Dr.Schulze FS-500 B User manual

Floor saw FS-500 B 1/ 65
Original operating instructions
Floor saw FS-500 B
Device designation: Floor cutter FS-500 B
Device number: Type plate
Year of manufacture: _________
Country of origin: Czech Republic
Read the operating instructions before each use

Table of contents
2/ 65 Floor saw FS-500 B
Table of contents
1General ...............................................................................................5
1.1 operating manual...................................................................................................... 5
1.2 conventions............................................................................................................... 5
1.3 address...................................................................................................................... 6
1.4 revision status .......................................................................................................... 6
1.5 Customer service...................................................................................................... 7
1.6 purpose of the operating instructions.................................................................... 7
1.7 Limitation of Liability................................................................................................ 8
1.7.1 Scope and other safety regulations............................................................................ 8
1.7.2 conformity................................................................................................................... 8
1.8 copyright protection................................................................................................. 9
1.9 location...................................................................................................................... 9
1.10 sale............................................................................................................................. 9
1.11 personnel requirement........................................................................................... 10
1.11.1 basic ......................................................................................................................... 10
1.11.2 instruction ................................................................................................................. 10
1.11.3 professional staff....................................................................................................... 10
1.11.4 qualified electricians ................................................................................................. 10
1.11.5 unauthorized persons............................................................................................... 11
2Security ............................................................................................12
2.1 Intended Use ........................................................................................................... 12
2.2 misuse ..................................................................................................................... 12
2.3 responsibility of the operator................................................................................ 13
2.3.1 operator .................................................................................................................... 13
2.3.2 Obligations of the operator ....................................................................................... 13
2.4 responsibility of staff ............................................................................................. 14
2.5 Explanation of symbols ......................................................................................... 15
2.5.1 Warning and Safety Instructions............................................................................... 15
2.5.2 Danger and information signs................................................................................... 16
2.5.3 Special safety instructions........................................................................................ 16
2.6 Personal protective equipment............................................................................. 17
2.7 Driven....................................................................................................................... 18
2.7.1 moving parts ............................................................................................................. 18
2.7.2 thermal hazard.......................................................................................................... 18
2.7.3 Vibration risks........................................................................................................... 19
2.7.4 Risks from noise....................................................................................................... 20
2.7.5 Risks due to safety devices that have been taken out of service............................. 20
2.7.6 Make sure you have a tidy workplace ...................................................................... 20
2.7.7 Observe the entire environment of the workplace.................................................... 20
2.7.8 Ensure a safe workplace .......................................................................................... 20

Table of contents
Floor saw FS-500 B 3/ 65
2.8 safety devices ......................................................................................................... 20
2.8.1 Emergency stop switch............................................................................................. 20
2.8.2 main switch............................................................................................................... 22
2.8.3 protective enclosure.................................................................................................. 23
2.9 Work, traffic and danger area................................................................................ 24
2.10 spare Parts .............................................................................................................. 25
2.11 Secure against being switched on again ............................................................. 25
2.12 Behavior in the event of danger and accidents................................................... 26
2.12.1 preventive measures ................................................................................................ 26
2.12.2 Do the right thing if the worst comes to the worst .................................................... 26
3Technical specifications .................................................................27
3.1 cutting disc.............................................................................................................. 27
3.2 Engine Honda GX390 ............................................................................................. 27
3.3 Dimensions ............................................................................................................. 27
3.4 Weight...................................................................................................................... 28
3.5 emissions ................................................................................................................ 28
3.6 environmental conditions...................................................................................... 28
3.7 type label ................................................................................................................. 28
4Layout and function ........................................................................29
4.1 General Descriptions.............................................................................................. 29
4.2 Machine overview................................................................................................... 29
4.3 Description of the assemblies............................................................................... 30
4.3.1 emergency stop switch............................................................................................. 30
4.3.2 cutting disc................................................................................................................ 31
4.3.3 Cutting disc cooling................................................................................................... 32
4.3.4 mobility...................................................................................................................... 33
4.3.5 Cutting depth adjustment.......................................................................................... 34
4.3.6 bout marker............................................................................................................... 35
4.3.7 main switch............................................................................................................... 36
5Scope of delivery , transport ..........................................................37
5.1 included supply ...................................................................................................... 37
5.2 Safety instructions for transport........................................................................... 37
5.3 transport inspection............................................................................................... 38
5.4 transport symbols .................................................................................................. 38
5.5 storage and transportation.................................................................................... 39
5.5.1 storage conditions..................................................................................................... 39
5.6 Handling packaging materials............................................................................... 39
6lineup................................................................................................40
7service ..............................................................................................41

Table of contents
4/ 65 Floor saw FS-500 B
7.1 Assembly................................................................................................................. 41
7.1.1 V-belt change............................................................................................................ 42
7.1.2 Assembly of the cutting disc..................................................................................... 44
7.2 Safety instructions for use .................................................................................... 47
7.2.1 Turn on ..................................................................................................................... 47
7.2.2 Turn off ..................................................................................................................... 49
7.3 Ideas......................................................................................................................... 50
7.3.1 Adjust handle............................................................................................................ 50
7.3.2 Set the cutting depth of the cutting disc.................................................................... 51
7.3.3 controls ..................................................................................................................... 52
7.4 Shutdown in an emergency................................................................................... 53
7.4.1 Measures before switching on again after an emergency stop:............................... 53
8maintenance and cleaning..............................................................54
8.1 maintenance............................................................................................................ 54
8.1.1 Maintenance Safety Instructions .............................................................................. 54
8.1.2 maintenance schedule.............................................................................................. 55
8.1.3 Measures after maintenance.................................................................................... 56
8.1.4 maintenance log ....................................................................................................... 56
8.2 cleaning ................................................................................................................... 57
8.2.1 cleaning schedule..................................................................................................... 57
9disturbances ....................................................................................58
9.1 Safety instructions for troubleshooting............................................................... 58
9.2 Who is allowed to fix faults ................................................................................... 59
9.3 Response to malfunctions..................................................................................... 59
9.4 Behavior after a fault has been rectified.............................................................. 59
9.5 Process technical disturbances............................................................................ 60
10 dismantling and disposal................................................................61
10.1 Safety instructions for dismantling and disposal............................................... 61
11 directories ........................................................................................62
11.1 List of Figures......................................................................................................... 62
11.2 List of Tables........................................................................................................... 62
12 Attachment.......................................................................................63
12.1 EC Declaration of Conformity ............................................................................... 64
12.2 Spare part list.......................................................................................................... 65

General
1
operating manual
1.1
Floor saw FS-500 B 5/ 65
1 General
1.1 operating manual
The operating instructions provide important information for the safe and effi-
cient use of the machine. It is part of the machine and must be accessible at
all times in its immediate vicinity and kept in a legible condition for the staff
working on it.
A prerequisite for safe work on the machine is compliance with all specified
safety instructions and instructions.
The personnel must therefore have read these operating instructions care-
fully before starting any work. The operating instructions are the basis for all
actions on the machine. It is the basis of all training courses that take place
on the machine.
In addition, the national accident prevention regulations and general safety
regulations applicable at the place of use of the machine must be observed.
1.2 conventions
In order to be able to work optimally with the operating instructions, the
following explanations of the typographical conventions must be observed.
Chapter
A chapter is the structure level within a part of the operating instructions. It
appears as a heading and is listed in the table of contents.
subheading
The subheading is used for subdivision into chapters and is not part of the
table of contents.
Count
−Texts presented in this way are bullet points of the first level.
−Texts presented in this way are second-level bullet points.
work sequence
1. Step 1 of the work sequence
2. Step 2 of the work sequence
3. Step 3 of the work sequence
The order of the work steps must be observed.
highlights
Highlighted text is italic or bold.

1
General
1.3
address
6/ 65 Floor saw FS-500 B
header
Each header contains: the first line, the main heading, the second line, the
subheading.
glossary
The glossary in the appendix explains technical terms. For this purpose,
there is a reference to the glossary after the technical term.
Example: ...the fluids (Glossary)...
Characters used
Tabelle 1: Signs and terms used
signs, terms
Explanation
➢
Tip, note (not machine/system damage)
1.3 address
dr Schulze sro
Hulínská 1814/1B
76701 Kromeriz
Czech Republic
Phone: [phone]
Email: [e-mail]
Fax: [phone]
Website: www.dr-schulze.de
1.4 revision status
Tabelle 2: revision status
Date
Chapter
Ground
version
Responsible
05/25/2018
Complete document
rebuild
1.0
Technical docu-
mentation CE

General
1
Customer service
1.5
Floor saw FS-500 B 7/ 65
1.5 Customer service
Our customer service is available for technical information.
Information about the regionally responsible contact person can be obtained
by telephone and can be called up at any time by fax, e-mail or via the Inter-
net.
In addition, our employees are always interested in new information and ex-
periences that result from the application and can be valuable for improving
our products.
dr Schulze sro
Hulínská 1814/1B
76701 Kromeriz
Czech Republic
Phone: [phone]
Email: [e-mail]
Fax: [phone]
Website: www.dr-schulze.de
1.6 purpose of the operating instructions
The operating instructions provide important information for the safe and
efficient use of the machine. It is part of the machine and must be kept in its
immediate vicinity and accessible to the personnel working on it at all times.
A prerequisite for safe work on the machine is compliance with all specified
safety instructions and instructions.
The personnel must therefore have carefully read through and understood
these operating instructions before starting any work.
In addition, the local accident prevention regulations and general safety
regulations applicable at the place of use of the machine must be observed.

1
General
1.7
Limitation of Liability
8/ 65 Floor saw FS-500 B
1.7 Limitation of Liability
All information and instructions in these instructions have been compiled
taking into account the applicable standards and regulations, the state of the
art and our many years of knowledge and experience.
The manufacturer accepts no liability for damage due to:
➢non-compliance with the instructions
➢Improper use
➢Use of untrained and untrained personnel
➢Unauthorized modifications
➢technical changes
➢Use of unapproved spare parts
The actual scope of delivery may deviate from the explanations and
illustrations described here in the case of special designs, the use of
additional order options or due to the latest technical changes.
The obligations agreed in the delivery contract, the general terms and
conditions as well as the delivery conditions of the manufacturer and the
legal regulations valid at the time of the conclusion of the contract apply.
We reserve the right to make technical changes within the scope of
improving the functional properties and further development.
1.7.1 Scope and other safety regulations
These operating instructions are only valid for the machine specified in the
title.
In addition to these operating instructions, country-specific and company-
specific safety regulations for handling the machine/system are binding.
1.7.2 conformity
The conformity assessment is based on the applicable directives (with their
associated amendment directives) in the version at the time of commission-
ing. The individual directives can be found in the declaration of conformity.
The declaration of conformity can be found in the appendix.

General
1
copyright protection
1.8
Floor saw FS-500 B 9/ 65
1.8 copyright protection
The operating instructions are copyright of the Dr. Schulze GmbH protected.
The operating instructions contain regulations and drawings or drawing
excerpts of a technical nature, which may not be reproduced, distributed or
used without authorization for competition purposes or communicated to
others, either in whole or in part.
The operator of the machine is expressly only permitted to make copies –
including excerpts –for internal use in connection with the operation of the
machine.
Dr. Schulze GmbH.
A claim for damages by the manufacturer arises from violations. We reserve
the right to make further claims.
1.9 location
The operating instructions must be kept in a place that is accessible to all
persons working with the machine.
The operator is responsible for internal distribution of the operating
instructions. The latter must inform the qualified personnel who work on or
with the machine about the storage location.
The operating instructions are part of the machine.
1.10 sale
The operating instructions are part of the machine.
If the machine is sold, the operating instructions must be supplied with it.

1
General
1.11
personnel requirement
10/ 65 Floor saw FS-500 B
1.11 personnel requirement
1.11.1 basic
Any work on the floor saw FS-500 B may only be carried out by people who
can carry out their work properly and reliably and who meet the specified re-
quirements.
➢Individuals whose ability to react is affected, e.g. B. through drugs,
alcohol or medication, may not carry out any work.
➢When deploying personnel, always observe the age and job-specific
regulations applicable at the place of work.
warning
Danger of injury due to insufficient qualification!
Improper work can lead to significant personal injury and damage to
property.
−Any activities may only be carried out by persons who have the neces-
sary training, knowledge and experience.
1.11.2 instruction
Instructed personnel are persons who have been extensively and verifiably
instructed by the operator about the tasks assigned to them and the possible
dangers.
1.11.3 professional staff
Skilled personnel are those who, based on their professional training,
knowledge and experience as well as knowledge of the relevant regulations,
are able to carry out the assigned work properly, independently recognize
possible dangers and avoid personal injury or damage to property.
1.11.4 qualified electricians
All work on the electrical equipment may only be carried out by qualified
electricians.
Qualified electricians are people who, due to their technical training,
knowledge and experience as well as knowledge of the relevant regulations,
are able to carry out work on electrical systems properly, independently rec-
ognize possible dangers and avoid personal injury and damage to property
through electrical current.

General
1
personnel requirement
1.11
Floor saw FS-500 B 11/ 65
1.11.5 unauthorized persons
warning
Risk of injury for unauthorized persons!
Untrained persons do not know the dangers in the work area and are
considered unauthorized.
−Keep unauthorized persons away from the work area, speak to the
persons concerned in case of doubt and direct them out of the work
area.
−Interrupt work as long as unauthorized persons are in the work area.

2
Security
2.1
Intended Use
12/ 65 Floor saw FS-500 B
2 Security
This section gives an overview of important safety aspects to protect the
operator and the operator from possible dangers and to ensure safe and
trouble-free operation.
Failure to comply with the instructions, warnings and safety instructions
listed can result in considerable danger.
2.1 Intended Use
The floor saw FS-500 B is used exclusively for cutting (wet and dry) slots
(joints) in asphalt, concrete and stone with a maximum depth of 200 mm
(with cutting disc Ø500 mm).
The floor saw FS-500 B has a Honda petrol engine GX390 (9.6 kW / 13 hp) .
Due to the emission of exhaust gases from the combustion engines of the
construction machinery, use in closed rooms is prohibited. The machine may
only be operated by one person.
Features
-Large 30l tank with wide filling opening
-Convenient cutting depth adjustment via hand crank
-Clear operating terminal
-Height adjustable handle
-Perimeter protection
-Water supply via blade guard
-Honda GX390 with 13 hp
This machine is only intended for commercial purposes and may only be
operated by trained personnel.
Intended use also includes compliance with the instructions:
➢For safety
➢To the operation
➢For maintenance/maintenance
➢To technical specifications that are described in the operating
instructions
Any other use or use that goes beyond this is considered to be improper.
The operator alone is liable for any resulting damage.
2.2 misuse
Misuse of the machine can lead to dangerous situations for people and
cause serious damage to property.
Any misuse of the machine is prohibited.
Misuse occurs when
−the floor saw FS-500 B cannot be used according to your application pro-
file.

Security
2
responsibility of the operator
2.3
Floor saw FS-500 B 13/ 65
2.3 responsibility of the operator
2.3.1 operator
The operator is any natural or legal person who uses the machine or allows
third parties to use it and who is responsible for the safety of the user, staff
or third parties during use.
2.3.2 Obligations of the operator
Personal safety can only be guaranteed if all necessary measures have
been taken. It is the responsibility of the operator of the machine to organize
and implement these measures and to control their execution.
In particular, the operator must:
−find out about the applicable health and safety regulations.
−identify possible additional hazards through a risk assessment that result
from the special application conditions at the place of use of the machine.
−implement the necessary behavioral requirements for operating the ma-
chine on site in operating instructions.
−regularly check during the entire service life of the machine whether the
operating instructions they have drawn up correspond to the current sta-
tus of the regulations.
−Adapt the operating instructions, if necessary, to new regulations, stand-
ards and conditions of use.
−clearly and unambiguously regulate the responsibilities for the installa-
tion, operation, maintenance and cleaning of the machine.
−ensure that all employees working on the machine have read and under-
stood the operating instructions. In addition, he must train the staff at reg-
ular intervals in how to use the machine and inform them about the
possible dangers.
−provide the personnel assigned to work on the machine with the pre-
scribed and recommended protective equipment.
Furthermore, the operator is responsible for ensuring that the machine
−is always in perfect technical condition.
−is maintained according to the specified maintenance intervals.
−all safety devices of the machine are regularly checked for completeness
and functionality.

2
Security
2.4
responsibility of staff
14/ 65 Floor saw FS-500 B
2.4 responsibility of staff
The machine is in commercial use. The staff is therefore subject to the legal
obligations regarding occupational safety.
In addition to the warning and safety instructions in this manual, the safety,
accident prevention and environmental protection regulations applicable to
the area of application must be observed.
In particular, the staff:
−find out about the applicable health and safety regulations.
−complies with the behavioral requirements given in the operating instruc-
tions for operating the machine at the place of use.
−correctly assumes the assigned responsibilities for the operation, mainte-
nance and cleaning of the machine.
−must have read and understood the operating instructions completely be-
fore starting work.
−uses the prescribed and recommended protective equipment.
Furthermore, everyone who works on the machine is responsible within his
or her scope of responsibility for ensuring that the machine
−is always in perfect technical condition.
−is maintained according to the specified maintenance intervals.
−all safety devices are regularly checked for completeness and functional-
ity.

Security
2
Explanation of symbols
2.5
Floor saw FS-500 B 15/ 65
2.5 Explanation of symbols
2.5.1 Warning and Safety Instructions
Warning and safety instructions in the manual are identified by pictograms
and highlighted in a block with a gray background.
Warning and safety instructions that draw attention to basic dangers are also
introduced with signal words that express the extent of the damage.
These are structured as follows:
Danger
... indicates an imminent danger that will result in death or serious injury
if not avoided.
warning
... indicates a potentially dangerous situation that can cause death or
serious injury if not avoided.
Caution
... indicates a potentially dangerous situation that can lead to minor inju-
ries if not avoided.
Danger
... indicates a potentially dangerous situation that can lead to property
damage if not avoided.
Notice
... highlights tips and recommendations as well as information for effi-
cient and trouble-free operation.

2
Security
2.5
Explanation of symbols
16/ 65 Floor saw FS-500 B
2.5.2 Danger and information signs
Caution
Risk of injury due to illegible signs!
Stickers and signs that have become unclear no longer adequately iden-
tify danger areas and cannot point out possible risks of injury.
−Always keep pictograms, safety, warning and operating instructions in
a legible condition.
−Replace damaged or unrecognizable pictograms, inscriptions, signs or
stickers immediately.
−Attach pictograms to the machine where they are clearly visible.
2.5.3 Special safety instructions
... indicates hazards from electrical current.
If the safety instructions are ignored, there is a risk of serious or fatal in-
juries.
... indicates hazards from hot surfaces.
If the safety instructions are not observed, there is a risk of burns and
severe skin injuries from heat.
... indicates a risk of being drawn in.
If the safety instructions are ignored, there is a risk of serious or fatal in-
juries.
... indicates hazards from sharp edges/knives.
If the safety instructions are not observed, there is a risk of cuts and se-
rious injuries from sharp edges.
... indicates a risk of cuts on the floor area.
If the safety instructions are not observed, there is a risk of cuts and se-
rious injuries from sharp edges.
... denotes an operating ban for people with pacemakers.
If the safety instructions are not observed, there is a risk of damage to
persons with cardiac pacemakers.
... denotes a ban on carrying metallic parts.
It is forbidden to carry metal parts, watches, magnetic or electronic data
carriers, as magnetic charging can damage or destroy parts.

Security
2
Personal protective equipment
2.6
Floor saw FS-500 B 17/ 65
2.6 Personal protective equipment
Wearing personal protective equipment is required at work to minimize
health hazards. For this reason:
−Put on the protective equipment properly before starting any work and
wear it during the work.
protective clothing
Close-fitting work clothing with low tear resistance, with narrow sleeves
and no protruding parts, mainly to protect against being caught by moving
machine parts.
Do not wear rings, chains or other jewelry.
Solid protective gloves
to protect hands from abrasions, abrasions, scratches, scrapes, cuts,
punctures or similar superficial skin injuries.
safety shoes
to protect the feet from injuries caused by falling parts and from slipping
and falling on slippery surfaces.
ear protection
To protect against hearing damage.
safety goggles
to protect against eye injuries caused by flying parts, particles, liquid
splashes or escaping compressed air.
mouthguard
to protect against health damage caused by inhaling dust and small parti-
cles.
face shield
To protect the eyes and face from injuries caused by flying parts, parti-
cles, liquid splashes or escaping compressed air.

2
Security
2.7
Driven
18/ 65 Floor saw FS-500 B
2.7 Driven
The machine has been subjected to a risk assessment. The dangers identi-
fied were eliminated as far as possible and identified risks were reduced.
Nevertheless, the machine poses residual risks, which are described in the
following section.
It is essential to observe the warning and safety instructions listed here and
in the action chapters of this manual in order to avoid possible damage to
health and dangerous situations.
2.7.1 moving parts
warning
Driven moving assemblies or parts can cause severe injuries!
−Do not allow people to remain in the danger area or in the immediate
vicinity.
−Do not remove covers such as flaps or maintenance covers.
−Do not disable, disable or bypass any safety device and/or function.
−Never reach into the running machine.
−Before starting work, always wait for the cutting disc to come to a
standstill and for residual energy to dissipate automatically.
2.7.2 thermal hazard
Caution
Risk of burns from hot surfaces!
Contact with hot components can cause burns.
−For all work on hot components, e.g. B. the engine, wear protective
clothing and protective gloves.
−Before starting any work, ensure that the components have cooled
down to the ambient temperature.

Security
2
Driven
2.7
Floor saw FS-500 B 19/ 65
2.7.3 Vibration risks
warning
Long-term damage caused by strong vibrations!
Strong vibrations can damage your health.
−Do not override vibration dampeners.
−During operation, do not stay at, in or near dangerous areas subject to
strong vibrations.

2
Security
2.8
safety devices
20/ 65 Floor saw FS-500 B
2.7.4 Risks from noise
warning
Hearing damage from noise!
The noise occurring in the work area can lead to severe hearing dam-
age and even deafness.
−Always wear hearing protection during all work.
−Stay in the danger area only as far as necessary.
2.7.5 Risks due to safety devices that have been taken out of service
warning
Danger to life due to defective or bypassed safety devices!
Inoperative, bypassed or disabled safety devices do not protect against
the hazards and can lead to serious injury or death.
−Before starting work, always check that all safety devices are correctly
installed and functional.
−Never disable safety devices.
−Ensure that the safety devices are always freely accessible.
2.7.6 Make sure you have a tidy workplace
A messy workplace can lead to accidents. Unauthorized persons (children)
may not enter the workplace or operate the machine. After completing work,
secure the machine against unauthorized use. Be sure to catch or support
any part cut out during cutting (especially when cutting floors or ceilings).
Secure the device for unauthorized persons after the work has been
completed and secure it against unauthorized use.
2.7.7 Observe the entire environment of the workplace
Provide good lighting. Pay attention to the position of the cables, lines and
reinforcing iron. Never operate electrical tools near flammable materials.
2.7.8 Ensure a safe workplace
Keep the tools belonging to the device safe so that they cannot become
loose. Before switching on the device, check that all keys and other aids
have been removed. Ensure blade guards are securely fitted. Always keep a
safe distance from moving parts. Avoid abnormal posture and maintain a
stable balance.
2.8 safety devices
The operator of the machine is responsible for regularly checking the safety
devices and their functional safety.
2.8.1 Emergency stop switch
