DROPSA VIP5 Pro Operation instructions

VIP5 Pro Controller
Control system for small and medium size
Lubrication Systems
Software Version 3.0
Version in compliance with Directive CE 94/9 (ATEX)
User Operating and Maintenance
Manual
Original text translation
II 2GD Exd IIB+H2 T6 IP65
Manual drawn up in accordance with C2163IE WK 41/14
EC Directive 06/42
TABLE OF CONTENTS
1. INTRODUCTION
2. MARKING PRODUCT
3. TECHNICAL CHARACTERISTICS
4. PRODUCT FEATURES
5. DESCRIPTION OF OPERATING PROCEDURES
6. INPUTS/OUTPUTS
7. OPERATOR INTERFACE FRONT PANEL
8. OPERATING MODE
9. CYCLE MONITORING
10. SETUP PROGRAMMING
11. FIXING AND INSTALLATION DETAILS
12. PROBLEMS AND SOLUTIONS
13. TECHNICAL SPECIFICATIONS
14. DISPOSAL PROCEDURES
15. ORDERING INFORMATION
16. MOVING AND SHIPPING
17. OPERATING PRECAUTIONS

2/25
1. INTRODUCTION
Thank you for purchasing the Dropsa VIP5 Pro controller – controller – The control device for Lubrication Systems
The Controller subject of this operating and maintenance manual is an evolution of the Vip5 Pro Atex family of
advanced lubrication control system. It maintains all its basic features and has additional functions and features such as
the ability to directly switch on/off three-phase pump and other devices. This product is certificated for Equipment and
protective systems intended for use in potentially explosive atmospheres that in compliance with the ATEX Directive
94/9 CE.
It is possible to obtain the latest documentation by visiting our website, www.dropsa.com
This manual contains important operating and safety information for users of this product. It is essential that you carefully
read this manual and conserve a copy with the product so that other users may consult it at any time.
1.1 DEFINITION OF LUBRICATION AND STANDBY PHASE, LUBRICATION PHASE, AND LUBRICATION CYCLE
In this manual the LUBRICATION PHASE and
LUBRICATION CYCLE refer to the specific
instances when the lubrication pump is operating
to provide lubrication in a system.
The LUBRICATION CYCLE is made up of: Cycle
Start -> Control of a sensor device -> Delay time
to allow sensor device to stabilize -> Wait Time
before another Cycle Start. This sub-cycle can be
repeated as many times as required and the
completion of this repetition is considered the
LUBRICATION PHASE. Fig. 1 illustrates this
graphically.
The STANDBY PHASE defines the interval between each LUBRICATION PHASE.
2. PRODUCT MARKING
On the door of VIP5 Pro controller is placed the label of Atex marking (fig. 2).
2.1 Legend of the ATEX marking
II Device Group: all areas at risk of explosion (not for
use in underground mines and their above ground
equipment)
2GD The categories define which zones the devices
may be used in. The classification states how frequently
and in what concentration the ignitable mixture occurs.
Furthermore, differentiation is made as to whether the
hazard is due to gases, vapors and mists or due to dust.
EEx d Identifier: define the electrical device.
IIB+H2 Explosion Group: device group II is sub-divided into Explosion Groups A, B or C. This classification is dependent on
the typical material properties of the gases and vapors that occur. The hazard level of materials increases from Explosion
Group IIA to IIC.
T6 Temperature class for inflammable gas.
T 85°C Max surface temperature for combustible dust.
IP65 Protection grade
ATTENTION: Automatic Control device
This control device is designed to automatically activate solenoid valve, motors, pumps and other
control devices based on timer or other inputs.
Failure to follow safety information may lead to serious personel injury.
Fig.1 A Lubrication Phase can comprise of many Lubrication Cycles
Cycle
Start
Control
Delay Wait
Lubrication Phase
Lubrication Cycle
Lubrication Cycle can be repeated

3/25
3. TECHNICAL CHARACTERISTICS
Supply voltage (see note par.5.1) 110V~- 230V~ - 400V~ - 460V~
Power Consumption
2 W (In Stop) - 10 W (In Start)
Temperature Operating Range
- 5 °C ÷ + 70 °C
Permissible Temperature storage range - 20°C ÷ + 80 °C
Operating Relative Humidity
90% max
Frequency
50/60 Hz
4. PRODUCT FEATURES
VIP5 Pro Atex offers many functions, the following brief summary are:
•Integrated LCD Display for diagnostic and ease of use;
•Diagnostic and Lubricant Counters for Operation and Alarm conditions;
•Three separate inputs (to monitor Dual line pressure switches, progressive cycle switch, injector pressure switch and
external signals to use as a counter for standby or lubrication phase );
•Signal Inputs can be NPN, PNP or a Clean Contact (or Namur style switching);
•Time or counter based determination of both Lubrication and Standby Phase;
•Counter based Lubrication phase can be used independently while monitoring correct function of a cycle switch,
ideal for use in impulse piloted system (e.g. chain and conveyor lubrication);
•Ability to configure pump output for Electrical or pneumatic pump (pump On/Pump Off values can be set
individually);
•General Alarm Output Relay can be a constant signal or generate a coded alarm to allow remote PLC to determine
nature of alarm;
•Monitoring and indication of the thermal protection trip input;
•Minimum Level Input;
•4..20mA Input for analogue measurement of Reservoir Level;
•Maximum level monitoring;
•Separate remote output signalling for Minimum Level alarm and General Alarm conditions;
•4-20 mA continuous input level monitoring;
•Ability to control line invertor valves for dual line systems with pneumatic or electromagnetic actuators;
•Ability to power input and output circuits using different power sources;
•Ability to isolate the voltage of the inverter valve power circuit from the main power framework;
•Remote reporting of pump operating;
•Management of charging (automatic charge);
•Solenoid valve air pipes cleaning, at the end of lubrication cycles;
•Possibility of selection local/remote mode with remote cycle start;
•Remote cancellation of error.
All configuration parameters can be set from the Setup menu via the LCD display using the front panel keys. No complex
internal switches need to be set.
5. DESCRIPTION OF OPERATING PROCEDURES
The VIP5 Pro Atex controller has three operating modes:
1. CYCLE 2. PULSE 3. FLOW
CYCLE and PULSE modes are designed for intermittent or continuous lubrication system that requires the control of a pump
and monitoring of feedback signals to determine when lubrication has successfully completed.
FLOW is designed as a monitoring only operating mode that allows the user to monitor a pulse signal and determine the
actual flow rate. This is useful for process control and generally used in re-circulating systems.
5.1 CYCLE and PULSE Control System operating Principles.
The VIP5 Pro Atex control system is designed to control intermittent or continuous lubrication system with a variety of
control inputs. Intermittent operating principle is based on three distinct phases.

3/25
PRELUBE Phase -> Pre Lubrication that occurs during power up of a system.
LUBRICATION Phase (Lube –> Wait stages) -> This is when lubricant is provided (as above)
STANDBY Phase -> The system is inactive awaiting for the next LUBRICATION PHASE
Additionally, the VIP5 Pro Atex Control system can also be used as a simple monitoring device in the “FLOW” operating
Mode described later in this manual.
5.1.1 PRELUBE Phase
The user can specify the number of lubrication cycles up to a maximum of 250.
If Prelube is set to zero, the VIP5 Pro controller controller will not perform any pre-lubrication; in this case if the START
parameter setting is "Resume", when the system is turned on it will revert to its pre-power down, or it will start from a
lubrication cycle if the setting of the start is "Lube".
When Prelube is set greater than zero, pre-lubrication will start in the following cases:
-When the VIP5 Pro controller system is powered on;
-After the RESET button is pressed;
-After the VIP5 Pro controller exists from the SETUP menu.
5.1.2 LUBE (Lubrication) Phase
The Lubrication Phase is a set of Lubrication Cycles that can be repeated up to 250 times.
A Lubrication Cycle consists of activating the lubrication pump, then Control monitoring a feedback signal from a sensing
device if installed. There is then Delay period before switching off the pump, and a Wait period before the lubrication cycle
can be repeated. Specifically:
-Cycle (time) determine how long to wait for the control signal before determining an alarm condition.
-Control (Type) determines what kind of control signal (Single Line, Dual Line, Injectors). Alternatively a Timer only
setting means no monitoring will occur.
-Delay (time): Is how long to wait for the signal to be confirmed and switch off the pump (in Pressure switch
applications).
-Wait (time): determines how long to wait in a pump off condition before repeating the cycle. This is necessary in
injector systems and represents the minimum time required for the injectors to reset. In progressive systems for
example this can be set to zero.
5.1.3 STANDBY Phase
During the Standby the VIP5 Pro Atex switches off the pump and waits for the start of another Lubrication Phase. The
duration of the Standby phase can be determined by a countdown timer or a by an external pulse signal that can be used
as a counter. The VIP5 Pro controller also allows a combination of both timer and external pulse signals to determine
either the next Lubrication phase or to signal an alarm if external pulse signals are not received within a pre-set time.
5.2 FLOW MODE OPERATING PRINCIPLES
The VIP5 Pro controller can also be used as a simple Flow monitoring system. When Flow mode is selected the unit
operates as a flow display and monitors an external signal to calculate the flow based on external impulses. The User can
additionally set a minimum and maximum Flow limit. If the flow is out of these limits, the remote alarm contact and the
alarm LED on the front panel are both activated.

4/25
6. INPUTS/OUTPUTS
6.1 ELECTRICAL CONNECTIONS
Fig. 3
Inside the control panel there are six connecting terminal boards (see image).
XM0 Terminal Board must be connected to supply voltage of control panel and three phase output control of the pump.
XM1 Terminal Board must be connected to Input- devices
XM3Terminal Board must be connected to Analog- devices
XM4Terminal Board must be connected to customer exchange signals
XM5 Terminal Board must be connected to output – devices
XD Terminal Board must be connected to input ex barrier – devices
The devices connected to the terminal change according to the working configuration choice (SEP, DUAL TIME, DUALTIME,
PS). Table 1 shows all the configurations with their associated devices. On the terminal XM1 you can configure the device to
connect PNP and NPN, through the setting of a connecting bar (as in Tables 2 and 3, marked in yellow)
In some configurations, there are some simple devices, which are interfaced to the Vip through the barriers. In these cases,
the connection must be effected in the terminal EX (blue) as shown in Tables 2-3.
NOTE: During the connection of field devices use the internal ducts to maintain tidy cabling.
All connections must be made by qualified staff in compliance relevant regulations. Only performing
wiring operation when power is completely removed from the unit.
Be careful that:
-The wires are not shorted;
-Have adequate insulation;
-Intact until their entry into the terminal and properly locked.

5/25
POWER SUPPLY
PUMP MOTOR
MAXIMUM LEVEL INPUT
MINIMUM LEVEL INPUT
PULSE INPUT/SUSPEND
PS1 INPUT/CYCLE SENSOR
PS2 INPUT
ANALOG LEVEL
MIN. LEVEL ALARM
LINE 1
LINE 2
DUAL
SEP
COMMON ALARM
TIME
DUAL
TIME
PS
C
P
P
P=PS1 INPUT / C=CYCLE SENSOR
Tab.1

6/25
3
2
4
5
6
Tab.2
For NPN Connections
Insert the commoning multiple bar as below
Max Level
Min Level
Pulse Input/Suspend
PS 1
PS 2
+
18
-
-
+
20
+
-
24
+
-
26
+
-
28
18
-
20
-
24
-
26
-
28
-
Connection without Ex Barrier
Max Level
Cycle Sensor
Connection with Ex Barrier
1
2
4
5
6

7/25
1
2
4
5
6
For PNP Connections
Insert the commoning multiple bar as below
Max Level
Min Level
Pulse Input/Suspend
PS 1
PS 2
+
17
-
-
+
19
+
-
23
+
-
25
+
-
27
17
+
19
+
23
-
25
-
27
-
Max Level
Cycle sensor
Connection without Ex Barrier
Connection with Ex Barrier
Tab.3
2
3
4
5
6

8/25
Location
Function
Block
Num
XM0
1
SUPPLY PANEL
2
3
4
PUMP CONTROL
5
6
Block
Signal level Function Note
Block
Num
+
+
DIGITAL INPUT MAXIMUM LEVEL
INPUT
IF SENSOR IS NOT EX CERTIFIED, SHOULD
BE CONNECTED TO BARRIER, XD 1/2
(SIMPLE DEVICE)
17
PNP
-
-
18
NPN
+
+
DIGITAL INPUT MINIMUM LEVEL
INPUT
19
PNP
-
-
20
NPN
+
+
DIGITAL INPUT PULSE
INPUT/SUSPEND
23
PNP
-
-
24
NPN
+
+
DIGITAL INPUT PRESSURE
SWITCH 1 INPUT
IF SENSOR IS NOT EX CERTIFIED, SHOULD
BE CONNECTED TO BARRIER, XD 4/5/6
(SIMPLE DEVICE)
25
PNP
-
-
26
NPN
+
+
DIGITAL INPUT PRESSURE SWITCH
2 INPUT
27
PNP
-
-
28
NPN
XM3
3
IN
ANALOG INPUT LASER PROBE
4
IN
+
+
XM4
8
C
FREE CONTACT MIN LEVEL ALARM
9
NC
10
NO
11
C
FREE CONTACT COMM.ALARM
12
NC
13
NO
XM5
1
OUT
SOLENOID VALVE LINE 1
2
OUT
5
OUT
SOLENOID VALVE LINE 2
6
OUT
XD
1
+
DIGITAL INPUT MAXIMUM LEVEL BARRIER CONNECTION
2
SIGN.
3
-
4
+
DIGITAL INPUT CICLE SENSOR BARRIER CONNECTION
5
SIGN
6
-
These connections are routed from the main terminal boards on the 1639187 board according tables below. For
correct wiring you should note the following:

9/25
1. All input and output signals refer to a nominal voltage of 24Vdc.
2. The outputs on terminal board M1 refer to voltage indicated as Vio on terminal 6 and 7 of M2.
3. The framework is provided with (Vio) power supply input coinciding with (Vint) internal power supply via bridges
on the terminals: M2: M2.5 with M2.7, M2.4 with M2.6
4. Outputs equipped with galvanic insulator; If you want to enter with active signals alimentation is taken outside the
framework is necessary to remove the connections on M2.5 with M2.7, M2.4 with M2.6; In this case is also necessary
carry this power to M2.7 e M2.6 in according to polarity.
5. Dual line command connections on M5 are configured for 24Vdc changeover valve. If the changeover solenoid use
different power supply, remove connection on terminal M7 and M5 and carry to M5 and connect the appropriate
voltage on M5.3 and M5.4.
6. Connections on terminal M6 are not clean contacts.
7. Connections on terminal M4 are SPDT type clean contacts.
For further details also check the completed electrical diagram enclosure with your specific equipment.
NOTE: To connect micro-switches or clean contacts inputs, equipped by creating a terminals for the
positive power supply (+) and the relative input P (IN +), you must make a link between (+) and (IN+) after
that connect the 2 wires of micro-switch at (-) or (IN-)
Fig. 4

10/25
Location
Signal level Function Note
Block
Num
M1
1
+
24 Vdc Inputs (Vio+)
Max level
17
IN +
Input P
2
-
0 Vdc Inputs (Vio-)
18
IN -
Input N
3
+
24 Vdc Inputs (Vio+)
Min level
19
IN +
Input P
4
-
0 Vdc Inputs (Vio-)
20
IN -
Input N
5
+
24 Vdc Inputs (Vio+)
Air pressure switch Safety pressure switch, for example air-oil
systems
21
IN +
Input P
6
-
0 Vdc Input (Vio-)
22
IN -
Input N
7
+
24 Vdc Inputs (Vio+)
PULSE Devices for counting
23
IN +
Input P
8
-
0 Vdc Inputs (Vio-)
24
IN -
Input N
9
+
24 Vdc Inputs (Vio+)
P1
First sensor input for system monitoring.
(Pressure injector, control loop for
progressive, suspend for timer…..)
25
IN +
Input P
10
-
0 Vdc Inputs (Vio-)
26
IN -
Input N
M1
11
+
24 Vdc Inputs (Vio+)
P2
Second sensor input for system monitoring.
(pressure 2 pressure switch dual line, Boost
for cycle SEP, ... )
27
IN +
Input P
12
-
0 Vdc Inputs (Vio-)
28
IN -
Input N
13
-
0 Vdc Inputs (Vio-)
Thermal protection Input for motor thermal protection alarm
29
IN -
Input N
14
-
0 Vdc Inputs (Vio-) Remote control Enables remote control of the cycle
30
IN -
Input N
15
-
0 Vdc Inputs (Vio-)
Remote cycle start If active the remote control input, activates
the cycle start
31
IN -
Input N
16
-
0 Vdc Inputs (Vio-)
Clear errors Delete any errors
32
IN -
Input N
Location Signal level Function Note
Block Num
M2
1
Vac1
19 Vac AC input Possible inputs also with 24Vdc
2
Vac2
19 Vac
3
Earth
Earth Earth connection If you want to report back to the ground
power connect these terminals 2
4
Vint -
GND internal logic Power logic and relay
control
5
Vint +
24 V internal logic max 1,5 A
6
Vio -
0 Vdc Inputs
Supply of external
inputs Max 1,2 A
7
Vio +
24 Vdc Inputs
8
Vio -
0 Vdc Inputs

11/25
Location
Signal level Function Note
Block
Num
M3
1
0:10V
0:10 V input
Analog input 0:10V to
future expansion Not isolated, not buffered , load 20 Kohm
2
0 V
0:10 V reference
3
4:20mA
4:20 mA input
Analog input 4:20mA to
future expansion Not isolated, not buffered, load 220R
4
0 V
4:20 mA reference
5
4:20mA
4:20 mA input
Analog input 4:20mA to
future expansion Not isolated, not buffered, load 100R
6
0 V
4:20 mA reference
Location Signal level Function Note
Block Num
M4
1
C
SPST, 3 A 250Vac
resistive load
Command "Alarm" on
Vip5 Pro panel
2
NC
3
NO
4
C
SPST, 3 A 250Vac
resistive load
Command cleaning
nozzles
5
NO
6
C
SPST, 3 A 250Vac
resistive load Load command
7
NO
8
C
SPST, 3 A 250Vac
resistive load Low alarm level
9
NC
10
NO
11
C
SPST, 3 A 250Vac
resistive load General alarm
12
NC
13
NO
14
C
SPST, 3 A 250Vac
resistive load Main pump control
15
NO
16
C
SPST, 3 A 250Vac
resistive load Main pump control
17
NC
18
NO
Location
Signal level Function Note
Block Num
M5
1
V inv
SPST-
NO
30 A 250Vac, 20 A 28Vdc
Inverter command line 1 Direct load
2
NO
Dial, contact NO
3
V inv
Direct load
Power inverter line Bring the voltage at these terminals for the
type of inverter used
4
C
line of contact C
5
V inv
SPST-
NO
30 A 250Vac, 20 A 28Vdc
Inverter command line 2 Direct load
6
NO
Dial, contact NO
Location Signal level Function Note
Block
Num
M6
1
Vint +
Positive power
Power tab
1639186
2
Vint -
Negative power
3 24V
Pump control
4
0 V
Location Signal level Function Note
Block
Num
M7
1
24 Vdc
Positive power
Power Inverter Line For 24Vdc inverter
2
0 Vdc
Negative power

12/25
6.2 ACTIVATING THE BATTERY FOR REAL TIME CLOCK FUNCTIONS
By inserting the Jumper into the bridging pins, the battery function is activated and this allows the VIP5 Pro controller
to operate with the Date/time and status save function when the power is removed.
6.3 PRECAUTIONS TO BE USED WHEN CARRING OUT WIRING
There is no specific safety risks associated with this device. Use general precautions that you would use when
operating an electrical device. All wiring should be carried out by a qualified electrician.
•Before wiring the panel ensure correct voltage as indicated on the product label.
•Only perform wiring operations once you are sure power is off and cannot be accidentally switched on.
•A circuit breaker that is easy accessible must be used in the wiring of the pump. Ensure the break contact has a
contact distance of at least 3 mm
•The power connections and pump must have armoured insulation until entrance into the terminals. The cable must be
positioned to have no damage to the insulation sleeve.
•Up to the terminal connections. The cable must be routed to avoid damage to the outer isolation sheaf.
•It is advisable to use a fuse or a differential isolation to protect the device. The device should have a recommended
value of 0,03 Ampere with 1 milllisecond maximum activation time. Isolation capability ≥ 10kV and nominal ln=6A.
Note: Every time the battery jumper is removed and reinserted causes the DATE/TIME function to be
set to zero. Therefore it is recommended that after inserting the battery jumper, the date and time is
set.
Set the JUMPER (as
shown) to ability the
battery
BATTERY
Fig. 5

13/25
7. OPERATOR INTERFACE FRONT PANEL
7.1 LAYOUT AND STATUS TABLE OF VIP5 Pro controller FRONT PANEL
VIP5 Pro Atex Condition
PUMP ON LED
CYCLE INPUT LED
ALARM LED
Alarm
OFF
ON
ON
Standby Phase
OFF
ON
OFF
Lubrication Phase/Cycle
ON
ON
OFF
Setup
OFF
OFF
ON
MODE (SET):
Change Value for selected
parameter
Cycle status LED
(yellow):
Shows cycle control
input condition
Pump ON LED (green):
Pump ON
Pump OFF
Stand by
Alarm LED
(red)
ESC:
Exit from setup menu without
saving changes
BACK:
Previous Parameter or Setting
Decrease displayed value
NEXT:
Next Parameter or Setting
Increase displayed value
Shows parameter and values during
set-up, or status and counters during
normal operation.
Hardware Reset Button
OK:
Exit from setup menu saving
changes
LED (green):
Presence of voltage
controller
ON - OFF
Instant stop button

14/25
8. OPERATING MODE
VIP5has three different operating modes which are determined during the setup stage described previously.
These are: CYCLE, PULSE and FLOW.
8.1 CYCLE Mode
In Cycle mode a cycle sensor determines the completion of the LUBRICATION PHASE. If using timer setting, the Lubrication
Cycle will complete when the timer expire. The Standby phase is determined by a timer or by an external input counter.
8.2 PULSE Mode
In Pulse mode, the duration of the Standby Phase and the Lubrication Phase are both determined by an external counter.
The correct operation of the Lubrication Cycle can be monitored using a cycle sensor.
Fig. 7
Example:
Standby Phase determined by the Pause Counter, and lubrication Phase
determined by Cycle Counter.
[CYCLE Cnt >1 PAUSE Cnt > 0 ]
The Lubrication Phase is Suspended if no external signals are recieved
within a time specified by the suspend Timer.
[SUSPEND T>0 ]
0-60.000 cycles
1-60.000 cycles
1-60.000 cycles
LUBE CONTROL WAIT
Alarm
LUBRICATION PHASE
Pump on
ALARM
Pump in Stand by
Example 1) Standby and Lubrication determined by ON & OFF Timer
Example 2) Standby determined by a counter
Example 3) Standby determined by a counter and timer combination
.
STOP
STOP
Alarm
Alarm
Time to break
out
0 min / 99 hours
0-60.000 cicli
1 min / 99 hours
The first of two events
0-60.000 cycles
1-60.000 cycles
1 min / 99 hours
Pompa in Standby
Pump on
ALARM
LUBE CONTROL WAIT
Lubrication Cycle
Repeted 1-250 Times
Lubrication Phase can be repeated
Example 4) Standby determined by a counter. Alarm signal given if the
external counter signals not detected within a set time.
Fig. 6

15/25
8.3 FLOW Mode
Using this mode allows the VIP5 Pro controller to be used as a simple flow monitoring and display device.
8.4 PRELUBE
The Prelube cycle is a pre-lubrication cycle that is triggered when the system is powered on or reset. If the pre-lube cycle
value is set to 1 or greater the VIP5 Pro Atex will perform the set number of Lubrication Phases.
Note that if Each Lubrication Phase comprises two or more Lubrication Cycles,then the total cycles performed will be
equal to the Lubrication Cycles multiplied by the Prelube Cycles.
Flow control
PRELUBE
1
YES
RUN n
LUBE Cycle
NO
NORMAL
OPERATION
POWER ON
OR RESET
The display shows the current Flow rate being
detected in the system.
It is also possible to scroll through menus to see
totalizing flow counter
Pump on
ALLARM
FIELD
CONTROL
COMPUTING
ALARM
OUTPUT
FLOW DATA
UPDATE
Flow control
Flow Out of Range
Fig. 8

16/25
9. CYCLE MONITORING
9.1 MONITORING OPTIONS.
There are four possible Cycle Monitoring Options, explained below.
2) TIMER – TIME ONLY
The Lubrication cycle is simply operated
according to a preset Timer value.
Therefore, no input is monitored to
confirm the correct completion of the
lubrication cycle.
LL
ALARM
MINIMUM LEVEL
MOTOR PUMP
PUMP
POWER
POWER
RESET BUTTON
Fig. 10
Fig. 9
1) DL – DUAL LINE
Dual Line cycles generally use two pressure
switches connected to P1 and P2.
The VIP5 Pro controller starts the pump
and must see that P1 switch is closed
within the timeout time. After this, the
Lubrication lines are inverted by use of a
directional valve.
The P2 switch must also then be made
within the timeout timer setting.
A user configurable DELAY timer can be set
to filter pressure spikes as in the PS
operating mode.
Power
Power
Minimum level
Inverter
Line 2
Line 1
P 2
P 1

17/25
4) SEP – SERIES PROGRESSIVE
Series progressive Operating mode is used
for Cycle switch monitoring typically on
progressive systems.
The Pump is switched on and P1 input is
monitored and must change state twice
within the timeout period otherwise a
timeout alarm will be generated.
Once P1 changes state twice, the pump is
switched off and VIP5 Pro controller
goes to standby or the Lubrication Cycle is
repeated for the desired number of times.
There is no WAIT time in this mode as
progressive systems do not need venting
time.
LL
ALARM
POWER
ELETTROVALVE
PUMP
MINIMUM LEVEL
ULTRASENSOR
P1
POWER
Fig. 12
Fig. 11
3) PS – PRESSURE SWITCH
Pressure switch monitoring is typically used
in injector system.
The VIP5 Pro controller will monitor
input P1 to verify that it is an OPEN contact
at the start of the cycle.
The pump is activated and the pressure
switch must CLOSE within a timeout period
otherwise a cycle alarm is generated.
Once the P1 contact is closed, a DELAY
timer checks that the switch is not broken
for a set time before switching off the
pump. This ensures that pressure spikes at
the start of a lubrication cycles on long lines
are filtered out.
A WAIT timer can be set to allow the
injectors to reset when using multi cycle
configuration.
P1
ALARM
PRESSURE SWITCH
LL
POWER
MOTOR
PUMP
MINIMO LIVELO

18/25
10. SETUP PROGRAMMING
The following section explains how to navigate the VIP5 Pro controller setup menus and contains detailed explanation
of each parameter and possible values.
10.1 Navigating around the setup menu.
The navigation map below shows how to navigate around the setup menu.
OPERATING
SETUP PARAMETERS
VALUES
To enter the SETUP menu from the OPERATING Mode, hold the (Mode) button for 5 seconds.
The (Up and Down) keys allow scrolling through the parameters.
By pressing the Mode button again, the indicated parameter value can be modified by using the Up and Down keys.
To exit, use the (OK) key, or (Esc) if you with to exit without saving.
10.2 MENÙ BASIC / EXTENDED
All’avvio il VIP5 Pro presenta un menù "BASIC" che consente all’operatore un rapido settaggio iniziale dell’impianto. Questo
menù è molto utile per configurare i parametri principali di un ciclo ed è prevalentemente utilizzato con il prodotto VIP5.
Per questo tipo di prodotto invece, nato principalmente per la gestione di impianti a linea doppia, è necessario selezionare
“extended” per accedere al menù completo di configurazione.
Per la lista completa dei parametri avanzati del VIP5 Pro impostabili tramite menù esteso fare riferimento alla tabella del
par. 10.3.
LUBE sep: 1
01m56s STOP
5 sec
MODE -Cycle-
SET - - NEXT
MODE -Cycle-
SAVE -+
OR
set value
save
parameters
no save
parameters
save
parameters
no save
parameters
OR
saved
value
not saved
value
LUBE Type SEP
SAVE -+
OR
set value
OR
not saved
value
saved
value
LUBE Type SEP
SET BACK NEXT
SETUP MODE

19/25
10.2 PARAMETERS AND VALUES
The following table shows the parameters and possible values of VIP5 Pro controller . The first two parameters (MODE
and TYPE) determine what parameters are available in the menu and they are the first that must be set.
PARAMETER
NAME
DEFAULT
VALUE DESCRIPTION VALUES/ RANGE
APPLICABILITY
MODE CYCLE
SELECT THE OPERATIMG MODE:
Flow monitoring mode
FLOW
FLOW
Lubrication Cycle completed when the cycle sensor
confirms correct lubrication CYCLE
CYCLE
Both Standby and Lubrication Phase determined by
external signal.
PULSE
PULSE
TYPE SEP
SELECTS THE CYCLE MONITORING:
X
X
Timer only
TIMER
Pressure switch
PS
TIMER/NO CONTROL
Progressive Cycle switch SEP
PS
Dual Line cycle with control signals DUAL
DUAL SEP
Timed Dual Line cycle DUAL TIMED
DUAL TIMED
INVERTER PNEUM Type of connected inverter for Dual systems PNEUM-ELETT X X X
INVER.Ton 3s Time for inversion 0,1s - 25,0s X X X X
INVE.Wait .null. Waiting time for inversion command and pump 1s - 1h X X X X
CYCLE TOUT 2 min
Timeout counter determines how long to wait for cycle
completion before a timeout alarm is generated
1s - 1h X X X X X X
LUBE TIME 2 min In timer Mode, how long the pump will run 0s – 99h X X
CYCLE CNT 1 The Duration of the Lubrication cycle (in PULSE Mode) 1 - 60000 X X X X X X
DELAY TIM 5s
When the pressure switch is made, how long to keep the
pump running to ensure that the signal is genuine and not a
pressure spike
0s – 2min X X X X X
With FLOW mode time that alarm condition must exist
before being reported X
SUSPEND T 1s
In Pulse Mode, will suspend the Lubrication Phase if a signal
is not received
Null – 2min X X X X X X
PAUSE CNT 1 Counter for standby phase (PULSE input).
See: PAUSE MULTIP.
Null -250
(cycle mode)
Null-60000
(pulse mode)
X X X X X X X
SUSPEND Never
With cycle mode suspend remote signal on pulse input can
be connected. The lubrication cycle is completed before
any suspension
Never, In Pause
In Cycle, Always X X X X X X
PAUSE BY Timer
Determines Standby Phase Timing
X X X X X X
Time based Standby Time
A set number of external PULSE signals Counter
Whichever of above 2 events occurs first Time & Counter
By PULSE signals. However, if PAUSE TIM. is reached, an
alarm will be given
Tout
& Count
PAUSE TIM. 6m 00s
Standby Timer setting. Null means the standby phase will
be skipped
Null
– 99h 00m
X X X X X X
PUMP Continuous
Pump output can be constant signal, pulsed signal or
synchronized with control signal (see next 3 parameters)
Continuous,
Pulsed
X X X X X X X
syncronyzed X
PUMP TON 5,0 Sets the ON value of the pump pulse 0,1-25,0s X X X X X X X
PUMP TOFF 5,0 Sets the OFF value of the pump pulse 0,1-25,0s X X X X X X X
PAUSE MULTIP.
1
Multiply pause settings by 10 or 100 to achive more higt
values. See: PAUSE CNT
1; 10; 100 X X X X X X
LUBE CYCLES 1
Number of Lubrication Cycles to complete a Lubrication
Phase
1 - 250 X X X X X X
BOOST CYCLES 1
In a SEP mode, If P2 input is closed the LUBE CYCLES values
is increased by this value contained in this setting
1 - 250 X X
