dreo Lynx CF511 User manual

DREO
Air Circulator Fan
USER MANUAL

Thanks for
Choosing
DREO!
Your support means the world to us. We
hope you enjoy our product as much as
we did creating it.
¢ ® © @Dreo

CONTENTS
IMPORTANT SAFETY KNOWING YOUR
INSTRUCTIONS AIR CIRCULATOR
FAN
1-2 3-5
USING YOUR AIR CLEANING AND
CIRCULATOR FAN MAINTENANCE
6-10 1-14
TROUBLESHOOTING DREO CUSTOMER
CARE
15 16

IMPORTANT SAFETY
INSTRUCTIONS
®®
READ ALL CAUTIONARY Donot coverthe Do not use the air
MARKINGS ON THE APPLIANCE airinlet and outlet circulator near
AND
SAFETY
INSTRUCTIONS
flammables
and
IN
THE
USER
MANUAL
BEFORE
while
in
operation.
combustibles.
use
General Safety
Children shall not play with the appliance. Cleaning and maintenance shall
not be performed by children without supervision.
n
Use the appliance as described in the user manual only. Any other use not
recommended in the user manual may cause fire, electrical shock, or personal
injury.
w
This appliance can be used by children aged above 8 years and persons with
reduced physical, sensory or mental capabilties or lack of experience and
knowledge if they have been given supervision or instruction concerning use
of this appliance in a safe way and understand the hazards involved.
Operation Safety
Place the appliance on a flat, dry surface before use.
Do not immerse in water and any other liquids.
Do not use the appliance until the base is installed
Do not insert your fingers, pencil and any other objects into the grilles
iunder any circumstances.
5. Do not dismantle, repair, or modify. All servicing should be performed by
qualified personnel.
6. Do not operate the unit close to the curtain. Do not hang foreign objects
on the grile to prevent damaging the balance of the fan or rotational structure.
7. Do not operate the fan under overly humid, high-temperature, dusty
environment or the place where acid or alkall is stored.
8. Fans should never blow directly on infant, the elderly and_patients for a
long time.
s

Electricity Safety
WARNING:
1
n
w
3
o
o
~
Make sure that the voltage of your electricity supply is the same as that
indicated on the appliance.
. Always unplug before cleaning or leaving the appliance unused for a long
period of time. Keep your hands dry when plugginglunplugging,
Do not operate any air circulator with a damaged cord or plug. Discard air
circulator or return to an authorized service facility for examination andior repair.
Do not run cord under carpeting. Do not cover cord with throw rugs, runners,
or similar coverings. Do not route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be tripped over.
WARNING: To reduce the risk of fire or electric shock, do not use this
air circulator with any solid-state speed control device.
This appliance employs overload protection (fuse). A blown fuse indicates an
overload or short-circuit situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing instructions and check
the appliance. If the replacement fuse blows, a short-circuit may be present
and the appliance should be discarded or retured to an authorized service
facility for examination andor repar
This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to fit in a polarized outlet
only one way, If the plug does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. Do not attempt to defeat this
safety feature.
FOR HOUSEHOLD USE ONLY READ
AND SAVE THESE INSTRUCTIONS
Gentle Reminder: Specifications
Check the appliance reguiarly and Model DRHAFOO!
fefer to TROUBLESHOOTING o1
Q) o P
¥ CPows oy of th folowi S
Rated Power 52w
- Power cord or plug is damaged.
- Loud noise, unusual smell or excessive heat. Battery Type CR2025 3V

KNOWING YOUR
AIR CIRCULATOR
FAN
Package Contents
Air Outlet
LED Display -
Control /
Panel N\
Base \ =
Air Inlet
Quick start
Power & Plug

Control Panel
Power Button
+ Turn power on/off
+ Long press 10 seconds to reset to factory settings
Mode Button
« Switch between Normal/Auto Mode
« Long press to mutefunmute:
Fan Speed Button
Adjust airflow speed (-4 levels)
Timer Button
Select to set a timer (0-8h)
Oscillation Button
Adjust airflow direction (90°)

LED Display
[}
]
Fan Speed/
Timer Hour
Auto Mode
x
Mute

USING YOUR
AIR CIRCULATOR
FAN
Getting the Most out of Your
Air Circulator Fan
l/‘-_‘—'\
Summer:
Use with Air Conditioner
Position the ai
of your AC to circulate ct
provide better cooling.
Winter:
Use with Heater
Send the heat to
room and circulat
of the
jarm air faster.
Spring & Fall:
Circulation
Make the indoors as fresh and
pleasant as the outdoors

General Operations
©
(©) to change the aiffiow
atimer
vorking mode.
read by hand tothe
ed angle.
Working Modes
Normal Mode
Fan runs at the fixed speed.
Auto Mode
Fan speed adapts to the ambient temperature

Additional Features
©
[}
[N
Timer
When the fan is ONOFF, touch the timer button
repeatedly to set a timer from 1 to 8 hours. When
the timer ends, the fan will stopistart running
automatically. To cancel, set the time to O hour.
Note: When the auto off timer is enabled, display will return
tofan speed after 3 seconds.
Child Lock
Long press the Oscillation button (2) and Timer button
at the same time for 3 seconds to turn on/off Child
. “L" wil fiash on the display when tured orvoff.
Note: Ch Lock doesn't apply to the remote control
You can also turn off Child Lock by re-plugging in.
Memory
If the fan is turned OFF or disconnected from power,
it will operate under the previous settings (except the
timer setting) when it is turned ON again.
Countdown Display
When long pressing buttons for Factory Reset, Child
Lock, and Mute, a countdown will show on the display
accordingly.
Display Auto Off
Display turns off after 1 minute.
Wake up the display with any button.

Remote Control
Power Indicator —————s©
) Power
Decrease — | e Increase
Fan Speed | Fan Speed
Mode g I Mute
Oscillation v © l Timer
Battery Replacement
@ Press the locking button to pop
out the battery holder.
@ Replace with the same battery
type with the (+) side facing up.
© Push in the holder until securely
locked into place.
Note: If the indicator on the remote
control doesn't turn on any more,
please consider replacing the battery.

WARNING
Chemical Burn Hazard. Keep batteries away
from children.
This product contains a lithium button/coin cell battery. If a new or
used lithium button/cain cell battery is swallowed or enters the body
it can cause severe intemal burns and can lead to death in as lttle
as 2 hours. Always completely secure the battery compartment. If the.
battery compartment does not close securely, stop using the product,
remove the battery, and keep it away from children. If you think
batteries might have been swallowed or placed inside any part of the
body, seek immediate medical attention.
The batteries must be disposed of properly, including keeping them
away from children. Even used cells may cause injury.

CLEANING AND
MAINTENANCE
Outer Surface
e dust with a soft,
CAUTION
Always unplug the air circulator before any cleaning or
maintenance to avoid the risk of fire, electric shack, or injury
to persons.
. Do not immerse in water or get water inside the motor
housing.
. Do not use any chemical agents when cleaning the fan.
. Store in a cool, dry place and cover it to protect from dust.
n
»w

Front Grille and Blades
WARNING
To reduce the risk of electrical shock and injury
to persons, turn off and unplug the appliance
before any cleaning and maintenance.
Remove the screw on the front grille,
rotate the grille counterclockwise to
take it off.
Remove the blade cap by rotating it Rinse cap, blades, and grille under
s shown and take the blade running water or with a clean, damp
assembly out of the shaft. cloth,

Dry up all parts, and insert the
blade assembly back into the
shaft by aligning the D-shaped
points on the center.
Align the point on the front grille with the
fight point on the casing as shown, then
rotate the grille clockwise and install the
screw backin place.

User Servicing Instructions (Fuse)
This appliance features a fused safety plug that protects against overload or
short-circuit situations. If the fuse blows, please cut off power and follow the
below instructions or consult a qualified electrician.
Grasp plug and remove from the receptacle or other outlet device. Do
not unplug by pulling on cord.
Open fuse cover. Slide open fuse access cover on top of attachment
plug towards blades.
Remove fuse carefully. Push the fuse from the other side to remove
the fuse.
Risk of fire. Replace fuse only with 5 Amp, 125 Volt fuse.
L]
2]
3]
(5]
Close fuse cover. Slide closed the fuse access cover on top of
attachment plug.
WARNING
Risk of fire. Do not replace attachment plug. Contains a
safety device(fuse) that should not be removed. Discard
product if the attachment plug is damaged.

TROUBLESHOOTING
My air circulator won't turn on!
Make sure that the cord is connected to a powered outlet and the:
mains voltage corresponds with the voltage indicated on the air
circulator.
My air circulator is shaky and wobbling!
Place the air circulator on a flat, level surface.
My air circulator is making vibration
and noise!
1. Place the air circulator on a flat, level surface.
2.Be sure not to insert anything into the air inlet and outlet.
3. Itis normal that the fan makes a little noise when manually adjusting
the fan head,
If your problem is not listed or still persists, please contact our
Customer Support (see page 16)

DREO CUSTOMER
CARE
Default 12-Month Warranty
This appliance is covered by Dreo warranty for 12 months from the date of its
original purchase.
Extend Your Warranty
Extend your warranty by registering your new appliance on our website
The warranty will not apply in cases of:
1. Accident, misuse, or repairs performed by unauthorized personnel.
2. Any unit that has been tampered with or used for commercial purposes.
3. Normal wear and tear of wearable parts.
4. Use of force, damage caused by external influences.
5. Damage caused by non-observance of the User Manual, e.g. connection to
an unsuitable mains supply or noncompliance with the instructions.
6. Partially or completely dismantled appliances.
7. Defects caused by or resulting from damages from shipping or from repairs,
service, or alteration to the product or any of its parts that have been
perform ed by a repair person not authorized by Dreo.
We can only provide after-sales service for products that are sold by Dreo or
Dreo authorized retailers and distributors. If you have purchased the appliance
from a different place, please contact your seller for return and warranty issues.
@ [phone] @ [email protected] @ www.dreo.com
Mon - Fi, 900 am-5:00 pm PSTPDT
@ www.dreo.com ), €‘|‘b
Shenzhen Hesung Innovation ‘ ’ lus
Technology Co., LTD
intertek
© 26F, Bidg A7, Creative City, Shenzhen, China MADE INCHINA 5018396
Rev_11_EN

www.dreo.com
DR-HAFOO1
Looking for help?
Contact us to get expert support.
@ [email protected] @ [phone] @ www.dreo.com
Mon - Fr, 00 am-5:00 pm PSTPDT
