DSG Technology SH2500 User manual

Switching Hub
Before you start, please check the contents of the product package. The package should
contain the following items:
ȭSH2500 Switch One Power Cord
ȭOne RS232 Cable Rack Mount Kit and screws
ȭOperation Manual CD
If any of the above items is missing, please contact our reseller or distributor immediately.
SH250
SH250
0 Quick Start Guide
Quick Start Guide
SH2500 is a 24-Port 10/100Mbps switch with 24-Port PoE. The provided Power
over Ethernet (PoE) ports can automatically detect the presence of IEEE 802.3af-
compliant devices and will provide power through ports. The Switch provides 15
Watts per port and can be connected to IP phone, WLAN access point, video camera,
and other PD devices.
1. Preparing a PC
Choose a browser-enable PC on LAN where the Switch is located. It is recommended you
use Microsoft Internet Explorer 5.0 or later. Change the computer's IP settings to confirm
to Switch's default settings, if necessary. The default IP settings of SH2500 switch are as
follows.
Default IP address : 192.168.0.100 Default Subnet Mask : 255.255.0.0
Default Gateway : 192.168.0.254
2. Connect to the Switch
Launch the web browser. On the address bar, type the Switch's default IP address
192.168.0.100 to access the Switch.
3. Log in
You will be connected to the Admin Website.
Log in using the default user name and
password as below.
Default Username: admin (case sensitive)
Default Password: 1234
After you log in, the configuration page will come up as below. Upon selecting any item from
the list, a page with detail information on that item will come up.
06SH25QE.A DSG Technology, Inc. All rights reserved.
C
DSG 24-port
Management
Switch
Switch
System
Setup
VLAN
Priority
Port Status
Port Config
Port Based
VLAN/TOS
QoS
Installation
Rack Mount Placement
1. Attach one rack mounting bracket on each
side of the Switch's front panel and secure
each bracket with the provided screws.
2. Use the other provided screws to secure
each Switch to the rack.
3. Plug in all network connections and the
power cord.
4. Turn on the power.
To Locate the Switch on a Desktop
1. Make sure the rubber feet are attached to
the bottom of the Switch.
2. Place the Switch on a clean, flat desk or
tabletop close to a power outlet.
3. Plug in all network connections and the
power cord.
4. Turn on the power.
Login to the Switch
Packing Information
If you have any
questions during
the installation,
please refer to the
manual.

SH2500 Quick Start Guide
Power Socket
The Power Socket is designed to be used with the power cord included in the product package.
1. Attach the female end of the power cord to the male power connector on the back panel.
2. Attach the male end of the power cord to a grounded power outlet.
Name Color Status Description
PWR Red Lit Power "On"
Green Lit
Status Blink When the port is sending or receiving data (Activity).
Amber Lit
Blink When the port is sending or receiving data (Activity).
Duplex Green Lit Full Duplex
Off Half Duplex
LED on Red Lit The port has PSD module and support power.
RJ45 Jack Green Lit The port detects a PoE endpoint connection.
Status LED
The table below lists each LED's name, color and a brief description of its function.
Cabling
Port Type Cable Type Connector
10BASE-T Category 3Ŋ4 or 5 TP RJ-45
100BASE-TX Category 5Ŋ5e TP RJ-45
Power-over-Ethernet Category 5Ŋ5e TP RJ-45
Console Port
The console port is used when you forget the Switch's IP address.
1. Connect one end of the RS232 Cable came with the product package to the COM
port on your PC, and the other end to the Console port on the Switch.
2. From your computer, run HyperTerminal program. Assign a name and set baud rate at
19200 bps.
3. Power off the Switch and then turn it on. The connection will be established automatically.
4. You can find the IP address of the Switch from the screen.
Notice:
The RS232 cable came with the Switch
is a crossover cable. If you would like
to use the regular RS232 cable, please
switch pin 2/3, pin 4/6 and pin 7/8.
Key Features
24-port 10/100 Mbps supporting Auto-
Negotiation
Support Auto-MDI/MDI-X function
Support up to 24 port-based VLAN
Groups
Support Store-and-Forward packet
transmission technology
Support Non-blocking Function
Support IEEE802.3x Flow-control for Full-
duplex and Back Pressure Flow-control for
Half-duplex
Support 802.1p/Q
Support 802.3af Power-over-Ethernet
Web Based Management
Introduction
When the port has a valid physical connection with
another device. Speed 10Mbps.
When the port has a valid physical connection with
another device. Speed 100Mbps.
