DSE RKK Series User manual

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 1
Plug & Play WiFi IP Kit
IP cameras and WiFi NVRs
Installation manual - Menu 5.0
How to install the system
How to connect to the network How to
insert an additional camera
DSE SRL - ITALY - WWW.DSE.EU
Translated from Italian to English - www.onlinedoctranslator.com

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page:2
Contents of the manual
The RKK series WiFi kits are designed to create small wireless video surveillance systems ready to work in a
few minutes and can be installed without any specific knowledge.
This manual explains how to install cameras and VCR, how to make basic adjustments and how to connect
from a computer on the internal network.
For more detailed information on the advanced functions, you can consult the RK Series NVR configuration
manual
This manual refers to the NVR / DVR with graphical interface Version 5.0 that you see below
If your NVR / DVR has our classic interface, instead of 5.0, you can download the specific manual for your
version, or you can continue reading this manual considering that you will find the same options on your
screen, only with different graphics.
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 3
Package Contents
The kit you purchased is a complete wireless video surveillance system. The package
includes:
1 - WI-FI VCR (NVR)
2 - From 1 to 8 WI-FI CAMERAS FOR OUTDOOR / INDOOR
3 - A 12V POWER SUPPLY FOR EVERY CAMERA
4 - ACCESSORIES
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 4
Connect the cameras
The cameras of this system are designed to not require any configuration and are delivered already paired
with the kit's NVR. You just have to plug the power supply into the socket. Initially you should power the
cameras near the NVR, before installing them in their position, in order to conveniently configure the
system.
1 - SCREW THE ANTENNAS
Screw the antenna onto the back of the camera. Hold the antenna steady with one hand and turn the
locking ring with the other hand. Do not point the antenna towards the NVR, but leave it vertical.
2 - CONNECT THE POWER SUPPLY
For each camera there is a power supply that you have to connect to the DC12V plug (on the right in the
photo below). The connector for the wired network is not needed in normal operation.
ATTENTION: Do not confuse the power supply of the NVR (2 / 3A) with the smaller one for the cameras
(0.5 A).
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 5
3 - INSTALL THE CAMERA
You can fix the camera on the wall or even on the ceiling and orient it thanks to the articulated bracket. The plugs
and the drilling template are provided. The Allen key of the bracket must be unscrewed to be able to orient the
joint and fully closed once the camera has been positioned.
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 6
Orient the antennas
The antennas of these cameras are omnidirectional, so they transmit in all directions. For better signal
propagation it is not advisable to point them towards the NVR, but to orient them at 90 ° with respect to the
direction of the NVR. Look at the following example.
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 7
Install the Hard Disk
If you want your system to record, you need to install a Hard Disk inside the VCR. Any 3.5 ”computer SATA
hard drive is fine, but for a longer life it would be better to purchase a dedicated model for video recording.
The maximum hard disk capacity that you can mount is 8 TB.
If you ordered the hard disk together with your kit you will receive it already assembled so you can skip this
section.
Remove the cover by unscrewing the 5 screws:
2 on each side and one rear
Connect the hard drive with the two power
and data cables you find inside
Secure the hard disk with the 4 screws provided
that screw tight from underneath the VCR
Close the lid and screw the 2 antennas onto
back of the appliance
At the next boot, the NVR will reveal the new hard disk installed and will ask you to start formatting
in order to use it.
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 8
Connect the NVR
The central unit of your system is a WiFi network video recorder, a device that is also called an NVR. To
use it you need to make some connections on the back. The diagram below may vary slightly depending
on the model of the kit
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 9
Follow this sequence to connect your NVR
1 - SCREW THE ANTENNAS
Screw the two antennas to the back of the NVR. Eastern straight up.
2 - CONNECT A COMPUTER MONITOR
To use your NVR you need a monitor where you can see the cameras and configure the options. If you
use a computer monitor, with the VGA port, you must connect the cable to the blue port of the NVR,
called VGA.
3 - CONNECT A TV
TV can also be a great monitor for your NVR. To connect it you need an HDMI cable to plug into the
HDMI port of the NVR. To see the images on the TV you must remember to select on your TV the external
HDMI input that you used for the NVR. This is usually done by pressing the SOURCE button on the
remote control.
4 - CONNECT THE MOUSE
The NVR is controlled with the mouse like a computer. Connect the mouse supplied with the product to
one of the USB ports your NVR is equipped with
5 - CONNECT THE POWER SUPPLY
The power supply, supplied with the DVR, must be connected to the DC12V connector on the back of the
NVR. As soon as the plug is connected, the NVR will turn on and you will see an image appear on the
monitor. If you don't see anything appear, check the connection with the monitor.
ATTENTION: Do not confuse the power supply of the NVR (2A) with the smaller one for the cameras.
6 - CONNECT THE ROUTER
To be able to view your cameras via the Internet, you need to connect the NVR to your network. You
have to use a normal straight-type network cable and insert it on one side into the portWAN of the NVR
and on the other hand to a free port on your router or switch. The NVR is factory set to automatically
configure itself to the network (DHCP).
Depending on the model, you will also find 3 LAN ports on the back of the NVR that are not needed for
the router, but to connect any wired IPs and are also used for the first configuration of new cameras
from the kit purchased later.
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 10
Make the first ignition
As soon as you plug in the power adapter, the NVR starts up and displays an image on the screen. If you
don't see the picture you need to check the cable and monitor settings.
The first time you turn on a wizard that helps you configure the main functions of your system in a few
minutes.
1 - CHOICE OF LANGUAGE
The first page of the wizard provides for the choice of language, factory set in Italian. If you do not need
to change the language, press EXIT
2 - AUTHENTICATION
The second step is authentication. At the first start you can enter the factory password:
USER: admin
PASSWORD: 12345
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 11
3 - SET THE TIME AND DATE
Here you set the system date and time. The time zone in Italy is GMT + 1.
At the bottom you can uncheck ENABLE CONFIG. GUIDED so that at the next start of the NVR this first
programming procedure is not proposed again.
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 12
4 - NETWORK
Here the network parameters of the NVR are set in relation to the wired connection network to the
router and to the Internet. At the factory you will find the DHCP setting enabled, so that the NVR
automatically receives the correct parameters from the router. The network parameters assigned to the
NVR automatically are indicated in the boxes. It is recommended to keep this automatic setting and
press next unless there are situations in the network to prefer a static IP assignment.
Pressing forward you pass to the parameters of the wifi network of the NVR, to which the cameras are
automatically connected. Also in this case it is absolutely advisable to keep the factory settings and
proceed with NEXT
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 13
5 - FORMAT THE HARD DISK
This page shows the hard disk inserted in the NVR. If you bought the hard disk together with the kit, we
will already mount it inside and format it for which you will find the page as in the example with the hard
disk IN USE. If, on the other hand, you have installed a new hard disk inside the NVR you will have to
select the disk and press FORMAT in order to delete the content and make it usable by the NVR.
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 14
6 - CHECK THE CAMERAS
This is the kit camera control window. If you have already powered the cameras, check that the blue dot
certifies the connection was successful. In this example camera 1 is present and connected successfully
while camera 2 has the yellow anomaly triangle, probably because the camera is off or too far from the
NVR.
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 15
7 - PROTECT ACCESS
The last step of the wizard allows you to change the login password of the NVR. If you decide to change
the factory password, you must set an access password to be kept with care, because if you forget it,
recovery will be laborious.
CHANGE PASSWORD - Set the new password by typing the old default first: 12345.
SECURITY RESET - Set the answer to 3 questions that will allow you to recover your password if you
forget it.
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 16
FINISHED!
At the end of the wizard your wifi CCTV system is already working.
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 17
Review the recordings
To review the recordings stored by your NVR please do the following.
1 - OPEN THE PLAYBACK WINDOW
Right-click and choose the PLAYBACK icon, second from the left in the top menu
2 - CHOOSE THE CAMERAS TO PLAY Select the cameras
to be reproduced at the top left
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 18
3 - CHOOSE THE DAY AND TIME YOU WANT TO REVIEW
Choose the day you are interested in at the bottom left. Days containing recordings are marked with a
colored box. Click on one of these.
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 19
4 - REPRODUCE THE INSTANT YOU WANT TO REVIEW
In the time bar at the bottom you will find the 24 hours of the day with the continuous recording colored
in green and the recordings made by motion detection in yellow. This is the MOTION DETECTION
function, which is very convenient for finding what interests you right away. Click wherever you want in
the timeline to play the images at that exact moment.
With the 24H slider you can vary the scale of the timeline.
With the command buttons below the timeline you can accelerate playback, stop or pause playback.
DSE SRL - ITALY - WWW.DSE.EU

INSTALLATION MANUAL
RKK SERIES - WIFI CAMERAS / NVR KIT
Page: 20
Connect the NVR to your network
To be able to connect to the surveillance system via PC or mobile, you need to connect the NVR to your
network. To do this use a network cable and connectthe WAN portof the NVR to a free port on your
router or switch. Check that the port LEDs light up, this means the connection is correct.
VERSIONS WITH A SINGLE WAN NETWORK PORT
If your NVR has only one network (WAN) port, use it to connect to your router or switch on your network
ATTENTION. You must necessarily connect to your network or your router if you want to make the
connections remotely illustrated in the following chapters.
