DSG Technology InterPBX Blaze5000 Operator's manual

InterPBX Communication System
Blaze5000/Blaze1200/Savanna8000
Administrator
Installation and Configuration Guide
07IPBXM.CS1.05m.EN12

DSG, DSG logo, InterPBX, Blaze, Savanna, Blaze/Savanna Server, VG5000, VG6000, AP8000, IP580, IP500, IP510,
DSG SoftPhone, DSG SoftConsole, DSG SIP Proxy Server, DSG NAT Proxy Server, SIP1200, Blaze Logger,
BlazeLink, and S300X are trademarks of DSG Technology. Windows and Outlook Express are trademarks of
Microsoft Inc. Other names used here are trademarks of their respective owners.
Copyright © DSG Technology Inc. All rights reserved.
7F, 222 Cheng-Te Road, Sec. 4, Taipei, Taiwan 111
Tel：886288615558
Fax：886288615557
E-mail：[email protected]
http：//www.dsgtechnology.com

Table of Contents 3
Table of Contents
Table of Contents...................................................................................................................................3
Chapter 1 InterPBX Communication System Overview...............................................................7
IP-Based Business Telephone System .......................................................................................8
Advantages of InterPBX..............................................................................................................8
Key Components .........................................................................................................................9
Blaze/Savanna Server .......................................................................................................9
VMS Server..........................................................................................................................9
Conference Server ..............................................................................................................9
Recording Server ................................................................................................................9
Voice Gateway..................................................................................................................10
SIP Proxy Server...............................................................................................................10
NAT Proxy Server............................................................................................................10
Blaze Logger Recording System.....................................................................................10
BlazeLink...........................................................................................................................11
Supportable Extension Types for InterPBX ..................................................................11
Web-based Management Tools ......................................................................................11
SH2500 PoE Switching Hub............................................................................................12
Chapter 2 Installing InterPBX Communication System.................................................................13
Before You Start .........................................................................................................................14
Prepare Your Telephone Numbering Plan ...................................................................14
Installing Blaze/Savanna Server .............................................................................................15
Installing and Configuring Blaze/Savanna Server......................................................16
Connecting Blaze/Savanna Server via Console Port ..................................................20
Installing VG5000/VG6000 Voice Gateway...........................................................................21
Installing and Configuring VG5000 Voice Gateway ...................................................21
Connecting VG5000 via Telnet .......................................................................................25
Connecting VG5000 via Console Port ...........................................................................26
Installing and Configuring VG6000 Voice Gateway ...................................................27
Installing IP Phones...................................................................................................................29
Create IP Phones via Auto Discovery ...........................................................................30
Create IP Phones Manually.............................................................................................34
Installing SoftPhone ..................................................................................................................36
Before You Start................................................................................................................37
Create SoftPhones by Auto Discovery ..........................................................................37
Create SoftPhones Manually ..........................................................................................42
Increase Virtual Phones ............................................................................................................43
Chapter 3 System Configuration.......................................................................................................45
General Parameters ...................................................................................................................46
Basic IP Settings................................................................................................................46
Timeout Settings...............................................................................................................47
The Settings of NAT.........................................................................................................49
Set QoS...............................................................................................................................49
Music on Hold ..................................................................................................................50
Ringing Patterns ...............................................................................................................50
Company Information...............................................................................................................50
Business Hours...........................................................................................................................51
Holidays......................................................................................................................................52
System Speed Dialing................................................................................................................53
Call Restriction...........................................................................................................................54
Route............................................................................................................................................54
Function Code ............................................................................................................................55

4 Table of Contents
Password Management.............................................................................................................56
Set System Date/Time ..............................................................................................................57
Chapter 4 Gateway Configuration....................................................................................................59
Analog Gateways.......................................................................................................................60
Creating Analog Gateway List .......................................................................................60
External Paging & MOH Functions...............................................................................61
Editing Analog Gateways ...............................................................................................61
Configuring CO Line Ports.......................................................................................................62
Setting CO Line Extension Number ..............................................................................63
CODEC ..............................................................................................................................63
Setting Fax Ext Number ..................................................................................................63
Ring Assignment ..............................................................................................................64
Silence Compression........................................................................................................64
Caller ID ............................................................................................................................64
Pickup After Rings...........................................................................................................64
Flash Timing .....................................................................................................................65
Apply Settings ..................................................................................................................65
Configuring SLT Ports ..............................................................................................................65
Flash Timing .....................................................................................................................66
Setting Analog Extension Numbers...............................................................................66
Off-Premises Gateways.............................................................................................................66
Creating Off-Premises Gateway List .............................................................................66
Configuring Off-Premises CO Line Ports .....................................................................67
Configuring Off-Premises SLT Ports.............................................................................68
Recording System ......................................................................................................................69
Setting the Built-in Recording System...........................................................................70
Store on Demand List ......................................................................................................71
Setting Professional Recording System.........................................................................73
Digital Line Gateways...............................................................................................................73
Adding Digital Gateway .................................................................................................73
Modifying a Digital Gateway .........................................................................................75
Setting Trunk Parameters................................................................................................75
Setting Trunk Port Parameters .......................................................................................76
Setting Digital Trunk ARS...............................................................................................79
CTI Gateway...............................................................................................................................81
NAT Proxy..................................................................................................................................82
SIP Proxy.....................................................................................................................................83
Add SIP Proxy ..................................................................................................................83
Add SIP Trunks ................................................................................................................84
Create SIP Trunk ARS .....................................................................................................86
Add SIP Extensions..........................................................................................................88
Chapter 5 Extension Management....................................................................................................91
Configuring IP Phone, SoftPhone, and Virtual Phone Extensions......................................92
Extension User Information............................................................................................92
User Password..................................................................................................................92
Off-Hook Access to ..........................................................................................................92
Class of Service .................................................................................................................93
Button Mapping Group...................................................................................................93
CODEC ..............................................................................................................................93
Jitter Buffer Depth ............................................................................................................93
Silence Suppression .........................................................................................................94
Conference Disabled........................................................................................................94
Paging Disabled................................................................................................................95
Enable/Disable Extension...............................................................................................95
Apply Settings ..................................................................................................................95
Button Mapping ...............................................................................................................96
Station Speed Dialing ......................................................................................................99

Table of Contents 5
Answer Option ...............................................................................................................100
Mailbox............................................................................................................................101
Notification .....................................................................................................................103
Distribution List .............................................................................................................105
Analog Extensions ...................................................................................................................105
Off-Premises Extensions................................................................................................106
Creating Off-Premises IP Phone List...........................................................................106
Configuring Off-Premises Analog Phones .................................................................109
SIP Phone List...........................................................................................................................109
Add a SIP Phone.............................................................................................................109
Settings on SIP Phones...................................................................................................109
Chapter 6 Group Management........................................................................................................111
CO Line Groups .......................................................................................................................112
Creating CO Line Groups .............................................................................................112
Assigning Members to CO Line Groups.....................................................................113
Extension Groups ....................................................................................................................113
Creating Extension Groups...........................................................................................114
Hunting Method.............................................................................................................114
Wrap Up Time ................................................................................................................114
Group Administrator Password...................................................................................115
Set Sec. of Rings..............................................................................................................115
Prompt Interval in Queue .............................................................................................115
Max Wait-Time in Queue..............................................................................................115
Queuing Announcement...............................................................................................115
Allow Members Login...................................................................................................115
Logout If No Answer.....................................................................................................116
Assigning Members to Extension Groups ..................................................................116
Group Answering Option.............................................................................................117
Group Mailbox ...............................................................................................................118
Message Notification for Extension Groups...............................................................120
Button Mapping Groups.........................................................................................................121
Class of Service.........................................................................................................................124
Creating a Class of Service............................................................................................125
Setting Allow and Disallow Table ...............................................................................126
Setting CO Priority.........................................................................................................127
Automatic Route Selection (ARS)..........................................................................................128
Operator....................................................................................................................................129
Chapter 7 Voice Mail Configuration...............................................................................................131
Types of Voice Mailbox...........................................................................................................132
Voice Mail Parameters ............................................................................................................132
Language .........................................................................................................................132
Name Directory ..............................................................................................................132
Inter-Digit and AA Timeout .........................................................................................133
Messages Storage Settings.............................................................................................133
Ring Notification ............................................................................................................134
Transfer Options Settings .......................................................................................................134
Transfer Announcement ...............................................................................................135
Leave Message Directly.................................................................................................135
Transfer Options.............................................................................................................136
Before Leaving Message Timeout................................................................................137
AA Management......................................................................................................................137
Planning Your Auto Attendant Tree ...........................................................................137
Planning an AA Menu...................................................................................................138
Recording AA Menu Greetings....................................................................................141
CO Priority of Notification.....................................................................................................142
Tel. Programming Mode.........................................................................................................143

6 Table of Contents
Chapter 8 Operation Management .................................................................................................145
General Information................................................................................................................146
Check Software Version ................................................................................................146
License Key .....................................................................................................................147
Auto Discovery ........................................................................................................................147
Setting Default Class of Service....................................................................................148
Enable/Disable Auto Discovery ..................................................................................148
Backup System Files ................................................................................................................149
Restore System Files ................................................................................................................149
Application Upgrades.............................................................................................................150
CDR Data ..................................................................................................................................151
Billing System .................................................................................................................152
Reboot........................................................................................................................................153
Reset to Default........................................................................................................................154
Chapter 9 Report Management .......................................................................................................155
System Summary Report ........................................................................................................156
System Log................................................................................................................................156
Extension Report......................................................................................................................157
Chapter 10 Multi-Server Management...........................................................................................159
Server Information...................................................................................................................160
Redundant Server ....................................................................................................................160
Assigning Slave Blaze/Savanna Server ......................................................................161
Installing and Setting Slave Blaze/Savanna Server...................................................161
Joint Server ...............................................................................................................................162
Creating Joint Server......................................................................................................162
Setting Remote CO Lines Access Control ...................................................................164
Setting Links with Joint Server.....................................................................................164
Setting Joint Server Extension List...............................................................................165
Appendix A: Function Code List ....................................................................................................167
Appendix B: Personal Voice Mailbox.............................................................................................171
Listening to Messages....................................................................................................171
Sending a Message.........................................................................................................172
Editing Your Mailbox Options .....................................................................................173
Listening to Messages Remotely..................................................................................176
Listening to Messages from E-mail..............................................................................177
Playing A Recording......................................................................................................177
Sending A Recording.....................................................................................................178
Appendix C: InterClient...................................................................................................................179
Login to the Web-based InterClient.............................................................................179
Setting Items....................................................................................................................179
Appendix D: Terminologies ............................................................................................................181
Appendix E: Default Values ............................................................................................................185
Appendix F: DTMF Programming..................................................................................................204
Appendix G: System Capacity.........................................................................................................211
Index ...................................................................................................................................................213

Chapter 1 InterPBX Communication System Overview 7
Chapter 1
InterPBX Communication System Overview
InterPBX Communication System is a new generation business phone system
that employs a data network for terminal connectivity and voice transport.
Contrary to traditional business phone systems that carry voice over legacy
TDM networks, InterPBX delivers voice in digitized packets over LAN or
Internet networks.

8Chapter 1 InterPBX Communication System Overview
IP-Based Business Telephone System
Packet switching telephony technology allows enterprises to work upon their
existing data network infrastructure for implementing advanced applications
and to save costs on long distance and international calls. As a nature of
IP-based communication systems, the InterPBX brings significant savings on
call tolls, simplifies wiring, improves management and maintenance, and
provides advanced voice applications to enterprises’ needs.
Advantages of InterPBX
 Feature-rich – InterPBX supports an abundant number of features,
including Auto Attendant, built-in Messaging System, Automated Call
Distribution (ACD), Conference, Unified Messaging, Recording System,
Auto discovery, Contact Center applications, and other new generation
business applications.
 Flexibility – The capacity of InterPBX is not limited to a fixed system
chassis. InterPBX provides flexible structure for growing businesses. It can
be set up to meet the needs of enterprises from small to large or single to
multiple sites. Enterprises can connect each location by VPN or Internet.
 Reliability – InterPBX employs a unique distributed NeuralServer
architecture that allows multiple servers to coexist and communicate with
one another in a single system. Through synchronization and backup
mechanisms, InterPBX provides redundancy in the event of server failure
and therefore drastically enhances the reliability of the system.
 Management – Browse-based management tool provides administrators
and users a user-friendly interface to set, control, and maintain the system.

Chapter 1 InterPBX Communication System Overview 9
Key Components
DSG provides various series of the InterPBX Communication Systems: Blaze
5000, Blaze 1200, and Savanna 8000. Each series comprises different key
components.
Blaze 5000 Series: It contains Blaze/Savanna Server (IP-PBX Server), VMS
Server (Voice Mail System), Conference Server, Voice Gateway, and Recording
Server.
Blaze 1200 Series: It contains Blaze/Savanna Server, VMS Server, Conference
Server, and Voice Gateway.
Savanna 8000 Series: It contains Blaze/Savanna Server, VMS Server,
Conference Server, and Recording Server.
The key components and other optional applications can be installed
individually or integrated together as a compact system.
Blaze/Savanna Server
Blaze/Savanna Server is the brain (central administration) of InterPBX
Communication System. It is a software-based switching solution that handles
call signals, call control and voice processing activities and manages all the
extensions and VoIP gateways within the system.
VMS Server
VMS Server works seamlessly with Blaze/Savanna Server and provides Auto
Attendant, Voice Mail, Automated Call Distribution (ACD) and Unified
Messaging features.
Conference Server
Conference Server improves communications among employees by providing
conference function.
Recording Server
Recording Server helps enterprises record, monitor and search recording files.
It can be integrated seamlessly with users’ IP phones bringing more efficiency
for customer service representatives, banking officers or attorneys.
Note: Only Blaze 5000 and Savanna 8000 Series offer the Recording Server
function. If your IP-PBX system is Blaze1200 Series but would like to add the

10 Chapter 1 InterPBX Communication System Overview
recording function, you can consider to purchase our professional recording
system “Blaze Logger.”
Voice Gateway
Voice Gateway connects PSTN and IP networks and allows voice packets to be
transferred between Internet and traditional PSTN network. VG5000 Voice
Gateway supports CO Line and/or SLT interfaces, which are able to connect
CO lines or analog phones. VG6000 Voice Gateway supports T1/E1 ISDN
network.
Note: The Savanna 8000 Series doesn’t include the Voice Gateway.
SIP Proxy Server
DSG's SIP Proxy is a full-featured proxy server. It allows your Blaze or Savanna
Series IP-PBX to get connected to operators' softswitch and to enjoy the
provided SIP Trunk services. DSG SIP Proxy can register the IP-PBX to your
service provider. All the extensions under the system, including DSG IP
extensions or third parties' SIP phones, can access the SIP Trunks to make
long-distance or international calls.
NAT Proxy Server
DSG NAT Proxy is a complete solution to solve complicated network problems
that may happen when enterprises use the IP PBX Communication System.
With DSG NAT Proxy, Blaze or Savanna IP PBX Communication Systems and
Off-Premises Phones can traverse more than 95% of NAT or firewall
successfully without creating other service ports, and therefore enterprises can
communicate via IP-PBX Communication System with pure and stable voice
quality.
Blaze Logger Recording System
DSG Blaze Logger is a professional recording system especially designed for
Blaze and Savanna Series IP-PBX Communication Systems. With superior VoIP
recording technology, Blaze Logger provides enterprises a high-quality, stable,
and convenient recording solution. Blaze Logger can select any IP phone,
SoftPhone, single line telephone or CO line from LAN to precede recording or
monitoring. It can record voice packets transmitted on IP networks directly.

Chapter 1 InterPBX Communication System Overview 11
Note: The Blaze Logger is not included in any series of InterPBX
Communication System. You can add this professional recording system in
your purchase list when you need to extend your recording capacity or
functions.
BlazeLink
DSG BlazeLink is a CTI solution enables business to develop applications to
optimize workforce in a call center or contact center. Applications developed on
BlazeLink for call control, monitoring, or managing are able to connecting DSG
IP-PBX System to the data processing environment. With the supported tools
and resources, developers are able to deliver a comprehensive solution for
effective communications and better interactive experiences.
Supportable Extension Types for InterPBX
InterPBX Communication System supports 3 different types of extensions – IP
phones, analog phones, and SoftPhones. Administrators may set up any types
of the phones as users’ needs.
IP Phone - IP phones offer various business telephone features. The IP580 IP
Phone can be installed on LAN or on a remote site. A wide range of IP phones
will be available in the future.
SoftPhone – DSG’s SoftPhone is an application software installed on PCs
offering telecommuters or business travelers full-featured extension functions.
Users can adopt their own headsets or use DSG S300X USB Phones when
utilizing the SoftPhone.
Off-premises Phone – Off-premises IP phones, SoftPhones or analog phones on
off-premises gateways are all able to connect to a company’s InterPBX
Communication System via Internet or VPN and perform the same way as the
extensions in the head office.
Analog Phone - Analog extensions are connected to the FXS ports of Voice
Gateway like VG5000.
Web-based Management Tools
InterPBX provides administrators and extension users a management tool with
a GUI interface that allows administrators and extension users to set the

12 Chapter 1 InterPBX Communication System Overview
preferences of InterPBX or extension via browser. The suggested browser is
Internet Explorer 5.0 or later.
Administrator - The Administrator web site provides a web-based GUI
interface allowing administrators to configure the InterPBX Communication
System through the web browser. It helps administrators to manage and
maintain the system easily.
Extension User - Extension users can use InterClient to customize personal
settings on phones like Button Mapping, Speed Dial, Message Option, Answer
Option, Password and Phone Book. InterClient provides web-based and
software versions for users.
SH2500 PoE Switching Hub
SH2500 is the recommended switching hub for InterPBX Communication
System. It supports 802.3af PoE (Power-over-Ethernet), which offers IP
extensions the current power over network cables. Users do not need additional
power socket when using IP phones.

Chapter 2 Installing InterPBX Communication System 13
Chapter 2
Installing InterPBX Communication System
This chapter guides you through the preparation, installation and basic
configuration of InterPBX Communication System.

14 Chapter 2 Installing InterPBX Communication System
Before You Start
The component of InterPBX Communication System contains servers, gateways
and IP phones. Please follow the recommendations below when you install or
operate your system in order to avoid any injury and damage.
Safety Recommendation
Always use ESD-preventive tools when you plug the power cord. Do not
disassemble or remove chassis cover of any components of your InterPBX
Communication System. If there is any problem of your system, please contact
our service representatives.
Environmental Prerequisite
InterPBX Communication System needs to be installed in clean, dry, adequately
ventilated areas. The server, gateway, and switching hub can be placed in a
control room or on a rack. Please remain the control room in a suitable
temperature and adequately ventilated environment.
Local Telecommunications Service
You have to apply for the local phone service in your area. The trunk lines of
the central office need to be connected to Voice Gateways. DSG VG5000 Voice
Gateway supports CO Line interface. Please make sure if your trunk lines
support analog interface.
Prepare Your Telephone Numbering Plan
If you are going to replace your traditional telephony system with InterPBX
Communication System, you can retain the old dialing plan. InterPBX
Communication System supports flexible extension number lengths. The
maximum extension number length is “5 digits”. The telephone numbering
plan must not overlap or conflict with other numbers that are on your system or
on Joint Server’s system.
You need to prepare the followings before you install InterPBX Communication
System.
 CO Line Extension Number: Prepare an extension number for each CO
Line port so that the associated extension number can reach each trunk line
that is connected to it.

Chapter 2 Installing InterPBX Communication System 15
 SLT Extension Number: Prepare an extension number for each SLT port
so that the associated extension number can reach each analog phone that
is connected to it.
 IP Phone: Prepare an extension number for each IP phone.
 Group Number: If you plan to group specific trunk lines or extensions as a
group, prepare a Group Number for each CO Line Group and Extension
Group.
 AA Menu: Plan your AA procedure and prepare an access code for each
AA Menu.
Installing Blaze/Savanna Server
Figure: Blaze 5000 Series Connection Diagram
Figure: Blaze 1200 Series Connection Diagram
Figure: Savanna 8000 Series Connection Diagram

16 Chapter 2 Installing InterPBX Communication System
Installing and Configuring Blaze/Savanna Server
1. Connecting to Power Cord
Plug one end of the power cord to the power connector on the rear panel of
Blaze/Savanna Server. Plug the other end of the power cord into a power outlet.
After you turn on the power switching on the rear panel, you can verify the
function by checking if the LED labeled “Power” is on.
2. Connecting to LAN
You need to connect Blaze/Savanna Server to your existing Ethernet network.
Connect an Ethernet cable from the “Network” RJ45 port on Blaze/Savanna
Server to any 10/100BaseT RJ45 port on a switching hub.
3. Connecting to CO Lines or Extension Lines (For Blaze Series Only)
With Blaze Series, the Server is integrated with Voice Gateway module. Voice
Gateway supports CO line or analog extension modules. Please plug a CO line
connector to a CO Line port or plug an analog extension to a SLT port.
NOTE: If you accidentally plug the equipment with CO Line interface to SLT
port, it may damage your equipment. Please make sure that your equipment
connects to an appropriate interface. About the external audio connector or
broadcasting equipment, please refer to Chapter 2 Install VG5000/VG6000
Voice Gateway.
4. Preparing a Computer
Prepare a computer with web browser and be sure it is on the same subnet as of
your Blaze/Savanna Server. Change the computer’s IP settings if necessary. The
suggested web browser is Internet Explorer version 5.0 or later.
The default values of Blaze/Savanna Server are as follows:
 Default IP Address: 192.168.1.200:88 (The service port is 88)
 Default Gateway: 192.168.1.254
 Default Subnet Mask: 255.255.0.0
5. Login Blaze/Savanna Server

Chapter 2 Installing InterPBX Communication System 17
 Launch the web browser. On the address bar, type in the Blaze/Savanna
Server’s default IP address 192.168.1.200:88 to access Blaze/Savanna Server.
 You will be connected to InterPBX Administration Website. Please click the
Administrator icon.
 When you login the InterPBX Administration for the first time, you will see
the following picture. Please enter your user name and password and then
save the settings. Please remember your user name and password in order
to login again in the future. The password shall not exceed 8-character
alphanumeric. The user name and password are case sensitive.
When you login the InterPBX Administration next time, you will see the
following picture. Please enter your user name and password to login.

18 Chapter 2 Installing InterPBX Communication System
 After you login the InterPBX Administration successfully, the screen will
display the main menu of InterPBX Administration website as follows:
6. Basic IP Settings
Go to Main Menu>System Configuration>General Parameters. Enter the IP
address, Gateway IP, and Subnet Mask that are assigned to your
Blaze/Savanna Server.
Please enter the SMTP Server IP address in the field SMTP Server and the
e-mail address in the field E-mail Account. When the Unified Messaging
function is enabled, the system can send the voice message file via e-mail
through the SMTP server to the extension user. You may also enable the SMTP
Authorization function if the SMTP Server needs to verity the e-mail account
and password. If you enable SMTP Authorization, please be sure to enter the
Account Name and Password.
If your Blaze/Savanna Server is installed behind NAT, select the checkbox of
“Behind NAT”and input your NAT device’s real IP address in “NAT IP
Address” box. Click the Submit button to save and exit.

Chapter 2 Installing InterPBX Communication System 19
7. Input License Keys
Go to Main Menu>Operation Management>General Information. Click the
Add button and input your License Keys to enable the system capacity.
8. Configuring Voice Gateway (For Blaze 5000/Blaze 1200 Only)
Each Blaze5000/Blaze1200 has its unique MAC address. You will find it from
the label on it. Record the MAC address for registration with the
Blaze/Savanna Server.
 Access Blaze/Savanna Server and login to InterPBX Administration
Website. Go to Main Menu>Gateway Configuration>Analog Gateways.
Click the Add button to add your Voice Gateway.
 Enter the name of gateway, MAC address, and the range of CO Line and
SLT on the page of “Add Analog Gateway.” The starting value of the CO
Line/SLT range is “1”. For example, the CO Line range of a VG5000 with a
24-port CO Line interface is from 1 to 24. For more details, please refer to
the section of Installing VG5000 Voice Gateway or Chapter 4 Gateway
Configuration.

20 Chapter 2 Installing InterPBX Communication System
9. Restart
Go to Main Menu>Operation Management>Reboot. Press “Restart” to reboot
your computer.
You may change your computer IP setting to the original values after you finish
setting up the Blaze/Savanna Server. You will need to enter the new IP address
to connect to the Blaze/Savanna Server next time.
Connecting Blaze/Savanna Server via Console Port
When you forget the IP address of the Blaze/Savanna Server, you can connect a
computer to the console port of the Blaze/Savanna Server in order to check the
current IP address, gateway address, and subnet mask.
1. Connect one end of the RS232 transmission line to the computer’s COM
port and the other end to the Console port of Blaze/Savanna Server.
2. Open the Hyper Terminal program. Enter the connection name and set the
baud rate to 9600 bps.
3. Turn off the power of Blaze/Savanna Server. Wait for a while and then
turn on the power again. The computer can start to connect to the
Blaze/Savanna Server.
4. You can see the IP address from the “Hyper Terminal” page. You can also
change the IP address here. If you are going to change the IP address,
please press any key within 3 seconds to setup.
NOTE: The RS-232 DB-9 connector enclosed with the package is with pin 2/3,
pin 4/6, and pin 7/8 shorted.
