Ducati Superbike 1199 Panigale ABS User manual

Owner’s manual

Owner's manual US/CANADA
1

We'd like to welcome you among Ducati enthusiasts and congratulate you on your excellent choice of
motorcycle. We imagine you'll be riding your Ducati motorcycle for long trips as well as short daily excursions.
Ducati Motor Holding S.p.A. wishes you smooth and enjoyable riding.
Your motorcycle is the result of constant research and development by Ducati Motor Holding S.p.A., so it's
important that the standard of quality is upheld through careful observance of the scheduled maintenance
chart and the use of original spare parts. In the Owner's Manual you'll find instructions for performing small
maintenance procedures. The most important servicing and maintenance procedures are contained in the
Service Manual available at Authorized Service Centers of Ducati Motor Holding S.p.A..
In your own interest and safety, and in order to guarantee product reliability, we strongly recommend that
you go to an Authorized Dealer or Service Center for any servicing included on the scheduled maintenance
chart, see page 276.
Our highly skilled staff has access to the special tools and equipment needed to perform any servicing
procedure with expertise. They use only Ducati original spare parts as the best guarantee for full
interchangeability, smooth running and long life.
All Ducati motorcycles come with a Warranty Booklet. The Warranty does not extend to motorcycles used
in competitions or competitive trials. Any tampering or even partial modification of the components will result
in automatic invalidation of Warranty rights. Incorrect or insufficient servicing procedures, use of non-original
spare parts or parts not explicitly approved by Ducati may lead to the invalidation of the Warranty, besides
potential damage and reduced performance.
2

Table of Contents
Introduction 7
Safety guidelines 7
Warning symbols used in the manual. 7
Permitted use 8
Rider's obligation 9
Reporting of safety defects 11
Rider education 12
Clothing 12
“Best Practices” for safety 14
Refueling 16
Carrying the maximum load allowed 17
Dangerous products - warnings 18
Vehicle ID number 20
Engine ID number 21
Plate positioning 22
Noise and exhaust emission control system
information 28
California emission control warranty
statement 28
Your warranty rights and obligations 28
Manufacturer’s warranty coverage 29
Owner's warranty responsibilities 29
California evaporation emission system 30
Ducati limited warranty on emission control
system 31
Instrument Panel (Dashboard) 34
Instrument Panel 34
Acronyms and abbreviations used in the
Manual 38
Technological Dictionary 38
Function pushbuttons 41
How to set/display parameters 42
Main functions 50
Riding Mode 57
DTC 62
EBC 69
DQS 73
ABS 74
Menu 1 functions 77
Menu 1: Odometer (TOT) 78
Menu 1: Trip 1 (TRIP 1) 80
3

Menu 1: Trip 2 (TRIP 2) 82
Menu 1: Partial fuel reserve counter (TRIP
FUEL) 84
Menu 1: LAP time 86
MENU 2 functions 90
MENU 2: Coolant temperature 91
MENU 2: Instantaneous fuel consumption 93
MENU 2: Average fuel consumption 94
MENU 2: Average speed 95
MENU 2: Trip time 96
MENU 2: External air temperature 97
Auxiliary functions 99
CLOCK 100
Service warning (SERVICE) 101
OIL SERVICE zero indication 102
OIL SERVICE or DESMO SERVICE indication 104
Warnings/Alarms (Warning) 105
Error indication 109
Displayed error description 111
Side stand status display 116
Setting MENU 117
Customizing Riding Modes 1
Customizing Riding Modes: ABS setting 123
Customizing Riding Modes: Display setting 126
Customizing Riding Modes: DQS enable/
disable 129
Customizing Riding Modes: DTC level setting 132
Customizing Riding Modes: Engine setting 135
Customizing Riding Modes: EBC level setting 139
Customizing Riding Modes: Restore default
settings 141
Engine rpm digital indication (RPM) 143
Battery voltage 144
DDA 146
Pin Code 151
Changing the PIN CODE 155
Clock setup 159
Setting the date 163
Setting the display background 168
LAP 170
Setting the unit of measurement 176
Other functions 187
Display background color 195
Light control 197
The Immobilizer system 202
Keys 203
Operation 204
Duplicate keys 205
Vehicle release through PIN CODE 206
Controls 210
4
20

Position of motorcycle controls 210
Key-operated ignition switch and steering
lock 211
Left-hand switch 212
Clutch lever 213
Right-hand switch 214
Throttle twistgrip 215
Front brake lever 216
Rear brake pedal 217
Gear change pedal 218
Adjusting the position of the gearchange and rear
brake pedals 219
Main components and devices 221
Position on the vehicle 221
Tank filler plug 222
Seat lock 223
Side stand 224
Steering damper 226
Adjusting the front fork 227
Adjusting the rear shock absorber 229
Changing the motorcycle track alignment 231
Riding the motorcycle 233
Break-in recommendations 233
Pre-ride checks 236
Starting the engine 239
Moving off 241
Braking 241
ABS system 241
Stopping the motorcycle 243
Parking 243
Refueling 244
Tool kit and accessories 245
Main maintenance operations 246
Remove the fairing 246
Side fairings 247
Change the air filter 248
Check and top up the coolant level 249
Check brake and clutch fluid level 251
Check brake pads for wear 253
Charge the battery 254
Charge and maintenance of the battery during winter
storage 257
Check drive chain tension 259
Chain lubrication 261
Replace the high and low beam bulbs 262
Rear turn indicators 264
5

Beam setting 265
Adjust rear-view mirrors 267
Tubeless tyres 268
Check engine oil level 270
Clean and replace the spark plugs 272
Clean the motorcycle 273
Storing the motorcycle 274
Important notes 275
Scheduled maintenance chart 276
Scheduled maintenance chart: operations to be
performed by the Dealer 276
Scheduled maintenance chart: operations to be
performed by the customer 280
Technical data 281
Weights 281
Overall dimensions 282
Top-ups 283
Engine 284
Timing system 285
Performance data 286
Spark plugs 286
Fuel system 286
Brakes 286
Transmission 287
Frame 288
Wheels 288
Tires 288
Suspensions 288
Exhaust system 289
Available colors 289
Electrical system 290
Routine maintenance record 296
Routine maintenance record 296
6

Introduction
Safety guidelines
Your safety and that of others are very important.
Ducati Motor Holding S.p.A. urges you to ride your
motorcycle responsibly.
Before using your motorcycle for the first time,
please read this manual carefully from start to finish
and closely follow the guidelines. This will allow you
to obtain all information regarding a correct use and
maintenance. If you have any doubts or questions,
consult a Dealer or Authorized Service Center.
Warning symbols used in the manual.
Different forms of information regarding potential
hazards that may affect you or others have been
used. These include:
- Safety stickers on the motorcycle;
- Safety warnings preceded by a warning symbol
and by one or the two words CAUTION or
IMPORTANT.
Attention
Failure to observe these instructions may lead
to a hazardous situation and cause severe injury to
the rider or others, or even death.
Important
Possibility of damaging the motorcycle and/or
its components.
Note
Additional information regarding the job being
performed.
The terms RIGHT and LEFT are referred to the
motorcycle viewed from the riding position.
7

Permitted use
This motorcycle must be used only on road surfaces
with asphalt or flat and even pavement. This
motorcycle may not be used on dirt roads or for off-
road riding.
Attention
Using the bike off-road may cause the rider to
lose control, which in turn may lead to vehicle
damage, injury or death.
Attention
This motorcycle must not be used for towing or
for the addition of a sidecar, since this may cause a
loss or control and consequent accident.
This motorcycle carries the rider and may carry one
passenger upon installation of a dedicated kit
performed exclusively at a Ducati Dealer or
Authorized Service Center.
Attention
The total weight of the motorcycle in running
order with rider, passenger, baggage and additional
accessories must not exceed 816 lb/ 370 kg.
8

Rider's obligation
All riders must hold a driver's license.
Attention
Riding without a license is illegal and punishable
by law. Make sure you always have your license on
you when setting out on the motorcycle. Do not allow
inexpert riders or those not in possession of an
authorized driver's license to ride the motorcycle.
Do not ride the motorcycle when under the influence
of alcohol or drugs.
Attention
Riding under the influence of alcohol or drugs is
illegal and punishable by law.
Avoid taking medication before riding the motorcycle
if you have not consulted your doctor about potential
side effects.
Attention
Some medications may induce sleepiness or
other effects that impair reflexes and the ability of the
rider to control the motorcycle, which may lead to
accident.
Some countries require mandatory insurance
coverage.
Attention
Check the laws applicable to your country. Take
out an insurance policy and keep the policy in a safe
place along with the other motorcycle documents.
To protect the safety of the rider and/or passenger,
some countries have made it a law to wear a
homologated helmet.
Attention
Check the laws applicable to your country.
Riding without a helmet may be punishable by a fine.
9

Attention
Failure to be wearing a helmet in case of
accident increases the chance of serious injury and
even death.
Attention
Make sure that the helmet is in compliance with
safety specifications, provides excellent visibility, is
the correct size for the head, and has the DOT
(Department of Transportation) label affixed to the
helmet surface. Laws regulating traffic vary from
country to country. Check the laws in force in your
country before riding the motorcycle and pay strict
adherence to them .
Attention
Tampering with Noise Control System
Prohibited. Federal Law prohibits the following acts
or causing thereof:
1) the removal or rendering inoperative by any
person, other than for purposes of maintenance,
repair, or replacement, of any device or element
of design incorporated into any new vehicle for
the purpose of noise control prior to its sale or
delivery to the ultimate purchaser or while it is in
use; or
2) the use of the vehicle after such device or
element of design has been removed or
rendered inoperative by any person.
Among the acts presumed to constitute tampering
are those listed below:
1) Removal of, or puncturing the muffler, baffles,
header pipes or any other component that
conducts exhaust gases.
2) Removal or puncturing of any part of the intake
system.
3) Lack of proper maintenance.
4) Replacing any moving part of the vehicle, or parts
of the exhaust or intake system, with parts other
than those specified by the manufacturer.
This product should be checked for repair or
replacement if the motorcycle noise has increased
10

significantly through use. Otherwise, the owner may
become subject to penalties under state and local
ordinances.
Reporting of safety defects
If you believe your vehicle has a defect that could
cause a crash or cause injury or death, you should
immediately inform the National Highway Traffic
Safety Administration (NHTSA), in addition to
notifying Ducati North America, 10443 Bandley Drive
Cupertino, California, 95014, Tel: [phone],
Fax: [phone]. If NHTSA receives similar
complaints, it may open an investigation, and if it
finds that a safety defect exists in a group of vehicles,
it may order a recall and remedy campaign. However,
NHTSA cannot become involved in individual
problems between you, your dealer, or Ducati North
America. To contact NHTSA, you may either call the
Auto Safety Hotline toll-free at 1-800-424-9393 (or
366-0123 in Washington, D.C. area) or write to:
NHTSA, 1200 New Jersey Avenue SE W43-488,
Washington, D.C. 20590. You can also obtain other
information about motor vehicle safety from the
Hotline.
11

Rider education
Accidents are frequently due to inexperience. Riding,
maneuvering and or braking are carried out differently
from other vehicles.
Attention
A rider's lack of preparation or an inappropriate
use of the vehicle may result in a loss of control, death
or serious damage.
Check your knowledge of current "TRAFFIC LAWS";
read carefully and familiarize yourself with the
contents of the M.O.M (Motorcycle Operator
Manual) pertinent to your state available at the M.S.F.
website (Motorcycle Safety Foundation) (www.msf-
usa.org).
You are strongly recommended to take a riding
course approved by the M.S.F. (Motorcycle Safety
Foundation).
Clothing
Clothing in the use of the motorcycle plays an
important role in safety, as the motorcycle provides
a person no protection from impact in the same way
as an automobile.
Suitable clothing includes: helmet, eye protection,
gloves, boots, long-sleeved jacket and long pants.
-The helmet must have the requisites as listed on
page 9, if the helmet model has no visor, use
suitable goggles;
- Gloves must have five fingers and be made of
leather or other abrasion-resistant material;
-Boots or shoes used for riding must have non-slip
soles and ankle protection;
- Jacket and pants, or even riding suits, must be
made of leather or abrasion-resistant material
and in a color with inserts that are very visible.
Important
In any case, avoid wearing loose or floppy
clothing that can become stuck in the motorcycle
parts.
Important
For your safety this type of clothing must be
used in both summer and winter.
12

Important
For the safety of the passenger, make sure that
he or she also wears appropriate clothing.
13

“Best Practices” for safety
Before, during and after use, remember to follow
some simple rules that are extremely important for
safety and for maintaining the motorcycle at top
efficiency.
Important
During the whole running-in period, the
indications recommended in section "Riding the
Motorcycle" shall be observed carefully.
Failure to follow these instructions releases Ducati
Motor Holding S.p.A. from any liability whatsoever for
any engine damage or shorter engine life.
Attention
Do not ride the motorcycle unless you are well
familiarized with the controls to be used during the
ride.
Before starting the motorcycle, always perform the
checks detailed in this manual (see page 241).
Attention
Failure to perform checks may cause damage to
the vehicle and serious injury to the rider and/or
passenger.
Attention
Start the engine when outdoors or in a well
ventilated place. Never start the engine in a closed
environment.
Exhaust gases are poisonous and may lead to loss of
consciousness or even death within a short time.
During the ride, assume a correct body position and
make sure the passenger does the same.
Important
The rider should ALWAYS keep both hands on
the handlebar.
Important
Both rider and passenger should keep their feet
on the footpegs when the motorcycle is in motion.
14

Important
The passenger should always hold on to the
strap on passenger seat with both hands.
Important
Be very careful when maneuvering
intersections or when riding in areas near exits from
private grounds, parking lots or access roads to
highways.
Important
Be sure you are clearly visible and do not ride in
the blind spot of the vehicles ahead.
Important
ALWAYS signal your intention to turn or pull
over to the next lane with due warning using the turn
indicators.
Important
Park your motorcycle where no one is likely to
hit it, and use the side stand. Never park on uneven
or soft ground or your motorcycle may fall over.
Important
Visually inspect the tires at regular intervals for
cracks and cuts, especially on sidewalls, bulges or
large spots which are indicative of internal damage.
Replace them if badly damaged.
Remove any stones or other foreign bodies caught in
the tread.
Attention
The engine, exhaust pipes and mufflers stay hot
for a long time after the engine has been turned off.
Be especially careful not to touch the exhaust system
with any part of the body and never park the
motorcycle near flammable materials (wood, leaves,
etc.).
Attention
When you leave the motorcycle unattended,
always remove the ignition key and make sure it is
inaccessible to anyone unsuitable to ride the
motorcycle.
15

Refueling
Refuel the motorcycle in an open area and with the
engine switched off.
Do not smoke or ever use flames during refueling.
Be careful never to drop fuel on the engine or exhaust
pipe.
When refueling, do not fill the tank completely: fuel
should never be touching the rim of filler recess.
When refueling, avoid inhaling fuel vapors and take
care that they do not come in contact with eyes, skin
or clothing.
Attention
The vehicle is compatible only with fuel having
a maximum content of ethanol of 10% (E10).
Using fuel with ethanol content over 10% is
prohibited. Using it could result in severe damage of
the engine and motorcycle components. Using fuel
with ethanol content over 10% will render the
Warranty null and void.
Attention
In case of malaise caused by prolonged
inhalation of fuel vapors, stay outdoors and consult a
physician. In case of contact with eyes, rinse eyes
thoroughly with water. In case of contact with skin,
wash the area immediately with soap and water.
Attention
Fuel is highly flammable. If it accidentally spills
onto clothes, change them.
16

Carrying the maximum load allowed
Your motorcycle is designed for long-distance riding
with the maximum load allowed carried in full safety.
Even weight distribution is critical to preserving these
safety features and avoiding difficulties when
performing sudden maneuvers or riding on bumpy
roads.
Attention
Do not exceed the total permitted weight for the
motorcycle and pay attention to the information
below regarding load capacity.
Information about carrying capacity
Important
Arrange your luggage or heavy accessories in
the lowest possible position and close to motorcycle
center.
Important
Never fix bulky or heavy objects to the steering
head or front mudguard, as this would affect stability
and be dangerous.
Important
Be sure to secure the luggage to the supports
provided on the motorcycle as firmly as possible.
Improperly secured luggage may affect stability.
Important
Do not insert any objects you may need to carry
into the gaps of the frame, as these may interfere
with moving parts.
Attention
Make sure tires are inflated to the correct
pressure and that they are in good condition.
Please refer to paragraph "Tires" on page 268.
17

Dangerous products - warnings
Used engine oil
Attention
Prolonged or repeated contact with used engine
oil may cause skin cancer. If exposed to used engine
oil on a daily basis, make it a rule to wash your hands
thoroughly with soap immediately after use. Keep
away from children.
Brake lining debris
Never attempt to clean the brake assembly using
compressed air or a dry brush.
Brake fluid
Attention
Avoid spilling brake fluid onto plastic, rubber or
painted parts of the motorcycle to avoid the risk of
damage. Protect these parts with a clean shop rag
before servicing the motorcycle. Keep away from
children.
Attention
The brake fluid used in the brake system is
corrosive. In the event of accidental contact with eyes
or skin, wash the affected area with generous
quantities of running water.
Coolant
Engine coolant contains ethylene glycol, which may
ignite under particular conditions, producing invisible
flames. Although the flames from burning ethylene
glycol are not visible, they are still capable of causing
severe burns.
Attention
Take care not to spill engine coolant on the
exhaust system or engine parts.
These parts may be hot and ignite the coolant, which
will subsequently burn with invisible flames. Coolant
(ethylene glycol) is an irritant and is poisonous when
ingested. Keep away from children. Never remove
the radiator cap when the engine is hot. The coolant
will be scalding hot and is under high pressure.
18

The cooling fan operates automatically: keep hands
well clear and make sure your clothing does not get
caught in the fan.
Battery
Attention
The battery gives off explosive gases; keep it
away from any source of ignition such as sparks,
flames and cigarettes. Charge the battery in a well-
ventilated area.
19
