Dr. Storage F1 User manual

Dry Cabinet
F1/X2B/A1B/T40W/T60M
F1/X2B/A1B/T40W/T60M

Contents
General specifications -F1 1
Installation 6
9
Introduction of control Panel
16
How to set Humidity(A1B Only)
General specifications -X2B 2
3
General specifications -A1B
4
General specifications -T40W
5
General specifications -T60M
How to set Temperature (T40W/T60M Only) 17
Alert Setting for Humidity(all models) 10
Alert Setting for Temperature(all models) 13
How to use software Humidity Manager V3 18
Notes 22
Warranty 23

1
■F1
Extension
Cable
Power
Power Cable
Power Box
P2
Handle
Antistatic
Glass
Antistatic 3”
Wheel
Adjustable
Level bolt
RS232 Port
Control Panel
Shelf
Bin
Front Right
Back
Wiring Diagram
P1
S1
Model: F1-1200-6
APower Box
S1
Dehumidifier unit
Dehumidifier unit
General specifications

2
■X2B
Extension
Cable
Power
Power Cable
Power Box
Handle
Antistatic
Glass
Antistatic 3”
Wheel
Adjustable
Level bolt
RS232 Port
Control Panel
Shelf
Bin
Front Right
Wiring Diagram
Model: X2B-1200-6
APower Box
P2
Dehumidifier unit
P1
Back
B
A
B
B B
P2
Dehumidifier unit
General specifications

3
■A1B
Handle
Antistatic
Glass
Antistatic 3”
Wheel
Adjustable
Level bolt
RS232 Port
Control Panel
Shelf
Bin
Front Right
General specifications
Wiring Diagram
Extension
Cable
Power
Power Cable
Power Box
Model: A1U/A1B-1200-6
APower Box
P2S1
Signal
Cable
Dehumidifier unit
Dehumidifier unit
BB
Back
A
P1
P2S1

4
■T40W
General specifications
Compression
Handle
Antistatic Glass
Antistatic 3” Wheel
Adjustable
Level Screw
Control Panel
Shelf
Memo Card
Front Right
Back
Cover
RS232 Port
Extension Cable
Power
Power Cable
Back
Wiring Diagram
Heater Switch
Overheat Protector
Please set the knob
at 50℃.
Dehumidifier
BB B B
H H H H
B
A
A
Heater
H
Power Box
ON
OFF
P1P4
70
60
50
40
30
20
10
0
80
℃

5
■T60M
General specifications
Grid Shelf
Right
Compression
Handle
Antistatic Glass
Antistatic 3” Wheel
Adjustable
Level bolt
Control Panel
Memo Card
Front
RS232 Port
Power Cable
Heater Power Switch
ON
OFF
Wiring Diagram
Dehumidifier unit
Model: T60M-1200-6
Power
Back Dehumidifier
B B
B B
B
A
APower Box
P1P4
Dehumidifier unit
P1-1
P4-1
P1-1
P4-1
Overheat Protector
Please set the knob
at 70℃.
70
60
50
40
30
20
10
0
80
℃

6
Installation
STEP1 Adjust the feet to balance the cabinet.
STEP2 Install shelves:
F1/X2B/A1B
T40W/T60M
1.Moveable column: the moveable column can be taken out for
installing the shelves. available models( F1/X2B/A1B-315/575/1200-6 )
fasten knob
2.Two methods for putting clips and shelves:
Shelves removable Shelves fixed
A
BAA+B
1 2
or

7
Installation
STEP5 Run the dry cabinet without putting any storage items for 24
hours and do not open its door during this period until the
cabinet reaches desired value.
STEP4 The voltage is specified in the Label which is affixed on power
socket of cabinet. Please ensure the power supply providing the
same voltage value as requirement of cabinet before connecting.
STEP3 Connect modules:connect all modules according to the Wiring
Diagram which is affixed at the back of cabinet.
3.The installation of Stopper: this stopper will avoid the object to drop
down from the gap between the shelf and wall of cabinet.available
models( F1/X2B/A1B-157/315/575/200/400 1600/1200-6 )
Shelf
Stopper

8
Installation
■
■
The opera�on mode of interior lights:(available for T40W/T60M)
Mode
Lights on
Lights off
Auto
Open door
Close door
M
anual Press F(★)
Close door or
wait 3 minutes
Default for overheat protector: 50℃for T40W and 70℃for T60M.
If they are not set at above values,please follow below steps to set it:
1 st. Turn the temperature protection switch knob to the end in a
counter-clockwise direction.
2nd. Turn the temperature protection switch knob to the scale 50/70
to complete the setting.
1.
2.
■Bin set up(available for F1/X2B/A1B)
1
2
1.Insert the tenons at the bottom of
bin into the slots on window frame.
2.Bend both
sides of bin then insert
the tenons into the slots on window
frame
.
2

9
Introduction of control Panel
(elapsed days) (default expiration days)
(decimal place)
Calibration Reminding function
The drift effect of sensor might influence the accuracy. In order
to help complying with the regulation of ISO. When the sensor
runs over 365 days, the decimal place in the panel will be flash
to remind the user.
Description:
1. SET Button 7. UP Button
2. Temperature Display 8. Power Button of Display
3. Humidity Display 9. Flash Alarm Lamp
4. Select Button
5. Calibration Expiration Button
6. DOWN Button
1 2 3 4 5 6
7 89
Check the elapsed days: Press “○”
Reset the elapsed days: Press “○”about 15 seconds,then press
to restart the display.

10
STEP1 Press and hold ▲, then press SET.
STEP2 Press ⊙to select from H→AHu. Choose AHu.
STEP3 Press ▲ or ▼ to reach the required upper limit level of 60%RH
[ Alert ]
Set AHu as 60%RH.
Alert is activated when the
relative humidity is higher than
60%RH.
%RH
AHu
Example
OFF
ON
Alert Setting for Humidity(all models)
■Set upper limit of humidity alarm(AHu)
STEP4 Press SET to store the setting.

11
Alert Setting for Humidity(all models)
■Time delay setting of humidity Flash alarm(AHF)
AHF=3 min
time
%RH
AHu=60
Flash ON
When the relative humidity is higher than 60%RH,
flash will be activated from Hb to Hc.
Hb
Ha HcHc
Time delay
Set AHF
Step 1 Press and hold ▲, then press SET.
Step 2 Press ⊙to select from H→AHu→AHF. Choose AHF.
Step 3 Press ▲ or ▼ to reach the required time delay of 3 minutes.
Step 4 Press SET to store the setting.

12
Alert Setting for Humidity(all models)
■ Time delay setting of humidity buzzer alarm(AHb)
AHb=60 min
time
%RH
AHu=60
buzzer ON
When the relative humidity is higher than 60%RH,
buzz will be activated from Hb to Hc.
Hb
Ha HcHc
Time delay
Set AHb
Step 1 Press and hold ▲, then press SET.
Step 2 Press ⊙to select from H→AHu→AHF→AHb. Choose AHb.
Step 3 Press ▲ or ▼ to reach the required time delay of 60 minutes.
Step 4 Press SET to store the setting.

13
Alert Setting for Temperature(all models)
STEP1 Press and hold ▼, then press SET.
STEP4 Press SET to save the setting.
■Set upper limit of temperature alarm(Atu)
STEP2 Press ⊙to select from t→Atu. Choose Atu.
STEP3 Press ▲ or ▼ to reach the required upper limit level of
30℃.
[ Alert ]
Set Atu as 30℃.
Alert is activated when the
temperature is higher than 30℃.
℃
Atu
Example
OFF
ON

14
Alert Setting for Temperature(all models)
■Time delay setting of temperature flash alarm(AtF)
AtF=3 min
time
℃
Atu=30
Flash ON
When the relative temperature is higher than 30℃,
flash will be activated from Hb to Hc.
Hb
Ha HcHc
Time delay
Set AtF
Step 1 Press and hold ▼, then press SET.
Step 2 Press ⊙to select from t→Atu→AtF. Choose AtF.
Step 3 Press ▲ or ▼ to reach the required time delay of 3 minutes.
Step 4 Press SET to store the setting.

15
Alert Setting for Temperature(all models)
■Time delay setting of temperature buzzer alarm(Atb)
Atb=60 min
time
℃
Atu=30
buzzer ON
When the relative temperature is higher than 30℃,
buzzer will be activated from Hb to Hc.
Hb
Ha HcHc
Time delay
Set Atb
Step 1 Press and hold ▼, then press SET.
Step 2 Press ⊙to select from t→Atu→AtF→Atb. Choose Atb.
Step 3 Press ▲ or ▼ to reach the required time delay of 60 minutes.
Step 4 Press SET to store the setting.

16
■ Relative humidity setting:
How to set the relative humidity(A1B Only)
STEP1 Press and hold ▲, then press SET. (The humidity display will show
H, while the temperature display will flash the current humidity
setting.)
STEP2 Press ▲ or ▼ to reach the required humidity level .
(setting range: 0~99%RH)
STEP3 Press SET to store the setting.

17
How to set temperature (T40W/T60M Only)
STEP1 Press and hold ▼, then press SET. (The humidity display will show
t, while the temperature display will flash the current
temperature setting.)
STEP2 Press ▲ or ▼ to reach the required temperature level of 60℃.
(setting range: 0~60℃)
STEP3 Press SET to store the setting.
Note:
1.Temperature control range:
T40W: >Room temperature ~40℃
T60M: >Room temperature ~60℃
2.Humidity reaches <5%RH only when the temperature reaches 40℃on T40W.
If it is lower than 40℃, the cabinet will perform higher humidity. Humidity
reaches ≦1%RH only when the temperature reaches 60℃
on T60M. If it is lower than 60℃, the cabinet will perform higher humidity.
3.If the heaters is turned off, please also disconnect power fan in order to
maintain humidity stabilized.
4.The best performance achieved at ambient condition 25℃ and <50%RH.
Lower ambient temperature may cause cabinet to take longer time
reaching desired temperature. Higher ambient humidity may cause
cabinet to take longer time reaching desired humidity.

18
How to use software Humidity Manager V3
STEP1 To install USB-RS232 driver by double clicking icon of “PL-2303
Driver Installer”.
STEP3 Restart the PC.
STEP2 To install Huminity Manager by double clicking icon of “setup”.
1
23
45
