Chapter 1
INTRODUCTION
9777PC1 Key Features
The 9777PC1 is a Professional sound card.
Its features meet professional musical application requirements.
This card can be used as a professional PnP sound board for Windows applications.
Effect processor
9777PC1 provides 16 reverb/chorus programs, a 4 band stereo equalizer and a surround 2 speaker
system.
Those effects can be applied on all the sound devices: Wave table, DSP waves, Line input and Mic input.
Wave Table Synthesis
9777PC1 provides 1M sample RAM Wave Table that will make your midi sequences sounds realistic.
Professional Synthesizer
The use of your PC’s memory enables the DSP to download and edit instruments. This lets you use the
9777PC1 as a professional synthesizer/sampler.
Direct To Disk
The 9777PC1 provides DtD full duplex capabilities with 8 stereo play waves with individual volume
panoramic reverb send and chorus send controls and one stereo record track.
(Simultaneous play wave number is subject to the PC hard disk performances).
Direct Sound
The 9777PC1 support Microsoft Direct Sound Features. This includes:
- Hardware mixing of Multi waves (up to 32 waves)
- 3D position & dynamic audio sources
Upgradable
Open to third party firmware download.
an Company
9777PC1 Sound card User’s guide 5
9777PC1 CD-ROM Content
Hardware installation
DREAM97.INF Device installation file
9777BK08.97B Sound bank
SAM97V.VXD Virtual driver file
SAM97D.DRV Driver file
DVB9772.BIN Firmware file
SAM9777.PDF SAM9777 IC data sheet
9777PC1.PDF This document
SNDBANK\ 8, 32 and 64Mbit Sound banks
G*.PDF Sound bank documentation
SNDEDIT\ Sound editor subdirectory
PROS77.PDF Sound tools (editor user manuals & sound list)
SETUP.EXE WIN setup Dream Instrument Editor & Dream Sound Bank Editor
SOFTWARE\ Programming libraries
PROREF77.PDF Programmer’s reference (Windows API & MPU messages)
BIN\ Files for AutoRun CD-ROM and Demo
ACROBAT3\ Acrobat™ Reader 3.01 from Adobe™
an Company
9777PC1 Sound card User’s guide 6
The 9777PC1 Sound Synoptic
Wave Table Synthesis
The High quality wave table synthesis provides 32 midi channels with 64 maximum voices of polyphony
(according to the configuration).
The 24 dB resonant filter and the audio CD quality samples provides professional synthesizer sound quality.
The use of the memory of your PC allows to download high quality GM factory sound bank.
DSP Waves
The DSP waves ensures the high quality required by professional musical applications.
Multi waves for DtD (Direct to Disk) applications: 8 stereo play tracks + 1 stereo record track simultaneous.
High quality wave due to the interpolation and the digital filter
Up to 65KHz sampling rate with 8/16 bits mono/stereo format, (48 KHz nominal sampling rate).
Individual send to the reverb and the chorus effects provided by the DSP mixer.
an Company
9777PC1 Sound card User’s guide 7
DSP Mixer
The DSP Mixer provides for all inputs an individual volume, panoramic , reverb and chorus send:
•32 mono inputs: Wave table
•8 stereo inputs: DSP waves
•1 stereo input: Line In / Mic In
Line input provides an additional echo with effect volume delay and feedback control.
DSP Waves record
This device records DSP mixer output including reverb & chorus in 8/16 bits mono/stereo format up to 65KHz
sampling rate.
Reverb Chorus
Reverb and chorus comply to GS standard:
•8 Reverb programs, effect volume, time and feedback controls.
•8 chorus programs, effect volume, delay, feedback, rate and depth controls.
Equalizer
Stereo four band parametric equalizer with +/- 12 dB band level
Surround
Surround processing enables to expand stereo image of a stereo signal or to create a pseudo stereo image from a
monophonic source. Surround operates on 2 or 4 speakers configuration.
The 9777PC1 surround processing involves a delay line that enables to creates actual 3D sound unlike most of the
products that claim to offer 3D sound.
an Company
9777PC1 Sound card User’s guide 8
Chapter 2
INSTALLATION
System Requirements
•PC with Pentium™ or above.
•Windows 95/98
•9777PC1 card
•CD ROM unit
•3 Mb disk space for installation
WIN95 Hardware Installation
•Turn power off
•Plug the card into an unused PCI slot.
•Turn power on
•WIN95 plug & play sequence finds new hardware « SAM9777 : PCI sound card »
•WIN95 asks for drivers to install
•Select « Driver from disk provided by hardware manufacturer»
•Browse into « cdrom:\Dream97.inf»
•Follow WIN95 installation procedure.
•Now your hardware is installed
WIN95 OSR2 (IE 4) Hardware Installation
•Turn power off
•Plug the card into an unused PCI slot.
•Turn power on
•Insert CD-ROM
•WIN95 plug & play sequence finds new hardware « SAM9777 : PCI sound card »
•WIN95 asks for drivers to install and automatically check CD-ROM
•WIN95 asks for disk
•Browse into « cdrom:\Dream97.bin »
•Follow WIN95 installation procedure.
•Now your hardware is installed
an Company
9777PC1 Sound card User’s guide 9
WIN98 Hardware Installation
•Turn power off
•Plug the card into an unused PCI slot.
•Turn power on
•Insert CD-ROM
•WIN98 plug & play sequence finds new hardware « SAM9777 : PCI sound card »
•WIN98 asks for drivers to install and asks to check a device, select CD-ROM
•Browse into « cdrom:\Dream97.bin »
•Follow WIN98 installation procedure.
•Now your hardware is installed
WIN95/98 Joystick Installation
•To install the joystick:
•From « start / settings /control panel / Add new hardware »
•WIN95/98 asks to automatically check for new hardware, select « No »
•Browse « sound, video & game controllers »
•In the « Manufacturers list » select « Microsoft » and in the « Products list » select « Gameport »
•Follow WIN98 installation procedure.
•Now the Game port is installed
WIN95/98 Hardware Checking
•From "start / settings /control panel / system / device manager / sound, video & game controllers",
check that your card is correctly installed. It should appears as « SAM9777 : PCI sound card »
•To define the 9777PC1 Wave table as default MIDI device:
From « start / settings /control panel / multimedia / midi »: select « Midi Dream »
•To define the 9777PC1 Wave as default wave device:
From « start / settings /control panel / multimedia / wave »:
select « DREAM 9777, wave Nb1 » as playback
select « DREAM 9777, wave record » as recording
check « show volume control on the taskbar »
•Now your hardware is checked & configured
WIN95/98 Hardware Uninstallation
•To Uninstall the 9777PC1 sound card:
From « start / settings /control panel / Add/Remove programs »:
select « SAM9777 : PCI sound card - Uninstall »
•Follow the Uninstall procedure
•Turn the power off
•remove the 9777PC1 card
•Now your hardware is correctly uninstalled
an Company
9777PC1 Sound card User’s guide 10
Installation Troubleshooting
•From "start / settings /control panel / system / device manager / sound, video & game controllers",
check that your card is correctly installed.
•If the device Icon is overlaid with a yellow circle, this means that the device installation failed.
Installation failures may comes from problem with previous installations :
uninstall the card and reboot the PC
Re-install the hardware
WIN95/98 Software Installation
•When your Hardware is installed you can use the Microsoft multimedia applications: mixer and
media player.
•To install the professional sound editors:
•From « start / run », browse « cdrom:\sndedit\setup.exe »
•The Dream instrument & sound bank editors applications are installed
•Run instrument editor from « start / programs / Dream Editors / Dream Instrument Editor »
•Run sound bank editor from « start / programs / Dream Editors / Dream Sound Bank Editor »
WIN95/98 Software Uninstallation
•To Uninstall the Dream bundle software:
From « start / settings /control panel / Add/Remove programs » select:
«DREAM Editors - Uninstall »
•Follow the Uninstall procedure
•Now your software is correctly uninstalled
an Company
9777PC1 Sound card User’s guide 11
9777PC1 External connection
J4 SAM9777 auxiliary input (1 & 2 : left and right, 3 : GND)
•Connect Line out to the front stereo powered speakers
•Connect Line in to an external audio stereo line source (CD player, Windows sound system audio
card line output
•Connect Mic in to an external microphone
•Connect a MIDI/Gameport connector to use external MIDI IN & OUT / Joystick
an Company
9777PC1 Sound card User’s guide 12
Chapter 3
SOFTWARE APPLICATIONS
For information about the professional sound editors, please refer to the « Pro Sound » documentation.
Microsoft Windows Mixer
This is the Microsoft Windows main mixer. You can control main, microphone, line-in, wave and MIDI volume.
This is the Microsoft Windows recording mixer. You can select one of microphone, line-in or mix record.
an Company
9777PC1 Sound card User’s guide 13
This is the effect send control panel. You can send reverb, chorus and echo effect either on microphone or line in.
an Company
9777PC1 Sound card User’s guide 14
Chapter 4
MIDI IMPLEMENTATION
DREAM Specific MIDI Messages
Various features of the SAM9777 can be also controlled by NRPN MIDI messages as follows :
NRPN #
(High|Low) Description Power-up
default
3700H Equalizer Low band (bass) 0=-12dB, 40H=0dB, 7FH=+12dB 60H (+6dB)
3701H Equalizer Med Low band 0=-12dB, 40H=0dB, 7FH=+12dB 40H (0dB)
3702H Equalizer Med High band 0=-12dB, 40H=0dB, 7FH=+12dB 40H (0dB)
3703H Equalizer High band (treble) 0=-12dB, 40H=0dB, 7FH=+12dB 60H (+6dB)
3708H Equalizer Low cutoff freq 0=0Hz, 7FH=4.7 kHz 0CH
3709H Equalizer Med Low cutoff freq 0=0Hz, 7FH=4.2 kHz 1BH
370AH Equalizer Med High cutoff freq 0=0Hz, 7FH=4.2 kHz 72H
370BH Equalizer High cutoff freq 0=0Hz, 7FH=18.75 kHz 40H
3720H Spatializer effect volume 0= no effect, 7FH= maximum effect 00H
3724H Mike1/AUXL volume 0 to 7FH 40H
3725H Mike2/AUXR volume 0 to 7FH 40H
3726H Mike 1/AUXL pan 0=hard left, 40H=center, 7FH=hard right 00H (left)
3727H Mike 2/AUXR pan 0=hard left, 40H=center, 7FH=hard right 7FH (right)
372CH Spatializer effect delay 0 to 7FH 2
372DH Spatializer effect input 0=mono input (left+right), 7Fh=stereo input (left-right) 0
372EH Spatializer effect output mode 0=2 speaker mode, 7Fh=4 speaker mode 0
3751H Rom + 32Kx16 sram test nprn data must be 23h to start test
an Company
9777PC1 Sound card User’s guide 15
Detailed MIDI Implementation
MIDI
MESSAGE HEX CODE DESCRIPTION COM-
PATIBI-
LITY
NOTE ON 9nH kk vv Midi channel n(0-15) note ON #kk(1-127), velocity vv(1-127). vv=0
means NOTE OFF MIDI
NOTE OFF 8nH kk vv Midi channel n(0-15) note OFF #kk(1-127),
vv is don’t care. MIDI
PITCH BEND EnH bl bh Pitch bend as specified by bh|bl (14 bits)
Maximum swing is +/- 1 tone (power-up). Can be changed using
«pitch bend sensitivity ». Center position is 00H 40H.
GM
PROGRAM
CHANGE CnH pp Program (patch) change. Specific action on channel 10 (n=9) : select
drumset. Refer to sounds / drumset list. Drumsets can be assigned to
other channels (see SYSEX MIDI channel to part assign and part to
rhythm allocation)
GM/GS
CHANNEL
AFTERTOUCH DnH vv vv pressure value. Effect set using Sys. Ex. 40H 2nH 20H-26H MIDI
MIDI RESET FFH Reset to power-up condition
CTRL 00 BnH 00H cc Bank select : Refer to sounds list. No action on drumset. cc=64
reserved for dream sound editor GS/
DREAM
CTRL 01 BnH 01H cc Modulation wheel. Rate and maximum depth can be set using SYSEX MIDI
CTRL 05 BnH 05H cc Portamento time. MIDI
CTRL 06 BnH 06H cc Data entry : provides data to RPN and NRPN MIDI
CTRL 07 BnH 07H cc Volume (default=100) MIDI
CTRL 10 BnH 0AH cc Pan (default=64 center) MIDI
CTRL 11 BnH 0BH cc Expression (default=127) MIDI/GM
CTRL 64 BnH 40H cc Sustain (damper) pedal MIDI
CTRL 65 BnH 41H cc Portamento ON/OFF MIDI
CTRL 66 BnH 42H cc Sostenuto pedal MIDI
CTRL 67 BnH 43H cc Soft pedal MIDI
CTRL 80 BnH 50H vv Reverb program vv=00H to 07H (default 04H)
00H : Room1 01H : Room2
02H : Room3 03H : Hall1
04H : Hall2 05H : Plate
06H : Delay 07H : Pan delay
DREAM
CTRL 81 BnH 51H vv Chorus program vv=00H to 07H (default 02H)
00H : Chorus1 01H : Chorus2
02H : Chorus3 03H : Chorus4
04H : Feedback 05H : Flanger
06H : Short delay 07H : FB delay
DREAM
CTRL 91 BnH 5BH vv Reverb send level vv=00H to 7FH GS
CTRL 93 BnH 5DH vv Chorus send level vv=00H to 7FH GS
CTRL 120 BnH 78H 00H All sound off (abrupt stop of sound on channel n) MIDI
CTRL 121 BnH 79H 00H Reset all controllers MIDI
CTRL 123 BnH 7BH 00H All notes off MIDI
CTRL 126 BnH 7EH 00H Mono on MIDI
CTRL 127 BnH 7FH 00H Poly on (default power-up) MIDI
CTRL CC1 BnH ccH vvH Assignable Controller 1. cc=Controller number (0-5Fh), vv=Control
value (0-7Fh). Control number (ccH) can be set on CC1
CONTROLLER NUMBER (Sys. Ex 40 1x 1F). The resulting effect is
determined by CC1 controller function (Sys.Ex. 40 2x 40-4A)
GS
CTRL CC2 BnH ccH vvH Assignable Controller 2. cc=Controller number (00h-5Fh), vv=control
value (0-7Fh). Control number can be set on CC2 CONTROLLER
NUMBER (Sys.Ex. 40 1x 20). The resulting effect is determined by
CC2 controller function (Sys.Ex.40 2x 50-5A).
RPN 0000H BnH 65H 00H 64H 00H 06H vv Pitch bend sensitivity in semitones (default=2) MIDI/GM
RPN 0001H BnH 65H 00H 64H 01H 06H vv Fine tuning in cents (vv=00 -100, vv=40H 0, vv=7FH +100 MIDI
RPN 0002H BnH 65H 00H 64H 02H 06H vv Coarse tuning in half-tones (vv=00 -64, vv=40H 0, vv=7FH +64 MIDI
NRPN 0108H BnH 63H 01H 62H 08H 06H vv Vibrate rate modify (vv=40H -> no modif) GS
NRPN 0109H BnH 63H 01H 62H 09H 06H vv Vibrate depth modify (vv=40H -> no modif) GS
NRPN 010AH BnN 63H 01H 62H 0AH 06H vv Vibrate delay modify (vv=40H -> no modif) GS
NRPN 0120H Bnh 63H 01H 62H 20H 06H vv TVF cutoff freq modify(vv=40H -> no modif) GS
NRPN 0121H BnH 63H 01H 62H 21H 06H vv TVF resonance modify (vv=40H -> no modif) GS
NRPN 0163H Bnh 63H 01H 62H 63H 06H vv Env. attack time modify(vv=40H ->no modif) GS
NRPN 0164H BnH 63H 01H 62H 64H 06H vv Env. decay time modify(vv=40H -> no modif) GS
an Company
9777PC1 Sound card User’s guide 16
NRPN 0166H BnH 63H 01H 62H 66H 06H vv Env. release time modif(vv=40H ->no modif) GS
NRPN 18rrH BnH 63H 18H 62H rr 06H vv Pitch coarse of drum instr. note rr in semitones (vv=40H -> no modif) GS
NRPN 1ArrH BnH 63H 1AH 62H rr 06H vv Level of drum instrument note rr (vv=00 to 7FH) GS
NRPN 1CrrH BnH 63H 1CH 62H rr 06H vv Pan of drum instrument note rr (40H = middle) GS
NRPN 1DrrH BnH 63H 1DH 62H rr 06H vv Reverb send level of drum instrument note rr (vv=00 to 7FH) GS
NRPN 1ErrH BnH 63H 1EH 62H rr 06H vv Chorus send level of drum instrument note rr
(vv=00 to 7FH) GS
NRPN 37xxH BnH 63H 37H 62H xx 06H vv Special SAM9503 features controls (see §1- above) DREAM
Sysex F0H 7EH 7FH 09H 01H F7H General MIDI reset GM
Sysex F0H 7FH 7FH 04H 01H 00H ll F7H Master volume (ll=0 to 127, default 127) GM
SYSEX F0H 41H 00H 42H 12H 40H 00H
00H dd dd dd dd xx F7H Master tune (default dd= 00H 04H 00H 00H) -100.0 to +100.0 cents.
Nibblized data should be used (always four bytes). For example, to
tune to +100.0 cents, sent data should be 00H 07H 0EH 08H
GS
SYSEX F0H 41H 00H 42H 12H 40H 00H
04H vv xx F7H Master volume (default vv=7FH) GS
SYSEX F0H 41H 00H 42H 12H 40H 00H
05H vv xx F7H Master key-shift (default vv=40H, no transpose) GS
SYSEX F0H 41H 00H 42H 12H 40H 00H
06H vv xx F7H Master pan (default vv=40H, center)
SYSEX F0H 41H 00H 42H 12H 40H 00H
7FH 00H xx F7H GS reset GS
SYSEX F0H 41H 00H 42H 12H 40H 01H
30H vv xx F7H Reverb type (vv=0 to 7), default = 04H
00H : Room1 01H : Room2
02H : Room3 03H : Hall1
04H : Hall2 05H : Plate
06H : Delay 07H : Pan delay
GS
SYSEX F0H 41H 00H 42H 12H 40H 01H
31H vv xx F7H Reverb character, default 04H GS
SYSEX F0H 41H 00H 42H 12H 40H 01H
33H vv xx F7H Reverb master level, default = 64 GS
SYSEX F0H 41H 00H 42H 12H 40H 01H
34H vv xx F7H Reverb time GS
SYSEX F0H 41H 00H 42H 12H 40H 01H
35H vv xx F7H Reverb delay feedback. Only if reverb number=6 or 7 (delays) GS
SYSEX F0H 41H 00H 42H 12H 40H 01H
38H vv xx F7H Chorus type (vv=0 to 7), default = 02H
00H : Chorus1 01H : Chorus2
02H : Chorus3 03H : Chorus4
04H : Feedback 05H : Flanger
06H : Short delay 07H : FB delay
GS
SYSEX F0H 41H 00H 42H 12H 40H 01H
3AH vv xx F7H Chorus master level, default = 64 GS
SYSEX F0H 41H 00H 42H 12H 40H 01H
3BH vv xx F7H Chorus feedback GS
SYSEX F0H 41H 00H 42H 12H 40H 01H
3CH vv xx F7H Chorus delay GS
SYSEX F0H 41H 00H 42H 12H 40H 01H
3DH vv xx F7H Chorus rate GS
SYSEX F0H 41H 00H 42H 12H 40H 01H
3EH vv xx F7H Chorus depth GS
SYSEX F0H 41H 00H 42H 12H 40H 1pH
02H nn xx F7H MIDI channel to part assign, p is part (0 to 15), nn is MIDI channel (0
to 15, 16=OFF).
This SYSEX allows to assign several parts to a single MIDI channel or
to mute a part.
Default assignment :
part MIDI channel
09(DRUMS)
1-9 0-8
10-15 10-15
GS
an Company
9777PC1 Sound card User’s guide 17
SYSEX F0H 41H 00H 42H 12H 40H 1pH 15H vv
xx F7H Part to rhythm allocation, p is part (0 to 15), vv is 00 (sound part)
or 01 (rhythm part).
This SYSEX allows a part to play sound or drumset. There is no
limitation of the number of parts playing drumset.
Default assignment : part 0 plays drums (default MIDI channel 9)
all other parts play sound.
GS
SYSEX F0H 41H 00H 42H 12H 40H 1nH 40H v1
v2 ... v12 xx F7H Scale tuning, n is MIDI channel (0 to 15), v1 to v12 are 12 semi-
tones tuning values (C, C#, D, ... A#, B), in the range -64 (00H)
0 (40H) +63(7FH) cents.
This SYSEX allows non chromatic tuning of the musical scale on
a given MIDI channel.
Default v1, v2, ... ,v12 = 40H, 40H,...,40H (chromatic tuning).
Scale tuning has no effect if the part is assigned to a rhythm
channel or if the sound played is not of chromatic type.
GS
SYSEX F0H 41H 00H 42H 12H 40H 1nH 1AH vv
xx F7H Velocity slope from 00H to 7FH (default = 40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 1nH 1BH vv
xx F7H Velocity offset from 00H to 7FH (default = 40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 1nH 1FH vv
xx F7H CC1 Controller number (00-5FH) (default = 10H) GS
SYSEX F0H 41H 00H 42H 12H 40H 1nH 20H vv
xx F7H CC2 Controller number (00-5FH) (default = 11H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 00H vv
xx F7H Mod pitch control (-24,+24 semitone) (default = 40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 01H vv
xx F7H Mod tvf cutoff control (default = 40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 02H vv
xx F7H Mod Amplitude control (-100%-+100%) (default=40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 03H vv
xx F7H Mod lfo1 rate control (default = 40H). n is don’t care. Rate is
common on all channels GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 04H vv
xx F7H Mod lfo1 pitch depth (0-600 cents) (default=0AH) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 05H vv
xx F7H Mod lfo1 tvf depth (default = 0H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 06H vv
xx F7H Mod lfo1 tva depth (0-100%) (default = 0H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 10H vv
xx F7H Bend pitch control (-24,+24 semitone) (default = 42H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 11H vv
xx F7H Bend tvf cutoff control (default = 40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 12H vv
xx F7H Bend Amplitude control (-100%-+100%) (default=40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 14H vv
xx F7H Bend lfo1 pitch depth (0-600 cents) (default=0AH) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 15H vv
xx F7H Bend lfo1 tvf depth (default = 0H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 16H vv
xx F7H Bend lfo1 tva depth (0-100%) (default = 0H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 20H vv
xx F7H CAF pitch control (-24,+24 semitone) (default = 40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 21H vv
xx F7H CAF tvf cutoff control (default = 40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 22H vv
xx F7H CAF Amplitude control (-100%-+100%) (default=40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 24H vv
xx F7H CAF lfo1 pitch depth (0-600 cents) (default=0AH) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 25H vv
xx F7H CAF lfo1 tvf depth (default = 0H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 26H vv
xx F7H CAF lfo1 tva depth (0-100%) (default = 0H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 40H vv
xx F7H CC1 pitch control (-24,+24 semitone) (default = 40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 41H vv
xx F7H CC1 tvf cutoff control (default = 40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 42H vv
xx F7H CC1 Amplitude control (-100%-+100%) (default=40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 44H vv
xx F7H CC1 lfo1 pitch depth (0-600 cents) (default=0AH) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 45H vv
xx F7H CC1 lfo1 tvf depth (default = 0H) GS
an Company
9777PC1 Sound card User’s guide 18
SYSEX F0H 41H 00H 42H 12H 40H 2nH 46H vv
xx F7H CC1 lfo1 tva depth (0-100%) (default = 0H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 50H vv
xx F7H CC2 pitch control (-24,+24 semitone) (default = 40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 51H vv
xx F7H CC2 tvf cutoff control (default = 40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 52H vv
xx F7H CC2 Amplitude control (-100%-+100%) (default=40H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 54H vv
xx F7H CC2 lfo1 pitch depth (0-600 cents) (default=0AH) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 55H vv
xx F7H CC2 lfo1 tvf depth (default = 0H) GS
SYSEX F0H 41H 00H 42H 12H 40H 2nH 56H vv
xx F7H CC2 lfo1 tva depth (0-100%) (default = 0H) GS
notes :
NRPN sending method : CTRL#99=high byte, CTRL#98=low byte, CTRL#6=vv
Example : NRPN 0108H = 40H -> CTRL#99=1, CTRL#98=8, CTRL#6=64
x or xx means « don’t care »
an Company
9777PC1 Sound card User’s guide 19
Sound List
MAIN SOUNDS - GENERAL MIDI (all channels except 10)
PC : Program change
PC GENERAL MIDI PC GENERAL MIDI PC GENERAL MIDI PC GENERAL MIDI
1(Grand) Piano 1 33 Acoustic Bass 65 Soprano Sax 97 FX 1 (rain)
2(Bright) Piano 2 34 Finger Bass 66 Alto Sax 98 FX 2 (soundtrack)
3(El. Grd) Piano 3 35 Picked Bass 67 Tenor Sax 99 FX 3 (crystal)
4Honky-tonk Piano 36 Fretless Bass 68 Baritone Sax 100 FX4 (atmosphere)
5El. Piano 1 37 Slap Bass 1 69 Oboe 101 FX 5 (brightness)
6El. Piano 2 38 Slap Bass 2 70 English Horn 102 FX 6 (goblins)
7Harpsichord 39 Synth Bass 1 71 Bassoon 103 FX 7 (echoes)
8Clavi 40 Synth Bass 2 72 Clarinet 104 FX 8 (sci-fi)
9Celesta 41 Violin 73 Piccolo 105 Sitar
10 Glockenspiel 42 Viola 74 Flute 106 Banjo
11 Music Box 43 Cello 75 Recorder 107 Shamisen
12 Vibraphone 44 Contrabass 76 Pan Flute 108 Koto
13 Marimba 45 Tremolo Strings 77 Blown Bottle 109 Kalimba
14 Xylophone 46 Pizzicato Strings 78 Shakuhachi 110 Bag pipe
15 Tubular Bells 47 Orchestral Harp 79 Whistle 111 Fiddle
16 Santur 48 Timpani 80 Ocarina 112 Shanai
17 Drawbar Organ 49 String Ensemble 1 81 Lead 1 (square) 113 Tinkle Bell
18 Percussive Organ 50 String Ensemble 2 82 Lead 2 (sawtooth) 114 Agogo
19 Rock Organ 51 Synth Strings 1 83 Lead 3 (calliope) 115 Steel Drums
20 Church Organ 52 Synth Strings 2 84 Lead 4 (chiff) 116 Woodblock
21 Reed Organ 53 Choir Aahs 85 Lead 5 (charang) 117 Taiko Drum
22 Accordion (french) 54 Voice Oohs 86 Lead 6 (voice) 118 Melodic Tom
23 Harmonica 55 Synth Voice 87 Lead 7 (fifths) 119 Synth Drum
24 Tango Accordion 56 Orchestra Hit 88 Lead8 (bass+lead) 120 Reverse Cymbal
25 Ac. Guitar (nylon) 57 Trumpet 89 Pad 1 (fantasia) 121 Gt. Fret Noise
26 Ac. Guitar (steel) 58 Trombone 90 Pad 2 (warm) 122 Breath Noise
27 El. Guitar (jazz) 59 Tuba 91 Pad 3 (polysynth) 123 Seashore
28 El. Guitar (clean) 60 Muted Trumpet 92 Pad 4 (choir) 124 Bird Tweet
29 El. Guitar (muted) 61 French Horn 93 Pad 5 (bowed) 125 Teleph. Ring
30 Overdriven Guitar 62 Brass Section 94 Pad 6 (metallic) 126 Helicopter
31 Distortion Guitar 63 Synth Brass 1 95 Pad 7 (halo) 127 Applause
32 Guitar harmonics 64 Synth Brass 2 96 Pad 8 (sweep) 128 Gunshot
an Company
9777PC1 Sound card User’s guide 20
SOUND VARIATIONS (all channels except 10)
To select variation : send CTRL 0, then PC
PC : Program change
C0 : controller 0 value (zero for General Midi capital sounds)
PC GENERAL MIDI C0 1st VAR C0 2nd VAR C0 3rd VAR
1(Grand) Piano 1 127 Acou Piano 1
2(Bright) Piano 2 Acou Piano 2
3(El. Grd) Piano 3 Acou Piano 3
4Honky-tonk Piano Elec Piano 1
5El. Piano 1 8Detuned EP 1 Elec Piano 2
6El. Piano 2 8Detuned EP 2 Elec Piano 3
7Harpsichord 8Coupled Hps. Elec Piano 4
8Clavi Honky Tonk
9Celesta Elec Org 1
10 Glockenspiel Elec Org 2
11 Music Box Elec Org 3
12 Vibraphone Elec Org 4
13 Marimba Pipe Org 1
14 Xylophone Pipe Org 2
15 Tubular Bells 8Church Bell Pipe Org 3
16 Dulcimer (Santur) Accordion
17 Drawbar Organ 8Det. Organ 1 Harpsi 1
18 Percussive Organ 8Det. Organ 2 Harpsi 2
19 Rock Organ Harpsi 3
20 Church Organ 8Ch. Organ 2 Clavi 1
21 Reed Organ Clavi 2
22 Accordion (french) 8Acc. (Italian) Clavi 3
23 Harmonica Celesta 1
24 Tango Accordion Celesta 2
25 Ac. Guitar (Nylon) 8Ukulele Syn Brass 1
26 Ac. Guitar (Steel) 812-str. Guitar Syn Brass 2
27 El. Guitar (jazz) 8Hawaiian Gt. Syn Brass 3
28 El. Guitar (clean) 8Chorus Gt. Syn Brass 4
29 El. Guitar (muted) 8Funk Gt. Syn Bass 1
30 Overdriven Guitar Syn Bass 2
31 Distortion Guitar 8Feedback Gt. Syn Bass 3
32 Guitar harmonics 8Gt. Feedback Syn Bass 4
33 Acoustic Bass Fantasy
34 Finger Bass Harmo Pan
35 Picked Bass Chorale
36 Fretless Bass Glasses
37 Slap Bass 1 SoundTrack
38 Slap Bass 2 Atmosphere
39 Synth Bass 1 8Synth. Bass 3 Warm Bell
40 Synth Bass 2 8Synth. Bass 4 Funny Vox
Table of contents
Other Dream Sound Card manuals
