Ducati Diavel Carbon User manual

cod 913.7.197.1A

1
ENGLISH
Owner’s manual

2
This manual forms an integral part of the motorcycle and must be kept with it whole its service life.
If the motorcycle is resold, the manual must always be handed over to the new owner.
This manual must be preserved with care.
If it lost or becomes damaged, contact a Ducati Dealer or authorised Service Centre without delay to obtain
a new copy of the manual.
The quality standards and safety of Ducati motorcycles are steadily improved as new design solutions,
equipment and accessories are developed. While the information contained in this manual is current at the
time of going to print, Ducati Motor Holding S.p.A. reserves the right to make changes at any time without
notice and without any obligations. For this reason, the illustrations in this manual might differ from your
motorcycle.
Any and all reproduction or spreading of the contents herein in whole or in part is forbidden. All rights
reserved to Ducati Motor Holding S.p.A. Any request for written authorisation to do so shall be addressed to
this company, specifying the reasons for request.

3
Foreword
We would like to welcome you among Ducati
enthusiasts, and congratulate you on your excellent
choice of motorcycle. We think you will ride your
Ducati motorcycle for long journeys as well as short
daily trips. Ducati Motor Holding S.p.A. wishes you
smooth and enjoyable riding.
Your motorcycle is the result of Ducati Motor Holding
S.p.A.'s on-going research and development efforts.
It is important that you preserve its quality standard
by strictly observing the maintenance plan and using
genuine spare parts.
This manual provides instructions on minor
maintenance operations.
Major maintenance operations are described in the
Service Manual available to Ducati Authorised
Service Centres.
In your own interest, for your safety and in order to
guarantee product reliability, you are strongly advised
to refer to our authorised Dealers and Service
Centres for any operations listed in the scheduled
maintenance chart, see 191.
Our highly skilled staff have access to special
implements and appropriate equipment required to
perform any servicing job at best, and use Ducati
original spare parts only as the best guarantee for full
interchangeability, smooth running and long life.
All Ducati motorcycles come with a Warranty Card.
The warranty does not apply to motorcycles used in
racing competitions.
Tampering with or altering any components, even
partially, will make the warranty null and void
effective immediately.
Improper or poor maintenance, using other than
original spare parts or parts not expressly approved
by Ducati may invalidate your warranty rights and
lead to damage or loss of performance.

4
Table of contents
Foreword 3
Safety guidelines 8
Safety alerts 8
Permitted use 9
Rider's obligations 9
Rider training 11
Riding gear 11
Best practices for motorcycle safety 12
Refuelling 14
Carrying the maximum load allowed 15
Dangerous products - warnings 16
Vehicle identification number 18
Engine identification number 19
Instrument panel (Dashboard) 21
Instrument panel on handlebar 22
LCD unit functions 24
Vehicle speed indicator 25
Engine rpm indicator (RPM) 26
Clock 27
Coolant temperature 28
Display background colour (Automatic
adjustment) 29
Instrument panel on tank 29
TFT - Parameter setting/display 31
Total distance covered indicator: ”Odometer” 33
”Trip 1” meter 34
”Trip 2” meter 35
Distance travelled on fuel reserve: ”TRIP FUEL” 36
Indicator ”CONS. AVG” - Average fuel
consumption 37
Indicator ”CONS.” - Instantaneous fuel
consumption 38
Indicator “SPEED AVG” - Average speed 39
Indicator ”TRIP TIME” - Trip time 40
Indicator “AIR” - Air temperature 41
Engaged gear indicator 42
“Riding Mode set” indication 42
Indication if the “LAP” function is
active/not active 43
“Riding Style” function (riding style change) 44
Maintenance indicator 46
Maintenance table 46
First warning - OIL SERVICE 1000 Km 47

5
Residual range indication when the SERVICE is
due 48
Indication of range reached for SERVICE 50
Warning indication (Alarms/Signals) 52
“Low” battery level 54
Traction Control (DTC) deactivated 54
Hands Free key (HF) not recognised 55
”Low” Hands Free key (HF) battery level 55
”High” engine coolant temperature 56
Steering release error - Steering still locked 57
Instrument panel diagnosis 58
“Setting” menu 62
“Riding Mode” customisation 64
DTC (Ducati Traction Control) setting function 66
ENGINE setting function (Engine Power Control) 72
DEFAULT function (Resetting Ducati default
parameters) 74
Menu 2 On/Off function 76
Background setting function for the instrument panel
on tank - DASHBOARD 1 78
Backlighting setting function for the instrument panel
on handlebar - DASHBOARD 2 80
Digital RPM indication function 82
LAP Activation/Deactivation function
(lap time) 84
LAP registration function 86
Stored LAP display function 88
Stored LAP erase function 90
Battery voltage indicator (BATTERY) 92
Clock setting function 94
Units of measurement modification function 96
ABS disabling function 100
The Immobilizer system 102
Keys 102
Replacing the battery in the active key 104
Duplicate keys 107
Immobilizer override procedure 107
Light control 113
Controls 118
Position of motorcycle controls 118
“Hands free” system 119
LH switch 128
Clutch lever 129
RH switch 130
Throttle twistgrip 131
Front brake lever 131
Rear brake pedal 132

6
Gear change pedal 132
Adjusting the position of the gearchange and rear
brake pedals 133
Main components and devices 135
Position on the vehicle 135
Tank filler plug 136
Seat lock 137
Side stand 140
Passenger grabhandle 141
Adjusting the front fork 142
Adjusting the rear shock absorber 144
Riding the motorcycle 148
Running-in recommendations 148
Pre-ride checks 150
Engine on/off 152
Moving off 154
Braking 154
Stopping the motorcycle 157
Parking 157
Refuelling 161
Tool kit and accessories 162
Main maintenance operations 163
Change the air filter 163
Checking and topping up coolant level 163
Checking brake and clutch fluid level 164
Checking brake pads for wear 166
Lubricating cables and joints 167
Adjusting throttle control free play 168
Charging the battery 169
Charging and maintenance of the battery during
winter storage 177
Checking drive chain tension 179
Chain lubrication 180
Replacing the high and low beam bulbs 181
Beam setting 182
Rear-view mirror adjustment 184
Tubeless tyres 185
Checking engine oil level 187
Cleaning and replacing the spark plugs 188
Cleaning the motorcycle 189
Storing the motorcycle 190
Important notes 190
Scheduled maintenance chart 191
Operations to be carried out by the dealer 191

7
Operations to be carried out by the customer 194
Technical data 195
Overall dimensions 195
Weights 195
Engine 197
Timing system 197
Performance data 198
Spark plugs 198
Fuel system 198
Brakes 199
Transmission 200
Frame 201
Wheels 201
Tyres 201
Suspensions 202
Exhaust system 202
Available colours 202
Electrical system 203
Routine maintenance record 209

8
Safety guidelines
Your safety and that of other road users are very
important. Ducati Motor Holding S.p.A. recommends
that you ride responsibly. Before using your
motorcycle for the first time, read this entire manual
carefully and closely follow the guidelines outlined in
it. The manual provides full information on proper
motorcycle operation and maintenance. In case of
any doubts, please call a Dealer or Authorised Service
Centre.
Safety alerts
To alert you to potential hazards that could potentially
harm you or other persons, the following safety alerts
have been used:
- Safety labels on motorcycle;
- Safety messages preceded by a warning symbol
and the word Warning or Important.
Warning
Failure to comply with these instructions may
put you at risk and result in severe injury to rider or
other persons or even death.
Important
Possibility of damaging the motorcycle and/or
its components.
Note
Additional information concerning the job being
carried out.
The terms RIGHT and LEFT are referred to the
motorcycle viewed from the riding position.

9
Permitted use
This motorcycle must be used only on asphalted
roads or on level, regular pavement.
This motorcycle may not be used for riding on dirt
trails or for off-road riding.
Warning
Off-road riding may lead to loss of control,
resulting in severe damage to vehicle, injury or death.
Warning
This motorcycle may not be used to tow any
trailers or with a side-car attached; this can lead to
loss of control and result in an accident.
Warning
The total weight of the motorcycle in running
order including rider, passenger, luggage and
additional accessories should not exceed 400 kg.
Rider's obligations
All riders must hold a valid licence.
Warning
Riding without a licence is illegal and is
prosecuted by law. Always make sure you have your
licence with you when riding. Do not let
inexperienced riders or who do not hold a valid
licence use your motorcycle.
Do not ride under the influence of alcohol and/or
drugs.
Warning
Riding under the influence of alcohol and/or
drugs is illegal and is prosecuted by law.
Do not take prescription or other drugs before riding
unless you have consulted your doctor about their
side effects.
Warning
Some medications and drugs may cause
drowsiness or other effects that slow down reaction
time and the rider's ability to control the motorcycle,
possibly leading to an accident.

10
Some states require vehicle insurance.
Warning
Check your state laws. Obtain insurance
coverage and keep your insurance document secure
with the other motorcycle documents.
To protect rider and passenger safety, some states
mandate the use of a certified helmet.
Warning
Check your state laws. Riding without a helmet
may be punishable by law.
Warning
Riders without helmets are more likely to suffer
severe bodily injury or die if they are in an accident.
Warning
Check that your helmet complies with safety
specifications, permits good vision, is the right size
for your head, and carries a certification label
indicating that it conforms to the standards in force in
your state.
Traffic laws differ from state to state. Learn about
traffic laws in your state before riding and always
obey them.

11
Rider training
Accidents are frequently due to inexperience. Driving
a motorcycle is different from driving other vehicles
and requires specific riding and braking techniques.
Warning
Poor training or improper operation of the
vehicle can lead to loss of control, death or severe
damage.
Riding gear
Riding gear is very important for safety. Unlike cars,
a motorcycle offers no impact protection in an
accident.
Proper riding gear includes helmet, eye protection,
gloves, boots, long sleeve jacket and long pants.
- The helmet must the requirements listed at page
10; if your helmet does not have a visor, use
suitable eye wear;
- Use five-finger gloves made from leather or
abrasion-resistant material;
- Riding boots or shoes must have non-slip soles
and offer ankle protection;
- Jacket, pants or riding suit must be made from
leather or abrasion-resistant material and have
high-visibility colours and inserts.
Important
Never wear loose clothing, items or accessories
that may become tangled in motorcycle parts.
Important
For your safety, always wear proper protective
gear, regardless of season and weather.
Important
Have your passenger wear proper protective
clothing.

12
Best practices for motorcycle safety
These few simple operations are critical to people
safety and to preserving the full performance of your
motorcycle. Never forget to perform them before,
while and after riding.
Important
Closely follow the indications provided at page
148 during the running-in period. Failure to follow
these instructions releases Ducati Motor Holding
S.p.A. from any liability whatsoever for any engine
damage or shorter engine life.
Warning
Before riding your motorcycle, become familiar
with the controls you will need to use when riding.
Perform the checks recommended in this manual
before each ride (see page 150).
Warning
Failure to carry out these checks before riding,
may lead to motorcycle damage and injury to rider
and/or passenger.
Warning
Start the engine outdoors or in a well ventilated
area. The engine should never be started or run
indoors.
Exhaust gases are poisonous and may lead to loss of
consciousness or even death within a short time.
Use proper body position while riding and ensure
your passenger does the same.
Important
Rider must hold the handlebars with both hands
AT ALL TIMES while riding.
Important
Both rider and pillion passenger should keep
their feet on the footpegs when the motorcycle is in
motion.
Important
The pillion passenger should always hold on to
the grab handle (foldaway-type, see page 141) placed
inside the tail guard with both hands.

13
Important
Be very careful when tackling road junctions, or
when riding in the areas near exits from private
grounds, car parks or on slip roads to access
motorways.
Important
Be sure you are clearly visible and do not ride
within the blind spot of vehicles ahead.
Important
ALWAYS signal your intention to turn or pull to
the next lane in good time using the suitable turn
indicators.
Important
Park your motorcycle where no one is likely to
hit it and use the side stand.
Never park on uneven or soft ground or your
motorcycle may fall over.
Important
Visually inspect the tyres at regular intervals for
cracks and cuts, especially on the side walls, and
bulges or large stains that indicate internal damage.
Replace them if badly damaged.
Remove any stones or other foreign bodies caught in
the tread.
Warning
The engine, exhaust pipes, and silencers stay
hot for a long time after the engine is stopped; take
special care not to touch the exhaust system with
any part of your body and do not park the motorcycle
next to inflammable material (wood, leaves, etc.).
Warning
Always remove the key when you leave your
motorcycle unattended and make sure it is not
accessible to persons not authorised to use the
motorcycle.

14
Refuelling
Refuel outdoors with the engine turned off.
Do not smoke or use open flames when refuelling.
Be extremely careful not to spill fuel on the engine or
on the exhaust pipe.
Never fill the tank completely. Fuel should never be
touching the rim of filler recess.
While refuelling, avoid inhaling fuel vapours and avoid
contact with eyes, skin or clothing.
Warning
The vehicle is only compatible with fuel having
a maximum content of ethanol of 10% (E10). Using
fuel with ethanol content over 10% is forbidden.
Using it could result in severe damage of the engine
and motorcycle components. Using fuel with ethanol
content over 10% will make the warranty null and
void.
Warning
In the event of illness after prolonged breathing
of fuel vapours, stay outdoors and seek medical
advice. In the event of contact with eyes, flush with
plenty of water. After contact with skin, wash
immediately with water and soap.
Warning
Fuel is highly inflammable. Clothing with spilled
fuel on it should be removed as possible.

15
Carrying the maximum load allowed
Your motorcycle is designed for long-distance riding,
carrying the maximum load allowed in full safety.
Even weight distribution is critical to preserving these
safety features and avoiding trouble when
performing sudden manoeuvres or riding on bumpy
roads.
Warning
Do not exceed the total permitted weight for
the motorcycle and pay attention to information
provided below regarding load capacity.
Information about carrying capacity
Important
Arrange your luggage or heavy accessories in
the lowest possible position and close to motorcycle
centre.
Important
Never fix bulky or heavy objects to the
handlebar or to the front mudguard as this would
affect stability and cause danger.
Important
Secure the luggage firmly to the motorcycle
structure. Luggage incorrectly secured may cause
the motorcycle to become unstable.
Important
Do not insert any objects you may need to carry
into the gaps of the frame as these may foul moving
parts.
Warning
Make sure the tyres are inflated to the proper
pressure indicated at page 185 and that they are in
good condition.

16
Dangerous products - warnings
Used engine oil
Warning
Prolonged or repeated contact with used engine
oil may cause skin cancer. If exposed to used engine
oil on a daily basis, make it a rule to wash your hands
thoroughly with soap immediately after use. Keep
away from children.
Brake lining debris
Never attempt to clean the brake assembly using
compressed air or a dry brush.
Brake fluid
Warning
Avoid spilling brake fluid onto plastic, rubber or
painted parts of the motorcycle to avoid the risk of
damage. Protect these parts with a clean shop cloth
before proceeding to service the motorcycle. Keep
away from children.
Warning
The brake fluid used in the brake system is
corrosive. In the event of accidental contact with
eyes or skin, wash the affected area with abundant
running water.
Coolant
Engine coolant contains ethylene glycol, which may
ignite under particular conditions, producing invisible
flames. Although the flames from burning ethylene
glycol are not visible, they are still capable of causing
severe burns.
Warning
Take care not to spill engine coolant on the
exhaust system or engine parts. These parts may be
hot and ignite the coolant, which will subsequently
burn with invisible flames.

17
Coolant (ethylene glycol) is an irritant and is
poisonous when ingested. Keep away from children.
Never remove the radiator cap when the engine is
hot. The coolant will be scalding hot and is under high
pressure.
The cooling fan operates automatically: keep hands
well clear and make sure your clothing does not snag
on the fan.
Battery
Warning
The battery produces explosive gases; keep it
away from any source of ignition such as sparks,
flames and cigarettes. Charge the battery in a well-
ventilated area.

18
Vehicle identification number
Note
These numbers identify the motorcycle model
and should always be indicated when ordering spare
parts.
It is recommended to record the frame number of
your motorcycle in the space below.
Frame number
fig. 1

19
Engine identification number
Note
These numbers identify the motorcycle model
and should always be indicated when ordering spare
parts.
It is recommended to record the number of your
motorcycle's engine in the space below.
Engine number
fig. 2
