Dover markerm-imaje 2200 User manual
?
Printer overview -
Interface overview
Starting/shutting down the printer
Selecting and printing a job
Replacing consumables -
Adjustments
Maintenance
Troubleshooting
Technical Specications -
Information
Instruction manual
2200
Instruction manual 2
System 2200 overview
5
6
9
7
8
3
2
4
1
11
10
1 Status beacon
2 Standalone terminal (optional)
3 Print module
4 Adjustable stand
5 Label module
6 Electrical power supply connection
7 Printer positioning screw
8 Interface with LCD screen
9 Power switch
10 CPU
11 Manufacturer’s plate
3Instruction manual
System 2200 overview
4
3
5
6
7
10
11
12
1
2
13
8
9
1 Ribbon supply spindle 8 Print head
2 Ribbon rewind spindle 9 Blow bar
3 Label roll guide 10 Status screen, LEDs and
control buttons
4 Label supply spindle 11 Label path
5 Label compensator arm 12 Print head lever
6Backing paper compensator
arm 13 Ink ribbon compartment
7 Backing paper rewind spindle
Instruction manual 4
Connections
Inlet
Air Plant
Applicator Pneumatic
module
Terminal strip
A
P10
P3
P18 P17 P19
P11 P13 P21 P16
P20 P15 P9 P24
P14 P12
B 110-240 VAC
50-60 Hz connector
with ground connection.
A Power switch P15 Beacon
B Electrical power supply P16 LVDS
P3 Relay outputs P17 Pre Trig photocell
P9 LHM (communication) P18 Input Main Trig photocell
P10 Opto input P19 Input Return Sensor photocell
P11 Port Série 1 (RJ45) P20 Applicator connection
P12 USB port P21 Barcode reader
P13 Serial port 2 (DE-9) P24 LHM (power)
P14 Ethernet LAN
5Instruction manual
User Interface
45
321
6
1 Print control button
2 Starting up
3 Simple User Interface (SUI) mode
4 Status screen
5Beacons
(same meanings as the LEDs, No. 6)
6 LEDs:
Green: System is OK
Orange and green: System is OK, warnings present
Orange: Printer paused
Blue: System error or cover open
Blue, orange and green: Test pattern mode
Instruction manual 6
User Interface
conrms a selection or displays
the following submenu
displays the following option in
the current submenu
displays the previous submenu
Labels <label 1>
Load labels
<label 2> ...
Load fonts
Add labels
Overwrite labels
Add fonts
Overwrite fonts
Add images
Overwrite images
Software version
IP Address
USB memory
... <label n>
Insert USB ash drive
Host name
Load images
System information
Layouts
Loads the selected
labels
A USB ash drive
must be inserted at
this point in order for
the following menu to
appear.
Pressing the button shifts the printer to Simple User Interface
(SUI) mode. The operation of SUI mode is detailed in the
diagram below:
7Instruction manual
Standalone terminal (optional)
987
246
51 3
1 Status led
Connection OK, error, print engine/not at production page (blue)
Connection OK, warning, print engine (orange)
Online (green)
No connection with print module (Allowed time elapsed).
2Resumes printing or conrms the warnings and faults.
3Message eld.
4 Exits current menu level and goes back one level.
5Conrms a menu selection or operation.
6Navigation key: moves the cursor in the menus and message eld.
7 Shifts between upper and lower case letters.
8 Accesses a list of local and Unicode characters.
9 Shifts to the red characters in the bottom right corner of the keys.
Instruction manual 8
Standalone terminal (optional)
Production settings
Counter
management System settings
Reset
counters Applicator settings
Set start
value Printer settings
Production
parameters Control panel
Edit the
conguration
requests
Port settings
Terminal – Printer
connection
Data input device
Settings
Time/Date
Set display language
Set display contrast
Password
management
Servicing Window
For more information, refer to the terminal user manual.
9Instruction manual
CoLOS Create Pro (optional)
CoLOS® Create Professional is a particularly functional graphic
design software that allows you to easily create and manage
complex labels and codes.
CoLOS® Create Professional allows you to:
• dene the location and format of information to be
printed, including default or xed information, using image
templates,
• preview images before loading them,
• upload one or more images to all compatible devices,
including CimComms, SmartLase, Small Character Ink Jet
and NextGen models,
• send images to a local or network desktop printer.
Instruction manual 10
CoLOS Create Pro (optional)
Supported elds and styles:
- barcodes (1D & 2D)
- line elds
- box elds
- logo elds
- xed text
- user entry text
- Time
- Date, particularly Offset
- Dates (BBE) and Shift Codes
- Merged text
- Calculated text
- Math text
- Printer setting text
- Variable text (information
from database or external
data)
The 2200 printer comes with 10 default TrueType fonts.
Further fonts may be added to the printer's memory.
UTF-8 Unicode is supported.
Example of an image template:
For more information, refer to the CoLOS Create Pro user
manual.
11 Instruction manual
Daily startup and shutdown
≈ 10 seconds
≈ 3 seconds
■Starting up
Ready for label data
■Shutting down
Instruction manual 12
Selecting a job -
Using the standalone terminal
or
ENTER
For more information, refer to the terminal user manual.
Either option depending on your
conguration.
13 Instruction manual
Printing a job
Pause printing - On printer
Stop printing - On standalone terminal
Instruction manual 14
Loading labels
1
3
8
24
5
10
11
!
9
12
7
!
61.5 m (5 ft)
■Outside wound roll
15 Instruction manual
Loading the ribbon
1
2
3
!
4
7
6
5
Instruction manual 16
Adjustments
■Test pattern
The test pattern displays the printer conguration and must
resemble the example.
Feed a continuous roll of paper in the printer before running a
test pattern.
1 - Turn off the printer for approx. 15 seconds.
2 - Turn the printer back on while pressing the Print key.
3 - Hold the key depressed until the grey test target is printed.
To return to normal operation, turn the printer off then back on.
■Automatic adjustment of the Media Position
Sensor (MPS)
4 - Press and hold the key for 7 seconds after printing the grey
test target.
5 - The automatic control starts and white labels are fed through
the printer.
6 - The automatic adjustment of the MPS is nished when the
printer stops.
17 Instruction manual
Positioning of labels
!
1
3
!
Stretched
2
Taut
Instruction manual 18
Adjusting the outfeed
d
1
2
1
2
■Adjusting
the air ow
■Adjusting the outfeed
plate
d = 0.4 mm ( ) and //.
19 Instruction manual
Adjusting a creased ribbon
1
3
2
4
5
Instruction manual 20
Adjusting the printing
+
+
-
-
13
25%
A B
25%50%
ZZZYYYXXX
2 mm
YesNo
■Adjusting the position
■Adjusting the pressure
