Technical Data
B-7.1,2,3,4 -Auto, LitePak Panels
Components 7.1 www.DouglasLightingControls.com
Programmable LitePak Panels L i t e P a k
PART No. SPECIFICATION
DESCRIPTION
DIMENSIONS & MOUNTING
LitePak Panel Ratings
nLitePak panels use Douglas 2wire HID
relays rated for all types of lighting loads.
n120/277V Panels contain 8 or 16 relays.
Rating: 20A @120/277V UL
20A @120/347V CSA
Max conductor size: 12 AWG
n277/480V panels contain 4 or 8, 2pole relays.
Rating: 20A @120/277/480V UL
20A @120/277/347V CSA
Max conductor size: 10 AWG
nPower supply:
120/277V Transformer, Class 2, UL
120/347V Transformer, Class 2, CSA
LitePak Controller Module
n8 time and/or photo controlled outputs,
each connected to a relay permitting
each relay to have a unique program.
Up to 4 relays can be controlled by an
output to share the same program.
Programming
nMembrane key pad with LCD display
graphic. Built-in prompts to guide users.
nAny output can be time, astro, photo
controlled or combination of time and
photo/astro controlled.
nUp to 900 events per week.
nSet any output schedule to run on any
week day (Su-Mo-Tu-W-Th-F-Sa) or on
any specific date or dates (holidays).
nThe controller's memory and time are
not lost when power fails. Programs
are held indefinitely and time is held for
a minimum of 72 hours.
Sensor & Switch Options
nWPS-5527K Remote Photo Sensor.
Range: 0 to 6,500 fc (0-65,000 lux), ±5%;
Using sensor, any output can be set to
switch at a specific light level.
(eg1: ON 5fc; OFF 15fc Dusk-to-Dawn)
(eg2: ON 2000fc; OFF 4000fc Skylight)
nFor remote switching, use any model of
Douglas 2wire relay switch.
Environment
nIndoors, stationary, non-vibrating, non-
corrosive atmosphere and non-
condensing humidity.
nAmbient operating temperature:
+15° to +120°F (-10° to +50°C).
120/277
WPAK-33518-S*
8-relay Control Panel
WPAK16-3351-S*
16-relay Control Panel
WPAK-33018-S*
Expansion Panel
120/347
WPAK-33318-S*
8-relay Control Panel
WPAK16-3331-S*
16-relay Control Panel
WPAK-33018-S*
Expansion Panel
277/480
WPAK-33524-S*
Four 2pole-Relay Panel
WPAK16-3352-S*
Eight 2pole-Relay Panel
WPAK-33024-S*
Expansion Panel
* -S = Surface Cover
-F = Flush Cover
Output 1
Output 2
Output 3
Output 4
Output 5
Output 6
Output 7
Output 8
Sensor 1
Sensor 2
Maste r Sw
Blue
White
White
White
Output 1
Output 2
Output 3
Output 4
Output 5
Output 6
Output 7
Output 8
123456789101112
Sensor !
Sensor 2
Maste r Sw
Maste r Sw Blue
(Pre0connec ted)
Blue
White
White
White
LitePak Panel (hinged cover open)
n Cover latch can be locked if desired.
n Open cover to access control module
or manual switching levers built into relays.
W
24VAC
Power
Sw
2
Sw
1
Sw
5
Sw
4
Sw
3
Group
Sw
LitePak Panel (cover removed,
controller door open)
n Remove cover to access line voltage circuits.
Optional Remote Switches
Connect standard Douglas switches
direct to relays for remote override.
Group switch input on controller can
switch some or all of the outputs.
Optional Remote Photo Sensor
Range: 0 to 6,500 fcandles (±5%).
Each output can have a unique setting.
If sensor not installed, use astronomic
function for dusk-to-dawn applications.
Controller Module
LCD display and membrane keypad
used to view/edit settings and schedules.
Eight outputs, each has a unique schedule.
14"
(356)
12"
(305)
4.5"
(114)
n
Indoor applications only.
Surface mount Nema 1 Enclosure.
nRemove cover to access 1/4" mounting
holes and attach to wall.
ABCD
Esc Clr
123
456
789
0
Power
Directions:
• ButtonsA, B , C & D selectoptionss hownat thebottom ofthe display. Followprompts
whichappearon the displayto set up theunit and/orview/editprograms.
• Use only to c ontrolDou glas Relays. This unit can be set to do s ome or all of the following:
- Standard Time Schedules: O N/O FF, Repeat O F F & Flick-Warn OFF.
- AstronomicControl:
Du sk-to-Daw n & Dusk-to-Dawn withTim e control.
- PhotocellControl:
D usk- to-Dawn , Dusk-to-Daw n w ith T ime contro l.S etpoints for each outpu t
can be unique t o suit dif feren t a pp lic atio ns (N ot e: Re qui res W P S-5 52 7 Sen s or ).
- Timed-ONm ode: A r e la y th a t is s wi tc he d O N with a loca l s w itc h w i ll b e au t om a ti cal ly
switchedOFFaftera"Timed-ON"period(adjustable).The"TimedON"modecanbe
sched ule d to be active f o r ce rt ain pe riod s (e.g. : eve nin gs).
• Fo r mo re inform ati o n , plea se r efer to "L iteP a k P a ne l s - A p p lic atio n s & I n str uc ti ons ".
n
All purpose panels suitable for
controlling all types of lighting loads
including HID ballasts and lamps.
Each panel has an 8 output
controller and 8 or 16 HID relays.
If needed, use an Expansion Panel
to increase capacity.
n
LitePak panels are equipped with a
controller unit that uses a self-
prompting graphical LCD display
and keypad. Several features are
available including: time
scheduling, astronomic, flick warn
and time-out.
n
Optional WPS-5527K photo sensor
permits the setting of precise
numeric light levels for each output
if desired.
n
Remote switch stations can be
connected to permit easy user
override. Indicating, non-indicating
and keyed switches are available.
24V Transformer
120/277 V primary, 24V sec @ 75VA
Class 2 control transformer.
Loads
8 relays
16 relays
8 or 16 Douglas 2wire HID Relays
Suitable for all types of lighting loads
including HID.
Relays have a manual control lever built in
and are latching.
Thus they will retain state (ON or OFF)
even if the controller module is
disconnected. This feature permits easy
testing during installation and provides a
guaranteed override provision for the
occupant.
Output1
Output2
Output3
Output4
Output5
Output6
Output7
Output8
123456789101112
Sensor!
Sensor2
Master Sw
Master Sw Blue
(Pre0connected)
Blue
White
White
White
8 relays
16 relays
8-relay models
L i t e P a k
lighting controls
L i t e P a k
lighting controls
16-relay models
23"
(584)
12"
(305)
N
ABCD
Esc Clr
123
456
789
0
Power
Directions:
•ButtonsA,B,C&Ds el ect option s sh ow n at thebottomofthedisplay.Followprompts
whichap pe aro n t he d is play toset upth e unit and/or v ie w/ed i tpr o grams .
•Us e on lyt o co ntr ol DouglasRelays. Thi s un i t ca n be se tt o d o some or a ll of thefollowing:
-StandardTimeSchedules:
ON/OFF , R epeatOFF &Fl ick -WarnOFF.
-Astronom i c Control: Dusk-to-Dawn&Dusk-to-DawnwithTimecontrol.
-PhotocellControl:
Dusk-t o- Da w n, D usk- t o- D aw n withTimecont r ol . Se tp oi nts f or eacho ut put
canbeu niq ue t o sui t diff eren t ap pl ica tions (No te: R equ ires WP S -5527 Sensor ).
-Timed-ONmode:A relayt ha t is swi tch ed O Nw ith a l ocal switchwillbeau tomatica ll y
switchedOF F af ter a "Ti med -ON"period(adjust abl e) .T he " Tim ed ON "mod e c an be
s che dul ed to be act i ve fo rce rtainperiods( e. g. : e veni ngs).
•Formo re in for mat i on , pl ea se r ef er to"LitePakPanels-Applications&Instructions".

Technical Data
B-7.1,2,3,4 -Auto, LitePak Panels
www.DouglasLightingControls.comComponents 7.2
Programmable LitePak Panels L i t e P a k
