Drive.web dw180-31 User manual

drive.web automation
!
!
!
!
!
!
!
!
Warning!!
This product is not rated and should only be installed in
light industrial locations. The product, its cabling and
antennae must be protected from dirt, contamination,
vibration and RF noise sources. Only qualified personnel
should proceed with installation or configuration!
Warning!
It is essential that you read and understand this manual and the entire
contents of the product manual(s), for any devices that are connected to
the access point’s wired or wireless Ethernet networks.
Warning!
Your use of savvy and savvyPanel software and drive.web devices may cause motors
and machinery to power up with high voltages or start or operate in an unexpected,
dangerous or lethal way. It is essential that you are completely familiar with savvy,
savvyPanel and all of the equipment and the system design you are working with before
attempting to program or edit a program or connect to any live device.
Warning!
You are entirely responsible for the configuration or use of any drive.web product. By
configuring or using these products you agree to indemnify and hold harmless Bardac
Corporation, its’ employees, directors, officers, distributors and resellers against the
consequences of your configuration or use of the products.
Warning!!
Information in this manual is subject to change without notice. You are responsible for
verifying the proper operation of your Ethernet network. Special care must be taken
when adding or removing devices.
Industrial WiFi Description and Features
This WiFi access point can host a stand-alone Ethernet network or connect to an
existing DHCP-enabled network with or without internet access to provide WiFi
access to it.
Four wired Ethernet LAN ports for drive.web devices or computers. Port one
provides power-over-Ethernet to PoE-capable devices.
WPA2 password protected security is set up by default.
Two antennae provide 2T2R MIMO, array &
diversity gain for link reliability.
Product labels should be observed for additional
installation information.!
Industrial WiFi HG503497iss1.1 www.driveweb.com Page !of 21
dw180-31
802.11n Access Point!
with PoE Port
Installation & Operation
Manual
drive.web
Industrial WiFi
Part No.
Description
Qty.
NC503499
WiFi base unit w/ antennae
1
NC503180
Antenna cable, 2m
2
Package Contents
®
®
®

drive.web automation
Industrial WiFi Getting Started
Plan and implement antenna placements: Antennae are omni-directional,
responsive in all directions. Locate near the center of the WiFi working area.
Best antenna diversity is achieved when the antennae are widely separated.
Avoid placing antennae near RF noise sources such as motors and power cables.
Metal mounting surfaces should be grounded to the power supply ground
with as short a connection as possible using standard single-point,
“star” ground configuration. Where mounting surfaces can not be
effectively grounded, insulate the antenna mounting.
All antennae connections must be tightened to 8in∙lbs torque.
Provide fused 24VDC power. Observe installation requirements marked
on the product label.
Open WiFi settings in your computer or Apple®mobile digital device. Choose or
enter network named “drive.web” with WPA2 security. It may take a minute or
two to discover.
Enter the password when prompted, “1driveweB”. Password is case-sensitive!
Verify that you are connected to the network, “drive.web”.
All devices on both wireless and wired networks must have unique IP addresses
on the subnetwork, 10.189.189.1/16.
DHCP server assigns addresses in the range 10.189.189.100 to 10.189.189.199.
This feature may only be useful for connecting Apple mobile digital devices
when there is no internet connection.
With no internet connection, invalid router, gateway, or DNS addresses in your
computer’s network setup may affect savvy and savvyPanel
performance. With no internet connection, use manual, static
addressing in your computer and be sure to set the DNS and router or
gateway addresses to 0.0.0.0 or blank.
Read “Getting Started with savvy”, which can be found under the Help menu
in drive.web savvy software. This document provides information for
setting IP address in a Windows7®computer.
Use savvy software to set IP addresses in your drive.web devices. Avoid
assigning addresses in the DHCP range.
Industrial WiFi HG503497iss1.1 www.driveweb.com Page !of 22
drive.web 40 Log Canoe Circle, Stevensville, MD 21666 USA.
Ph. 410-604-3400, Fax [phone], www.driveweb.com
savvy, Bardac and drive.web are trademarks of Bardac Corp., registered in the U.S. and other countries.
Apple and iPad are trademarks of Apple Inc., registered in the U.S. and other countries.
Windows7 is a trademark of Microsoft Inc., registered in the U.S. and other countries.
⅛” max
¼” dia.
Possible antenna
mounting solution.
