DOREMIDI MIDI THRU-6 Box User manual

1. Product Introduction
MIDI THRU-6 box (hereinafter referred to as product) can be used to convert 1 MIDI input into
6 MIDI outputs. This product has a standard MIDI input interface, MIDI output interface,
high-fidelity communication, no delay, with standard MIDI 16 channels, can communicate all
standard MIDI commands.
2. Product Parameters
Name
Description
Model
THRU-6
Size(L x W x H)
115*73*33mm
Weight
210g
MIDI Interface
1 input, 6 output, standard MIDI five-pin interface
Power In Interface
Powered by USB-B interface, 5VDC
Indicator Light
Product power indicator
MIDI Compatibility
Compatible with all musical instruments with MIDI standard interface
3. Product Interface
❶POWER IN：Product power supply interface, use USB-B plug to supply power to the product,
supply voltage 5V/1A, with power indicator.
❷MIDI IN：MIDI input interface, using a standard five-pin MIDI cable, connected to the output
interface of the MIDI device.
❸MIDI THRU1-6：6 MIDI output interfaces, using standard five-pin MIDI cable, connected to the
input interface of the MIDI device.

4. Product Connection
Support up to 1 MIDI input and 6 MIDI outputs at the same time:
Note: According to the situation, you can choose whether to supply power to the product through
POWER IN. In most cases, if you connect 3 or 4 MIDI THRUs, you don't need to supply power.
However, whether power is supplied or not depends on whether the power of MIDI IN is sufficient.
