DSE XH1137 User manual

XH1137
PCI ADSL Modem
Installation Guide
V1.1 – November 2001 – © Copyright 2001 - DSE(NZ)Ltd

1
Copyright
Copyright 2001 by DSE(NZ)Ltd - all rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer
language, in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, manual or otherwise, without the prior
written permission of DSE(NZ)Ltd.
Disclaimer
DSE(NZ)Ltd makes no representations or warranties, either expressed
or implied, with respect to the contents hereof and specifically
disclaims any warranties, merchantability or fitness for any particular
purpose. Any software described in this manual is sold or licensed "as
is". Should the programs prove defective following their purchase, the
buyer (and not DSE(NZ)Ltd, its distributor, or its dealer) assumes the
entire cost of all necessary servicing, repair, and any incidental or
consequential damages resulting from any defect in the software.
Further, DSE(NZ)Ltd reserves the right to revise this publication and to
make changes from time to time in the contents hereof without
obligation to notify any person of such revision or changes.
All brand and product names mentioned in this manual are trademarks
and/or registered trademarks of their respective holders.
Warning
This is a Class A product. In a domestic environment, this product may
cause radio interference in which case the user may be required to
take adequate measures.

XH1137 – DSE ADSL PCI Modem
2
Contents
1INTRODUCTION...........................................................................4
2INTERNET SECURITY.................................................................4
3ADSL SERVICE............................................................................5
4FEATURES & SPECIFICATIONS.................................................6
5TELCO CONNECTION SETTINGS..............................................7
5.1 TELECOM & XTRA SETTINGS.....................................................8
5.2 OTHER TELCOS & ISP SETTINGS..............................................9
6HARDWARE INSTALLATION....................................................10
6.1 ABOUT ADSL SPLITTER & FILTERS.........................................10
6.2 INSTALLATION OF THE DSE ADSL LINE FILTER.......................11
6.2.1 Filter Installation Rules..................................................11
6.3 IMPORTANT ANTISTATIC PRECAUTIONS....................................12
6.4 PCI CARD INSTALLATION.........................................................13
7SOFTWARE INSTALLATION.....................................................15
7.1 LOCATION OF DRIVER FILES.....................................................15
7.2 WINDOWS 95 DRIVER INSTALLATION.......................................16
7.3 WINDOWS 98 DRIVER INSTALLATION........................................18
7.4 WINDOWS 2000 & XP DRIVER INSTALLATION .........................20
7.5 WINDOWS ME DRIVER INSTALLATION .....................................22
7.6 WINDOWS NT4.0 USERS........................................................24
7.6.1 Installation for RFC1483/1577.........................................24
7.6.2 Installation for RFC2364..................................................27
8NETWORKING SETTINGS........................................................30
8.1 WINDOWS 95/98.....................................................................30
8.1.1 Configuring RFC1483/1577/2364 .................................30
8.1.2 Configuring RFC1483/1577 ..........................................31
8.1.3 Configuring RFC2364....................................................33
8.2 WINDOWS 2000 & XP............................................................34

3
8.2.1 Configuring RFC1483/1577/2364................................. 34
8.2.2 Configuring RFC1483/1577.......................................... 35
8.2.3 Configuring RFC2364 ................................................... 36
8.3 WINDOWS ME....................................................................... 37
8.3.1 Configuring RFC1483/1577/2364................................. 37
8.3.2 Configuring RFC1483/1577.......................................... 38
8.4 WINDOWS NT4.0................................................................... 41
8.4.1 Configuring RFC1483/1577/2364................................. 41
8.4.2 Configuring RFC1483/1577.......................................... 42
8.4.3 Configuring RFC2364................................................... 43
9SUPPORT................................................................................... 44
10 GLOSSARY OF TERMS......................................................... 45

XH1137 – DSE ADSL PCI Modem
4
1Introduction
The DSE PCI ADSL Modem is an “always on” high-speed broadband
device for connection to the Internet. Using existing twisted pair
telephone lines, ADSL technology provides data rates over 100 times
the speed of a traditional analog modem, without an interruption in
telephone service. ADSL is the ideal solution for high-bandwidth
applications such as access to a corporate network, Internet access,
and video delivery.
The DSE ADSL Modem provides line speeds of up to 8Mbps
downstream (to your computer) and up to 1Mbps upstream (to the
Internet), depending on telephone line conditions. A point-to-point
connection is established between the computer and the central office
of the ADSL service provider, the computer is always connected - this
eliminates dial-up time and simplifies connectivity issues.
The DSE PCI ADSL modem is an easy to install Plug & Play PCI
device that connects directly to your telephone line via a standard BT
telephone plug. The intuitive software interface allows you to easily
configure the necessary settings with ease.
2Internet Security
As ADSL provides a permanent connection from your computer to the
Internet, the possibility exists for hackers and viruses to obtain data
from your computer. To this end, we strongly recommend that you
install suitable Firewall software on your computer. The software
should be installed and configured according to the manufacturers
instructions and should be running the entire time your DSE ADSL
Modem is connected to the Internet. For more information on this
topic, please contact your local Dick Smith Electronics store or search
the Internet using the words “Firewall Software Security”. Suitable
search sites include www.google.com or www.yahoo.com

5
3ADSL Service
In order to use the DSE ADSL Modem you must first have the ADSL
service established at your premises with your local telephone
company, or an Internet Service Provider (ISP). To check if the service
is available in your area:
•Visit your local Dick Smith Electronics store where an employee
will help you to check ADSL service availability. If you wish to sign
up for a Telecom or Xtra ADSL service while you are in-store, the
Telecom account holder will need to be present along with a
current Telecom bill.
•Alternatively visit http://adsl.dse.co.nz and click on the “ADSL –
Services & Links” category. From here, select “ADSL - Check
Service” and then enter your phone number into the appropriate
panel. After a short while you will be advised if the service is
available or not. If the service is available, you can sign up for any
Telecom or Xtra service providing you have a phone account
handy. If the service is not available, you have the option to
“register your interest”. By informing Telecom of your interest, you
may help speed up the installation of the ADSL service in your
area.
•If you have inadvertently purchased any DSE ADSL product and
cannot get the service or it is not suitable, simply return the
product to any Dick Smith Electronics store, in new condition,
complete with packaging and receipt, for a full refund.

XH1137 – DSE ADSL PCI Modem
6
4Features & Specifications
ADSL Modem Features
•Controllerless Internal PCI ADSL Modem
•ANSI T1.143 Issue 2, ITU-T G.992.1 (G.dmt) and ITU-T G.992.2 (G.lite) compliant
•Discrete Multi-Tone (DMT) line encoding scheme
•Full-rate transmission at up to 8 Mbps downstream and 1 Mbps upstream
•G.lite transmission at up to 1.5 Mbps downstream and 512 Kbps upstream
•Plug-n-Play Installation
•PCI 2.1 Power Management Specification compliant
•Compliant with PCI Local Bus Specification Revision 2.2
•Software upgradable for future feature enhancement
ADSL Chipset
•P4601 ADSL PCI Interface Chip
•11627 Falcon2P DMT Data Pump Chip
•20431 Analog Front End Chip
•20441 Line Driver Chip
ADSL Protocol Support
•RFC-1483 Ethernet Bridging over ATM PVCs
•RFC-1577 Classical Internet Protocol over ATM
•RFC-2364 PPP over ATM PVCs
Operating System Support
•Windows 95, Windows 98, Windows 98SE, Windows 2000, Windows Millenium,
Windows XP & Windows NT 4.0
PTT Approval
•New Zealand Telepermit – PTC 272-01-019

7
Connectors
•1 x RJ11 Telephone socket for Telephone line
Temperature
•Operating : 10oto 45o Celsius (50o to 113 o Fahrenheit)
•Non-Operating : -25o to 70o Celsius (13 o to 158o Fahrenheit)
Humidity
•Operating : 30% to 80% Relative Humidity (Non-Condensing)
•Non-Operating : 10% to 95% Relative Humidity (Non-Condensing)
Minimum System Requirements
•Pentium II 300MHz (min) with 64MB RAM
Package contents.
Carefully unpack and remove the contents. If any if the following items are missing or
damaged, contact the Dick Smith Electronics store that you purchased the modem
from.
•1x XH1137 DSE ADSL PCI Modem
•1x Telephone line cord with RJ11 plugs at either end
•1x RJ11 to BT Phone Plug Adapter
•1x Installation Guide
•1x Driver CD with Application Software
5Telco Connection settings
High Speed ADSL Internet is a complex service generally provided to
you by 2 companies:
1. A telecommunications company (like Telecom) who’s
responsibility it is to send and receive high speed computer data
from your premises to your nearest phone exchange.
2. An Internet Service Provider (ISP like Xtra) who is responsible for
connecting your high-speed data from the phone exchange to the
Internet.

XH1137 – DSE ADSL PCI Modem
8
5.1 Telecom & Xtra Settings
At the time of writing, Telecom New Zealand has issued the following
information to customers wishing to use their JetStream & JetStart
ADSL services.
•Operating Mode set to: G.992.1, G.DMT or ANSI T1.413 iss 2
(but not G.Lite or G.992.2)
•VPI Value set to: 0
•VCI Value set to: 100
•Protocol set to: PPP over ATM (PPPoA) (RFC2364) with VC-
multiplexed encapsulation
•Username and password are set according to the user ID for the
service you are trying to connect to (either ISP or corporate). The
user name must be set to the user ID followed by an @ symbol
followed by the domain name eg: [email protected]. Note that for the
Xtra service (JetStart & JetStream) the customer user ID has
".xadsl" appended to it ie: "[email protected]". Other ISPs
may or may not have similar requirements – you will need to check
this with your ISP.
•Primary DNS: 202.27.184.3
•Secondary DNS: 202.27.184.5

9
5.2 Other Telcos & ISP Settings
Other telecommunications companies may offer alternative High
Speed ADSL Internet services supported by this modem.
In the spaces provided, write down the various required settings as a
handy reference. If you are unsure, check with your ISP.
1. Common Internet Protocols used internationally by ADSL service
providers are indicated in the following table. Check with your ISP and
tick the protocol you will be installing.
Standard Protocol Selection Tick
RFC1483 Bridged Ethernet over ATM q
RFC2364 Point-to-Point Protocol over ATM q
RFC1577 Classical Internet Protocol over ATM q
RFC2516 Point-to-Point Protocol over Ethernet q
2. Having determined the ADSL protocol you will be installing, now gather
the connection information supplied by your Telecommunications
Company and or ISP.
VPI value:_________
VCI value: _________
Framing: qVC/MUX qLLC/SNAP
Mode: qANSI T1.413 qITU G.lite qITU G.dmt
For RFC1483 or 2516 For RFC2364 or 1577
Host: User Name:
Domain: Password:
Gateway: Host or IP Address:
IP Address:
Subnet Mask:
DNS/ server add:
