Dorel Living DA7567-SEC User manual

Model Number: UPC Code: Color:
DA7567-SEC
0-65857-17408-3 Gray
Date of Purchase: _____ / _____ / _____ Lot Number:
(taken from carton)
NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Instagram page.
SECTIONAL SOFA
Congratulations on your latest furniture purchase! Dorel Living furniture has been developed
with quality, convenience and style in mind. We trust it will provide you with many years of
exceptional comfort and service.
Before beginning assembly, we encourage you to familiarize yourself with your new furniture
piece by taking a few minutes to go through this booklet. It contains important information on our
warranty and care tips to keep your furniture looking as good as new.
Customer satisfaction is important to us at Dorel Asia. Our agents are available Monday to Friday
8am to 5pm (EST) to answer any question you may have. For faster service, always have the
model number ready when calling our toll free number 1-800-295-1980 or emailing us at
[email protected] .
For more great furniture ideas, check out our website at www.dorelliving.com
You can also keep up to date on all the latest trends by liking our Facebook page.
DO NOT RETURN PRODUCT TO THE STORE. If a part is missing or damaged, contact our
customer service department. We will replace the part FREE of charge.

*
*
*
*
*
*
*
12345 Albert-Hudon Boulevard, Suite 100
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact our customer
service representative first!
CALL 1-800-295-1980
You can also order parts by writing to the address listed below. Please include the
product model number, color and a detailed description of the part.
Customer Service Department No. 413
Montreal, Quebec
Canada H1G 3L1
E-MAIL: [email protected]
NOTES
Ensure all parts and components are present before beginning assembly.
Assembly and handling will require two people.
Assemble on a soft, smooth surface to prevent damage to the product finish.
Read all instructions completely before assembly.
DO NOT use power tools.
CAUTION: Adult assembly required.
Estimated assembly time: 15 minutes.
WARNING: Should this product become damaged, and/or
components are broken or missing, DO NOT USE.
CARE AND CLEANING
Dust regularly with a soft, dry cloth to prevent soil build up. Keep away from heat to avoid glazing,
melting or scorching. Use a professional cleaning service to clean the fabric.
MAINTENANCE
Check bolts/screws periodically and tighten them if necessary.
LIMITED WARRANTY
Dorel warrants its product to be free from defects in material and workmanship and agrees to remedy
any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid
only upon presentation of proof of purchase. This is solely limited to the repair or replacement of
defective furniture components and no assembly labor is included. This warranty does not apply to any
product which has been improperly assembled, subjected to misuse or abuse or which has been altered
or repaired in any way. Any wearing, tearing or fading of the fabric is not covered under the warranty.
This warranty gives you specific legal rights and you may also have other rights which vary from State to
State.

PARTS LIST
A B
C D
E F
G H
I J
K
SECTIONAL SOFA
DA7567-SEC
1 PC
2 PCS
1 PC
1 PC
LEFT ARM
FRONT RAIL
CHAIR BACK
SEAT PANEL
1 PC
1 PC
3 PCS
1 PC
BACK CUSHION
SUPPORT LEG
SEAT CUSHION
RIGHT ARM
LONG SEAT CUSHION
1PC
OTTOMAN
1PC
OTTOMAN FOOT
4PCS

STEP 1:
SECTIONAL SOFA
Place all parts on a clean, smooth surface.
Attach front rail (C) to right arm (E) and left arms (D) by inserting the metal brackets on
front rail (C) into the metal plate on left and right arms (D & E) as shown.
Push the front rail (C) with a downward force to secure it into place.
DA7567-SEC

STEP 2:
SECTIONAL SOFA
Place seat panel (B) on a clean, smooth surface.
Flip the metal bars on seat panel (B) up as shown below.
DA7567-SEC

STEP 3:
SECTIONAL SOFA
Attach the support leg (H) to the seat panel (B) by rotating clockwise.
DA7567-SEC

STEP 4
SECTIONAL SOFA
Attach chair back (A) to left and right arms (D & E) by inserting the brackets on chair back
(A) into the metal glides on left and right arms (D & E).
Slide chair back (A) halfway down the metal brackets on arms (D & E). DO NOT fully insert
the chair back (A). Leaving it partially raised will facilitate assembly in the following step.
NOTE 1: This step is best performed with 2 people.
DA7567-SEC

STEP 5
SECTIONAL SOFA
Attach seat panel (B) to left arm (D) and right arm (E ) by inserting the matal brackets on
seat panel (B) into the metal glides on left arm (D) and right arm (E).
Push the seat panel (B) with a downward force to secure it into place.
DA7567-SEC
Seat panel (B) must be
placed underneath chair
back (A) before it can be
lowered into the brackets on
side arms (D & E).

STEP 6
SECTIONAL SOFA
Push the chair back (A) with a downward force to secure it into place.
Secure the fabric flap on chair back (A) to the left and right arms using the velcro strips
NOTE 1: Both sides must be instered at the same time. This step is best performed with 2
people.
DA7567-SEC

STEP 7
SECTIONAL SOFA
Attach the ottoman feet (K) to ottoman (J) by rotating clockwise.
Turn the ottoman (J) upright and place it in front of the assembled sofa.
DA7567-SEC
