Dot Hill Systems AssuredSAN 4844 User manual

AssuredSAN Ultra48 Series
Setup Guide
P/N 83-00006723-10-01
Revision A
April 2014
Abstract
This document describes initial hardware setup for Dot Hill AssuredSAN Ultra48 Series controller enclosures, and is intended for use
by storage system administrators familiar with servers and computer networks, network administration, storage system installation
and configuration, storage area network management, and relevant protocols.

Copyright © 2014 Dot Hill Systems Corp. All rights reserved. Dot Hill Systems Corp., Dot Hill, the Dot Hill logo, AssuredSAN, AssuredSnap,
AssuredCopy, AssuredRemote, R/Evolution, and the R/Evolution logo are trademarks of Dot Hill Systems Corp. All other trademarks and registered
trademarks are proprietary to their respective owners.
The material in this document is for information only and is subject to change without notice. While reasonable efforts have been made in the
preparation of this document to assure its accuracy, changes in the product design can be made without reservation and without notification to its
users.

AssuredSAN Ultra48 Series Setup Guide 3
About this guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
CNC ports used for host connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
HD mini-SAS ports used for host connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Intended audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Related documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Document conventions and symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1 Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Front panel components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
48-drive enclosure front panel components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Enclosure bezel installed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Enclosure bezel removed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Enclosure drawers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Disk drives used in Ultra48 Series enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Controller enclosure — rear panel layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4844 controller module — rear panel components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4544 controller module — rear panel components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4144 drive enclosure rear panel components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Component installation and replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cache . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
CompactFlash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Supercapacitor pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2 Installing the enclosures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Installation checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Populating drawers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Opening and closing a drawer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Aligning an AMS or disk module for installation into a drawer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Installing an AMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Installing a disk module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
FDE considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Connecting the controller enclosure and drive enclosures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Connecting the Ultra48 Series controller to the 4144 drive enclosure. . . . . . . . . . . . . . . . . . . . . . . . . 29
Cable requirements for storage enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Summary of drive enclosure cabling illustrations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Testing enclosure connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Powering on/powering off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
AC PSUs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Connect power cord to AC power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Power cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3 Connecting hosts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Host system requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Cabling considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Connecting the enclosure to hosts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
CNC technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Fibre Channel protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
10GbE iSCSI protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
1 Gb iSCSI protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
HD mini-SAS technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
12 Gb mini-SAS ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Connecting direct attach configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Contents

4Contents
Fibre Channel host connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
10GbE iSCSI host connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
1 Gb iSCSI host connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
HD mini-SAS host connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Dual-controller configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Connecting switch attach configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Dual-controller configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Connecting a management host on the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Connecting two storage systems to replicate volumes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Cabling for replication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
CNC ports and replication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Dual-controller configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Updating firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Obtaining IP values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Setting network port IP addresses using DHCP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Setting network port IP addresses using the CLI port and cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Change the CNC port mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Set CNC port mode to iSCSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Set CNC port mode to FC and iSCSI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Configure the system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
4 Basic operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Accessing RAIDar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Configuring and provisioning the storage system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
USB CLI port connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Fault isolation methodology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Basic steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Options available for performing basic steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Use RAIDar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Use the CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Monitor event notification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
View the enclosure LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Performing basic steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Gather fault information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Determine where the fault is occurring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Review the event logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Isolate the fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
If the enclosure does not initialize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Correcting enclosure IDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Stopping I/O. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Diagnostic steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Is the enclosure front panel Fault/Service Required LED amber?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Is the controller back panel FRU OK LED off? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Is the controller back panel Fault/Service Required LED amber? . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Is the drawer panel Fault/Service Required LED amber? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Is the disk drive module LED off? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Is the disk drive module LED blinking blue (4Hz blink rate)? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Is a connected host port Host Link Status LED off? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Is a connected port Expansion Port Status LED off?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Is a connected port’s Network Port link status LED off? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Is the power supply Input Power Source LED off? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Is the Voltage/Fan Fault/Service Required LED amber? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Controller failure in a single-controller configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
If the controller has failed or does not start, is the Cache Status LED on/blinking? . . . . . . . . . . . . . . . . 60
Transporting cache via professional services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Isolating a host-side connection fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Host-side connection troubleshooting featuring CNC ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

AssuredSAN Ultra48 Series Setup Guide 5
Host-side connection troubleshooting featuring SAS host ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Isolating a controller module expansion port connection fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Isolating AssuredRemote replication faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Cabling for replication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Replication setup and verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Diagnostic steps for replication setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Can you successfully use the AssuredRemote feature? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Can you view information about remote links? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Can you create a replication set? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Can you replicate a volume? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Can you view a replication image?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Can you view remote systems? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Resolving voltage and temperature warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Sensor locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Power supply sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Cooling fan sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Temperature sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Power supply module voltage sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
A LED descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Front panel LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Enclosure bezel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Enclosure bezel attachment and removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Enclosure bezel attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Enclosure bezel removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
48-drive enclosure front panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
LEDs visible with enclosure bezel installed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
LEDs visible with enclosure bezel removed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Disk drive LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Controller enclosure — rear panel layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
4844 CNC controller module — rear panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
4544 SAS controller module—rear panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Power supply LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
4144 drive enclosure rear panel LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
B Environmental requirements and specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Safety requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Site requirements and guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Site wiring and AC power requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Weight and placement guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Electrical guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Ventilation requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Cabling requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Management host requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Physical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Environmental requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Electrical requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Site wiring and power requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Power cable requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
C Electrostatic discharge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Preventing electrostatic discharge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Grounding methods to prevent electrostatic discharge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
D USB device connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Rear panel USB ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
USB CLI port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Emulated serial port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Supported host applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Command-line Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

6Contents
Device driver/special operation mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Microsoft Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Obtaining the software download. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Setting parameters for the device driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Using the CLI port and cable—known issues on Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Workaround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
E SFP option for CNC ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Locate the SFP transceivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Install an SFP transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Verify component operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

AssuredSAN Ultra48 Series Setup Guide 7
Figures
1 2U48 enclosure: front panel with bezel installed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2 2U48 enclosure: front panel with bezel removed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3 2U48 enclosure: drawer front and side views with disk slot numbering. . . . . . . . . . . . . . . . . . . . . . . 16
4 2U48 enclosure: sample drawer population . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5 Ultra48 Series high-capacity controller enclosure: rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6 4844 controller module face plate (FC or 10GbE iSCSI). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7 4844 controller module face plate (1 Gb RJ-45) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8 4544 controller module face plate (HD mini-SAS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
9 4144 high-capacity expansion enclosure: rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
10 CompactFlash card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
11 Opening a drawer: loosen the drawer stop screw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
12 Opening a drawer: revolve the handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
13 Opening and closing a drawer: pull or push drawer along slide . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
14 Align AMS or disk module for installation into the drawer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
15 Orient the AMS for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
16 Secure the AMS into the disk bay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
17 Orient the disk for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
18 Secure the disk module into the drive slot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
19 Cabling connections between a controller enclosure and one drive enclosure . . . . . . . . . . . . . . . . . . 30
20 Fault-tolerant cabling between a dual-controller enclosure and three drive enclosures . . . . . . . . . . . . . 30
21 AC PSU with power switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
22 AC power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
23 Connecting hosts: direct attach—one server/one HBA/dual path . . . . . . . . . . . . . . . . . . . . . . . . . . 37
24 Connecting hosts: direct attach—two servers/one HBA per server/dual path . . . . . . . . . . . . . . . . . . 37
25 Connecting hosts: direct attach—four servers/one HBA per server/dual path . . . . . . . . . . . . . . . . . . 37
26 Connecting hosts: direct attach—four servers/one HBA per server/dual path . . . . . . . . . . . . . . . . . . 38
27 Connecting hosts: switch attach—two servers/two switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
28 Connecting hosts: switch attach—four servers/multiple switches/SAN fabric. . . . . . . . . . . . . . . . . . . 39
29 Connecting two storage systems for AssuredRemote: multiple servers/one switch/one location . . . . . . 42
30 Connecting two storage systems for AssuredRemote: multiple servers/switches/one location. . . . . . . . 42
31 Connecting two storage systems for AssuredRemote: multiple servers/switches/two locations . . . . . . . 43
32 Connecting two storage systems for AssuredRemote: multiple servers/SAN fabric/two locations . . . . . 44
33 Connecting a USB cable to the CLI port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
34 Front panel enclosure bezel: 48-drive enclosure (2U48) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
35 Partial assembly showing bezel alignment with 2U48 chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
36 Drawer detail showing handle rotation and drawer travel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
37 LEDs: 2U48 enclosure front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
38 LEDs: 2U48 drawer front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
39 LEDs: Disk drive modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
40 Ultra48 Series controller enclosure: rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
41 LEDs: 4844 CNC controller module (FC and 10GbE SFPs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
42 LEDs: 4844 CNC controller module (1 Gb RJ-45 SFPs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
43 LEDs: 4544 SAS controller module (HD mini-SAS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
44 LEDs: Power supply units — rear panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
45 LEDs: 4144 drive enclosure — rear panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
46 Rackmount enclosure dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
47 USB device connection — CLI port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
48 Install a qualified SFP option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

8Figures

AssuredSAN Ultra48 Series Setup Guide 9
Tables
1 Related documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2 Document conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3 Installation checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4 Terminal emulator display settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5 Terminal emulator connection settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
6 Diagnostics LED status: Front panel “Fault/Service Required” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
7 Diagnostics LED status: Rear panel “FRU OK” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
8 Diagnostics LED status: Rear panel “Fault/Service Required” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
9 Diagnostics LED status: Drawer panel “Fault/Service Required”. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
10 Diagnostics LED status: Disk LED off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
11 Diagnostics LED status: Disk drive module fault status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
12 Diagnostics LED status: Rear panel “Host Link Status” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
13 Diagnostics LED status: Rear panel “Expansion Port Status” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
14 Diagnostics LED status: Rear panel “Network Port Link Status” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
15 Diagnostics LED status: Rear panel power supply “Input Power Source” . . . . . . . . . . . . . . . . . . . . . . . 59
16 Diagnostics LED status: Rear panel power supply “Voltage/Fan Fault/Service Required” . . . . . . . . . . . 59
17 Diagnostics LED status: Rear panel “Cache Status”. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
18 Diagnostics for replication setup: Using AssuredRemote feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
19 Diagnostics for replication setup: Viewing information about remote links . . . . . . . . . . . . . . . . . . . . . . 65
20 Diagnostics for replication setup: Creating a replication set. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
21 Diagnostics for replication setup: Replicating a volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
22 Diagnostics for replication setup: Viewing a replication image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
23 Diagnostics for replication setup: Viewing a remote system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
24 Power supply sensor descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
25 Cooling fan sensor descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
26 Controller module temperature sensor descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
27 Power supply temperature sensor descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
28 Voltage sensor descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
29 LEDs: Disks in 2U48 enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
30 LEDs: Vdisks in 2U48 enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
31 Power requirements - AC Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
32 Rackmount controller enclosure weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
33 Rackmount compatible drive enclosure weights (ordered separately) . . . . . . . . . . . . . . . . . . . . . . . . . 87
34 Operating environmental specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
35 Non-operating environmental specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
36 Supported terminal emulator applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
37 USB vendor and product identification codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92

10 Tables

AssuredSAN Ultra48 Series Setup Guide 11
About this guide
Overview
This guide provides information about initial hardware setup for the AssuredSAN™ Ultra48 Series storage
enclosure products listed below:
•CNC (Converged Network Controller) controller enclosure: 4844
• Qualified Fibre Channel SFP option supporting (4/8/16 Gb)
• Qualified Internet SCSI (10GbE) SFP option
• Qualified Internet SCSI (1 Gb) Copper RJ-45 SFP option
•HD mini-SAS (12 Gb) controller enclosure: 4544
AssuredSAN Ultra48 Series provides high-capacity storage enclosures supporting up to 48 2.5" small form
factor (SFF) disks in a 2U chassis. The chassis form factor supports controller enclosures and expansion
enclosures. Storage enclosures are equipped with dual I/O modules (IOMs); and they are equipped with
two AC power supply modules.
The Ultra48 Series controller enclosures can optionally be cabled to 4144 drive enclosures for adding
storage. A maximum of four enclosures (including the controller enclosure) are supported.
See the Dot Hill web site for more information about specific storage product models and uses:
http://www.dothill.com.
CNC ports used for host connection
AssuredSAN 4844 models use Converged Network Controller (CNC) technology, allowing you to select
the desired host interface protocol from the available Fibre Channel (FC) or Internet SCSI (iSCSI) host
interface protocols supported by the system. You can use the Command-line Interface (CLI) to set all
controller module CNC ports to use one of these host interface protocols:
•16 G b F C
•8 Gb FC
•4 Gb FC
•10 GbE iSCSI
•1 GbE iSCSI
Alternatively, you can use the CLI to set CNC ports to support a combination of host interface protocols.
When configuring a combination of host interface protocols, host ports 0 and 1 are set to FC (either
both16 Gbit/s or both 8 Gbit/s), and host ports 2 and 3 must be set to iSCSI (either both 10GbE or both
1 Gbit/s), provided the CNC ports use the qualified SFP connectors and cables required for supporting
the selected host interface protocol. See CNC technology on page 33 and 4844 CNC controller module
— rear panel LEDs on page 78 for more information.
TIP: See the “Configuring host ports” topic within the RAIDar User Guide for information about
configuring CNC ports with host interface protocols of the same type or a combination of types.
IMPORTANT: AssuredSAN 4844 models ship with CNC ports initially configured for FC. When
connecting CNC ports to iSCSI hosts, you must use the CLI (not RAIDar) to specify which ports will use
iSCSI. It is best to do this before inserting the iSCSI SFPs into the CNC ports (see Change the CNC port
mode on page 48 for instructions).

12 About this guide
HD mini-SAS ports used for host connection
AssuredSAN 4544 models provide four high-density mini-SAS (HD mini-SAS) ports per controller module.
The HD mini-SAS host interface protocol uses the SFF-8644 external connector interface defined for
SAS3.0 to support a link rate of 12 Gbit/s using the qualified connectors and cable options. See
4544 SAS controller module—rear panel LEDs on page 80 for more information.
Intended audience
This guide is intended for storage system administrators.
Prerequisites
Prerequisites for installing and using this product include knowledge of:
•Servers and computer networks
•Network administration
•Storage system installation and configuration
•Storage area network (SAN) management and direct attach storage (DAS)
•Fibre Channel (FC), Internet SCSI (iSCSI), Serial Attached SCSI (SAS), and Ethernet protocols
Related documentation
* Printed document included in product shipkit.
For additional information, see Dot Hill’s Customer Resource Center web site: http://crc.dothill.com.
Table 1 Related documents
For information about See
Enhancements, known issues, and late-breaking
information not included in product documentation
Release Notes
Overview of product shipkit contents and setup tasks Getting Started*
Using a rackmount bracket kit to install an enclosure
into a rack
AssuredSAN Rackmount Bracket Kit Installation*
Obtaining and installing a license to use licensed
features
AssuredSAN 4004 Series Obtaining and Installing a
License Certificate File
Using the web interface to configure and manage the
product
AssuredSAN 4004 Series RAIDar User Guide
Using the command-line interface (CLI) to configure
and manage the product
AssuredSAN 4004 Series CLI Reference Guide
Event codes and recommended actions AssuredSAN Event Descriptions Reference Guide
Identifying and installing or replacing field-replaceable
units (FRUs)
AssuredSAN Ultra48 Series FRU Installation and
Replacement Guide

AssuredSAN Ultra48 Series Setup Guide 13
Document conventions and symbols
CAUTION: Indicates that failure to follow directions could result in damage to equipment or data.
IMPORTANT: Provides clarifying information or specific instructions.
NOTE: Provides additional information.
TIP: Provides helpful hints and shortcuts.
Table 2 Document conventions
Convention Element
Blue text Cross-reference links and e-mail addresses
Blue, underlined text Web site addresses
Bold text •Key names
•Text typed into a GUI element, such as into a box
•GUI elements that are clicked or selected, such as menu and list
items, buttons, and check boxes
Italic text Text emphasis
Monospace text •File and directory names
•System output
•Code
•Text typed at the command-line
Monospace, italic text •Code variables
•Command-line variables
Monospace, bold text Emphasis of file and directory names, system output, code, and text
typed at the command-line

14 About this guide

AssuredSAN Ultra48 Series Setup Guide 15
1Components
Front panel components
AssuredSAN Ultra48 Series supports 2U48 enclosures. The 2U48 chassis—configured with up to 48 2.5"
small form factor (SFF) disks—is used as either a controller enclosure or expansion enclosure.
Supported expansion enclosures are used for adding storage. The 4144 is the high-capacity 2U48 drive
enclosure used for adding storage. The 4144 is briefly described in this guide.
Storage enclosures support dual I/O modules (IOMs), and they are equipped with two redundant AC
power supply modules.
48-drive enclosure front panel components
Enclosure bezel installed
When the enclosure is in operation, the bezel should be installed on the front panel as shown in Figure 1.
The enclosure bezel is equipped with an EMI (Electromagnetic Interface) shield to provide protection for the
disks.
Figure 1 2U48 enclosure: front panel with bezel installed
TIP: See Enclosure bezel attachment and removal on page 71 and Figure 35 on page 72 (2U48).
NOTE: Front and rear panel LEDs for controller enclosures are described in LED descriptions.
1Enclosure ID LED
2Enclosure status LED: Unit Locator
3Enclosure status LED: Fault/Service Required
4Enclosure status LED: FRU OK
5Enclosure status LED: Temperature Fault
OK
2
3
4
5
Note: Remove this enclosure bezel to access the front panel components shown below1, 2
1

16 Components
Enclosure bezel removed
To access the drawers, you must remove the enclosure bezel (shown removed in Figure 2).
Figure 2 2U48 enclosure: front panel with bezel removed
Enclosure drawers
You can open the enclosure drawers to access the disks. Drawers 0 and 1 provide access to disk bays from
the right side of the drawer; whereas drawer 2 provides access to disk bays from the left side of the
drawer. These respective side views—or profiles—are shown below.
Figure 3 2U48 enclosure: drawer front and side views with disk slot numbering
Your 2U48 enclosure is shipped with the drawers installed, but they are not populated with disks.
Depending on the your product configuration, disk bay blanks—also known as Air Management Solution
(AMS) inserts—might be installed. Locate the box containing your sledded disks and AMS inserts (if
applicable) in preparation for populating the drive slots.
•See Table 3 on page 23 for sequential tasks required for successful enclosure installation.
•See Populating drawers on page 24 for instructions on installing disks and AMS inserts.
1Enclosure ear LEDs (see Figure 1 on page 15)
2Thumbscrew for securing or accessing drawer
3Disabled button (used by engineering only)
4Drawer handle (shown in stowed position)
5Drawer status LED: FRU OK
6Drawer status LED: Fault/Service Required
7Drawer status LED: OK to Remove
8Drawer status LED: Unit Locator
1 20
61 7
2
Left ear Right ear
Note: Integers atop drawers indicate drawer numbering sequence.
OK
(Silk screens on bezel)
14
358
Drawer Profiles
Disk bays with sequentially−numbered disk slots
Right side view
(Revolved Y −90°)
Left side view
(Revolved Y +90°)
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
0
1
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Right side view
(Revolved Y −90°)
2

AssuredSAN Ultra48 Series Setup Guide 17
IMPORTANT: Disk drive slot numbering is also provided on the label that is laminated to the sheet metal
housing (top face) on each drawer. Refer to the drawer label when installing disks into the drawer.
Figure 4 below provides a sample partial configuration of disk bays within a drawer. The bay on the left is
populated with four disks, whereas the adjacent bay on the right contains an AMS insert to manage air
flow within the enclosure to maintain optimal operating temperature.
1The disk is oriented in the sled such that its PCBA faces upward on the top side of the disk drive module as shown.
2Electromagnetic interface protection for disk drives is provided by the EMI shield within the enclosure bezel.
3The AMS insert spans an entire disk bay (4 slots). A single disk slot AMS might become a future option.
Figure 4 2U48 enclosure: sample drawer population
IMPORTANT: Empty bays will cause overheating. To avoid overheating, install an AMS insert in disk bays
that do not contain quantity four disk drive modules.
Disk drives used in Ultra48 Series enclosures
Ultra48 Series enclosures support SFF Midline SAS, SFF Enterprise SAS, and SFF SSD disks. They also
support LFF/SFF Midline SAS and LFF/SFF Enterprise self-encrypting disks that work with the Full Disk
Encryption (FDE) feature. For information about creating vdisks and adding spares using different disk
drive types, see the AssuredSAN 4004 Series RAIDar User Guide or online help. Also see FDE
considerations on page 27.
12.5" sledded disk module assembly pictorial1, 2
2Disk drive status LED (see Disk drive LED on page 75)
32.5" disk drive module (installed in 3 of 4 disk bays)
4Air Management Solution (AMS) insert (installed)3
5AMS insert pictorial3
123 5
4
Disks and AMS installed in drive slots
(partial view of a 4-bay drawer)

18 Components
Controller enclosure — rear panel layout
The diagram and table below display and identify important component items that comprise the rear panel
layout of an AssuredSAN Ultra48 Series controller enclosure. The 4844 is shown as a representative
example of 2U48 controller enclosure models included in the product series.
Figure 5 Ultra48 Series high-capacity controller enclosure: rear panel
A controller enclosure accommodates two AC power supply FRUs within the two power supply slots (see
two instances of callout No.1 above). The controller enclosure accommodates two controller module FRUs
of the same type within the I/O module (IOM) slots (see callouts No.3 and No.4 above).
IMPORTANT: Ultra48 Series controller enclosures support dual-controller configuration only.
Single-controller support is provided only when a controller fails over to its partner controller. A controller
module must be installed in each IOM slot to ensure sufficient airflow through the enclosure during
operation.
The diagrams with tables that immediately follow provide descriptions for the controller modules and
power supply modules that can be installed into the rear panel of an Ultra48 Series controller enclosure.
Showing controller modules and power supply modules separately from the enclosure enables improved
clarity in identifying the component items called out in the diagrams and described in the tables.
Descriptions are also provided for optional drive enclosures supported by Ultra48 Series controller
enclosures for expanding storage capacity.
NOTE: Ultra48 Series enclosures support hot-plug replacement of redundant controller modules, fans,
power supplies, and expansion modules. Hot-add replacement of drive enclosures is also supported.
1AC power supply
2AC power switch
3Controller module A (see face plate detail figures)
4Controller module B (see face plate detail figures)
CACHE
LINK
ACT
6Gb/s
CACHE
LINK
ACT
6Gb/s
CLI
CLI
PORT 2 PORT 3
SERVICE−1SERVICE−2
PORT 0 PORT 1
CLI
CLI
PORT 2 PORT 3
SERVICE−1SERVICE−2
PORT 0 PORT 1
1 1
4
2 2
3

AssuredSAN Ultra48 Series Setup Guide 19
4844 controller module — rear panel components
Figure 6 shows CNC ports configured with SFPs supporting either 4/8/16 Gb FC or 10GbE iSCSI. The
SFPs look identical. Refer to the CNC LEDs that apply to the specific configuration of your CNC ports.
Figure 6 4844 controller module face plate (FC or 10GbE iSCSI)
Figure 7 shows CNC ports configured with 1 Gb RJ-45 SFPs.
Figure 7 4844 controller module face plate (1 Gb RJ-45)
NOTE: See CNC ports used for host connection on page 11 for more information about CNC technology. For
CNC port configuration, see the “Configuring host ports” topic within the RAIDar User Guide or online help.
1CNC ports used for host connection or replication
(see Install an SFP transceiver on page 95)
2CLI port (USB - Type B) [see Appendix D]
3Service port 2 (used by service personnel only)
4Reserved for future use
5Network port
6Service port 1 (used by service personnel only)
7Disabled button (used by engineering only)
(Sticker shown covering the opening)
8mini-SAS expansion port
1CNC ports used for host connection or replication
(see Install an SFP transceiver on page 95)
2CLI port (USB - Type B) [see Appendix D]
3Service port 2 (used by service personnel only)
4Reserved for future use
5Network port
6Service port 1 (used by service personnel only)
7Disabled button (used by engineering only)
(Sticker shown covering the opening)
8mini-SAS expansion port
CACHE
CLI
CLI
LINK
ACT
6Gb/s
SERVICE−1SERVICE−2
PORT 0 PORT 1 PORT 2 PORT 3
5
2 3 6 8
17
4
= FC LEDs
= 10GbE iSCSI LEDs
CACHE
CLI
CLI
LINK
ACT
6Gb/s
SERVICE−1SERVICE−2
PORT 0 PORT 1 PORT 2 PORT 3
5
2 3 6 8
17
4
= FC LEDs
= 1Gb iSCSI LEDs (all CNC ports use 1 Gb RJ-45 SFPs in this figure)

20 Components
4544 controller module — rear panel components
Figure 8 shows host ports configured with 12 Gbit/s HD mini-SAS (SFF-8644) connectors.
Figure 8 4544 controller module face plate (HD mini-SAS)
4144 drive enclosure rear panel components
AssuredSAN Ultra48 Series controller enclosures support the high-capacity 2U48 drive enclosure for
adding storage. The 4144 expansion enclosure uses the same 2.5" SFF disk drive modules use by the
Ultra48 Series controller enclosures (see Figure 4 on page 17 for a visual representation of disk drive
modules and AMS inserts used by the 4144). The 4144 uses mini-SAS (SFF-8088) connectors to facilitate
back-end SAS expansion. See Cable requirements for storage enclosures on page 29 for cabling
information.
Figure 9 4144 high-capacity expansion enclosure: rear panel
Component installation and replacement
Installation and replacement of Ultra48 Series FRUs (field-replaceable units) is addressed in the
AssuredSAN Ultra48 Series FRU Installation and Replacement Guide within the “Procedures” chapter.
FRU procedures facilitate replacement of a damaged chassis or chassis component:
•Replacing a controller or expansion module
•Replacing a disk drive module
1HD mini-SAS ports used for host connection
2CLI port (USB - Type B) [see Appendix D]
3Service port 2 (used by service personnel only)
4Reserved for future use
5Network port
6Service port 1 (used by service personnel only)
7Disabled button (used by engineering only)
(Sticker shown covering the opening)
8mini-SAS expansion port
CACHE
CLI
CLI
LINK
ACT
6Gb/s
SERVICE−1SERVICE−2
ACT
LINK 12Gb/s S
S
A
ACT
LINK
SAS 0 SAS 1
ACT
LINK 12Gb/s S
S
A
ACT
LINK
SAS 2 SAS 3
5
2 3 6 8
17
4
1AC Power supply
2AC Power supply switch
3Expansion module A
4Expansion module B
5Disabled button (used by engineering/test only)
6Service port (used by service personnel only)
7SAS In port
8SAS Out port
IN OUT
IN OUT
6Gb/s 6Gb/s
6Gb/s 6Gb/s
167 85 1
4
22
3
