DTVS Smart1 User manual

Please read this installation manual carefully before use.

2
Be sure to observe these precautions so as to use the product correctly and prevent injuries or damage to property.
Warning
Safety Precautions
Do not connect multiple power plugs to one outlet.
It may result in a re.
Do not bend the power cord too much and do not place heavy objects
on the power adapter as it may become damaged.
Never disassemble, repair, or modify the product
, accessories, or power
adapter. This presents the danger of re and electric shock.
Disconnect the the power adapter during thunder and lightning to
avoid damage and re.
Do not use or keep the product and accessories for a long time at 0°C or
lower or at 40°C or higher.
It may cause re, heat, or other dangers.
Do not let children or pets suck on or bite the
product and accessories .
It may result in a re or other dangers.
Do not drop or hit your remote control. This may cause a malfunction
or injury.
Do not pull the power cord to disconnect it.
If the power cord is damaged, it may cause a re or an electric shock.
Do not connect or disconnect the power adapter with wet hands.
It may cause an electric shock.
Do not let foreign substances, moisture, or water get into the
product
and accessaries
. It may cause malfunctions or re.
Do not place this product under direct sunlight, near heaters or in places
where there is heat.
It may result in a re.
When there is heat or smoke from the product, immediately remove the
power adapter. It may cause a re or an electric shock.
Do not bend the HDMI cable or damage the power adaptor by pressing on it
with a heavy object. There may be a risk of re or electric shock.
Avoid placing the product and accessories in places where there is high
temperature or moisture.
The product may malfunction or cause electric shock.
Always use certied parts.
If you do not use certied parts, the product may work abnormally and
cause overheating, re, explosion, electric shock, and/or injuries.
Keep the power adaptor and HDMI cable from heating devices.
It may cause explosion or electric shock.
Do not clean the product with chemicals such as benzene or thinner.
It may cause deformation and discolouration.
Do not plug or unplug the power adaptor and HDMI cable with wet
hands. Doing so may pose a hazard.
Caution - Batteries
Do not use damaged batteries for your remote control.
If you replace the battery with the wrong type of battery, you can cause an
explosion. Replace only with the same battery or an equivalent type.
Do not dispose of batteries in a re as it may explode.
Caution - Data Protection

Do not interrupt the power while in the process of upgrading the system
software or an application.
Do not interrupt the power during le uploading/downloading.

3
Table of Contents
Safety Precautions .......................................................................................................2
Table of Contents..........................................................................................................3
Names and Functions of Parts ..................................................................................4
Front Panel.............................................................................................................................4
Side Panel ...............................................................................................................................4
Rear Panel...............................................................................................................................4
RF RCU - Optical Trackpad...............................................................................................5
RF RCU - QWERTY ...............................................................................................................7
Connections...................................................................................................................8
Connecting HDMI & AV cable........................................................................................8
Connecting ETHERNET cable ........................................................................................8
Connecting S/PDIF.............................................................................................................8
Connecting satellite antenna cable............................................................................8
Connecting external storages.......................................................................................9
Connecting USB storages ...............................................................................................9
Connecting power adaptor ...........................................................................................9
Connecting peripherals...................................................................................................9
Getting Started .......................................................................................................... 10
Turning the unit on......................................................................................................... 10
Turning the unit o......................................................................................................... 10
RF RCU pairing................................................................................................................... 10
First-time installation...................................................................................................... 10
Basic Settings..................................................................................................................... 12
Satellite setting - Antenna type................................................................................. 12
Satellite setting - Scan.................................................................................................... 12
Satellite setting - edit...................................................................................................... 13
TP setting - scan................................................................................................................ 14
TP setting - edit................................................................................................................. 14
Deleting a channel .......................................................................................................... 14
Conguring the Home Screen................................................................................... 14
Viewing program information................................................................................... 15
Using the status information menu........................................................................ 15
Using multi mode............................................................................................................ 15
Conguring the Main Menu....................................................................................... 16
CHANNEL..................................................................................................................... 17
CHANNEL conguration............................................................................................... 17
Using the sort menu....................................................................................................... 17
Advanced Channel List conguration.................................................................... 18
Using the channel sort menu..................................................................................... 18
Channel editor................................................................................................................... 19
Favorite group................................................................................................................... 20
APP................................................................................................................................ 21
APP menu............................................................................................................................ 21
Using screen capture...................................................................................................... 22
Using iMedia player........................................................................................................ 22
Using PVR player .............................................................................................................. 24
Using TimeShift................................................................................................................. 25
Using YouTube................................................................................................................... 26
Using DLNA ........................................................................................................................ 26
Using Search....................................................................................................................... 26
Using Browser.................................................................................................................... 26
Using IPTV (Advanced Application) ........................................................................ 27
Using xbmc (Advanced Application)...................................................................... 28
Using APK Installer (Advanced Application) ....................................................... 28
FAVORITE ..................................................................................................................... 29
Remove from Favorites ................................................................................................. 29
INTERNET..................................................................................................................... 29
Add to Favorites................................................................................................................ 29
EPG................................................................................................................................ 29
Conguring the EPG....................................................................................................... 29
Viewing program information................................................................................... 30
Using the sort menu....................................................................................................... 30
Add Reservation Recording........................................................................................ 30
Reservation List................................................................................................................. 31
SETUP ........................................................................................................................... 31
Using the SETUP............................................................................................................... 31
Managing applications ................................................................................................. 33
Troubleshooting........................................................................................................ 34
Specications ............................................................................................................. 35

4
Names and Functions of Parts
 Front panel
 Side panel
 Rear panel
1. RCU signal status
The indicator light is on when the device is recieving an RCU signal.
2. Network status
The indicator light turns on when the unit connects to a network.
3. Power status
The indicator light turns on when power is on.
1. LNB 13/18V 400mA Max. Connect a satellite antenna cable.
2. e-SATA(OPTION) Connect e-SATA device to e-SATA slot.
3. S/PDIF(OPTICAL) Connect S/PDIF to the digital audio unit.
4. AV OUT Connect AV cable to the display.
5. HDMI Connect HDMI cable to the display.
6. USBConnect external USB devices to USB slot. ( 5V)
7. USBConnect external USB devices to USB slot. ( 5V)
8. USBConnect external USB devices to USB slot. ( 5V)
9. ETHERNET Connect the LAN cable to ETHERNET.
10. RS-232 Connect PC.
11. 12V 2A Connect power adaptor.
1. USBConnect USB type peripheral devices to USB slot. ( 5V)
2. SD/MMC Insert SD/MMC to memory slot.
If SD/MMC is not mounted, the camera application is not available.
321 21 3 4 5 10 119
76 8
1 2

5
Names and Functions of Parts
 RF RCU - Optical Trackpad
1 2
4
6
8
3
5
7
9
10
1. (Power) Power button.
2. (Mute) Mute button.
3. /(VOL) Volume buttons.
4. /(CH) Channel buttons.
5. Assigns hotlink application.
Press the button for 3 seconds to capture the hotlink icon image.
6. Switches to the previous channel.
7. MENU Displays application menu items if available.
8. (Back) Returns to the previous screen.
(Home) (Long press) Displays current channel.
9. Plays/pauses media.
(OK) Selects highlighted menu item and changes values inside the menu.
Optical Trackpad Provides mouse-like functionality.
10. Opens Audio and Subtitle Language selection options.
Drag (Press and Hold) While the Drag button is pressed, the Optical Track Pad
can be used to drag to the desired position.

6
Names and Functions of Parts
 RF RCU - Optical Trackpad
11
16
15
17
19
18
13
14
11. ///Moves the focus up/down/left/right.
- TimeShift (Option) TimeShift function is activated by pressing the left button while
watching program.
12. EPG (White) Displays the Electronic Program Guide (EPG).
(Status Information)
(Press and Hold) Displays notications, weather reports and recent
applications.
13. CHANNEL (Red) Moves to CHANNEL menu.
Zoom In Zoom in function is available on images and web browsers.
14. APP (Green) Moves to APP menu.
Zoom Out Zoom out function is available on images and web browsers.
15. FAVORITE (Yellow) Moves to FAVORITE menu.
Page up Page up function is available on text pages and web browsers.
16. INTERNET (Blue) Moves to INTERNET menu.
Page down Page down function is available on text pages and web browsers.
17. Number Changes the channel number or enters numbers.
18. (Record) Records the current channel.
(Stop) Stops recording.
19. Displays teletext, audio language, and subtitle.
(Press and Hold) Displays keyboard screen.
12

7
Names and Functions of Parts
 RF RCU - Qwerty
1. Character, number, and functions
Enter characters or numbers.
2. Shift If you want to input capital letters or upper letters,
press Shift button together.
3. Fn If you wan to input numbers, special characters
and functions with blue, press Fn button together.
4. (Multi Language)
You can enter the language you selected in the
System menu of Setup.
(Search) (Press and Hold) Displays search screen.
5. (Back) Returns to the previous screen.
6. ▲/▼/◄/► Movesthefocusup/down/left/right.
/ Use Zoom in/out function with Fn button.
/ Use Volume up/down with the Fn button.
/ Use Page up/down function with the Shift button.
7. MENU Displays the menu screen.
8. BACK Removes the previous character.
9. ENTER Finishes the current text input or executes a
command.
OK OK or select function with Fn button.
Inserting the batteries
Use the 2 AA batteries for RF RCU.
1. Push and slide in the direction of the arrow in the gure to open the battery cover.
2. Insert the new batteries into the battery slot.
yMake sure you match the plus (“+”) ends with the plus markings on the
battery case.
3. Close the battery covers.
1 9
4 5 6 7 8
23

8
Connections
 Connecting HDMI & AV cables  Connecting S/PDIF
 Connecting Ethernet cable  Connecting a satellite antenna cable
HDMI cable
AV cable
(stereo type)
Digital audio cable(Optical)
Satellite antenna cable

9
Connections
 Connecting external storage devices  Connecting the power adaptor
 Connecting USB storage devices  Connecting peripherals
e-SATA cable
USB Storage
Device
USB Storage
Device
Power adaptor
Wireless dongle
SD/MMC
Wireless keyboard and mouse.

10
Getting Started
 Turning the unit on
Press the Power button on the RCU to turn the device on and o.
Please refer to Connections before initial use.
 Turning the unit off
You can press the Power button to select Sleep, Shutdown or
Reboot. To Sleep, Shutdown, pressbutton to select o timer.
 RF RCU pairing
During the initial booting, a pairing screen will be displayed.
 First-time installation
Before you can watch television or listen to the radio, you must rst
perform the installation procedures.
The First time installation gives you the convenience of selecting
various languages, displays setting, network setting, weather
setting, channel location setting and channel search.
1. Using the // (OK) buttons, select Country and Language
settings. You can skip by pressing the (BLUE) button.
2. Press the (OK) button to select Display Settings.
3. Press (OK) button to changes icon for move.
4. Use the ///buttons to change the display size.
5. Press the (Back) button to save.
1. Press the and buttons at the same time for 2 seconds.
2. An “OK” message will be displayed after pairing is complete.

11
9. Press the (OK) button to select Channel Location Settings.
10. Using the // (OK) butons, select the channel search
location.
11. Select ALL, FTA or Scramble and then press the (OK) button
to display the Channel Search screen.
12. Press the (OK) button to save and then press (Back)
button.
13. Select ALL, FTA or Scramble and then press the (OK)
button.
6. Press the (OK) button to select Network Settings.
7. Select Ethernet DHCP, Ethernet Manual or Wireless.
Ethernet DHCP : Automatic setting.
Ethernet Manual : Manual setting. (IP address, Sub-Netmask,
Default gateway, DNS address)
Wi-Fi DHCP : Displays the Wi-Fi list.
Wi-Fi Manual : Manual setting.
8. Press the (OK) button to select Weather Settings.
Use the // (OK) buttons to select the city name.
Getting Started

12
Getting Started
 Basic Settings
.
Select the System menu (the default PIN code is 0000).
You can change the language, locale, font size, resolution, PIN
code, sound and picture options and screen size from this menu
screen.
 Satellite setting - Antenna type
.
1. Select the System menu (the default PIN code is 0000).
2. Select the Channel Search menu item to display the
“Antenna type” popup menu.
3. Use the // (OK) buttons to select the DiSEqc 1.0,
DiSEqc 1.1, Motor or USALS options.
The Channel Search screen will be shown.
Note
If you want to change the Antenna type,
press the (YELLOW) button.
 Satellite setting - Scan
1. Use the // (OK) buttons to select the satellite for multi
search. The blue indicator light should turn on.
 Note
Motor or USALS does not support multiple selection.
2. Press the (RED) button to scan for satellites.
3. Select the ALL, FTA or Scramble menu items to display the
Channel Search screen.
4. Press the (OK) button to save.

13
Getting Started
 Satellite setting - edit
1. Use the // (OK) buttons to select a satellite to search for.
The blue indicator light should turn on.
2. Press the (GREEN) button to display the Satellite Edit
popup menu.
 y Satellite
Press the (OK) button to display a popup menu.
To edit sort, use the /buttons to select the Satellite name
or Longitude.
Next, use the // (OK) buttons to select the satellite.
 Note
You can select a satellite using the /buttons.
 y Edit Name
You can change the satellite name.
To save the name, press the (OK) button.
 y LNB Frequency
Press the (OK) button to display popup menu.
Use the // (OK) buttons to select an option.
 Note
You can select the LNB frequency using the /buttons.
 y LNB Power
Use the /buttons to select ON or OFF.

y LNB 22KHz
Use the /buttons to select AUTO, ON or OFF.

y DiSEqC Version
Use the /buttons to select DiSEqC version.

y DiSEqC Port
Use the /buttons to select DiSEqC port.

y The Motor and USALS settings do not support DiSeqC 1.0
or 1.1.
 Satellite setting - edit
DiSEqC 1.0 or 1.1 Motor or USALS setting

14
Getting Started
 TP setting - scan
 TP setting - edit
1. Use the // (OK) buttons to select a satellite for TP search.
The blue indicator light should turn on.
2. Press the (RED) button to display the Channel Search
screen.
3. Set up the menu.
Note
NIT search is only supporteed in TP search mode.
1. Use the // (OK) buttons to select a satellite for TP edit.
The blue indicator light should turn on.
2. Press the (GREEN) button to display the Transponder Edit
popup menu.
4. Set up the menu.
 Deleting a channel
1. Use the // (OK) buttons to select a satellite or transponder
list. The blue indicator light should turn on.
2. To delete a channel, press the (BLUE) button.
3. Press the (Back) button to return to the previous screen.
 Configuring the Home Screen
To display Home Screen, press and hold (Home)button.
Current Time Current Channel Information
Quality (blue)
Signal (red)
Channel name
Program progress bar
Program
name & time
Channel Information icon Dolby
Teletext
Multi Audio
Subtitle
Network
High Denition
Radio
Scramble
Lock
Favorite
T
S
2

15
Getting Started
 Viewing program information
 Using the status information menu
To display Status information, press and hold the button
1. While watching a program, press the button to display the
program information.
2. While the program information is displayed, press the button
to display detailed program information
 Note
Program information will disappear after ve seconds of inactivity.
Current area Date & time 4-Day Weather Forecast
Recent applications
1. Press the button while watching a program to select Teletext,
Audio and Subtitle Language, and Audio Mode.
2. Press the (Back) button to return to the previous screen.
 Using multi mode

16
Getting Started
Use the //(OK) buttons to make a selection.
Main menu Hot button Description
Red button.
Displays the Channel list.
Green button.
Displays the Application list.
Yellow button.
Displays the CHANNEL, APP or INTERNET favorites.
Blue button.
Displays the bookmarks list.
White button.
Displays the 7-day Electronic Programme Guide
(EPG).
None Selects on main menu.
Displays the settings list’s main menu.
 Configuring the Main Menu
To display the Main Menu, press the (MENU)button.
Current date & time

17
CHANNEL
 CHANNEL configuration
To display the CHANNEL menu, press (RED) button.
 Using the sort menu
or .Select CHANNEL menu.
 Using the sort menu
2. The Options screen will be displayed.

y TV, Radio or TV+Radio sort
Use the /buttons to select TV, Radio or TV+Radio.
The channel list will change to the selected option.
 y Satellite name sort
Use the /buttons to select the satellite name.

y Group sort
Use the /buttons to select the group. Possible options are
Default, A-Z, Z-A, HD, SD, Scrambled or FTA.
 y Find sort
To Find channels, enter the rst letters of the channel name.
 Note
To Find sort, select the Default of Group sort.
Sorted channels on Find sort will not be saved.
If you cannot nd any channels using Find sort, there are no saved
channels beginning with the specied letters.
 y Favorite group sort
Use the /buttons to select the favorite group name.
 Note
The Favorite group can be set in the Channel editor.
1. Press the (MENU)button to display the Options screen.
Displays the channel information.
(Satellite name, Frequency, Polarity and Symbol rate)
Channel list
You can select the Channel Editor, Options menu or
Advanced Channel List.

18
CHANNEL
 Advanced Channel List configuration
To display the Advanced Channel List menu,
press

buttons.
The preview screen will be displayed.
The colour buttons can be used to sort channels.
 Using the channel sort menu
 or  .
1. You can sort channels by using colour buttons.
 y Sorting by Satellite
 Press the (RED) button to sort channels by Satellite.
 y Sorting by Favorite group
Press the (GREEN) button to sort channels by Favorite
Group.
To select F1 ~ F12, press (OK) button.

y Sorting by Channel name
Press the (YELLOW) button to sort channels by channel
names. (A~Z or Z~A)
 y Display all channel
Press the (BLUE) button to display all channels.
2. Press the (Teletext) button to go to the Channel List menu.
3. Press the button to go to the Channel Editor menu.
You can select sort menu.
Channel list
Displays selected program information.
You can select the Channel List or Channel Editor.

19
CHANNEL
 Channel editor
or .Select the Channel Editor menu.
 Channel editor
1. Press the (OK) button to enter multi edit mode.
The blue indicator light should turn on.
Note
Refer to help menu for select/deselect.
 y Channel sort
 Press the (RED) button to sort channels.
Select satellite TV or Radio Default, A-Z, Z-A, CAS,
FTA, HD-SD. Next, press the (OK) button to save changes.

y Channel edit
 Press the (GREEN) button to edit channels.
Select (lock), (unlock), (delete), (rename), or
Add/Remove favorite .
Press the (OK) button to select.
Finally, press the (Back) button to save changes.
Displays sorted satellite.
Displays selected program information.
Selection commands Edit commands
Sort (Red button)
Edit - Rename (Green button)
Edit - Lock (Green button)
Edit - Add/Remove favorite
(Green button)

20
CHANNEL
 Favorite group
or .
Select Favorite group menu.
 Channel editor
 y Channel move
 Press the (BLUE) button to move channels.
Use the //(OK) buttons to make a selection.
 Note
To switch channel, select the ALL satellite of Sort
( (RED) button).
Displays the channel lists of
sorted satellite. Displays selected favorite group.
Add/remove commands Help menu for edit.
Multi select for move Move focus (Blue button)
1. Press the (YELLOW) button to select the favorite group.
2. Press the (OK) button to add the channel to the favorite
group. A will be displayed next to the channel.
