Dr.Shrink+ Go Cart User manual

315 Washington St.
Manistee, Michigan
49660-1855
CONTACT OUR WORLD CLASS CUSTOMER SERVICE
[phone]
[phone]
[phone]
www.dr-shrink.com
[e-mail]
P:
P:
F:
MANUAL
ASSEMBLY
Go Cart

D. x2
Support Poles
C.x2
Caster/Frame
B. x4
Support Pole D-Clip
E. x2
X-Support Poles
A. x8
3/8” Nuts
Go Cart
PARTS
Before beginning installation, layout and verify that all parts are included before putting together your Go Cart. If a part is missing, contact us at:
800-968-5147.
MANUAL
ASSEMBLY
Go Cart
Go
Cart
TOOLS
Hammer Socket
with 3/8”
The tools listed here are not included as part of your Go Cart
purchase from Dr. Shrink. We recommend having these tools
on hand during the construction of your lm rack.

Go Cart
STEP-BY-STEP
INSTRUCTIONS
Attach X-Support Pole (E) to Caster/Frame (C) using 3/8”Bolts (A).
Tighten bolts rmly, but do not completely tighten them down.
Repeat Step 1 for the other Caster/Frame (C).
Attach X-Support Pole (E) to the backside of the Caster/Frame (C)
using 3/8” Bolts (A). Tighten bolts rmly, but do not completely
tighten them down. Repeat Step 1 for the other Caster/Frame
(C).
Go Cart
MANUAL
ASSEMBLY
STEP
2
Place Support Poles (D) to Caster/Frame (C) then using Support
Pole D-Clip (B). Do this for both Support Poles (D).
Lastly, double check all nuts and bolts used in assembly and be
sure they are tightened securely. Tighten any that are not secure.
