Dr.Meter LX1330B User manual

OPERATION MANUAL
DIGITAL LUX METER
Appreciate your choice of this Lux meter. Please read throught this manual carefully for
proper operating techniques.This digital lux meter is a precise instrument which could be use for
detecting light intensity in any situations.
ⅠFEATURES
●Measuring range: 0.1Lux～200,000Lux
0.01FC～20,000FC
●High accuracy in measuring, fast reflection time
●Data hold function
●Symbolly and unit display for easy reading
●Zeroize automatically
ⅡGENERAL SPECIFICATIONS
●Display: 3 1/2 digits LCD display, maximum display value 1999
●Range selection: 200Lux、2，000Lux、20，000Lux、200，000Lux
20FC、200FC、2，000FC、20，000FC
20,000Lux range: reading×10
200,00Lux range: reading×100
20,000FC range: reading×10
Annotate: 1FC=10.76Lux
●Accuracy: <20,000Lux/2,000FC, ±(4%rdg+10dgt)
≥20,000Lux/2,000FC, ±(5%rdg+10dgt)
(Calibrated to standard incandescent lamp at color temperature 2856K)
●Resolution: 0.1Lux
●Repeatable Accuracy: ±2%
●Temperature Characteristic: ±1%/℃
●Test Rate: 2times/sec.
●Photo Sensor: one silicon photo diode with filter.
●Operation temperature-humidity: 0℃ to 40℃(32℉-104℉) 0～70%Rh
●Storage temperature-humidity: -10℃ to 50℃(14℉-140℉) 0～80%Rh
●Over-input: indication of “1”
●Power Supply: one 9V battery, Model 6F22
●Bttery life: 200 hours for continuously use
●Photo Detector Dimension: 105*58*28mm
●Dimension: 162*78*43mm

●Weight: 310g
ⅢPANEL DESCRIPTIONS AND FUNCTIONS:
1. LCD display
2. Power wsitch button
3. Data-hold button: press this button, hold the current value on display
4. Peak-hold button: press this button, enter peak hold mode.
5. Unit switch button: press this button, switch between LUX and FC unit
6. Range select button: 200.0Lux、2，000Lux、20，000Lux、200，000Lux;
or 20.00FC、200.0FC、2，000FC、20，000FC
7. Photo detector probe
ⅣOPERATION INSTRUCTIONS:
1. Insert the battery, and turn on meter
2. Press the range select button until desired range.
3. Remove the photo detector cap and face it to light source. The detector can turn 180 degree
clockwise, 90 degree counterclockwise.
4. Read the test value from the LCD display.
5. If the instrument only display one “1” , it means the range used is overflow and should
change to larger range.
6. Data-hold mode: press the “DH”key to select Hold mode. During Hold mode, the LCD
display the “H”and the value is locked on the LCD. Press the button“DH”again, exit Hold

mode.
7. Peak-hold mode: press’PEAK” key to select peak hold mode, LCD display “P-H” symbol.
The meter is sensitive for light pulse signal larger than 100ms and will display max light
intensity. It updates and display new value only when a larger light pulse or light intensity
appear. Press “Peak” button again to exit peak hold mode.
8. After using the insturment, cover photo detector with cap and turn off power.
ⅤBATTERY CHECK-UP & REPLACEMENT:
1. when left corner of LCD display show“ ”, a battery replacement is required.
2. After turning off meter, unscrew and open battery cover to replace a new 9V battery.
3. Close battery cover and tighten the screw.
ⅥSPECTRAL SENSITIVITY CHARACTERISTIC:
ⅦMAINTENANCE:
1. Do not use or store the instrument in extrem high temperature or humidity environment.
2. Keep photo detector clean during usage.
3. The reference level, as marker on the face plate, is the top of photo detector globe.
4. According to operational conditions and time, the sensitivity of meter decreases. In order to
maintain the accuracy of instrument, periodic calibration is recommended.
ⅧRECOMMENDED ILLUMINATION：
SCHOOL：
illumination
（Lux）
locale
1500～300
drawing classroom、sartorial room、PC room
750～200
classroom、laboratory、practical factory、lab、library、stack room、office、
retiring room、assembly room、sanitarian room、dining-room、cookroom、
broadcasting room、printing room、guardroom、indoor schoolyard
300～150
big classroom、hall、repository、retiring room、stair well
- V (入)
S p ec tral S e n sitivity

150～75
aisle、lift、washroom、washroom、overbridge、outdoor schoolyard
75～30
storage、carbarn、safety passage
HOSPITAL：
illumination
（Lux）
locale
10000～300
ophthalmological room
1500～750
operating room
750～300
dispensary、remedial room、drugstore、dissecting room、pathogen room、
first-aid room、delivery room、deanery、office、nurse room、assembly room
300～150
sickroom、powder chamber、surgical treatment room
150～75
changeroom、physiotherapy room、x-ray room、sickroom aisle 、germfree
room、sickroom、stairway
75～30
zoom room、darkroom、mortuary
HOME：
illumination
（Lux）
locale
2000～1500
handicraft、dressmake
1500～750
do homework
750～300
reading room、toilette、table、phone room, repairing room
300～150
washhouse、playroom、living room
150～75
garderobe、balneary、washroom、stairway、aisle
75～30
mail drop、veranda
OFFICE：
illumination
（Lux）
locale
2000～300
design room、affair room
1500～750
hall passage（daytime）、bussinesshall、drawing room、clock on and off
750～300
PC room、assembly room、pressroom、antechamber、playroom、dining-room
300～150
stack room、playroom、refectory、retiring room、gatehouse、lift、washroom
150～75
drinking room、changeroom、storage、night watchman room(entrance)
75～30
safety passage
FACTORY：
illumination
（Lux）
locale
3000～1000
transnormal exactitude work、design room、drawing room、exact checking
1500～750
design room、analysis、debuger、packaging
750～300
product line、warehouse office
300～150
dye-works、foundry、electrical room
150～75
inlet and exit、aisle、passage、stairway、toilet room、washroom、

inspection office
75～30
safety passage、storage、dynamic equipment outdoor
HOTEL、CABARET、RECREATION GROUND：
illumination
（Lux）
locale
1500～750
counter
750～300
玄关、banquet、affair room、stall、cookroom
300～150
restaurant、washroom、big house which is Japanese style
150～75
playroom、aisle、stairway、guest room、balneary、basilic lighting in the
courtyard、changeroom
75～30
safety passage
SHOP、BAZAAR：
illumination
（Lux）
locale
3000～300
display in the room、jewelry showcase、the place where demonstrate perform、
check-out counter、packing counter
750～300
lift hall、escalator
300～150
chatting room、toilet room、washroom、stair、aisle
150～75
retiring room、normal illumination in the store
HAIR SOLON：
illumination
（Lux）
locale
1500～750
marcel and hairdressing room 、toilet room
750～300
shampoo、registration dais、bathing box
300～150
Washroom in the store
150～75
aisle、stairway
