . . . . . . . . . . . . . . . . . .69
Aparelho de refrigeração para
vinho
Manual de instruções . . . . . . . . . . . . . . . . .90
IRefrigeratore per vino
Istruzioni per l’uso . . . . . . . . . . . . . . . . . . . 111
Wijnkoelkast
Gebruiksaanwijzing. . . . . . . . . . . . . . . . . .132
Vinkøleapparat
Betjeningsvejledning . . . . . . . . . . . . . . . . 153
Vinkyl
Bruksanvisning . . . . . . . . . . . . . . . . . . . . . 174
Vinkjøler
Bruksanvisning . . . . . . . . . . . . . . . . . . . . . 195
Viinijäähdytin
Käyttöohje . . . . . . . . . . . . . . . . . . . . . . . . . 215
Устройство для охлаждения вина
Инструкция по эксплуатации . . . . . . . . . 236
冷藏酒柜
使用说明书 . . . . . . . . . . . . 258
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
CN
REFRIGERATION
MACAVE
_MaCave_A5.book Seite 1 Freitag, 2. Dezember 2016 10:15 10

_MaCave_A5.book Seite 2 Freitag, 2. Dezember 2016 10:15 10

D15, D 50
3
D 15 D 50
1
2
3
4
5
6
7
1
1 2 3 4 5 6 7 8
2
3
_MaCave_A5.book Seite 3 Freitag, 2. Dezember 2016 10:15 10

D15,D 50
4
5
4
7
6
9
8
_MaCave_A5.book Seite 4 Freitag, 2. Dezember 2016 10:15 10

D15, D 50
5
0
1
2
a
1
b
_MaCave_A5.book Seite 5 Freitag, 2. Dezember 2016 10:15 10

D15,D 50
6
1
c
_MaCave_A5.book Seite 6 Freitag, 2. Dezember 2016 10:15 10

EN
D15,D50
7
Please read this instruction manual carefully before first use, and storeit in
a safe place. If you pass on the product to another person, hand over this
instruction manual along with it.
Contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3 Contents of product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4 Optional extras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
8 Setting up and connecting the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . .14
9 Using the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
10 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
11 Maintaining and cleaning the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
12 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
13 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
14 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
_MaCave_A5.book Seite 7 Freitag, 2. Dezember 2016 10:15 10

EN
Explanation of symbols D15, D50
8
1 Explanation of symbols
!
!
A
I
2 Safety instructions
The manufacturer accepts no liability for damage in the following cases:
•Faulty assembly or connection
•Damage to the product resulting from mechanical influences and excess voltage
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
_MaCave_A5.book Seite 8 Freitag, 2. Dezember 2016 10:15 10

EN
D15, D50 Safety instructions
9
2.1 General safety
!WARNING!
•Before you start up the device for the first time, verify that the
operating voltage matches the line voltage (see type plate).
•Do not operate the device if it is visibly damaged.
•This device may only be repaired by qualified personnel. Improper
repairs can lead to considerable hazards.
Should your device need to be repaired, please contact customer
services.
•Persons (including children) whose physical, sensory or mental
capabilities or lack of experience and knowledge prevent them from
using the device safely should not use it without initial supervision or
instruction by a responsible person.
•Electrical devices are not toys.
Always keep the device out of the reach of children.
•Children must be supervised to ensure that they do not play with the
device.
•If this device's power cord is damaged, it must be replaced by the
manufacturer, customer service or a similarly qualified person in order
to prevent safety hazards.
•Do not store any explosive substances, such as spray cans with
propellants in the device.
!CAUTION!
•Disconnect the device from the power supply
– before cleaning and maintenance
–afteruse
•The appliance should be moved and set up by at least two people.
Otherwise this could lead to back or other injuries.
ANOTICE!
•Never pull the plug out of the electrical outlet by the cord.
•Do not use accessories that have not been recommended by the
manufacturer. This can lead to injury and damage to material.
_MaCave_A5.book Seite 9 Freitag, 2. Dezember 2016 10:15 10

EN
Contents of product D15, D50
10
2.2 Operating the device safely
!WARNING!
•Never use the device in rooms where flammable materials are stored
or flammable gases have built up. Sparks from the motor could ignite
them.
!CAUTION!
•Do not use the device with wet hands.
ANOTICE!
•Only use the device in indoors, never outside.
•Never expose the device to moisture.
•Keep children and pets at a safe distance when operating the device.
•Do not place any electrical devices inside the refrigerator.
3 Contents of product
•Wine refrigerator
•Water container
•Key
•Operating manual
_MaCave_A5.book Seite 10 Freitag, 2. Dezember 2016 10:15 10

EN
D15, D50 Optional extras
11
4Optionalextras
Available as accessory (not included in scope of delivery):
5 Spare parts
6 Intended use
This device is a wine refrigerator. It is only intended for storing wine.
The supply voltage suitable for your device is listed in the table “country versions”,
see chapter “Technical data” on page 26.
Designation Ref. no.
D15 D50
Storage shelves 9103500158 9103500159
Presentation shelves (tilted) – 9103500157
Decorative film
POP-WineListing
9103500143 9103500144
Decorative film
POP-GrandCrus
9103500146 9103500147
Decorative film
POP-GlassShape
9103500149 9103500150
Decorative film
POP-BottleShape
9103500152 9103500153
Designation Ref. no.
D15 D50
Storage base 9103500158 9103500159
Active carbon filter 9103500156 9103500156
Water container 9103500155 9103500155
Decorative film
POP-WineDiffSizes
9103500140 9103500141
_MaCave_A5.book Seite 11 Freitag, 2. Dezember 2016 10:15 10

EN
Technical description D15, D50
12
7 Technical description
The wine refrigerator comes in three models:
•D15:
with capacity for up to 23 Bordeaux standard bottles
•D50:
with capacity for up to 62 Bordeaux standard bottles
The device has two separate temperature zones.
The temperature zones are chilled or heated automatically to reach or maintain the
temperature that is set.
The temperature is set in 1 °C or 1 °F increments using sensor buttons.
The appliance has:
•Sensor buttons: Just touch slightly to select the required function.
•automatic defrosting
•a UV impervious door
•an active carbon filter for improving the inner climate
•a fan for maintaining a constant inner climate, such as in a cellar
(dynamic cooling mode)
•a lockable glass door with a reversible door hinge
•a replaceable decorative film for the glass door
•detachable shelves for storing the bottles
•a Sabbath mode
•LED interior lighting with two operating modes
•a temperature memory function: The set temperature is also saved when the unit
is switched off.
•a temperature monitor: A warning signal sounds and the temperature display
flashes if the interior temperature noticeably deviates from the one set.
_MaCave_A5.book Seite 12 Freitag, 2. Dezember 2016 10:15 10

EN
D15, D50 Technical description
13
Overview
Control elements
No. in
fig. 1,
page 3
Designation
1 Control panel
2 Upper temperature zone
3 Cooling area divider
4 Lower temperature zone
5Lock
6 Ventilation slots
7 Adjustable feet
No. in
fig. 2,
page 3
Symbol Description
1 On/off switch
2 Increases the set temperature of the upper temperature zone by
1 °C or 1 °F
3 Decreases the set temperature of the upper temperature zone by
1 °C or 1 °F
4 Display indicates the current temperature of the upper temperature
zone
5 Display indicates the current temperature of the lower temperature
zone
6 Increases the set temperature of the lower temperature zone by
1°Cor1°F
7 Decreases the set temperature of the lower temperature zone by
1 °C or 1 °F
8 Switches the interior light on or off
_MaCave_A5.book Seite 13 Freitag, 2. Dezember 2016 10:15 10

EN
Setting up and connecting the appliance D15, D50
14
8 Setting up and connecting the
appliance
8.1 Notes on setting up the appliance
When selecting the location, observe the following instructions:
•The ambient temperature should be in accordance with the climate class
mentioned for your country in the supplementary brochure. Otherwise, it is
possible that the inner temperature you set cannot be reached or maintained.
This could also be the case if there are extreme fluctuations in the ambient
temperature.
•The appliance should stand in the coldest part of the room, away from heat
sources (ovens, heating devices or radiators).
•The location must not be damp or wet.
•The appliance must not be exposed to direct sunlight. This can damage the
acrylic coating and lead to higher power consumption.
•The ground must be level and sufficiently stable to support the wine cellar at full
capacity.
•The appliance must be sufficiently ventilated. The ventilation slots on the front of
the appliance must not be obstructed.
•Note the information on the electrical connection, see chapter “Notes on the
electrical connections” on page 15.
•Remove all the inner and outer packaging material before setting up.
•Make sure the appliance is level by adjusting the feet.
8.2 Notes on installing the appliance
D15and D50can be built-in or free-standing.
Installation size
D15 D50
Width 300 mm / 11,8 " 600 mm / 23,6 "
Depth 590 mm / 23,2 " 590 mm / 23,2 "
Height 870 mm / 34,3 " 870 mm / 34,3 "
_MaCave_A5.book Seite 14 Freitag, 2. Dezember 2016 10:15 10

EN
D15, D50 Setting up and connecting the appliance
15
8.3 Reversing the door
You can also change the hinge of the door, so that it opens to the left rather than the
right.
Then fit the door handle on the other side, see chapter “Fitting the door handle on
the other side” on page 15.
D15andD50
➤Change the door as described in fig. 3, page 3 to fig. 7, page 4.
Fitting the door handle on the other side
➤Fit the door handle on the other side as described in fig. 8, page 4 to fig. 9,
page 4.
8.4 Notes on the electrical connections
A
Observe the following when connecting the appliance:
•Connect this appliance to a separate 15 A circuit.
•Have the receptacle and the circuit checked by a qualified electrician to ensure
that the socket is grounded correctly.
•Check that the voltage specification on the type plate is the same as that of the
power supply.
•If you are using an extension cord, it must be suitable for the values which
correspond to the device, see chapter “Technical data” on page 26.
•Do not use an extension cord or a multiplepower socket that can be switched off
with just one switch.
•The cord must rest securely behind the appliance and not be allowed to lie or
hang unprotected.
NOTICE!
Leavethe applianceto standupright forabout2 hoursafter transporting,
before you connect it to the power supply.
Otherwise this could cause faults in the cooling system.
_MaCave_A5.book Seite 15 Freitag, 2. Dezember 2016 10:15 10

EN
Using the appliance D15, D50
16
9 Using the appliance
9.1 Energy saving tips
•Do not open the device more often than necessary.
•Do not leave the door open for longer than necessary.
•Clean dust and dirt from the condenser at regular intervals.
9.2 Notes on the use
•Only store wine in unopened bottles.
•Do not overload the device.
•Fig. 0, page 5, shows you how you can store the bottles.
•Do not cover the bottom with aluminium foil or any other objects, as this
obstructs the air circulation.
•If the device has been empty for a long time, disconnect it from the power supply
and clean it thoroughly. Leave the door open slightly to allow the air to circulate
and prevent condensation, mould or odours from building up.
•After a power outage or if the appliance has been switched off, wait
3 to 5 minutes before switching on the appliance again.
_MaCave_A5.book Seite 16 Freitag, 2. Dezember 2016 10:15 10

EN
D15, D50 Using the appliance
17
Quick reference
Key lock
If the buttons are not touched for 2 minutes or longer, the key lock is activated
automatically.
➤To remove the key lock, press the and buttons for at least 5 seconds.
Sets the unit (°C / °F)
You can select the temperature in Fahrenheit or Celsius.
➤To do this, press the button for 5 seconds.
✓The unit is converted and the display shows the temperature in the other form.
Function Press the button
Switches on the appliance > 5 s
Switches off the appliance > 5 s
Removes the key lock + > 5 s
Changes the unit (°C / °F) > 5 s
Indicates the set temperature of the temperature zone or < 1 s
Increases the temperature in the temperature zone by 1 °C or
1°F < 1 s
Decreases the temperature in the temperature zone by 1 °C
or 1 °F < 1 s
Switches off the fan (silent mode) > 5 s
Switches on the fan (dynamic cooling) > 5 s
Switches interior light on/off < 1 s
_MaCave_A5.book Seite 17 Freitag, 2. Dezember 2016 10:15 10

EN
Using the appliance D15, D50
18
Setting the temperature
The device has two separate temperature zones. The temperature of both zones can
be set between 5 °C and 22 °C (40 °F and 72 °F).
The lower temperature zone is ideal for storing white and red wine at 13 °C to
22 °C (55 °F to 72 °F).
The upper temperature zone is suitable for storing champagne and white wine
at a setting of 5 °C to 13 °C (40 °F to 55 °F).
I
➤Press the or button to set the temperature.
✓The display flashes while you make the setting.
✓After the temperature has been set, the display shows the current inner
temperature of the particular temperature zone.
I
Checking the set temperature
This is how to display the set temperature:
➤Press the or button briefly.
✓The set temperature is shown in the display for 5 seconds.
Then the display shows the current inner temperature again.
I
NOTE
•The temperature for the lower temperature zone must always be
just as high or higher than the upper temperature zone .
•The appliance functions at its best if the difference in temperature
between the two zones is at least 4 °C.
NOTE
When using the appliance for the first time or if it has not been used for a
long time, the inner temperature could differ from the one you have set.
The temperature display flashes as long as this is the case.
Once the set temperature has been reached, the temperature display
remains lit.
NOTE
In the event of an interruption to the power supply (power failure, switch
over) the unit saves the previous temperature settings.
_MaCave_A5.book Seite 18 Freitag, 2. Dezember 2016 10:15 10

EN
D15, D50 Using the appliance
19
Temperature monitoring
A warning signal sounds and the temperature display flashes.
•if the inner temperature of a zone deviates from the set temperature by more than
5°C.
•if the power supply has been disconnected for a long time.
•if the door has not been shut properly.
•if the door is open for more than 60 seconds.
This prevents the temperature from falling or rising unnoticed, which could affect the
quality of the wine.
Once the unit has reached the set temperature, the warning signal stops and the
temperature display stops flashing.
To switch off the warning signal prematurely:
➤Press the button briefly.
✓The temperature display flashes until the set temperature is reached. The display
is then illuminated constantly and indicates that the alarm system is active again.
Using the Sabbath mode
In this mode, the display, interior lighting and warning signal for the temperature
monitor are deactivated. The refrigeration continues as usual.
To switch on the Sabbath mode:
➤Press the and buttons simultaneously for at least 5 seconds.
✓The temperature display flashes 4 times. The Sabbath mode is activated. The
Sabbath mode switches off automatically after 96 hours.
To switch off the Sabbath mode:
➤Press the and buttons simultaneously for at least 5 seconds.
✓The temperature display flashes 4 times. The Sabbath mode is deactivated. The
display, interior lighting and warning signal for the temperature monitor are
activated.
_MaCave_A5.book Seite 19 Freitag, 2. Dezember 2016 10:15 10

EN
Using the appliance D15, D50
20
Setting the LED interior lighting
The unit has two different modes for lighting:
Standard mode and vitrine mode.
– Standard mode: The interior is illuminated when the door is opened.
– Vitrine mode: The interior is illuminated constantly.
To switch between standard and vitrine modes:
➤Press the buttons briefly.
Switching the fan on/off (Dynamic Cooling Mode/Silent Mode)
The fan is switched on (Dynamic Cooling Mode) by default to ensure a homo-
geneous climate in a temperature zone. The fan operates automatically to regulate
the humidity and temperature. The fan can be switched off (Silent Mode) once the
set temperature has been reached.
This is how to switch on the fan (dynamic cooling mode):
➤Press the button for > 5 seconds.
✓5 acoustic signals are emitted.
The fan is switched on (dynamic cooling mode).
This is how to switch off the fan (silent mode):
➤Press the button for > 5 seconds.
✓3 acoustic signals are emitted.
The fan is switched off (silent mode).
_MaCave_A5.book Seite 20 Freitag, 2. Dezember 2016 10:15 10
