Draper 23312 User manual

HAND HELD
BRAKE PIPE
FLARING TOOL
3 ⁄ 16" SAE
23312 – BPF/HAND/SAE INSTRUCTIONS FOR USE
EN
Original Instructions
Version 1 – December 2023
Read this manual in full before using this product and retain it for future use. Always use the latest version of the manual.
Please visit drapertools.com/manuals for the latest version.
Helpline: [phone] Sales Desk: [phone] General Enquiries: [phone] Website: drapertools.com Email: [email protected]
Draper Tools Limited, Hursley Road, Chandler’s Ford, Eastleigh, Hampshire, SO53 1YF, UK 0123
1. Intended Use
This product is designed to are brake pipes of 3 ⁄ 16" and
4.75mm according to SAE Convex and SAE Double
standards. Any other application beyond the conditions
established for use will be considered misuse. Draper Tools
accepts no responsibility for improper use of this product.
Important: Ensure that you are familiar with the various
types of ares and their applications before using this
product. ALWAYS consult the vehicle manufacturer’s
instructions before use.
2. What’s in the Box?
Before assembling the product, lay the contents out and
check them against the parts listed below.
If any part is damaged or missing, do not attempt to use the
product; please contact the Draper Helpline.
A. 1 × Flaring tool
A1. Die
A2. Locking screws
B. 1 × Double-ended 3 ⁄ 16" punch
C. 1 × Stop punch
D. 1 × Punch grease
3. Operating Instructions
1. Partly screw the stop punch (C) into the aring tool so
that the nut is no more than 5mm from the die (A1).
1 Fig.
(C)
(A1)
2. Ensure that the tube nut is installed onto the brake pipe,
then insert the brake pipe into the open end of the die
and hand-tighten the locking screws (A2) just enough to
grip the pipe.
2 Fig.
(A2)
Important: DO NOT over tighten the locking screws at
this stage as the stop punch may damage the pipe.
(A)
(D)
(C)
(A1)
(A2)
(B)

3. Use a 16mm spanner (not supplied) to screw the stop
punch fully into the die until tight.
3
Fig.
4. Use a 10mm spanner (not supplied) to fully tighten the
locking screws and secure the pipe.
Important: If the locking screws are not suciently
tight, the pipe will move during the aring process and
damage the are.
5. Unscrew the stop punch from the die.
6. Fully screw the OP. 1 end of the 3 ⁄ 16" punch (B) into the
die until it is tight (see the punch nut for identication).
(B)
4 Fig.
7. Remove the punch from the die; the SAE Convex are is
complete.
8. To create an SAE Double are, fully screw the other end
of the punch into the die until it is tight, then remove it.
5 Fig.
9. Loosen the locking screws and remove the pipe from the
tool.
4. Preparing the Brake Pipe
Important: ALWAYS ensure that the brake pipe is correctly
prepared before aring.
• The end of the pipe MUST be cut square.
• The outside edge of the pipe must be chamfered by
approximately 0.25mm at 45°.
• The bore of the pipe must be deburred.
• If the pipe is plastic-coated, remove at least 6mm from
the end of the pipe to be ared, ensuring that the pipe is
not scored and that no metal is removed while doing so.
Important: DO NOT use an abrasive cloth on the end of the
brake pipe to be ared.
5. Maintenance and Storage
• Clean the product of dust or debris before and after
each use.
• Replace any punch that shows signs of damage or
excessive wear.
• Before storing the product, wipe it thoroughly with a
lightly oiled cloth to prevent corrosion of the exposed
metal parts.
• Store the product in a clean and dry environment, out of
reach of children.
6. Explanation of Symbols
Read the instruction manual
Flaring output size
