Dosel DOSWDDT26002 User manual
DOSWDDT26002
تﺎﻤﻴﻠﻌﺘﻟا ﺐﻴﺘﻛ
ﺰﺗﺮﻴﻫ ٦٠ / ٥٠ ~ ﺖﻟﻮﻓ ٢٤٠ - ٢٢٠
ءﺎـﻣ داﺮـﺑ
( درﺎﺑ و رﺎﺣ )
ﻦﻴﺼﻟا ﻲﻓ ﻊﻨﺻ
www.dosel.company
:
2 1
Maintenance and clean
Periodical maintenance can make it a good use time.
Please pull of the plug before maintenance.
Use soft cloth with warm water to clean the water dispenser .Never
use the hot water corrosive cleaner or chemical solvent. Otherwise it will
damage the appearance of the water dispenser.
Raise the hot water tank and cold tank periodically with puried water.
First pull of the plug. Open the cover then clean the cold water tank with
soft brush. Open the outlet valve cover, clean it with puried water. Then
install it one by one.
Clean the dust on condenser regularly. Dust cleaner or brush can be
used it will affect the heating performance if the electric heating cell is dirty.
You can soak the tube in 3% citric acid then clean it.
This appliance is intended to be used in household and similar appliances such as:
•staff kitchen areas in shops, ofces and other working environment;
• farm houses;
• by client in hotels, motels and other residential type environment;
• bed and breakfast type environments.
This appliance can be used by children aged from 8 years and above
and persons with reduced physical,sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
• Children shall not play with the appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a hazard.
• the appliances are not intended to be operated by means of an external
timer or separate remote-control system.
3 3
up to 95°C, the yellow light will turn on, it’s in the mode of warm-Keeping,
and when the water temperature is below 80°C, the red light will turn on
automatically and the water is heated.
8-The green light will turns off automatically when the temperature is below around 8°C.
9-Turns off the cooling switch when no need for the cold water valve is
the normal temperature.
10-Pull out the plug, and open the outlet valve cover and cold water
valve, exhausting the water in the unit when not using for period of time.
Caution:
Please use bottled puried water of self made super puried water.
Please do not supply the power when there is no water in bottle.
Otherwise it will burn the electric heating cell.
Keep the children away from the hot water in the water dispenser.
Keep the water dispenser at least 10CM away from the wall for ventilation.
Keep the water dispenser away from high temperature place, rain and sun.
Never use the same socket with other appliance at the same time to
avoid the danger only the separate 3-pin socket can be used.
Never connect the ground with water tube, gas tube, telephone line or lighting line.
Do not put the water dispenser horizontally or up-down when necessary,
inclined angle must be more than 45°C.
Please pour the water try timely when there is water in it.
When clean the water tank, please do not use cleaner or chemical agents
which is harmful to health.
About how to use the secured bracket:
-Please use bracket, which can protect the water dispenser from falling down.
-Punch two holes on the side plate, assure the holes punched is same size
as the ones in the middle of the bracket, then fastens the bracket on the
back of water dispenser. After that according to the size of the bracket
holes, punch another two holes of the same size on the wall or xed
object so that to secure the water dispenser.
INSTRUCTION MANUAL
Please read this manual carefully before using
Technical Specications:
The water dispenser with the world advanced technology, Computer
assistance design and streamlined appearance is elegant and easy to use
and possessing the character of low-noise Energy-saving and durability
The device cold and hot tanks electric-heating cell, tube is all made of
stainless steel and compliance with the national standard. You can use the
puried water, stilled water and mineral water as the source. The water
dispenser is the high-class water device in house and place of work. There
are three kinds of temperature mode like cold, hot
and warm you can choose to satisfy your demands like making tea, coffee
and drinking and cold drink In order to make the water dispenser work
effectively and make your life more convenient please read the instruction
Carefully before using.
Instruction:
After unpacking the water dispenser put it on the at, solid and dry oor
Put the bottled puried water upside down stringent into the inlet, open
the hot and cold water valve, there is bubble up in the bottle showing
that the water is owing Into the inner of the the water dispenser.
Hold on the valves until the water until the water running out of the
valves. the water dispenser inner is full of water.
Insert the plug into separate three-pin socket, and the power available
for the water dispenser is 220-240V~ 50/60HZ.
Cold-hot type of the water dispenser can be used to make hot and cold water
separately, or you use the unit making hot and cold water at the same time.
If you need the hot and cold water simultaneously turn on the cold
water switch and hot water switch, and the two Indicators light.
7-The red light turns off automatically when the hot water temperature
1 2
Instruction Manual
DOSWDDT26002
220-240V~ 50/60Hz
Water Dispenser
( Hot & Cold )
Made in China
www.dosel.company
