DPT SmartRaidV Century Ultra2 SCSI RAID Controller... Owner's manual

Ultra2SCSI RAID Controller
PM2654U2-R
Available with one,two or three
Ultra2 SCSI Channels
1
2
3
4
1
5
4
4
6
SMARTRAID
V
®
Features:
•Fully I2O® compliant
•Controls SCSI-1, SCSI-2 or SCSI-3 devices
•Controls Wide or Narrow Ultra2, Ultra or Fast SCSI
devices with up to 80MB/s transfer rate
•Controls up to 15 SCSI devices per channel
•Up to 12 meter SCSI cable length
•Integrated hardware RAID 0, 1, 5,0+1 and 0+5
•4 SIMM sockets support up to 64MB of hardware cache
(DPT ECC EDO or industry standard EDO SIMMs)
•Expansion Modules add 1 or 2 additional Ultra2 SCSI
channels or 1 Fibre Channel Arbitrated Loop
•PCI 2.1 compliant with 132MB/s bus mastering
•Intel i960 RD processor for ultra-low host CPU utilization
•SCSI SCRIPTS®processor for maximum SCSI performance
•Very high-density SCSI connector allows 3 external
SCSI channels from one slot
•Flash-upgradable firmware and BIOS
•Supports SAF-TE, SES and DEC Fault Bus for intelligent
storage cabinets
•Dynamic Array Expansion permits drives to be added
on-the-fly to existing arrays
•Easy-to-use GUI Storage Management Software
•BIOS-based SCSI and RAID configuration utility
3
5
Intel® i960® RD processor for peak performance
Expansion Modules add 1 or 2 additional Ultra2 SCSI
channels or 1 Fibre Channel Arbitrated Loop
PCI 132MB/s data transfers,32-bit,33MHz
Internal and external 68-pin SCSI connectors
Includes high-speed RAID data path engine,
hardware XOR and ECC processor
Support for up to 64MB of hardware cache
6
2
Century

X•treme Performance
SCSI Features
SCSI Interface Ultra2 SCSI-3
Maximum SCSITransfer Rate 80MB/s
SCSI Bus 16-bit with multi-mode SE/LVD termination
Number of SCSI Busses 1 (upgradable to 3)
Maximum Number SCSI Devices 15 (upgradable to 45)
External SCSI Connector 68-pin Very High Density Cable Interconnect (VHDCI)
Internal SCSI Connector 68-pin High Density
PCI Features
Host Interface 32-bit PCI 2.1
Maximum PCITransfer Rate 132MB/s
Operating Environments
• Microsoft®Windows® NT® 4.0,SCO® 3.2.4.2,SCO OpenServer 5,NetWare® 4.11,
UnixWare® 2.1.4.2,SCO UnixWare 7,OS/2®,Win 95/98
• I2O compliant
• Compatible with I2O block storage or SCSI OSMs provided withWindows NT, SCO,NetWare
Power Requirements
Voltage 5V +/- 5%
Ripple and Noise 50mV peak-to-peak max
Current 2.0A typical
Reliability
MTBF > 400,000 Hours
Environmental Specifications (operating)
AmbientTemperature 0° to 50° C
Relative Humidity 10% to 90% non-condensing
Altitude 3,000 meters (10,000 feet)
Agency Certifications
FCC, CE, UL, CSA, AUSTEL, SMA
Complete Kit Contents
• PM2654U2-R Ultra2 SCSI RAID Controller
• Ultra2 Wide internal SCSI cable with multi-mode terminator, supports 4 SCSI devices
• Storage Management software
• I2O device drivers
• User’s Manual and Quick Install Guide
PM2654U2-R Technical Specifications
MM-0491-1298
Expansion Modules
SX4054U2 SCSI Expansion Modules
add one (SX4054U2-1) or two (SX4054U2-2)
additional Ultra2 SCSI
channels to any SmartRAID V
SCSI controller, supporting
up to 45 SCSI devices from a
single PCI slot. Supports
Fast and Ultra SCSI devices
as well.
SX4055F Fibre Expansion Module
adds one Fibre Channel
Arbitrated Loop port to
any SmartRAID V SCSI or
Fibre Channel controller,
controlling up to 126
Fibre Channel devices.
SM4050 ECC EDO SIMMs provides 16MB
(SM4050-16) or 64MB (SM4050-64) of high-speed
disk cache for SmartRAID V controllers, plus DPT’s
exclusive SmartCorrect™ ECC technology
which detects and corrects up to
32-bit data errors. (SmartRAID V
controllers also accept industry
standard EDO 4MB,16MB or
64MB SIMMs.)
Management Utilities
Storage Manager™ is a window into your storage
system. This user-friendly, self-installing, GUI-based
utility provides:
•Easy, point-and-click creation, deletion and
maintenance of disk arrays
•Array diagnostics
•Event logging and notification
•I/O load monitoring
•Device identification, status, and inventory
•Supports Windows® 95/98, NT®, NetWare®,
SCO® Unix®, UnixWare® and others
•Remote management of NT, NetWare, SCO
Unix, UnixWare and other servers via TCP/IP or
modem connection
•Online help
SMOR (Storage Manager On ROM) is a BIOS-based
set-up utility that allows you to quickly configure
SmartRAID controllers and attached devices
without having to boot an operating system.
Features include:
•Device identification, status, and inventory
•Configure controller hardware options
•Low-level formatting hard drives
•Create and delete disk arrays
•View and modify RAID configurations
