Duke Fitness SC40 User manual
DUSC40.01.02
max. 120 kg
~ 30 Min.
CM
30 kg
L 120 | B 61 | H 125
Art. No. DU-SC40
ASSEMBLY AND
OPERATING INSTRUCTIONS
INDOOR CYCLE SC40
2
INDOOR CYCLE SC40
3
Content
1 GENERAL INFORMATION 7
1.1 Technical Data 7
1.2 Personal Safety 8
1.3 Set-Up Place 9
2 ASSEMBLY 10
2.1 General Instructions 10
2.2 Scope of Delivery 11
2.3 Assembly 12
2.4 Adjustments 17
2.4.1 Adjusting the pedal belt 17
2.4.2 Adjust the resistance 17
2.4.3 Emergency brake function 17
2.4.4 Saddle adjustment 18
2.4.5 Adjusting the handlebars 18
3 OPERATING INSTRUCTIONS 19
3.1 Console Display 19
3.2 Button Functions 19
4 STORAGE AND TRANSPORT 20
4.1 General Instructions 20
4.2 Transportation Wheels 20
5 TROUBLESHOOTING, CARE AND MAINTENANCE 21
5.1 General Instructions 21
5.2 Faults and Fault Diagnosis 21
5.3 Maintenance and Inspection Calendar 22
6 DISPOSAL 22
7 RECOMMENDED ACCESSORIES 23
8 ORDERING SPARE PARTS 24
8.1 Serial Number and Model Name 24
8.2 Parts List 25
8.3 Exploded Drawing 27
5
Dear customer,
Thank you for choosing a Duke Fitness brand tness equipment. Duke Fitness oers you tness
equipment that makes it easy to start exercising regularly, stay t and lose weight. We want to help
you to achieve your tness goals quickly and sustainably and hope that your new tness equipment
will help you to do so. Do not hesitate to contact us if you have any further questions about your
training or tness equipment, or if you would like to add more equipment to your existing tness
equipment. We wish you much of success!
Your Fitness Team from Sport-Tiedje and Duke Fitness
Further information can be found at www.sport-tiedje.com
Legal Notice
Sport-Tiedje GmbH
Europe’s No. 1 for home tness
International Headquarters
Flensburger Straße 55
24837 Schleswig
Germany
Management:
Christian Grau
Sebastian Campmann
Dr. Bernhard Schenkel
No. HRB 1000 SL
Local Court Flensburg
European VAT Number: DE813211547
Disclaimer
©2019 Duke® is a registered brand of the company SportTiedje GmbH. All rights
reserved. Any use of this trademark without the explicit written permission of Sport-
Tiedje is prohibited.
Product and manual are subject to change. Technical data can be changed without
advance notice.
Intended Use
The equipment may only be used for its intended purpose.
The equipment is only suitable for home use. The equipment is not suitable for semi-professional
(e.g. hospitals, associations, hotels, schools, etc.) and commercial or professional use (e.g. tness
studios).
6
INDOOR CYCLE SC40
ABOUT THIS MANUAL
Please carefully read the entire manual before installation and rst use. The manual will help you to
quickly set up the system and explains how to safely use it. Make sure that all persons exercising with
the equipment (especially children and persons with physical, sensory, mental or motor disabilities)
are informed about this manual and its contents in advance. In case of doubt, responsible persons
must supervise the use of the equipment.
This equipment has been manufactured according to the latest safety knowledge.
As far as possible, potential safety hazards which could cause injury have been
eliminated. Make sure to carefully follow the instructions and that all parts are
securely in place. If required, read through the instructions again to correct any
mistakes.
Please pay close attention to the safety and maintenance instructions given here. The contract
partner cannot be held liable for damage to health, accidents or damage to the equipment when it
is not used in accordance with these instructions.
The following safety instructions may appear in this manual:
࣑ATTENTION
This notice indicates potentially hazardous situations which, if not avoided, may result in
property damage.
⚠CAUTION
This notice indicates potentially hazardous situations which, if not avoided, may result in slight
or minor injuries!
⚠WARNING
This notice indicates potentially hazardous situations which, if not avoided, may result in death
or serious injuries!
⚠DANGER
This notice indicates potentially hazardous situations which, if not avoided, will result in death
or serious injuries!
LNOTICE
This notice indicates further useful information.
Retain these instructions in a safe place for future reference, maintenance or when ordering
replacement parts.
7
1 GENERAL INFORMATION
1.1 Technical Data
LED - Display of
+ Time in min
+ Distance in m
+ Calories in kcal
+ Pulse
+ Gesamtschläge
Brake system: Magnet manual brake system
Weight and dimensions
Article weight (gross, including packaging): 35.5 kg
Article weight (net, without packaging): 30 kg
Packaging dimensions (L x W x H): approx. 107 cm x 25 cm x 87.5 cm
Set-up dimensions (L x W x H): approx. 120 cm x 61 cm x 125 cm
Maximum user weight: 120 kg
8
INDOOR CYCLE SC40
1.2 Personal Safety
⚠DANGER
+ Before you start using the equipment, you should consult your physician that this type of
exercise is suitable for you from a health perspective. Particularly aected are persons who:
have a hereditary disposition to high blood pressure or heart disease, are over the age of 45,
smoke, have high cholesterol values, are overweight and/or have not exercised regularly in
the past year. If you are under medical treatment that aects your heart rate, medical advice
is absolutely essential.
+ Note that excessive training can seriously endanger your health. Please also note that
heart rate monitoring systems can be inaccurate. If you notice any signs of weakness,
nausea, dizziness, pain, shortness of breath, or other abnormal symptoms, stop exercising
immediately and seek advice from your doctor if necessary.
⚠WARNING
+ This equipment may not be used by children under the age of 14.
+ Children should not be allowed unsupervised access to the equipment.
+ Persons with disabilities must have a medical license and must be under strict observation
when using the equipment.
+ The equipment is strictly for use by one person at a time.
+ If your equipment provides a safety key, the clip of the safety key must be attached to your
clothing before starting your training. In the event of a fall, the EMERGENCY STOP of the
equipment can be initiated.
+ Keep your hands, feet and other body parts, hair, clothing, jewellery and other objects well
clear of moving parts.
+ During use, wear suitable sports clothing rather than loose or baggy clothing.When wearing
sports shoes, make sure they have suitable soles, preferably made of rubber or other non-
slip materials. Shoes with heels, leather soles, studs or spikes are unsuitable. Never exercise
barefoot.
⚠CAUTION
+ If your equipment needs to be connected to the power supply with a mains cable, make
sure that the cable is not a potential tripping hazard.
+ Make sure that nobody is within the range of motion of the equipment during training so as
not to endanger you or other persons.
࣑ATTENTION
+ Do not insert any objects of any kind into the openings of the device.
9
1.3 Set-Up Place
⚠WARNING
+ Do not place the equipment in main corridors or escape routes.
⚠CAUTION
+ Choose a location in which to place the equipment such that there is enough free space/
clearance to the front, the rear and to the sides of the equipment. Make sure that you leave
at least 30 cm on each side of the equipment and at least 15 cm in front of and behind the
equipment as a training zone. This is the minimum required area in order to safely use the
equipment. The recommended free zone around the equipment should be at least 60 cm on
each side and 45 cm in front of and behind the equipment.
+ The training room should be well ventilated during training and not be exposed to any
draughts.
+ Choose the place in which to set up the equipment such that there is enough free space/
clearance to the front, the rear and to the sides of the equipment.
+ The set-up and mounting surface of the equipment should be at, loadable and solid.
࣑ATTENTION
+ The device may only be used in one building, in suciently tempered and dry rooms
(ambient temperatures between 10°C and 35°C). The equipment should not be used
outdoors or in rooms with high humidity (over 70%) like swimming pools.
+ A oor protective mat/equipment underlay can help to protect high-quality oor coverings
(parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight
unevenness.
Training zone
10
INDOOR CYCLE SC40
2 ASSEMBLY
2.1 General Instructions
⚠DANGER
+ Do not leave any tools, packaging materials such as foils or small parts lying around,
as otherwise there is a danger of suocation for children. Keep children away from the
equipment during assembly.
⚠WARNING
+ Pay attention to the instructions attached to the equipment in order to reduce the risk of
injuries.
⚠CAUTION
+ Do not open the packaging when it is lying on its side.
+ Ensure to have sucient room for movement in each direction during assembly.
+ The assembly of the equipment must be carried out by at least two adults. If in doubt, seek
the help of a third technically skilled person.
࣑ATTENTION
+ To prevent damage to the equipment and the oor, assemble the equipment on a mat or
packaging board.
LNOTICE
+ In order to make the assembly as simple as possible, some screws and nuts to be used can
already be pre-assembled.
+ Ideally, assemble the equipment at its later set-up place.
User
manual
Hardware
list
Main frame 1PC
Rear stabilizer 1PC
Front stabilizer 1PC
Handlebar 1PC
Pedal 2PCS
Handlebar post 1PC
Seat 1PC
Hardware list 1PC
User manual 1PC
#9 4PCS;#10 4PCS;#11 4PCS
#10 3PCS
#11 3PCS
#76 3PCS
#33 1PC
#34 1PC
#B 1PC
#A 1PC
11
2.2 Scope of Delivery
The scope of delivery consist of the following parts. At the beginning, check whether all parts
and tools belonging to the device are included in the scope of delivery and whether damage has
occurred. In the event of complaints, the contractual partner must be contacted directly.
⚠CAUTION
If parts of the scope of delivery are missing or damaged, the assembly must not be carried out.
Main Frame 1PC
Front Stabilizer 1PC
Rear Stabilizer 1PC
Seat 1PC
Pedals 2PCS
Handlebar Post 1PC
Handlebar 1PC Hardware List
1PC
Manual
1PC
#33 d10*Φ30*2.5 1PC
#34 M10*Φ58*32 1PC
#B S13*15 1PC
#A S6 1PC
#9 M8*20*S6 4PCS
#10 d8 4PCS
#11 d8*Φ16*1.5 4PCS
#10 d8 3PCS
#11 d8*Φ16*1.5 3PCS
#76 M8*16*S6 3PCS
x
xx
x
x
12
INDOOR CYCLE SC40
2.3 Assembly
࣑ATTENTION
Please remove the brake stop from the brake handle before you start assembling
the indoor cycle.
Before assembly, take a close look at the individual assembly steps shown and carry out the assembly
in the order given.
LNOTICE
First loosely screw all parts together and check that they t properly. Tighten the screws using
the tool only when you are instructed to do so.
Step 1: Assembly of the rear and front stabilizer and the pedals
1. Attach the front and rear stabilizer (1 & 12) to the main frame (81) with four screws (9), four spring
washers (10), and four washers (11) and tighten with the allen wrench (A).
LNOTICE
The pedals (27L/R) are marked with “L” and “R” for left and right. Be sure to attach the correct
pedal to the appropriate crank.
2. Attachtheleftpedal(40L)totheleftcrank(39L)byturning theleftpedal(40L)counterclockwiseby
hand until it is rmly seated, then use the spanner (B) to tighten it.
3. Attach the right pedal
(40R) to the right crank
(39R) by turning the right
pedal (40R) clockwise
by hand until it is rmly
seated, and then use the
spanner (B) to tighten it.
x
x
x
x
13
Step 2: Assembly of the handlebar post
1. Pass the cable (88) through the handlebar post (74) and the main frame (81).
࣑ATTENTION
Make sure not to pinch the cable during the next steps.
2. Attach the handlebar (78) to the handlebar post (74) using three screws (76), three spring
washers (10) and three washers (11) and tighten with the allen wrench (A) (Fig. B).
3. Loosen the knob (13) and pull it out.
4. Slide the handlebar post (74) into the main frame (81) and position it at the desired height.
5. Fasten the handlebar post (74) with the previously released knob (13) by tightening it again.
6. Connect the trunk line (88) to the sensor wire (89) (Fig. A).
x
x
14
INDOOR CYCLE SC40
Step 3: Assembly of the seat
1. Attach the seat slider (30) to the seat post (31) using a washer (33) and the knob (34).
2. Now tighten all screw connections tightly
15
Step 4: Alignment of the feet
1. If the oor is uneven, you can stabilise the unit by turning the foot pads (3) under the stabilisers
(1 & 12).
2. Lift the unit to the desired side and turn the foot pad under the stand.
3. Turn the foot pad clockwise to remove it and lift the unit.
4. Turn the foot pad counterclockwise to lower the unit.
16
INDOOR CYCLE SC40
Step 4: Insertment of the batteries
LNOTICE
Pay attention to the correct polarity (+
and -) in the following step.
1. Remove the battery cover (95) from the
console and insert the supplied batteries
(94).
2. Close the battery compartment again.
17
2.4 Adjustments
2.4.1 Adjusting the pedal belt
+ If the pedal strap is too tight, push the buckle and pull the strap upwards to loosen it. (Fig. A).
+ If the pedal strap is too loose, push the buckle and pull the strap down to pull it tighter (Fig. B).
2.4.2 Adjust the resistance
+ To increase the resistance, turn the knob (52) (“+”)
clockwise (A).
+ To decrease the resistance, turn the knob (52) (“-”)
counterclockwise (B).
2.4.3 Emergency brake function
+ The brake handle (19) is an emergency brake. Use
this safety function in any situation where you
need to get o the bike or stop the indoor cycle
ywheel. During exercise, press the brake lever
rmly (19) to stop the Indoor Cycle immediately.
18
INDOOR CYCLE SC40
2.4.4 Saddle adjustment
The seat of this indoor cycle is adjustable
horizontally and vertically.
+ To adjust the saddle vertically, release
and pull out the knob (13) on the seat
frame (31) and lift or lower the saddle
to the desired height. After adjustment,
reinsert the knob (13) and tighten it
again (Fig. A).
+ To adjust the saddle horizontally, turn
the knob (34) on the seat slider (30) out
and then slide the seat slider (30) into
the desired position. After positioning,
tighten the knob (34) again (Fig. B).
2.4.5 Adjusting the handlebars
The height of the handlebar of the indoor
cycle is is adjustable
+ To adjust the height of the
handlebar(78), loosen and pull out the
knob (13) on the handlebar post (74)
and then push the handlebar post(74)
up or down to the desired height. After
adjustment, tighten the knob (13)
again.
19
3 OPERATING INSTRUCTIONS
LNOTICE
Familiarise yourself with all the functions and setting options of the device before starting
training. Have the proper use of this product explained to you by a specialist.
3.1 Console Display
TIME + Display of the training time
+ Display range 0:00 – 99:59
SPEED + Display of the current speed
+ Display range 0.0 – 240 km/h
DISTANCE + Display of the covered distance
+ Display range 0 – 999.9 km
CALORIES + Display of calories
+ Display range 0 – 999.9 kcal
PULSE + Display of total beats
+ Display range 0 – 240 beats/min
SCAN + Automatically changing display of individual parameters (TIME - SPEED -
DISTANCE - CALORIES - PULSE)
BATTERY + Batteries must be replaced when necessary. Use two AAA batteries.
3.2 Button Functions
MODE Use this button to switch between the display of the dierent parametres manually.
20
INDOOR CYCLE SC40
4 STORAGE AND TRANSPORT
4.1 General Instructions
࣑ATTENTION
+ Make sure that the equipment is protected from moisture, dust and dirt in the selected
storage location. The storage location should be dry and well ventilated and have a constant
ambient temperature between 5°C and 45°C.
⚠WARNING
+ The storage location should be chosen so that improper use by third parties or children can
be prevented.
+ If your equipment does not have transportation wheels, the equipment must be
disassembled before transportation.
4.2 Transportation Wheels
࣑ATTENTION
If you want to transport your equipment over particularly sensitive and soft oor coverings, such
as parquet, planks or laminate, lay out the transport route with cardboard or similar to avoid
possible oor damage.
1. Stand in front of the equipment and lift it until the weight is transferred to the transportation
wheels. After that, you easily can move the equipment to a new position. For long transport
distances the equipment should be disassembled and safely packed.
2. Select the new location by following the instructions in the section 1.3 of this manual.
Table of contents
Other Duke Fitness Exercise Bike manuals
