  9. Dripex Q202A-QW User manual

Dripex Q202A-QW User manual

INSTALLATION MANUAL
[email protected] [email protected]
Q202A-QW
2
Step 1
Step 3
Step 2
Insert base legs into base joint,
screw together
↓
Keep the gap on the castor loop down
Insert a little, make sure the castor precisely aligned with base leg hole
screws M6*12MM*10pcs11
1
 
Base legs SGS cylinder
  
Base joint Cap
  
2D Arms

 
 
  

  
Base joint
(x 5 pcs)
(x 5 pcs)
Castors
Backrest
Tilt/height contol
Headrest Screws
(x 10 pcs)
M6*12MM M6*35MM
(x 6 pcs)
Seat
(x 6 pcs)
M6*15MM (x 4 pcs)
M6*20MM
Washers
(x 7 pcs)
M8*17MM
(x 3 pcs)
M8*20MM (x 3 pcs)
M8*13MM (x 2 pcs)
M6*20MM


Screwdriver
Screws
Washers
Screws Washers Screws
Screws
43
Step 4 Step 7 Step 8
Step 9 Step 10
Step 5 Step 6
√
×
→
arched area
Push castor into base leg hole with both of your thumbs
The force of both thumbs focus
on the upper arched area (blue
dashed box).
DO NOT SPARE YOUR THUMB
FORCE ONTO THE LOWER
ARCHED AREA (red dashed
box).
. If jammed, pull out the castor, switch to other castors then push it into holes again.
. For petite girls, you may try it yourself first. If not succeed, it’s advised to ask a man
for help.
Insert base caps and cylinder into base Arms to seat
screws M6X35MM*6pcs
washer M6X15MM*6pcs
Tilt control to seat
screws M6X20MM*4pcs
washer M8X17MM*4pcs
Backrest to seat
screws M8X20MM*3pcs
washer M8X17MM*3pcs
washer M8X13MM*3pcs
screws M6X20MM*2pcs
Follow the installation& adjustment video on Amazon
FACEDOWN
FACEDOWN
FACEDOWN
(lay it on the corner
of a desk or on the
packing box)
Insert headrest into the connector
(on the top of backrest), then raise
headrest to its highest point; Screw
the connector. Adjust headrest height
12
13
14
15
15
16
17
18
OPERATING INSTRUCTIONS FOR
TILT/HEIGHT CONTROL
1. Seat Height Adjustment
TO RAISE THE SEAT, pull lever outward. T
hen, BUTTOCKS OFF SEAT, pull lever
upward to your comfort height, then
TO LOWER THE SEAT, KEEP YOURSELF
SEATED ON THE PRODUCT, pull out lever.
Then, pull lever upward to your comfort
height, push in lever to fix the height.
2. Tilt Adjustment
YOUR BACK OFF THE BACKREST, pull
lever outward. Then, lay your back on the backrest,
press backrest with your back, tilt to your comfort angle.
Push in lever to fix the angle.
CARE AND CLEANING
1. Do NOT get it close to the fire or a wet,acidic and corrosive
environment. Avoid overexposure to the sun.
2. Do NOT use sharp or hooked objects to scrape the chair
3. Do NOT use abrasive chemicals for cleaning.
4.
support@dripex.co.uk
NOTES
AND
WARNINGS
1. For one person to sit on. Do NOT stand on.
2. Do NOT sit on the armrest in case of danger.
3. Do NOT put overweight on the chair, or used
as trolley.
4. Do NOT let the child sit on the chair alone if he
is under 5 year-old.
5. To avoid danger of suffocation, keep the
plastic bag away from babies&children.
6. If parts missing, broken, damages or wrong.
Stop using this product until repairs are made
using factory authorized parts.
For parts missing or any quality issues, please
message us via Amazon or email with your
order id + photo/video proof.
We'll respond within 24hours.
5 6
push in lever to fix the height.
If the frame stained, wipe clean with warm water or pledge
surface cleaner (available on Amazon).
5. If squeaks, tighten screws underneath the seat.
INSTALLATION MANUAL
[email protected] [email protected]
Q202A-QW
INSTALLATION MANUAL
[email protected] [email protected]
Q202A-QW
