dosatron D9 Green Line Operator's manual

Congratulations on your new Dosatron.
Please read the following important information.
QUICK START UP
IMPORTANT NOTES
For complete information on the features and operations,
refer to your Manual on www.dosatron.com
or download our DOSATRON app
NEED HELP ?
Contact your DOSATRON distributor for service or parts
CAUTION
- When connecting a DOSATRON either to the
public water supply or to its own water source, you
must respect the regulations in force concerning
protection of the source i.e. backflow prevention, etc.
- Contact local authorities for requirements of
backflow prevention.
- When installing, operating, and maintaining the
DOSATRON water powered metering pump, keep
safety considerations foremost. Use proper tools,
protective clothings, and eye protection when
working on the equipment and install the equipment
with a view toward ensuring safe operation.
- Follow the instructions in the manual and take
additional safety measures appropriate to the liquid
being pumped and the temperature of the water that
powers the DOSATRON. Be extremely careful in the
presence of hazardous substances (e.g. corrosives,
toxins, solvents, acids, caustic, flammables, etc.).
- Before applying any aggressive chemicals, please
consult your distributor to confirm compatibility with
the dosing pump.
Hand tighten. No tools needed.
This document does not form a contractual engagement on the part of Dosatron International and is for
information only. Dosatron International reserves the right to alter product specification or appearance
without prior notice.
© DOSATRON INTERNATIONAL S.A.S 2019
DOSATRON INTERNATIONAL S.A.S. Certified QEH&S System
Rue Pascal - B.P. 6 - 33370 TRESSES (BORDEAUX) - FRANCE
Tel. [phone]
Fax. [phone]
[email protected] - www.dosatron.com
CUSTOMER SERVICE - (WORLDWIDE - EUROPE)
Manufactured by
ET398/QSU/D9-06-22
RECOMMENDATIONS
DO NOT USE THIS UNIT WITHOUT A 60 MICRON
[300 MESH] WATER FILTER*
OR YOUR WARRANTY WILL BE VOID.
*The 60 micron [300 mesh] water lter (sold separately)
protects your unit from debris in the water that causes
scoring to the piston and housing.
KNOW YOUR WATER FLOW!
GRADUALLY TURN ON THE WATER.
COUNT THE NUMBER OF CLICKS IN
15 SECONDS. DO NOT EXCEED 44* CLICKS.
CLICK CHART
Clicks/15 sec l/h gpm
4 820 3,6
8 1640 7,2
16 3280 14,5
32 6500 29
40 8000 36
44 9000 40
MAXIMUM PRESSURE 8 bar [116 psi]
D9 - 9 m3/h - 40 US gpm
D9

;
1
2a 2b
3 4 5
6 7 8
910
Scan the QR-
code on the
dosing pump.
w
a
t
e
r
f
o
w
Filter :
60 microns [300 mesh]
Depending on your water quality
8EQ001
(option)
When possible,
DO NOT PLACE
the container directly
under the DOSATRON
WHAT YOU SHOULD NOT DO
t
t
NO !
Air-Bleed
Button
By-Pass version

 

 
Air-Bleed Button Version
WHAT YOU SHOULD DO
Ø 6
Ø 6
1 2 3
Max. Torque 30 Nm
Maximum: 44 clicks/15 sec.
