DORIC DS3006 User manual

INSTALLATION
GUIDE
DS3006W DS3006
v1.1 - 08/02/2022
I TWO POINT UNIVERSAL STRIKE SLIDING DOOR KEEPER
DS3006
DS3006W
Head oce:
38 Redfern St
Wetherill Park NSW 2164
Australia
Ph: 1300 132 389
Fax: [phone]
[email protected]
www.doric.com.au

Head oce:
38 Redfern St
Wetherill Park NSW 2164
Australia
Ph: 1300 132 389
Fax: [phone]
[email protected]
www.doric.com.au
INSTALLATION GUIDE 2
Cross/ Face
Mounting
screw
Inline
Mounting
screw
DS3006
Two Point
Universal Strike
DS3006W
Wide Two Point
Universal Strike
Cover Keeper
base
Cover
mounting
screws
Adjustment
Grub
Screws
v1.1 - 08/02/2022
I TWO POINT UNIVERSAL STRIKE SLIDING DOOR KEEPER
DS3006
DS3006W

Head oce:
38 Redfern St
Wetherill Park NSW 2164
Australia
Ph: 1300 132 389
Fax: [phone]
[email protected]
www.doric.com.au
INSTALLATION GUIDE
3. Horizontal Adjustment
Adjust the keeper horizontally
using the four screws as shown.
The keeper base offers up to
6mm horizontal adjustment.
4. Cover Mounting
Install keeper cover using
screw provided.
1. Placing Keeper
Install the Keeper base,
secured loosely using the
Cross/ Face fixing holes with
the mounting screws provided.
Do not tighten the screws yet.
2. Vertical Adjustment
Adjust the Keeper base vertically
until the correct position is found
in relation to the door lock.
The keeper base offers adjustment
up to 10mm
Now tighten the mounting screws.
3
CROSS/ FACE FIXING
v1.1 - 08/02/2022
I TWO POINT UNIVERSAL STRIKE SLIDING DOOR KEEPER
DS3006
DS3006W

Head oce:
38 Redfern St
Wetherill Park NSW 2164
Australia
Ph: 1300 132 389
Fax: [phone]
[email protected]
www.doric.com.au
INSTALLATION GUIDE
1. Placing Keeper
Install the Keeper base,
secured loosely in the Inline
fixing holes using the mounting
screws provided.
Do not tighten the screws yet.
2. Vertical Adjustment
Adjust the Keeper base vertically
until the correct position is found
in relation to the door lock.
The keeper base offers adjustment
up to 10mm
Now tighten the mounting screws.
3. Horizontal Adjustment
Adjust the keeper horizontally
using the four screws as shown.
The keeper base offers up to
6mm horizontal adjustment.
4. Cover Mounting
Install keeper cover
using screw provided.
4
INLINE FIXING
