Dometic TROPICOOL TCX14 User manual

TCX14, TCX21, TCX 35
Thermoelectric cooler
Operating manual . . . . . . . . . . . . . . . . . . . . .6
Thermoelektrische Kühlbox
Bedienungsanleitung . . . . . . . . . . . . . . . . . 17
Glacière thermoélectrique
Notice d’utilisation . . . . . . . . . . . . . . . . . . .28
Nevera termoeléctrica
Instrucciones de uso . . . . . . . . . . . . . . . . . .39
Geleira termoeléctrica
Manual de instruções . . . . . . . . . . . . . . . . . 51
Frigorifero termoelettrico
Istruzioni per l’uso . . . . . . . . . . . . . . . . . . . .63
Thermo-elektrische koelbox
Gebruiksaanwijzing. . . . . . . . . . . . . . . . . . .75
Termoelektrisk køleboks
Betjeningsvejledning . . . . . . . . . . . . . . . . .86
Termoelektrisk kylbox
Bruksanvisning. . . . . . . . . . . . . . . . . . . . . . .96
Termoelektrisk kjøleboks
Bruksanvisning . . . . . . . . . . . . . . . . . . . . . 106
Sähkökäyttöinen kylmälaukku
Käyttöohje . . . . . . . . . . . . . . . . . . . . . . . . . 116
Термоэлектрический холодильник
Инструкция по эксплуатации . . . . . . . . . 126
Przenośna lodówka
termoelektryczna
Instrukcja obsługi . . . . . . . . . . . . . . . . . . . 137
Termoelektrický chladiaci box
Návod na obsluhu. . . . . . . . . . . . . . . . . . . 148
Termoelektrický chladicí box
Návod k obsluze . . . . . . . . . . . . . . . . . . . . 159
Termoelektromos hűtőkészülék
Használati utasítás. . . . . . . . . . . . . . . . . . . 169
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
COOLING BOXES
TROPICOOL
TCX14-TCX35--O-16s.book Seite 1 Montag, 7. November 2016 11:04 11

TCX14-TCX35--O-16s.book Seite 2 Montag, 7. November 2016 11:04 11

TCX14, TCX21, TCX35
3
3
2
1
1
2
NORMAL WARMER
NORMAL COLDER
HOT
COLD
1 2 3 4 5 6
3
TCX14-TCX35--O-16s.book Seite 3 Montag, 7. November 2016 11:04 11

TCX14, TCX21, TCX35
4
4
12/24 Vg
5
1
6
TCX14-TCX35--O-16s.book Seite 4 Montag, 7. November 2016 11:04 11

TCX14, TCX21, TCX35
5
1,5/2 L
450
323
250
303
208
201
260
335
7
1, 5/2 L
550
340
466
376
265
350
TCX14
TCX21
TCX35
1,5/2 L
450
319
288
426
303
198
208
352
TCX14-TCX35--O-16s.book Seite 5 Montag, 7. November 2016 11:04 11

EN
TCX14, TCX21, TCX35
6
Please read this operating manual carefully before starting the device.
Keep it in a safe place for future reference. If the device is passed on to
another person, this operating manual must be handed over to the user
along with it.
The manufacturer cannot be held liable for damage resulting from improper usage
or incorrect operation.
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4 Use as intended. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7 Cleaning and servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
8 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
9 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
10 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
TCX14-TCX35--O-16s.book Seite 6 Montag, 7. November 2016 11:04 11

EN
TCX14, TCX21, TCX35 Explanation of symbols
7
1 Explanation of symbols
!
!
A
I
2Safetynotes
2.1 General safety
!WARNING!
•Do not operate the device if it is visibly damaged.
•If this device's power cable is damaged, it must be replaced by the
manufacturer, customer service or a similarly qualified person in order
to prevent safety hazards.
•This device may only be repaired by qualified personnel. Improper
repairs can lead to considerable hazards.
•This device can be used by children aged 8 years or over,as well as by
persons with diminished physical, sensory or mental capacities or a
lack of experience and/or knowledge, providing they are supervised
or have been taught how to use the device safely and are aware of the
resulting risks.
•Cleaning and user maintenance must not be carried out by children
without supervision.
•Children must not play with the device.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
TCX14-TCX35--O-16s.book Seite 7 Montag, 7. November 2016 11:04 11

EN
Safety notes TCX14, TCX21, TCX35
8
•Children must be supervised to ensure that they do not play with the
device.
•Always keep and use the device out of the reach of children under the
age of 8 years.
•Do not store any explosive substances such as spray cans with a
flammable propellant in the device.
!CAUTION!
•Disconnect the device from the power supply
– before each cleaning and maintenance
– after every use
•Food may only be stored in its original packaging or in suitable
containers.
ANOTICE!
•Check that the voltage specification on the type plate corresponds to
that of the energy supply.
•Only connect the device as follows:
– With the DC cable to a DC plug socket in the vehicle (e. g.
cigarette lighter)
– Or with the AC connection cable to the AC mains supply
•Never pull the plug out of the socket by the cable.
•If the cooler is connected to the DC socket: Disconnect the cooler and
other power consuming devices from the battery before connecting
the quick charging device.
•If the cooler is connected to the DC socket: Disconnect the cooler or
switch it off when you turn off the engine. Otherwise you may dis-
charge the battery.
•The cooling device is not suitable for transporting caustic materials or
materials containing solvents.
•The cooling device contains inflammable cyclopentane in the
insulation. The gases in the insulation material require special disposal
procedures. Deliver the device at the end of its life-cycle to an appro-
priate recycling.
TCX14-TCX35--O-16s.book Seite 8 Montag, 7. November 2016 11:04 11

EN
TCX14, TCX21, TCX35 Scope of delivery
9
2.2 Operating the device safely
!CAUTION!
•Before starting the device, ensure that the power supply line and the
plug are dry.
ANOTICE!
•Do not use electrical devices inside the cooler unless they are
recommended by the manufacturer for the purpose.
•Do not place the device near naked flames or other heat sources
(heaters, direct sunlight, gas ovens etc.).
•Danger of overheating!
Ensure at all timesthat there is sufficient ventilation so that the heatthat
arises during operation does not build up. Make sure that the device
is sufficiently far away from walls and other objects so that the air can
circulate.
•Ensure that the ventilation openings are not covered.
•Do not fill the inner container with ice or fluid.
•Never immerse the device in water.
•Protect the device and the cable against heat and moisture.
3Scopeofdelivery
Check before starting up the device that all parts are available belonging to the
scope of delivery.
No. in
fig. 1, page 3 Quantity Description
1 1 Thermoelectric cooler
2 1 Connection cable for AC connection
3 1 Connection cable for DC connection
– 1 Instruction manual
TCX14-TCX35--O-16s.book Seite 9 Montag, 7. November 2016 11:04 11

EN
Use as intended TCX14, TCX21, TCX35
10
4Useasintended
The cooler can be used to cool and keep foodstuffs warm. The device can be also
used for camping purposes.
All materials processed in the refrigerator are safe for foodstuffs.
!
5 Technical description
The cooling device is suitable for mobile use. It can cool goods up to max. 30 °C
under ambient temperature (thermostatic switch-off at approx. 0 °C) or keep them
cool or warm them up to max. 65 °C or keep them warm.
If the device has reached the set temperature range, it will automatically switch over
to the energy save mode. In this mode only the energy which is required to reach the
temperature inside the box is consumed.
The cooling is a wear-free thermo-electric cooler with heat removal through a
ventilator.
The cooling box is equipped with an automatic priority circuit. Thus it is ensured that
with simultaneous connection to the AC mains supply and to a 12/24 V battery, the
AC mains supply will be used.
CAUTION! Health hazard!
Please check if the cooling capacity of the device is suitable for storing
the food or medicine you wish to cool.
TCX14-TCX35--O-16s.book Seite 10 Montag, 7. November 2016 11:04 11
