DSPPA MP9823S User manual

SEQUENCE POWER SET
MP9823S
Operation Instructions
Welcome to use the public address system manufactured by DSPPA Company. For the better
application of this equipment, please read the operation instruction carefully prior to use.
Guangzhou DSPPA Audio Co., Ltd.
http：//www.DSPPA.com

** Sequence Power Set
MP9823S
1
广州市迪士普音响科技有限公司 Guangzhou DSPPA Audio Co.,Ltd.
MP系列公共广播系统控制器
TIMER IN
N
GND
L
请勿打开
以免触电
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
CH 10 CH 11 CH 16
CH 1 CH 2 CH 3 CH 4 CH 5 CH 6 CH 7 CH 8
CH 9 CH 10 CH 11 CH 12 CH 13 CH 14 CH 15 CH 16
~220V/50Hz/16A
(CH1-CH16=3.5KW)
F1AL250V
FEATURES
Sequentially switching power supply for 16 channels;
Auto controlled by a timer or manual operates;
3.5kVA of capacity available.
FRONT PANEL
12 3 4
1Power Switch 2 Power Indicator
3 Timer Input Indicator 4 Output Indicators
REAR PANEL
1 Power supply outlet 2 Legend for the pins of outlet
3PowerCable 4Fuse
5TimerInput
1234
5

** Sequence Power Set
MP9823S
2
CONNECTIONS
EXAMPLE 1: For sequentially switching an electric audio system.
CH1 CH2 CH16
… … TIMER IN
TIMER
PREAMP. POWER AMP. AUDIO SOUCE PERIPHERAL
CH3
EXAMPLE2: For Sequentially switching series power amplifiers.
CH1 CH2 CH16
… … TIMER IN
TIMER
AMPLIFIER-1
CH3
AMPLIFIER-2 AMPLIFIER-n
OPERATION
1. Make connections correctly. Attention: The power cable must be connected to main power directly.
2. Press the “power switch” on front panel, can be step-by-step to switching the devices under controlled.
Note: In this case, must be disabling the timer.
3. By a timer control, it can switch the devices automatically. Note: In this case, must be set the “power
switch” on “off ” status.

** Sequence Power Set
MP9823S
3
SPECIFICATIONS
Total Capacity 3.5kVA, 16A，16channels,
220V, 10A/channel
Timer In sensitive AC 220V, 0.01A
Step time 0.4S-0.5S
Protection AC fuse
Power Requirement AC 220V/50Hz/16A
Outer Packing Size（mm）（L×W×H）530×440×195
Unit Size（mm）（L×W×H）484×365×88
Gross weight 10kg
Net weight 8.3kg
Specifications are subject to be changed without notice.
CAUTION
●When the “Power switcher” is off, please pull out the power cord from the socket.Please
keep the equipment out of water.
●To reduce the ris
k
of electric shock, do not remove the cover.
●No user parts inside. Refer servicing to qualified service personnel.
●The symbol on rear panel indicates hazardous live. The connection of these terminals
must be operated by the instructed person.
●The unit connects to the mains by the plug. Pull out the plug when the unit is in fault or
danger status. So the socket for the unit plugging must be set in the place can be easy to
plug into and pull out the plug.
Guangzhou DSPPA Audio Co., Ltd.
