DONPER Bubbler User manual

DRINK MACHINE
USER MANUAL
Operating Instructions
D25 “Bubbler”
Donper USA
500 Stonegate Dr.
Katy, TX 77494
1-844-366-7371
[email protected]
www.donperusa.com

Table of Contents
Explosion Diagram..............................................................................1
Safety Precuations............................................................................2
Unpacking & Setup...........................................................................3
1. Unpalletize Machine 2. Unpack & Inspect Parts 3. Routine Maintenance Operations
Spec Sheet......................................................................................4,5
1. Dimenstions 2. Parameters
I
II
III
D25
SPEC SHEETS

1-844-366-7371
[email protected]
www.donperusa.com
1

([SORGHG'LDJUDP/3;
&RYHU 6XSSRUWLQJEORFN  &RPSUHVVRU  3XPS FRYHU
6SUD\ WXEH 0DJQHWLF FOXWFK  &RQGHQVHU  )DVWHQHU
 %RZO  6ZLWFK  )DQ PRWRU  'ULQJ
'LVSHQVLQJYDOYH  5LJKW SDQHO  /HIW SDQHO  2ULQJ
+DQGOH  )URQW SDQHO  3XPS PRWRU  7KHUPRVWDW
,PSHOOHU  'ULS WUD\  5HDU SDQHO  6ZLWFK FRYHU
(YDSRUDWRU 
&RYHU RI GULS WUD\  %HDULQJ VOHHYH  )DQ
D25 Parts Vie
w
I EXPLOSION DIAGRAM
D25

1-844-366-7371
[email protected]
www.donperusa.com
2
II SAFETY PRECAUTIONS
SOFT SERVE ICE CREAM MACHINE
All safety regulations, local codes, and instructions that appear in the
manual or on the equipment must be observed to ensure personal safety
and to prevent damage to the machine. If equipment is used in a manner
not specified by the manufacturer, the protection covered by the warranty
will become null and void.
ICONS FOUND THROUGHOUT THIS DOCUMENT AND
WHAT THEY REPRESENT
NOTE: Non-hazardous, informational text.
IMPORTANT: Represents an extremely important step or note the
user must be aware of.
CAUTION: Informs the operator of a task that may lead to harm if
instructions are not followed.
WARNING: Risk of harm to the operator or machine if performed
incorrectly.

1-844-366-7371
[email protected]
www.donperusa.com
3
III UNPACKING & SETUP
WARNING
Unpalletizing requires lifting. Two or more personnel should remove the
machine from its packaging and place it in its final operating location.
Failure to do so may result in severe injury or damage.
UNPALLETIZE MACHINE
1. To remove all sides and cover of shipping box, unfold all tabs on the
shipping box from their closed position to the open position using a flat-head
screwdriver, and a hammer if needed.
2. Remove plastic wrapping from around the machine.
3. Being careful not to scratch or dent the machine panels, remove both side
panels with a phillips-head electric screw driver.
4. On the bottom of the machine there are 2 stabilizing bolts securing the
machine to the bottom of the shipping pallet/box. Using a #12 wrench and a
#12 ratchet carefully remove both bolts.
5. Reattach both side panels using the phillips-head electric screw driver.
CAUTION
The machine is designed to operate in normal ambient temperatures of
60-75oF. Operating in higher ambient temperatures will result in less than
optimal performance.
6. Prepare the area where the machine will be placed.
7. Place the machine in its final location according to the Installation
Requirements.
D25 | UNPACKING MACHINE

1-844-366-7371
[email protected]
www.donperusa.com
4
Features
*The D25 is manufactured for Donper USA by
a third party.
D25
DRINK MACHINE
D25
●Self-contained air cooled countertop model
●
●
●
●Large 9.5 gallon, dishwasher safe, plastic
bowls.
Donper USA
500 Stonegate Dr.
Katy, TX 77494
1-844-366-7371
[e-mail]
www.donperusa.com
"Bubblers" are much more than just a cold drink
dispenser, as these circulate the drink from the bottom
to the top of the bowl using a pump so that the drink
cascades down all sides of the bowl. for great visual
merchandising.
The bowls are made of poly carbonate for easy clean-
ing and long life.
The machine design is easy to use (just pour in the mix
and turn on the power).
Super-strong, virtually unbreakable
polycarbonate bowls and covers give lasting
durability
Stainless steel allow easier cleaning and less
maintenance
1 motor per bowl, 1 switch per bowl - Each
bowl operates independently of each other.

1-844-366-7371
[email protected]
www.donperusa.com
5
Side View Front View Top View
Voltage
Phase
Current
Compressor
Hertz
Plug Type
115 v
Single
3.7 Amps
1/3 HP
60 Hz Standard US
115 volt Standard Plug
Electrical
Size and Capacity
Number of Bowls
Bowl Capacity (each)
Total Machine Capacity
Height
Width
Depth
Weight
2
9.5 gallons (36 L)
28.75 in (730.25 mm)
19.75 in (501.65 mm)
15.25 in (387.35 mm)
75 lbs (35 kg)
Measurements in inches.
Donper USA
500 Stonegate Dr.
Katy, TX 77494
1-844-366-7371
[e-mail]
www.donperusa.com
Distributed By:
D25
15.25
28.75
19.75
4.75 gallons (18 L)

Donper USA
500 Stonegate Dr.
Katy, TX 77494
1-844-366-7371
[e-mail]
www.donperusa.com
Need Parts? [e-mail]
Visit Our Online Parts Store
Technical Support
1-844-366-7371
D250 | MACHINE SETTINGS
