DragonWave Horizon Compact Plus User manual

Horizon COMPACT PlusTM
Wireless Ethernet
Release 1.0.1
Product Manual - Volume 2
Advanced Configuration Features
Version 1.1

Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
NOTICE
This document contains confidential information, which is proprietary to DragonWave. No part of its
contents can be used, copied, disclosed, or conveyed to any party in any manner whatsoever without
prior written permission from DragonWave Inc.
Copyright © 2000 - 2012 DragonWave Inc.

DragonWave Inc.
ii
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
Table of Contents
1.0 USER MANUAL STRUCTURE .......................................................................1
2.0 ADVANCED CONFIGURATION FEATURES .................................................3
2.1....... DYNAMIC CONFIGURATION CHANGE....................................................................................3
3.0 UPGRADE/DOWNGRADE LICENSED FEATURES.......................................5
3.1....... UPGRADE/DOWNGRADE FEATURE GROUP...........................................................................5
3.2....... UPGRADE SYSTEM LICENSE SPEED ....................................................................................8
3.3....... DOWNGRADE SYSTEM LICENSE SPEED .............................................................................10
4.0 CONFIGURING ETHERNET PORTS 1 AND 2 .............................................13
5.0 SYNCHRONOUS ETHERNET (SYNCE).......................................................17
5.1....... MASTER/SLAVE................................................................................................................17
5.2....... WANDER FILTERING .........................................................................................................17
5.3....... CONFIGURING SYNCE......................................................................................................18
6.0 RADIUS SERVER USER AUTHENTICATION..............................................22
6.1....... CONFIGURING THE RADIUS SERVER................................................................................25
7.0 MANAGEMENT VLAN TAGGING ................................................................26
7.1....... VLAN TAGGING OVERVIEW..............................................................................................26
7.2....... 802.1Q TAGGING.............................................................................................................26
7.3....... VLAN TAGGING IMPLEMENTATION IN HORIZON COMPACT PLUS .........................................26
7.4....... HORIZON COMPACT PLUS VLAN SETTINGS ......................................................................27
8.0 QUALITY OF SERVICE (QOS).....................................................................30
8.1....... CLASS OF SERVICE TYPES................................................................................................30
8.2....... CLASS OF SERVICE BIT LEVELS ........................................................................................30
8.3....... OPERATION WITH QOSDISABLED .....................................................................................30
8.4....... OPERATION WITH QOSENABLED ......................................................................................31
8.4.1 ASSIGNING USER DATA TO QOSQUEUES......................................................................................31
8.4.2 SLOW BRIDGE PROTOCOL FRAMES ...............................................................................................31
8.4.3 COMMITTED INFORMATION RATE (CIR)..........................................................................................32
8.4.4 COMMITTED BURST SIZE (CBS) ...................................................................................................32
8.5....... QOSSCHEDULER POLICIES..............................................................................................32
8.5.1 CUT THROUGH............................................................................................................................33
8.5.2 STRICT PRIORITY QUEUING ..........................................................................................................33
8.5.3 WEIGHTED FAIR QUEUING (WFQ) ................................................................................................34
8.5.4 WEIGHTED FAIR QUEUING –EXPEDITE MODE ................................................................................36
8.6....... USER FLOW MAPPING......................................................................................................44
9.0 PAUSE FRAMES..........................................................................................48
10.0 BANDWIDTH MANAGEMENT......................................................................50
10.1..... MAXIMUM THROUGHPUT SPEED........................................................................................50

Table of Contents
iii
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
10.2..... ASYMMETRIC THROUGHPUT SPEED...................................................................................53
10.3..... THROUGHPUT (BANDWIDTH)LOGGING ..............................................................................55
11.0 ADAPTIVE TRANSMIT POWER CONTROL (ATPC) ...................................60
11.1..... NORMAL LINK...................................................................................................................60
11.2..... SATURATED LINK .............................................................................................................63
11.3..... COORDINATED POWER ALARM..........................................................................................64
12.0 AUTHENTICATION.......................................................................................66
12.1..... NO AUTHENTICATION........................................................................................................66
12.2..... UNIQUE AUTHENTICATION.................................................................................................66
12.3..... GROUP AUTHENTICATION .................................................................................................66
12.4..... AUTHENTICATION FAILURE ACTION ...................................................................................67
12.5..... CONFIGURE AUTHENTICATION ..........................................................................................68
13.0 THRESHOLD ALARMS................................................................................72
14.0 RAPID LINK SHUTDOWN (RLS)..................................................................78
14.1..... DETERMINATION OF ERROR RATES ON HORIZON COMPACT PLUS SYSTEMS .......................78
14.2..... RLS CONFIGURATION –PORT GROUPS ............................................................................79
14.2.1 BASIC MODE...............................................................................................................................79
14.2.2 ADVANCED MODE........................................................................................................................79
14.3..... SETTINGS FOR BASIC MODE.............................................................................................80
14.3.1 RLS SIGNAL DEGRADE SETTINGS.................................................................................................80
14.3.2 RLS LINK MONITOR PARAMETERS ................................................................................................80
14.4..... SETTINGS FOR ADVANCED MODE......................................................................................81
14.4.1 RLS SIGNAL FAULT SETTINGS......................................................................................................81
14.4.2 RECOVERY FROM A HARD FAILURE................................................................................................81
14.5..... RLS LINK CONTROL SETTINGS .........................................................................................81
15.0 CONFIGURING THE TIME SOURCE (SNTP)...............................................90
16.0 ADAPTIVE MODULATION ...........................................................................94
16.1..... HITLESS AUTOMATIC ADAPTIVE MODULATION....................................................................94
17.0 SYSTEM MANAGEMENT...........................................................................100
17.1..... IN-BAND AND OUT-OF-BAND MANAGEMENT......................................................................100
17.2..... TELNET ACCESS ............................................................................................................103
17.3..... SECURE SHELL ACCESS SECURITY.................................................................................104
17.4..... CONFIGURING SECURE SHELL (SSH)..............................................................................104
17.5..... WEB INTERFACE ............................................................................................................105
17.5.1 FEATURES ................................................................................................................................105
17.5.2 CONNECTING TO THE WEB INTERFACE.........................................................................................106
17.5.3 EXITING THE APPLICATION..........................................................................................................107
17.5.4 LOGIN ......................................................................................................................................107
17.5.5 HOME SCREEN..........................................................................................................................108
17.5.6GRAPHICS AND TABLE VIEW .......................................................................................................109

DragonWave Inc.
iv
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
17.5.7 WEB PAGE TREE DIAGRAM ........................................................................................................111
17.6..... SECURE SOCKETS LAYER (SSL)WEB SERVER ...............................................................111
17.6.1 WHAT IS SSL?..........................................................................................................................112
17.6.2 GENERATING A CERTIFICATE ......................................................................................................112
17.6.3 INSTALLING CERTIFICATES ON YOUR WEB BROWSER....................................................................114
17.6.4 ENABLING SSL PER USER GROUP ..............................................................................................116
18.0 EVENT AND PERFORMANCE LOGGING .................................................118
18.1..... EVENTS LOG..................................................................................................................118
18.2..... PERFORMANCE LOG.......................................................................................................119
18.3..... SYSLOG FEATURE..........................................................................................................121
19.0 RADIO AND NETWORK LOOPBACK........................................................ 124
19.1..... RADIO LOOPBACK ..........................................................................................................124
19.2..... NETWORK LOOPBACK.....................................................................................................126
19.3..... EOAM LOOPBACK .........................................................................................................127
20.0 NETWORK MANAGEMENT .......................................................................128
20.1..... SIMPLE NETWORK MANAGEMENT PROTOCOL (SNMP) ....................................................128
20.2..... SUPPORTED SNMP VERSIONS.......................................................................................128
20.3..... ENTERPRISE MANAGEMENT INFORMATION BASE (MIB)....................................................136
20.4..... SNMP TRAPS................................................................................................................136
21.0 EDITING SYSTEM CONFIGURATION FILES.............................................142
APPENDIX A –DETAILED CLI COMMAND LIST ..................................................144
APPENDIX B –SYSTEM CONFIGURATION OID INDICES ...................................165
APPENDIX C –SITE SURVEY INFORMATION......................................................189
APPENDIX E - 802.1P PRIORITY TAGGING OVERVIEW...................................... 191

Table of Contents
v
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
List of Figures
Figure 7-1 CoS Queues can be allocated a CIR and a Committed Burst Size (CBS).........................33
Figure 7-2 Weighted Fair Queuing Concept...........................................................................................34
Figure 16-1 Web Interface - Login Screen............................................................................................107
Figure 16-2 Web Interface - Home Screen............................................................................................108
Figure 16-3 Web Interface –Graphics withTable View........................................................................109
Figure 16-4 Web Interface –Graphics Features...................................................................................110
Figure 16-5 Web Interface –Graphics –Loss of Signal......................................................................110
Figure 16-6 Web Interface –Tree Diagram...........................................................................................111
Figure 18-1 Radio/Network Loopback..................................................................................................124
List of Tables
Table 6-1 VLAN tagging is OFF ...............................................................................................................27
Table 6-2 VLAN tagging is ON. ................................................................................................................27
Table 9-1 System Mode and Modulation Scheme..................................................................................50
Table 14-1 Time Sources..........................................................................................................................90
Table 15-1 Modulation Up/Downshift SNR Thresholds.........................................................................94
Table 17-1 Performance Log Durations................................................................................................121

Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
1.0 User Manual Structure
This user manual is divided into three volumes:
Volume 1 –Contains an overview of the product, basic configuration, installation and the
alignment procedures that are sufficient to set up a link and have it passing traffic. Also, a list of
the advanced configuration features.
Volume 2 (this volume) –includes step-by-step configuration details for the advanced
configuration features that are listed in Volume 1.
Volume 3 –contains a complete list of the frequency tables associated with the radio bands
supported by the Horizon Compact Plus
Volume 4 - Contains configuration details relating to industry standard networking features.

DragonWave Inc.
2
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
This page left blank intentionally

Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
2.0 Advanced Configuration Features
Volume 1 describes the configuration of the basic features that allow the Horizon Compact Plus to
provide a wireless Ethernet link, with a throughput of up to 400 Mbps. A number of advanced
configuration features provide enhanced throughput, system access and management security, link
protection, quality of service and alarm management. Each advanced feature is described in detail in
the following sections.
Note that all redundancy related commands (web, SNMP, CLI) are not supported in this release.
2.1 Dynamic Configuration Change
There are a number of CLI commands that normally require a save mib followed by a reset system
command to take effect. This is disruptive to network traffic. Four commands that normally require this
are:
set radio config
set ip configuration
set network management interface
set vlan tag
These four commands are part of the basic configuration requirements for the system (see Volume 1 of
this manual for more information).
Only the Super User can invoke the CLI command set dynamic config change on/off. When this
feature is turned on, the above four commands can be run and the various associated parameters
modified and applied without resetting the system. This has advantages, but note that if the radio link
between two systems is the sole management connection, any changes to the radio
configuration parameters (set radio config) on a local system will result in loss of
communication and management to the far end system.
The far end system radio configuration needs to be applied first and then the local system. In this way
communicatons across the link can be reinstated and the system brought back up running with the
revised radio configuration.
WARNING:
The set radio config CLI command may be used to change the radio configuration
of an existing working link. If management of the far end Horizon Compact Plus is
only via the radio link, then configure the far end radio first. Otherwise, if you
change the radio configuration of the near end radio first, you will lose the link to
the far end radio and be unable to manage or configure it.

DragonWave Inc.
4
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
This page is left blank intentionally

Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
3.0 Upgrade/Downgrade Licensed Features
Some of the features described in this manual are only available if a license for the feature(s) is obtained
from DragonWave Inc. These are as follows:
1. RLS - Rapid Link Shutdown
2. EOAM, ECFM(802.1ag/Y.1731) –EOAM and ECFM support
3. HAAM –Hitless Automatic Adaptive Modulation
To enable/disable any of these features there are CLI commands that provide information about your
system that DragonWave Inc. requires before it can provide you with the necessary license upgrade key,
or a refund for a downgraded feature. The first three items in the above list are called the Feature Group
and are indexed 1, 2 and 3. These features can be upgraded or downgraded using the
“Upgrade/Downgrade Feature Group” procedure. The fourth item in the list is upgraded/downgraded
using the “Upgrade and Downgrade System License Speed” procedures.
3.1 Upgrade/Downgrade Feature Group
The following procedure shows what features in the feature group may already be enabled and how they
are enabled or disabled.
Procedure 3-1
Upgrade/Downgrade Feature Group
Required Action
Steps
login
Log in using the Super user, or a NOC user, account.
List the licensed features
This command lists the licensed features available.
Sequence:
get licensed feature groups press Enter
The system responds:
Index Licensed Feature Group Is Licensed
1 RLS No
2 EOAM,ECFM(802.1ag/Y.1731) No
3 HAAM No

DragonWave Inc.
6
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
Required Action
Steps
List the indexed licensed feature
upgrade information.
Note that this information needs
to be sent to DragonWave Inc.
before an upgrade key can be
issued. Fees apply to upgrade
licenses.
This command lists the licensed features available for the Horizon Compact
Plus and also indicates if they are licensed for this sytem.
Sequence:
get feature group upgrade information [group index 1 to 3] press Enter
Examples:
get feature group upgrade information 1 press Enter
The system responds:
Feature group 'RLS' upgrade request information:
Count :0
Unit Serial Number :C1N14AED0013
MAC Address :00-07-58-03-14-AC
get feature group upgrade information 2 press Enter
The system responds:
Feature group 'EOAM,ECFM(802.1ag/Y.1731)' upgrade request information:
Count :0
Unit Serial Number :C1N14AED0013
MAC Address :00-07-58-03-14-AC
get feature group upgrade information 3 press Enter
The system responds:
Feature group 'HAAM' upgrade request information:
Count :0
Unit Serial Number :C1N14AED0013
MAC Address :00-07-58-03-14-AC
Note that this information needs to be sent to DragonWave Inc. before an
upgrade key can be issued. Fees apply to upgrade licenses.
Upgrade an indexed feature
Once you have paid for and received the required upgrade key, use this
command to upgrade your system.
Sequence:
upgrade feature group <group index> <license key>
Example:
upgrade feature group 3 61ba1455c138af096b312efe7f321b98 press
Enter
The system responds:
This operation will force to save MIB. Continue? Enter Y(Yes) or N(No):y
Feature group 'HAAM' is licensed!

Upgrade/Downgrade Licensed Feature
7
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
Required Action
Steps
Downgrade an indexed feature
Use this command to downgrade, or unlicense, a feature. Note, once
downgraded you will need another license key from DragonWave in order to
re-license a group.
Sequence:
downgrade feature group <group index>
Example:
downgrade feature group 3 press Enter
The system responds:
This operation will unlicense this feature group. Continue? Enter Y(Yes) or
N(No):y
The feature group is unlicensed!
Feature group 'HAAM' downgrade confirmation information:
Count :1
Unit Serial Number :A1316774M090014
MAC Address :00-07-58-02-92-10
Confirmation Number :c32d57d9c6765f9df34a99f48dee369d
Confirm downgrade information
This command will return the downgrade confirmation information, similar to
that provided by the downgrade feature group command.
Sequence:
get feature group downgrade information <group index>
Example:
get feature group downgrade information 3 press Enter
Feature group 'HAAM' downgrade confirmation information:
Count :1
Unit Serial Number :A1316774M090014
MAC Address :00-07-58-02-92-10
Confirmation Number :c32d57d9c6765f9df34a99f48dee369d

DragonWave Inc.
8
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
3.2 Upgrade System License Speed
Upgrading the system licensed speed requires an upgrade license key obtainable from DragonWave.
Upgrading the licensed speed does not cause you to lose the ability to reduce the speed and then
return to the new licensed speed at a later time.
Note that the throughput of a system (current speed) can be configured to be less than, or equal to, the
licensed speed. The actual throughput that the system will operate at is the lesser of the configured
current speed and the System Mode.
Procedure 3-2
Upgrading Horizon Compact Plus System License Speed
Required Action
Steps
login
Log in as a NOC user.
View existing licensed and
current system speeds
Returns the licensed speed key value, the current set system speed and the
set mode.
Sequence:
get system speed press Enter
The system responds:
Licensed speed set to : n Mbps
Current speed set to : n Mbps
System mode set to : <system mode>
Example:
Licensed speed set to :200 Mbps
Current speed set to :150 Mbps
System mode set to :hy50_285_128qam
Note that although the mode shows a speed of 285 Mbps, the actual speed
will be limited to the current speed, or the licensed speed, whichever is the
lower.

Upgrade/Downgrade Licensed Feature
9
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
Required Action
Steps
View the information required by
DragonWave Inc. in order to
process a licensed speed
upgrade request.
Returns the information requested by DragonWave for licensed speed
upgrade purposes.
Sequence:
get licensed speed upgrade information [required speed] press Enter
Example (assuming current licensed speed is 200 Mbps and we wish to
increase it to 400 Mbps):
get licensed speed upgrade information 400
The system responds:
Speed upgrade information:
Speed increment :200
Speed count :0
System MAC address :00-07-58-03-14-AC
Unit serial number :C1N14AED0013
This information must be sent to DragonWave along with the request for
a speed upgrade before a license upgrade key can be issued.
Upgrade system licensed speed
Upgrades the system to operate at a higher speed. A license upgrade key is
required for this command. Contact DragonWave.
Sequence:
upgrade system licensed speed [speed] [key] press Enter
Where [speed] is the new licensed speed, and [key] is the license upgrade
key obtained from DragonWave
Example –continued from above:
upgrade system licensed speed [400] [xxxxxxxxxxxxxxxxxxxxxx]
press Enter
This will upgrade the system license speed from 200 to 400 Mbps.

DragonWave Inc.
10
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
3.3 Downgrade System License Speed
Downgrading the system license speed to a value lower than previously purchased is supported.
Information presented by the system, when downgraded, needs to be sent to DragonWave in order to
confirm the status of your license.
NOTE: Once the system license speed has been downgraded, a new license key is required if
you wish to return to a higher licensed speed.
Note that the licensed speed is the maximum speed that the system can operate at, regardless of the
setting of the System Mode.
Procedure 3-3
Downgrading Horizon Compact Plus System License Speed
Required Action
Steps
login
Log in as a NOC user.
View system speed
Returns the licensed speed value, the current set system speed and the
set mode.
Sequence:
get system speed press Enter
The system responds:
Licensed speed set to : n Mbps
Current speed set to : n Mbps
System mode set to : <system mode>
Example:
Licensed speed set to :400 Mbps
Current speed set to :400 Mbps
System mode set to :hy50_364_256qam

Upgrade/Downgrade Licensed Feature
11
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
Required Action
Steps
Downgrade system licensed
speed
Downgrades the system licensed speed to operate at a lower maximum
speed.
Warning: Once you issue this command your current license speed
key will be lost and you will not be able to return to your original
licensed speed without acquiring another license key from
DragonWave.
Sequence:
downgrade system licensed speed [speed] press Enter
Where [speed] is the new lower licensed speed in Mbps.
Example:
downgrade system licensed speed 200
The system responds: (Example)
The current system licensed speed will be downgraded to 200 Mbps.
This operation will force to save Mib. Continue? Enter Y(Yes) or
N(No):y
Saving MIB. Please wait for a while...
Mib saved successfully.
The current system licensed speed is downgraded to 200 Mbps.
Downgrade Confirmation Information:
Speed Decrement :200
Speed Count :2
Unit Serial Number :DW130AAG0100
MAC Address :00-07-58-00-a2-16
Confirmation Number :bc7ed7dd89a4d98adbab263630a9a27e
To determine the status of your license, the information shown above,
under the heading “Downgrade Confirmation Information”, needs to be
sent to DragonWave, along with the current licensed speed count (see
next step).
Licensed speed count
This command returns the number of times that the licensed speed has
been changed. This value is required by DragonWave, in addition to the
information returned in the previous step, in order to determine the status
of your license.
Sequence :
get licensed speed count press Enter
The system responds :
Licensed Speed Counter is: 3 (Example)

DragonWave Inc.
12
Horizon Compact Plus Release 1.0.1 Wireless Ethernet Product User Manual –Volume 2
Required Action
Steps
Licensed speed downgrade
information
This command returns the licensed speed downgrade information that
was presented during the downgrade process. This is the same
information, along with the licensed speed count, that DragonWave
needs in order to verify the status of your license.
Sequence :
get licensed speed downgrade information press Enter
The system responds : (Example)
Downgrade Confirmation Information:
Speed Decrement :200
Speed Count :2
Unit Serial Number :DW130AAG0100
MAC Address :00-07-58-00-a2-16
Confirmation Number :bc7ed7dd89a4d98adbab263630a9a27e
