Woodward 2301E-HT User manual

Product Manual 35092
(Revision A, 1/2019)
Original Instructions
2301E-HT Hydro (Francis Turbines)
P/N 8237-2046
Installation and Operation Manual
Released

General
Precautions
Read this entire manual and all other publications pertaining to the work to be
performed before installing, operating, or servicing this equipment.
Practice all plant and safety instructions and precautions.
Failure to follow instructions can cause personal injury and/or property damage.
Revisions
This publication may have been revised or updated since this copy was produced.
To verify that you have the latest revision, check Manual 26455, Customer
Publication Cross Reference and Revision Status & Distribution Restrictions, on
the publications page of the Woodward website:
www.woodward.com/publications
The latest version of most publications is available on the publications page. If
your publication is not there, please contact your customer service representative
to get the latest copy.
Proper Use
Any unauthorized modifications to or use of this equipment outside its specified
mechanical, electrical, or other operating limits may cause personal injury and/or
property damage, including damage to the equipment. Any such unauthorized
modifications: (i) constitute "misuse" and/or "negligence" within the meaning of
the product warranty thereby excluding warranty coverage for any resulting
damage, and (ii) invalidate product certifications or listings.
Translated
Publications
If the cover of this publication states "Translation of the Original Instructions"
please note:
The original source of this publication may have been updated since this
translation was made. Be sure to check Manual 26455, Customer Publication
Cross Reference and Revision Status & Distribution Restrictions, to verify whether
this translation is up to date. Out-of-date translations are marked with . Always
compare with the original for technical specifications and for proper and safe
installation and operation procedures.
Revisions—A bold, black line alongside the text identifies changes in this publication since the
last revision.
Woodward reserves the right to update any portion of this publication at any time. Information provided by Woodward is
believed to be correct and reliable. However, no responsibility is assumed by Woodward unless otherwise expressly
undertaken. Manual 35092
Copyright © Woodward, Inc. 2017-2019
All Rights Reserved
Released

Manual 35092 2301E-HT Hydro (Francis Turbines)
Woodward 1
Contents
WARNINGS AND NOTICES .......................................................................... 3
ELECTROSTATIC DISCHARGE AWARENESS................................................. 4
REGULATORY COMPLIANCE....................................................................... 5
CHAPTER 1. GENERAL INFORMATION ......................................................... 7
CHAPTER 2............................................................................................... 8
Installation...............................................................................................................8
CHAPTER 3. CONTROL OVERVIEW............................................................ 11
Introduction...........................................................................................................11
Description of I/O..................................................................................................11
Control Inputs .......................................................................................................11
Control Outputs ....................................................................................................13
External I/O...........................................................................................................14
Communications...................................................................................................16
2301E-HT Functions.............................................................................................16
Control Diagram ...................................................................................................31
CHAPTER 4. ENTERING CONTROL SETPOINTS........................................... 33
Introduction...........................................................................................................33
Control Assistant PC Interface .............................................................................33
Configure Menu Descriptions...............................................................................35
CHAPTER 5PRODUCT SUPPORT AND SERVICE OPTIONS ........................... 56
Product Support Options......................................................................................56
Product Service Options.......................................................................................56
Returning Equipment for Repair...........................................................................57
Replacement Parts...............................................................................................57
Engineering Services............................................................................................58
Contacting Woodward’s Support Organization ....................................................58
Technical Assistance............................................................................................59
APPENDIX A. MODBUS LIST..................................................................... 60
APPENDIX B. SERVICE/CONFIGURATION CHART........................................ 68
SPECIFICATIONS...................................................................................... 78
REVISION HISTORY.................................................................................. 79
DECLARATIONS....................................................................................... 80
The following are trademarks of their respective companies:
Modbus (Schneider Automation Inc.)
Released

Manual 35092 2301E-HT Hydro (Francis Turbines)
Woodward 2
Illustrations and Tables
Figure 2-1a. 2301E-HT Control Wiring Diagram (1 of 3)........................................8
Figure 2-1b. 2301E-HT Control Wiring Diagram (2 of 3)........................................9
Figure 2-1c. 2301E-HT Control Wiring Diagram Notes........................................10
Figure 3-1. AIO Loop-Powered LINKnet HT.........................................................15
Figure 3-2. AIO Self-Powered LINKnet HT ..........................................................15
Figure 3-3. Gate Limit...........................................................................................17
Figure 3-4. Speed Deadband Function ................................................................18
Figure 3-5. Gate Position......................................................................................20
Figure 3-6. Pond Level Control Accuracy.............................................................24
Figure 3-7a. Control Diagram (1 of 2) ..................................................................31
Figure 3-7b. Control diagram (2 of 2)...................................................................32
Figure 4-1. Control Assistant................................................................................33
Figure 4-2. Inspector ............................................................................................34
Figure 4-3. RS-232...............................................................................................34
Figure 4-4. RS-422...............................................................................................34
Table 3-1. Commands..........................................................................................30
Released

Manual 35092 2301E-HT Hydro (Francis Turbines)
Woodward 3
Warnings and Notices
Important Definitions
This is the safety alert symbol used to alert you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid possible injury or death.
DANGER - Indicates a hazardous situation, which if not avoided, will result in death or serious injury.
WARNING - Indicates a hazardous situation, which if not avoided, could result in death or serious
injury.
CAUTION - Indicates a hazardous situation, which if not avoided, could result in minor or moderate
injury.
NOTICE - Indicates a hazard that could result in property damage only (including damage to the
control).
IMPORTANT - Designates an operating tip or maintenance suggestion.
Overspeed /
Overtemperature /
Overpressure
The engine, turbine, or other type of prime mover should be
equipped with an overspeed shutdown device to protect against
runaway or damage to the prime mover with possible personal injury,
loss of life, or property damage.
The overspeed shutdown device must be totally independent of the
prime mover control system. An overtemperature or overpressure
shutdown device may also be needed for safety, as appropriate.
Personal Protective
Equipment
The products described in this publication may present risks that
could lead to personal injury, loss of life, or property damage.
Always wear the appropriate personal protective equipment (PPE) for
the job at hand. Equipment that should be considered includes but is
not limited to:
Eye Protection
Hearing Protection
Hard Hat
Gloves
Safety Boots
Respirator
Always read the proper Material Safety Data Sheet (MSDS) for any
working fluid(s) and comply with recommended safety equipment.
Start-up
Be prepared to make an emergency shutdown when starting the
engine, turbine, or other type of prime mover, to protect against
runaway or overspeed with possible personal injury, loss of life, or
property damage.
Automotive
Applications
On- and off-highway Mobile Applications: Unless Woodward's
control functions as the supervisory control, customer should install
a system totally independent of the prime mover control system that
monitors for supervisory control of engine (and takes appropriate
action if supervisory control is lost) to protect against loss of engine
control with possible personal injury, loss of life, or property
damage.
Released

Manual 35092 2301E-HT Hydro (Francis Turbines)
Woodward 4
Battery Charging
Device
To prevent damage to a control system that uses an alternator or
battery-charging device, make sure the charging device is turned off
before disconnecting the battery from the system.
Electrostatic Discharge Awareness
Electrostatic
Precautions
Electronic controls contain static-sensitive parts. Observe the
following precautions to prevent damage to these parts:
Discharge body static before handling the control (with power to
the control turned off, contact a grounded surface and maintain
contact while handling the control).
Avoid all plastic, vinyl, and Styrofoam (except antistatic
versions) around printed circuit boards.
Do not touch the components or conductors on a printed circuit
board with your hands or with conductive devices.
To prevent damage to electronic components caused by improper
handling, read and observe the precautions in Woodward Manual
82715, Guide for Handling and Protection of Electronic Controls,
Printed Circuit Boards, and Modules.
Follow these precautions when working with or near the control.
1. Avoid the build-up of static electricity on your body by not wearing clothing made of synthetic
materials. Wear cotton or cotton-blend materials as much as possible because these do not store
static electric charges as much as synthetics.
2. Do not remove the printed circuit board (PCB) from the control cabinet unless absolutely necessary.
If you must remove the PCB from the control cabinet, follow these precautions:
Do not touch any part of the PCB except the edges.
Do not touch the electrical conductors, the connectors, or the components with conductive
devices or with your hands.
When replacing a PCB, keep the new PCB in the plastic antistatic protective bag it comes in
until you are ready to install it. Immediately after removing the old PCB from the control cabinet,
place it in the antistatic protective bag.
External wiring connections for reverse-acting controls are identical
to those for direct-acting controls.
Released

Manual 35092 2301E-HT Hydro (Francis Turbines)
Woodward 5
Regulatory Compliance
European Compliance for CE Mark
These listings are limited only to those units bearing the CE Marking.
EMC Directive:
Declared to Directive 2014/30/EU of the European
Parliament and of the Council of 26 February 2014 on the
harmonization of the laws of the Member States relating to
electromagnetic compatibility (EMC)
Machinery Directive:
Compliant as partly completed machinery with Directive
2006/42/EC of the European Parliament and the Council of
17 May 2006 on machinery.
ATEX –Potentially
Explosive Atmospheres
Directive:
Directive 2014/34/EU on the harmonisation of the laws of
the Member States relating to equipment and protective
systems intended for use in potentially explosive
atmospheres
Zone 2, Category 3, Group II G, Ex nA IIC T3 Gc X
Zone 2, Category 3, Group II G, Ex nA IIC T4 Gc X
Low Voltage Directive:
Directive 2014/35/EU on the harmonisation of the laws of
the Member States relating to the making available on the
market of electrical equipment designed for use within
certain voltage limits
North American Compliance
These listings are limited only to those units bearing the appropriate CSA identification and marking.
CSA: CSA Certified for Class I, Division 2, Groups A, B, C, D, T3 or T4 Hazardous
Locations and ordinary locations at 70 °C ambient. For use in Canada and
the United States.
Certificate 1150575
NOTE—Wiring must be in accordance with applicable electric codes with the authority having jurisdiction.
T3 when the Potential Transformer input is 240 Vac
T4 when the Potential Transformer input is 120 Vac or less
Marine Compliance
American Bureau ABS Rules 2012 SVR 1-1-4/7.7, 1-1-A3, 4-2-1/7.3,
of Shipping: 7.5.1; 4-9-3/17, 4-9-4/23 & 4-9-7/Table 9 (as appropriate)
Bureau Veritas: BV Rules for the Classification of Steel Ships, Approval valid for ships
intended to be granted with the following additional class notations: AUT-
UMS, AUT-CCS, AUT-PORT and AUT-IMS.
China Classification CCS Chapter 2, Part Seven of CCS ~ “Rules for
Society: Classification of Sea-going Steel Ships~” 2012
Det Norske Veritas: Standard for Certification No. 2.4, 2006: Temperature Class B, Humidity
Class B, Vibration Class A, EMC Class A, Enclosure B.
Released

Manual 35092 2301E-HT Hydro (Francis Turbines)
Woodward 6
Lloyd’s Register LR Type Approval Test Specification No. 1, 2002 for
of Shipping: Shipping: Environmental Categories ENV1, ENV2 and ENV3
Nippon Kaiji Kyokai: NKK requirements specified in Chapter 1, Part 7 of Guidance for the
approval and Type Approval of materials and equipment for Marine use and
relevant Society’s Rules.
Other International Compliance
Australia &
New Zealand:
Compliance is limited to application for those units bearing the
Regulatory Compliance Mark (RCM) or used in applications
where only EMC is applicable, such as “Fixed Installations”
where the RCM & a DoC are not required.
EMC:
The Electromagnetic Compatibility (EMC) portion of
RCM Declaration for the Australian Radio
Communications Act (with applicable amendments) is
a separate document only created for marked
products. The products with RCM on the label have a
DoC available, but all products comply with CISPR11
Group 1 Class A emissions per EN/IEC 61000-6-4 via
Electromagnetic Interference (EMI) testing. This
product is part of “Fixed Installations.”
Special Conditions for Safe Use
The control must be installed in a suitable enclosure. The final combination must be approved by the local
authority having jurisdiction.
Connect the ground terminal to earth ground.
Use supply wire rated for minimum 75 °C
Use signal wire rated for a minimum of 240 Vac.
Per EN 60079-15:2010: Device meets ATEX Zone 2 requirements when installed in an ATEX compliant
IP54 or better enclosure.
T3 when the Potential Transformer input is 240 Vac.
T4 when the Potential Transformer input is 120 Vac or less.
EXPLOSION HAZARD—Do not remove covers or connect/disconnect
electrical connectors unless power has been switched off or the area
is known to be non-hazardous.
Substitution of components may impair suitability for Class I,
Division 2.
Released

Manual 35092 2301E-HT Hydro (Francis Turbines)
Woodward 7
Chapter 1.
General Information
This manual describes the installation and configuration procedures for the Woodward 2301E-HT digital
speed control for Francis turbines (p/n 8237-2046).
The 2301E-HT controls the speed and load of Francis hydraulic turbines with one gate analog output in
generator applications.
The control hardware includes:
1 Load Sensor
1 Actuator Driver
1 MPU Speed Sensor
1 Configurable Analog Output
2 Configurable Analog Inputs
8 Discrete (Switch) Inputs (3 inputs are configurable)
4 Configurable Discrete (Relay Driver) Outputs
2 Serial Ports (RS-232 and RS-422)
Refer to Manual 26641 (2301E Digital Control) for further hardware specifications of the 2301E-HT.
Released

Manual 35092 2301E-HT Hydro (Francis Turbines)
Woodward 8
Chapter 2
Installation
Qualified Personnel
Only qualified and trained personnel must prepare and install the
unit.
This chapter provides general information about how to install the 2301E-HT digital control for Francis
turbines. For detailed information about how to perform the product installation, see Manual 26691
(2300E Hardware Manual).
Figure 2-1a. 2301E-HT Control Wiring Diagram (1 of 3)
Released
