Dualit XL900 Technical specifications

XL900 Food Processor
Instruction Manual & Guarantee
IB-DMP1-C_Layout 1 15/03/2011 11:55 Page 1

32
SAFETY PRECAUTIONS
READ ALL THE
INSTRUCTIONS
CAREFULLY BEFORE
USING YOUR DUALIT
FOOD PROCESSOR.
KEEP THESE
INSTRUCTIONS SAFE
FOR FUTURE
REFERENCE.
Always follow these safety precautions
when using your food processor, for your
own safety and to avoid damaging the
processor.
• This appliance is designed to
operate with an AC power supply.
Make sure your network voltage
corresponds to the voltage shown
on the rating plate underneath the
food processor
• Do not use the food processor if
the cord or plug is damaged, it must be
replaced by a special cord available
from Dualit or Authorised service
agent. For more information, call the
Dualit customer care line on
01293 652 500
• Never use a plug without the fuse
cover fitted. Always make sure a
replacement fuse is the same rating as
the original
• Replacement fuses should be
approved to BS 1362
• NOTE: Any plug cut from its power
supply cord should be disposed of
immediately. Inserting any cut-off
plug into an electrical socket is
dangerous
• Unplug the unit when not in use,
before fitting or removing parts
and before cleaning.To unplug it,
hold the plug and pull it out of the
socket. Never pull it out by the
power cord
• Do not use the food processor
outdoors
• This product is for domestic use only
• Do not use the processor on a sloping
surface
• Make sure the power cord doesn’t
hang over the edge of the table or
countertop
• Make sure it isn’t in contact with
anything hot or wet
• Never leave the processor
unattended when it is plugged into
a wall socket or switched on
• Children should be supervised to
ensure that they do not play with
the appliance
CONTENTS
Safety precautions
Know your food processor
Processing bowls & lid
Blades & spindle
Grating & variable slicing disc
E-disc & spatula
Continuous processing
Pulse & auto pulsing
Processing tips
Cleaning & maintenance
Storing you processer
Troubleshooting
Recipe ideas
Maximum loading chart
Guarantee
3
6
8
9
10
11
12
13
14
16
17
18
19
26
27
Unpack the box with care, keeping all the packaging materials until you are satisfied
everything is present and in working order. Once satisfied remove any tags from the food
processor and recycle the packaging appropriately.
All illustrations are for representation only, your model may have a different from illustrations shown.
IB-DMP1-C_Layout 1 15/03/2011 11:55 Page 2

54
• Never touch moving parts or insert
your hand or utensils into the bowl.
Use the food pusher provided to guide
ingredients through the feed tube
• The processor features an overheat
cut-out that cuts the power if it
becomes too hot for any reason. If
this occurs turn the control knob to the
off position. Once it cools down, the
safety cut-out will automatically reset
itself within 1 hour and the power will
be restored
• Do not submerge the motor housing,
cord or plug in water or any other
liquids
• Clean all parts after each use; please
refer to the cleaning instructions on
page 16
• If your ingredients include raw meat,
make sure the bowls and attachments
are cleaned thoroughly, immediately
after use
• When using a dishwasher, always set it
to the lowest setting (max 40ºC) and
keep bowls and accessories well away
from the heating elements. Avoid the
drying cycle.
SAVE THESE
INSTRUCTIONS
In the interest of improving products,
Dualit Ltd. reserves the right to change the
product specification without prior notice.
• This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of
the appliance by a person
responsible for their safety
• Ensure that the processor, the toolbox
and all accessories are always kept well
out of reach
• When moving the processor, use both
hands and lift holding the base unit.
Never lift the processor using the bowl
handle
• Never tamper with the safety systems.
They are included for your personal
safety
• The blades and discs are extremely
sharp; take extra care when handling
these parts, especially when removing
from the bowl, emptying the bowl and
during cleaning. Avoid touching the
sharp edges
• The use of attachments not
recommended or sold by Dualit may
cause fire, electric shock or injury to the
user or the appliance
• Use the spatula only when the unit is
turned off, the blade or discs are
removed and the processor is
unplugged
• Store the tool tray out of reach
of children
• Never operate the processor with the
bowls empty.
• Do not misuse the processor; it is
designed for use with food items
only
• Before each use, check that the
bowls contain only the ingredients
and nothing else
• Do not process boiling or hot liquids
• Bowls and attachments are not
suitable for microwave use
• Ensure the bowl(s), accessory(s),
lid and food pusher are all securely
in place before turning the processor
on. It will not work without the large
bowl and lid in place and locked
• Only use the food pusher supplied
to insert and push ingredients down
the feeder tube. Never use your fingers
or utensils; this could cause severe
injury and also damage the appliance
• Do not overfill the bowls; ingredients
need room to move around. Use the
maximum loading chart on page 22 for
reference
• Always turn the power off via the
control knob before opening the lid
• Switch off the appliance before
changing accessories or
approaching moving parts while
in use
• Never remove the bowl or lid until the
blades or discs have come to a
complete stop
IB-DMP1-C_Layout 1 15/03/2011 11:55 Page 4

76
KNOW YOUR FOOD PROCESSOR
LID & FEED TUBE
Easy to assemble and clean.
FOOD PUSHER
Features easy to read
measurement markings.
Spindle
Use on the bowl drive to
attach accessories.
Spatula
For quick and easy
removal of ingredients.
WORK BOWL
Features the largest
working capacity
Grating/shredding disc
Can grate most vegetables
into fine food.
Adjustable slicer
A precision sharp slicing
blade with height adjustable
for different thickness slicing.
Tool tray
For storage of most of the
accessories.
E Disc
Will emulsify liquids and whisk
egg whites in seconds.
Multipurpose Chopping Blades
It chops, minces, blends and mixes in a matter of seconds. Note: small blade is optional extra
Medium bowl
Use this as a secondary
bowl,This is also the best
bowl when using slightly
smaller quantities.
Large bowl
Use this bowl for all liquids
(it has a sealed drive). It
offers the maximum
working capacity
Small bowl - (optional extra)
Perfect for everyday
processing tasks like chopping
herbs or puréeing baby food.
The small bowl must sit inside
the medium bowl.
CONTROLS
Main on/off, start/stop, pulse
and auto pulse
CORD
STORAGE
HANDLE
GRIPS
SUCKER FEET.
IB-DMP1-C_Layout 1 15/03/2011 11:55 Page 6

1st
2nd
3rd
CLICK
98
BLADES & SPINDLE
CAUTION BLADES ARE VERY SHARP.WITH THE EXCEPTION OF THE
CHOPPING BLADES,ATTACHMENTS MUST BE USED WITH THE SPINDLE.
PROCESSING BOWLS & LID
IF THE PROCESSING BOWL AND COVER ARE NOT CORRECTLY
ASSEMBLED,THE FOOD PROCESSOR WILL NOT FUNCTION.
Before you assemble the
food processor, ensure that
the power cord is unplugged,
and placed facing you on a
dry, level surface. Push down
on the body to secure firmly.
Place the large bowl onto
the main body, with the
handle pointing to the right
(4 o’clock).
Hold the handle and turn it
clockwise until you hear and
feel it lock in place.
123
POSITION BODY LARGE BOWL LOCK LARGE BOWL
1ADDITIONAL
BOWLS
When using the medium
bowl, insert this into the
large bowl; it will self-locate.
If using the optional small
bowl, place this into the
medium bowl.
2ATTACH THE LID
To attach the lid, place it on
the large bowl aligning to
the slots on the bowl rim.
3LOCKING THE LID
Hold the large bowl handle
with one hand, with your
other hand, hold the base of
the feed tube and rotate
clockwise to lock.
Handle blades and
attachment using only the
centre plastic section.The
large chopping blade locates
directly onto the bowl drive,
once the large bowl is
locked in place.
The medium chopping blade
also locates directly onto the
bowl drive, once both large
and medium bowls are in
place.
The small chopping blade
needs to be used with the
spindle. This must be
attached to the bowl drive
once the large and medium
bowls are in place.
123
LARGE BLADE MEDIUM BLADE SMALL BLADE
1SPINDLE IN
LARGE BOWL
The drive shaft locates on
the bowl drive on the large
processing bowl.
1st
2nd
2SPINDLE IN
MEDIUM BOWL
When using the medium
bowl, place the medium
bowl in the large bowl then
the drive shaft on the bowl
drive.
3SPINDLE IN
SMALL BOWL
When using the optional small
bowl with blade, place in the
large bowl with medium bowl,
drive shaft in position, then
place the small bowl & small
blade on the drive shaft.
IB-DMP1-C_Layout 1 15/03/2011 11:55 Page 8

11
10
GRATING & VARIABLE SLICING DISC
You will always need to use the large bowl first, no matter what other bowls and discs you
wish to use.
Select the fine or course side
of the grating/shredding disc
to suit your requirement.
OR
Place the reversible grating
disc on the drive shaft and
rotate it clockwise to firmly
attach. Ensure it is securley
locked in place.
Place the drive shaft and
grating disc assembly onto
the bowl drive of large
processing bowl.
123
SELECT GRATE LOCK ON SPINDLE LOCATE ON BOWL
3FOR LARGE &
MEDIUM BOWLS
The Variable slicing disc can
only be used with the large
and medium bowls.
It creates any slice thickness
between 0.5mm and 7.5mm.
1SLICE THICKNESS
To adjust the slicing
thickness, rotate the outer
spindle of the disc
anti-clockwise to make the
slices thicker, or clockwise to
make thinner slices
2LOCATE THE SLICER
Fit the slicing disc over the
spindle and press firmly into
place. Warning: Use caution
as the blades are sharp.
Attach the drive shaft onto
the centre of the e-disc.
Push down until you hear
and feel it lock into place.
Place the e-disc assembly
directly onto the bowl drive
in the large bowl.
For best results use a
minimum of two/three egg
whites.To emulsify liquids
successfully, add additional
liquids slowly through the
feeder tube.
123
SETUP THE E-DISC LOCATE E-DISC ADDING LIQUIDS
1TURN OFF
Always turn off the power
by pressing START/STOP
button THEN the MAIN
POWER button, finally
unplug the processor before
using the spatula.
2REMOVE BLADES
Use the spatula to
redistribute ingredients that
have built up around the
sides of the bowls, or to help
decant ingredients from
bowls to other containers.
3USE SPATULA
Be careful not to touch the
cutting blades with your
hands when you use the
spatula to scrape the inside
of the bowl.
E-DISC & SPATULA
The e-disc can only be used with the large bowl, and only with liquids (including cream,
egg whites, dressing).
IB-DMP1-C_Layout 1 15/03/2011 11:56 Page 10

1312
PULSE & AUTO PULSING
ONLY USE THESE FEATURES WITH THE LARGE & MEDIUM CHOPPING BLADES.
The Pulse & Auto Pulse feature is perfect for mixing in foods without pureeing the mixture.
Turn the main power ‘ON’
Press the ‘PULSE’ button to
start processing. The blade
or disc will only rotate when
the Pulse buton is pressed.
,
Turn the main power ‘OFF’
before removing bowl,
attachments or processed
foods. Use the spatula to
remove the food items from
the bowl.
123
SETUP PROCESSOR PUSH TO PULSE TURN OFF
Insert attachment as
described on previous pages.
Add food items to be
chopped and close the lid or
just lock the lid ready for
items to be feed through
the feed tube.
Plug in the power cord and
turn the main power 'ON'.
The power light will
illuminate.
123
SETUP PROCESSOR ADD FOOD MAIN POWER ON
4START PROCESSING
Use the START/STOP button
on the control panel, press
once to start processing.
5FEEDING FOOD
Feed items through the feed
tube using the food pusher.
NEVER USE YOUR
FINGERS!
Press the START/STOP
button to stop processing
6TURNING OFF
Turn the main power ‘OFF’
before removing bowl,
attachments or processed
foods. Use the spatula to
remove the food items from
the bowl.
CONTINUOUS PROCESSING
DO NOT PROCESS CONTINUOUSLY FOR MORE THAN 5 MINUTES
AT A TIME.
1TURN ON
For auto pulsing, prepare
the food processor as if
continuous processing.
Turn the main power ‘ON’
2AUTOPULSE
Press the ‘AUTO PULSE’
button to start processing.
The blade or disc will
automatically pulse 10 times.
To stop mid cycle press
‘START/STOP’ button.
3TURN OFF
Turn the main power ‘OFF’
before removing the bowl,
attachments or processed
foods. Use the spatula to
remove the food items from
the bowl.
IB-DMP1-C_Layout 1 15/03/2011 11:56 Page 12

1514
PROCESSING TIPS
USING THE BOWLS
Always try and start with the tasks that require the smallest bowl first, so that you are
removing the used bowls instead of putting clean bowls inside dirty ones.
AUTO PULSE
Use this feature to achieve greater control for delicate foods or for a more even chop.The
Auto Pulse feature is perfect for mixing in foods without pureeing the mixture. When
selected the power light flashes, Press again to stop (or press pulse) If you press
START/STOP the processor will stop.
CHOPPING
For the best, most consistent results, you should try to process pieces of food that are
approximately equal in size. When you break, cut or tear food into uniform pieces before
you begin processing, the finished results will be more uniform. More consistent processing
results are achieved if the container is not overloaded.
MINCING
Pre-cut meat into cubes approximately 2cm square.
VEGETABLES
When processing vegetables such as onions, peel and quarter or cut large vegetables into
smaller evenly sized chunks.
MIXING
The quantities that can be processed within the processing bowls will vary with the density
of the mixture.
ADDING INGREDIENTS
When various recipes require dry ingredients such as flour, add them directly into the
bowl before processing.There is no need to sift ingredients when using your food
processor. Liquid ingredients may be added while the processor is operating
by pouring through the feed tube in the processor cover.
Note: When processing sauces or semi-liquid ingredients, stop the food processor and
scrape down the container sides with the spatula provided.
USING THE FEED TUBE
The most important factor for successful slicing and shredding is the way in which the food
is packed into the feed tube.
Note: Never use fingers to push food down the feed tube. Always use the food pusher.
For best results when slicing.The feed tube should always be packed firmly to allow each
piece of food to support the others.There will always be a small portion of food left
unprocessed between the food pusher and the blade. Preparing longer slices Pack food
items horizontally.
WHEN SLICING, SHREDDING AND GRATING
Cut all ingredients to a size that fits comfortably into the feed tube. Pack the feed tube and,
while holding food steady and upright with the food pusher, press down evenly until all
ingredients are sliced or shredded.The more firmly you push, the thicker the slices or
shreds. Do not use excessive force or you may damage the food processor.
PREPARING SHORTER SLICES
Pack the food items vertically in the feed tube, for best results when shredding and grating.
Remember that softer foods such as cheese (cheddar, mozzarella or Swiss) should be well
chilled before processing. Harder foods such as Parmesan or Romano cheese should be at
room temperature before processing. Note: When grating Parmesan cheese do not apply a
lot of pressure to the food pusher.
LIQUIDS
To maximize the capacity of the largest bowl when making soups use the Auto Pulse
feature rather than Start/Stop button when processing.To start, add the food chunks (e.g.
tomatoes) and use Auto Pulse, gradually adding the liquid through the feed tube. If mixture
overflows or fails to blend, stop processing, remove some of the ingredients and process in
smaller amounts.
DISASSEMBLY
When processing is completed.Turn off and dismantle the processor, clean and dry all parts.
Store the bowls, Medium blade and lid with food pusher assembled on the processor body.
Do not lock the bowl lid whilst in storage.This can damage the safety mechanism built into
the bowl. Note: Always wait for the processing blade to stop moving completely before
removing the cover. Warning: Use extreme caution, as blades are sharp.Always
handle the chopping blade by its central plastic section.
IB-DMP1-C_Layout 1 15/03/2011 11:56 Page 14

1716
CLEANING & MAINTENANCE
IT IS IMPORTANT TO CLEAN THE PROCESSOR AND ALL PARTS AFTER
EACH USE.THIS WILL PROLONG THE LIFE OF YOUR APPLIANCE.
STORING YOUR PROCESSER
TAKE CAUTION WHEN HANDLING THE BLADES AND DISC THEY ARE
ALL VERY SHARP. KEEP THE TOOLBOX OUT OF REACH OF CHILDREN.
ALWAYS SWITCH OFF AND
UNPLUG BEFORE ANY
CLEANING. NEVER USE
ABRASIVE CLEANERS ON
ANY OF THE PARTS.TAKE
EXTRA CARE WHEN
WASHING BLADES.
Dismantle the attachments
& bowls from the main
unit before you start
cleaning.
Wipe the main body with a
damp cloth. Dry immediately.
1TURN OFF &
UNPLUG
4CLEAN
IMMEDIATELY
Wash the bowl, lid, blades
and discs immediately after
each use with warm soapy
water. Use a small brush to
get to hard to reach areas.
40oC
5DISHWASHER
All attachments and bowls
excluding the main body are
suitable for dishwasher use..
Use a wash cycle below
40°C. Remove prior to
drying cycle.
TOP RACK
ONLY
6POSITIONING
Only put the food processor
parts on the top rack of
your dishwasher and keep
them well away from the
heating elements.
ENSURE THE PROCESSOR
IS UNPLUGGED WHILST
IN STORAGE, WITH THE
LID UNLOCKED.
THOROUGHLY CLEAN
AND DRY.
Dismantle the processor,
clean and dry all parts.
Store the bowls and lid with
food pusher assembled on the
processor body. Do not lock
the bowl lid whilst in storage.
This can damage the safety
mechanism built into the bowl.
1UNPLUG
4USE TOOL TRAY
The large blade, spindle,
spatula and all discs should
be stored in the toolbox
provided. Note there is one
empty disc space for spare
discs.
5CORD TIDY
Excess power cord can be
stored in the cord tidy on
the underside of the
processor.
6STORE IN A
SAFE PLACE
Remember to store all
accessories in the same
manor you would store
sharp knifes, away from
children and away from
the edge of a shelf.
DISMANTLE WIPE CLEAN
2323
CLEAN & DRY UNLOCK LID
IB-DMP1-C_Layout 1 15/03/2011 11:56 Page 16

1918
What do I do if my processor does not
turn on?
• Check the plug is correctly fitted in the
outlet and power supply is switch on.
• Check the fuse in the plug. Ensure the
new fuse is the same current value as
original.
• Ensure the bowl and lid are locked in
position.
• Check that the small bowl has properly
located onto the medium bowl. If not
the lid will not locate properly and the
processor will not turn on.
What if it switches itself off while I’m
using it?
• Check the lid or large bowl has not
become lose.
• The motor may have overheated.To
prevent damage, the motor has a safety
will thermal cutout, if it overheats for
any reason the motor will automatically
turn off.
If this happens: Press the main on/off
button to so no power light is visible,
unplug and allow the unit to fully cool.
Once cool the overheat safety feature
will reset and you can carry on using
the processor.
The main body is getting warm?
• You may have continuously processed
for more than 5 minutes or the mixture
may be too dense. Stop processing and
allow the processor to fully cool.
TROUBLESHOOTING
What if it doesn’t chop uniformly?
• Blades or discs may not be attached
properly.
• You may be exerting too much force
on the food while pushing down
the feeder tube.
What if my egg whites won’t
stiffen up?
• You may not be using enough eggs
(we recommend a minimum
of two eggs).
• You may be using the wrong accessory;
for egg whites you need the e-disc and
the large bowl.
• You may not be whisking for long
enough.
• Your bowl must be completely clean
and dry.
What if the drive shaft is sticking or
the motor is struggling to turn the
mixture?
• The mixture may be too dense,
remove some of the mixture and
process in batches.
RECIPE IDEAS
More home cooking means more control over what you feed yourself and your family.That
means no preservatives, additives or undesirable fats. And if the tedium of all that chopping,
slicing, grating and blending used to put you off cooking, it can now be done at the touch of
a button.
Mayonnaise – serves up to 8 people
1 egg – the freshest and best quality you can find
1 tbsp Dijon or grain mustard (or to taste)
the juice of half a lemon
300ml ground nut and extra virgin olive oil, mixed in a jug – see below salt and white
pepper
The ingredients will emulsify best if they are not cold.
Warm the egg a little by placing it (still in its shell) in a jug of warm water.
Stand the oils in a warm place to remove any chill. Use about 250ml ground nut and the
remainder olive oil, or more – if you prefer a stronger flavour.
Break the egg into the large bowl fitted with the E-disc and add the mustard and lemon
juice. Whiz until combined.
With your hand cupped over the feeder tube and the motor running, slowly and steadily
pour in the oils until the mixture becomes thick and shiny.
Season with salt and pepper, and add more lemon juice if you like.
Pulse briefly.
It will last for up to four days in the fridge.
IB-DMP1-C_Layout 1 15/03/2011 11:56 Page 18

2120
Quick and Easy Loaf – makes a 500g loaf
This basic bread recipe is quick and easy and can be adapted to your own taste.
Why not have fun and experiment with your choice of ingredients to vary the flavour and
texture.You can add seeds, nuts, curry pastes, dried fruits or herbs but always use good
quality organic flour from local mills as this produces a much more nutritious and
high quality product.
250g strong white flour
or 250g strong wholemeal flour
12.5g butter
3/4 tsp salt
3/4 tsp fast action dried yeast
1 tsp sugar
150ml warm water for the white loaf or
175ml warm water for the wholemeal loaf
In the large bowl fitted with the large blade mix together the flour, salt, yeast, butter and
sugar.
Process well, slowly adding the water through the feeder tube until the flour forms a craggy
ball – this should take approximately 2 minutes.
Leave the dough in the food processor to rise for approximately 20-30 minutes. Keep the
lid on for this process.
Pulse 3-4 times to knock the air out of the dough.
Remove the dough from the food processor and place in a greased 500g bread tin or on
an oiled baking sheet and cover with a cloth.
Allow to rise in a warm draught free place for another 1-2 hours or until doubled in size.
Bake in a preheated oven 220ºC/Gas Mark 7 for 25-30 minutes or until golden brown.
Tomato Ketchup – makes 600ml
Glistening and smooth, this homemade ketchup is made with the best of summer toma-
toes.The amount of sugar depends on the quality and sweetness of the fruit, and you could
get by with less. Serve with burgers, barbecues, chips, poached eggs, or what you will.
1.8kg ripe red sweet tomatoes
salt
200g onions, peeled, and chopped using the large bowl fitted
with its chopping blade. Feed the peeled onion down the feeder
tube onto the whirring blades
1 finger ginger, peeled
1 tsp blade mace
1 tsp black peppercorns
2 bay leaves
1/2 tsp allspice berries
100ml white wine vinegar
60g golden caster sugar (according to taste)
Cut the tomatoes into thick slices and place in a wide saucepan, sprinkling with salt as you
go.
Sprinkle the chopped onion on top.
Chop the ginger, using the medium bowl fitted with its chopping blade and tie in a bag
(muslin or a new j-cloth) with the spices. Nestle the bag between the tomatoes and cook
on a medium heat until a thick spicy pulp. Remove the bag,
Put the mixture into the large bowl fitted with its chopping blade and whiz quickly.
Rub through a sieve. Return to a rinsed out pan, and stir in the vinegar and sugar.
Cook gently, stirring regularly, until the consistency of double cream.
Pour into clean bottles, and store in the fridge, where it will keep for months.
IB-DMP1-C_Layout 1 15/03/2011 11:56 Page 20

2322
Fresh Beef Burgers
with Mint and Parsley – serves 6
These quarter-pounders are quickly made from the finest British beef and traditional herbs.
Enjoy them in the fresh air on a barbecue or rustle them up for a quick meal indoors.
Buy the trimmings of prime steaks from your butcher or at the farm gate.
680g rump, sirloin or fillet or use a mix, chopped into chunks,
trimmed of gristle
1 egg yolk
1 small bunch (5g) parsley leaves
1 small bunch (5g) mint leaves
salt and pepper
Tip all the ingredients into the large bowl fitted with its chopping blade, and pulse until a
coarse mince.
With wetted hands, shape into equal sized patties, using a kitchen scale to divide them into
112g burgers.
Place on a non-stick tray and chill until ready to cook.
Heat a non-stick pan with a smidgen of oil, and when smoking hot, season one side of the
burgers, pressing them well down each side with a fish slice to achieve a wonderful dark
colour. Flip over, season again, and cook as before. If you like them cooked all the way
through, turn down the heat, and cook for about 3-4 minutes each side.
Serve with fresh Tomato Ketchup.
Homemade Game Chips
and Straw Potatoes – serves 6
600g large potatoes, peeled
salt
1-2 litres groundnut or vegetable oil for deep-frying
a culinary thermometer is a great help when deep-frying
You will need a large deep pan.The oil should come less than half way up the sides.
Shape or cut the potatoes lengthwise to go down the feeder tube as snugly as possible.
Using the large bowl fitted with the slicing disc adjusted for the thickness of crisp you would
like, push the potatoes down the feeder tube with the food pusher.
Wash the slices, and if you have time soak the sliced potato for 15 minutes or so this will
make them light and airy. Drain and dry thoroughly on tea towels or kitchen paper. Frying
wet chips makes the oil rise and bubble up and over the sides of the pan.
Heat the oven to 50ºC/Gas mark low, cover an oven tray with several sheets of paper
towel, and place inside.
Heat the oil on full heat, and when it reaches 190ºC add a handful of sliced potato.When
the oil has stopped bubbling, stir the chips gently to stop them sticking. Keep the pan on full
heat – and don’t worry, the temperature of the oil falls dramatically when you add cold, raw
potatoes.
When golden, in about 5-7 minutes, lift them with a skimmer, and drain on a bed of
crumpled paper towel.They will rustle as you lift them, showing they are cooked. When
drained of all oil, transfer the chips to the oven, where they can be kept warm, uncovered.
Wait until the oil returns to 190ºC before frying the next batch. Sprinkle the chips with a
little salt before serving.
Straw Potatoes
Fit the shredding disc in the large bowl and use the larger holes to make fabulous little
straw potatoes.These are lovely served with hot and grilled seafood and fish.
Heat the oil to 120ºC and fry the chips for 5-6 minutes.They should be very pale and
crush easily with the back of a spoon. Leave draining on crumpled paper towel. Serve while
still hot and crisp.
IB-DMP1-C_Layout 1 15/03/2011 11:56 Page 22

2524
Traditional Victoria
Sponge Cake – 18cm, serves 8
There is nothing nicer than the simplicity of a Traditional Victoria Sponge cake.This all-in-one
method makes a perfectly light sponge for an indulgent afternoon tea - why not try a filling
of whipped cream, blueberry and lemon zest for a contemporary twist.The large bowl will
effortlessly take double the amount of ingredients to make an 8-egg sponge cake when
larger quantities are required.
175g soft butter or margarine (butter will produce a richer mix)
175g caster sugar
4 large eggs (weigh eggs in shells and then use same weight)
1 tsp baking powder
175g self-raising flour
1 tsp vanilla essence
4 tbsp strawberry jam (to decorate)
icing sugar to dust
Place the butter or margarine, sugar, baking powder and flour in the large bowl with its
chopping blade.
Remove the feeder tube to allow as much air into the mix as possible.
Pulse until the mixture is creamed together.
Break in the eggs and process for a further 10-15 seconds.
Pour into two 18cm cake tins.The tins should be well buttered and bases lined with silicone
mat or baking parchment.
Spread evenly and bake in a preheated oven 180ºC/Gas Mark 5 for 15-20 minutes or until
risen golden brown and firm to the touch.
Leave to cool.
Apply the jam to the top of one cake and sandwich together with the other.
Dust liberally with icing sugar and slice into generous helpings.
Vanilla Thins – makes about 20 biscuits
Homemade biscuits are always delicious, always impressive, and are much easier to make
than people think.These are thin and crunchy and are especially good to serve with
desserts. Give them a try – make them at the weekend, as the mixture likes a good rest
before baking. Keep any spare biscuit dough in the freezer for instant baking.
1 egg
2 tsp cream
1/2 tsp vanilla extract
125g unsalted butter, soft
100g caster sugar
25g icing sugar
150g self-raising flour
In a jug, lightly whisk the egg and then discard half of it, using a spoon. Stir in the cream and
vanilla extract.
Using the large bowl fitted with the large blade, whiz the butter and sugars until pale and
creamy. Add the egg and cream mixture, and then the flour, and press autopulse to mix until
you have a soft, paste-like dough.
On a lightly floured board, form the dough into a long roll of about 5cm diameter, and
wrap in foil or clingfilm. Put into the fridge until the next day.
Preheat oven to 190ºC/Gas Mark 5
Using a sharp, fine knife, cut the thinnest possible slices from the dough roll for the amount
of biscuits you require. Any spare dough will freeze well. Lay on a non-stick baking tray or
one lined with baking parchment.
Bake for 5 minutes, but watch! The biscuits should remain pale in colour.
Cool on a rack.
For special occasions, cut out each biscuit with a cookie cutter to achieve even shapes.
IB-DMP1-C_Layout 1 15/03/2011 11:56 Page 24

This Guarantee covers both parts and
labour. Carriage is not included.
Your guarantee period is as follows:
• 12 year guarantee on the motor,
• 3 year guarantee on parts
This Guarantee provides benefits which are
additional to, and do not affect, your
statutory rights.This guarantee does not
cover the cost of returning the product to
the dealer from whom it was purchased or
to ourselves.This guarantee applies only to
products sold and located in mainland
Great Britain. It does not cover liability in
respect of or replacement of plugs, cables
or fuses and also does not cover defects
due to:
• Failure to use or maintain product in
accordance with Dualit's instructions.
• The product being connected to an
unsuitable electricity supply.
• Accidental damage to or abuse or
misuse of the product.
• The product has not been modified
except by Dualit or approved agent.
• Dismantling of or interference with the
product.
• Theft or attempted theft of the
product.
Before returning any product under this
guarantee, please check that:
• You have followed the product
instructions correctly.
• Your mains electricity supply is
functional.
• The defect is not due to a blown fuse.
If you wish to claim under this guarantee
you should:
• Send the product, postage or carriage
paid, to the dealer from whom it was
purchased or to Dualit direct.
• Ensure that the product is clean and
packed carefully (preferably in its
original carton).
• Enclose details of your name, address
and telephone number and when and
where the product was purchased,
together with proof of purchase (e.g. a
till receipt).
• Give exact details of the nature of the
defect.
This Guarantee does not cover any other
claims whatsoever, including, without
limitation, any liability for incidental, indirect
or consequential damage, nor does it cover
any claims for conversion or modification or
for the costs of repair carried out by any
third party without the prior consent of
Dualit. If replacement parts are fitted to the
product this will not extend the period of
the guarantee.
For further advise contact the Dualit
customer helpline on [phone]
(09:00 to 17:00 Monday to Friday).
Alternatively, email Dualit at [email protected]
or visit www.dualit.com.
GUARANTEE
This appliance is of excellent quality and construction. However, if any defects in materials
or workmanship do appear during the relevant guarantee period, we will, at our discretion,
either repair or replace the defective parts, free of charge, subject to the terms and
conditions of our Guarantee shown below.
Bread Dough
Shortcrust Pastry
Minced Meat
Grated Soft Cheese
Grated Carrots
Sliced Tomatoes
Sliced Cucumber
Soup
Victoria sponge mix
Ingredients Large Bowl
600g
600g
1Kg
0.8Kg
1.3Kg
1.5Kg
1.3Kg
1.0L Thin - 1.3L Thick
4 Eggs - 2lbs
MAXIMUM LOADING CHART
Use the chart below as a guide to determine the maximum amount of ingredients to
be processed at one time in the large bowl:
2726
IB-DMP1-C_Layout 1 15/03/2011 11:56 Page 26

Dualit Limited County Oak Way Crawley West Sussex RH11 7ST
Telephone: +44 (0)
1293 652 500
Facsimile: [phone]
Email: [e-mail] Web: www.dualit.com
GB0311
IB-DMP1-C_Layout 1 15/03/2011 11:56 Page 28
