Duplo DBM-150 User manual

INSTRUCTION MANUAL
STAPLER FOLDER
DBM-150
Be sure to read this manual prior to use.
Please leave this manual at the site of use for easy reference.
TRIMMER
DBM-150T
Original instructions

Introduction
Thank you for purchasing a Duplo product.
Be sure to read this manual prior to using the product.
After reading, leave the manual at the site of use for easy reference whenever questions related to the
product arise in the future.
Symbols
In this manual, several symbols are used to indicate important warnings. Please make sure to read
instructions accompanied by these symbols. These symbols have the following
meanings.
Describes instructions which must be followed in use.
Be sure to read the instructions to avoid problems due to incorrect operations.
Indicates supplementary or useful information.
Describes names of related items and supplementary instructions.
Trademark
The product name and company name used in this manual are trademarks or registered trademarks of the
respective companies.
For North America
Note:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.

i
Safety Precautions
Safety Precautions
In this manual, operations and handling of the unit which are hazardous are described using the following
marks to prevent personal injury or property damage to the user and others.
Ignoring this mark could result in the possibility of
serious injury or even death.
Ignoring this mark could result in the possibility of injury
or physical damage.
This mark indicates a “Warning” or “Caution”.
A graphic may be shown inside the mark to describe the warning or caution more specically.
This mark indicates a forbidden action.
A graphic may be shown inside the mark to describe the forbidden action more specically.
This mark indicates actions that must be performed.
A graphic may be shown inside the mark to describe the action to be performed more specically.
Power Supply
• Make sure the power supply used is always within the following range.
Power supply : 120 to 240 V AC, 50/60 Hz
• When you power other appliances from the same AC outlet, make sure that the combined power
consumption does not exceed the power supply capacity.
Rated power: 230 W (Excl. DBM-150T 130 W)
Rated current: 2.2 to 1.1 A (Excl. DBM-150T 1.2 to 0.7 A)
Use only the power supply voltage specified on the main nameplate.
Using other voltages could result in a re or an electrical shock.
Make sure that the combined power consumption of the appliances to be
connected does not exceed the capacity rating of the power outlets or plug
receptacles.
Exceeding the capacity rating could cause the power outlets, plug receptacles, or power extension cords to
overheat and catch a re.

ii
Safety Precautions
Operating Environment
Operate this unit in the following environment.
• where the temperature range is between 5 and 35°C (-10 to +50°C in storage)
• where the humidity range is between 20 and 85% RH (10 to 90% RH in storage, however no condensation)
• which is not subject to direct sunlight
• which is reasonably free from dust
• which is subject to little or no vibration
• which is free from air-borne salt
• where there are no harmful chemicals
• where the unit is not exposed to water
Keep this unit and the power cord away from heaters and heater vents.
Excessive heat could melt the cover or power cord covering, and result in a re or an electrical shock.
Do not place metal objects or vessels containing liquids on top of the unit.
The entry of any metal object or liquid could result in a re or an electrical shock.
Do not insert any metal or easily-combustible object inside this unit.
This could result in a re or an electrical shock.
Do not use flammable sprays inside or near the unit (e.g. when cleaning the
unit).
Such ammable gas may ignite and cause a re or combustion.
Do not install this unit in a location where there is excessive humidity or
where contact with water is possible.
Poor choice of location could result in deterioration of the insulation, a re or an electrical shock.
Install this unit on a level, stable stand or floor, with sufficient space around it.
Failure to do so could result in the unit overturning and causing injury.
Disconnect the power plug from the power outlet before attempting to move
this unit.
Failure to do so could result in power cord damage, a re or an electrical shock.
Always disconnect the power plug from the power outlet when the unit is not
to be used for an extended period.
Failure to do so could result in a re due to leakage current if the insulation should deteriorate.

iii
Safety Precautions
Maintenance / Other
Do not damage the power cord or power plug.
Do not scratch, alter, bend, twist, pull or place heavy objects on the power cord or power plug.
This could result in damage, a re or an electrical shock.
Do not touch the power switch with wet hands.
Otherwise electric hazards may occur.
Do not remove the cover or back panel.
This unit contains high-voltage components that could cause an electrical shock.
Do not disassemble, modify or repair this unit.
There is a danger of re, electrical shock or injury.
Contact your dealer when repairs are necessary.
If any foreign object such as metal or liquid should enter this unit,
immediately turn the unit off at the power switch and disconnect the power
plug from the power outlet.
Failure to do so could result in a re or an electrical shock.
Contact your dealer immediately.
Before cleaning this unit, turn the unit off at the power switch and disconnect
the power plug from the power outlet.
Accidental operation of the unit during cleaning could result in injury.
Remove any dust that accumulates on the power plug prongs and the surface
of the plug from which the prongs extend. Before removing dust, turn the unit
off at the power switch and disconnect the power plug from the power outlet.
Accumulated dust could result in a re.
Always grip the plug when disconnecting the power plug from the power
outlet.
Forcibly pulling on the power cord could cause damage, resulting in a re or an electrical shock.
Do not touch or insert foreign objects into any rotating part during operation.
This could result in injury.

iv
Safety Precautions
WARNING / CAUTION Labels
"WARNING" and "CAUTION" labels are pasted on the machine to ensure user safety.
Do not remove or change them.
When the labels become dirty or are lost, be sure to contact your dealer for a new one.
For North America
Do not sit on the stacker tray.
Do not push the stacker tray.
Do not put a heavy load on the stacker tray.

v
Safety Precautions
For EU
Do not sit on the stacker tray.
Do not push the stacker tray.
Do not put a heavy load on the stacker tray.

vi
Contents
Contents
Safety Precautions .............................................i
Power Supply .................................................................................i
Operating Environment ...........................................................ii
Maintenance / Other ............................................................... iii
WARNING / CAUTION Labels ................................................iv
Chapter 1 Before Operation
1. Features ................................................... 1-1
1-1. The features of the DBM-150 ..............................1-1
1-2. The features of the DBM-150T ...........................1-2
2. Names and Functions of
Components ............................................ 1-3
2-1. DBM-150 external parts ........................................1-4
2-2. DBM-150 internal parts .........................................1-6
2-3. DBM-150T ................................................................... 1-8
2-4. Belt stacker .................................................................1-9
2-5. Accessories ...............................................................1-10
3. Names of Control Panel .......................1-11
4. Screen Descriptions .............................1-12
4-1. Top screen ................................................................1-12
4-2. Menu list ....................................................................1-13
5. Options .................................................. 1-19
5-1. CORNER AND SIDE STAPLE KIT .........................1-19
5-2. SXS MODIFICATION KIT .......................................1-20
6. Workflow ...............................................1-22
Chapter 2 Basic Operation
1. Turning On/Off the Power ..................... 2-1
1-1. Turning on the power ............................................2-1
1-2. Turning o the power ............................................2-2
2. Setting the Control Panel ...................... 2-2
2-1. Setting the standard size ......................................2-2
2-2. When setting the custom size ............................2-3
3. Preparing the DBM-150 ......................... 2-5
3-1. Adjusting the position of the stapler...............2-5
3-2. Adjusting the folding roller gap ......................2-10
3-3. Adjusting the position of the paper guide
roller ............................................................................2-11
4. Preparing Upstream Unit ....................2-11
5. Adjusting Each Section (Step
Mode) .....................................................2-11
5-1. Starting the step mode .......................................2-11
5-2. Adjusting the guide position ............................2-12
6. Checking a Finished Set .......................2-13
6-1. When sheets are not aligned ............................2-13
6-2. When stapling and folding positions do not
align ............................................................................2-14
6-3. Adjusting stapling and folding positions
simultaneously .......................................................2-16
6-4. Adjusting the trimming position (when the
DBM-150T is connected) ..............................................2-17
7. Adjusting Each Part .............................. 2-17
7-1. When the folding position is not straight ....2-17
7-2. Adjusting the roller gap .....................................2-18
7-3. Adjusting trimming misalignment .................2-19
7-4. Adjusting the belt stacker .................................2-20
8. Starting Operations ............................. 2-21
Chapter 3 Advanced Operation
1 Attaching the CORNER AND SIDE STAPLE KIT
(Option)...................................................................... 3-1
2. Attaching the SXS MODIFICATION KIT
(OPTION) .......................................................... 3-4
2-1. Preparing the side guide unit .............................3-5
2-2. Attaching the lower conveyance unit (L) and
the side guide unit ..................................................3-7
2-3. Attaching the lower conveyance unit (S) and
the side guide unit ................................................3-11
2-4. Attaching the SXS stapler guide......................3-14
2-5. Setting the number of jogs on the sheet
feeder .........................................................................3-14
2-6. Using the TRAIL EDGE AIR KIT (option) .........3-14
3. Feeding Paper Manually ...................... 3-15
Chapter 4 Cleaning the Unit
1. Cleaning Each Part ................................. 4-1
1-1. Cleaning the conveyance belt and rollers .....4-1
1-2. Cleaning the LCD .....................................................4-1
1-3. Cleaning the sensor ................................................4-2
2. Replacing the Stapler Cartridge ........... 4-4
Chapter 5 Trouble Guide
1. Error Code (Error Message) ................... 5-1
1-1. Warning error ............................................................5-1
1-2. Paper jam error .........................................................5-2
1-3. Power and motor error ..........................................5-2
1-4. Errors requiring a service call ..............................5-3
2. Paper Jam ................................................ 5-4
2-1. Paper jam at the DBM-150 ...................................5-4
2-2. Paper jam at the DBM-150T ................................5-6
3. Troubleshooting ..................................... 5-7

vii
Contents
3-1. Troubleshooting for the DBM-150 ...................5-7
3-2. Troubleshooting for the DBM-150T ...............5-10
3-3. Common troubleshooting for the DBM-150
and DBM-150T ........................................................5-10
Chapter 6 Appendix
Specifications ................................................ 6-1

viii
Contents
Memo

1-1
Chapter 1 Before Operation
Chapter 1 Before Operation
1. Features
1-1. The features of the DBM-150
• The DBM-150 is a stapler folder that can make a booklet in two binding modes: saddle staple and fold (no
staple, fold only).
Saddle staple Fold
You can also make a booklet in other modes using the option kit below.
CORNER AND SIDE STAPLE KIT: side staple, corner staple
SXS MODIFICATION KIT: used to connect a sheet feeder as a upstream unit.
• The DBM-150T (trimmer) can be connected to the DBM-150 as a downstream unit.
• When connected to a collator, the DBM-150 and the DBM-150T can be used as a system machine. With
the use of the SXS MODIFICATION KIT (option), the sheet feeder can be connected to this machine as a
upstream unit.

1-2
Chapter 1 Before Operation
1-2. The features of the DBM-150T
The DBM-150T is a trimmer and is connected to the stapler folder DBM-150. The DBM-150T trims the fore-
edge of a booklet made by the DBM-150.
As a downstream unit of the DBM-150, this machine starts or stops in conjunction with the DBM-150.
Binding Operations
1) Stapled and folded paper
The booklet stapled and folded by the upstream unit is sent to this machine and trimmed. After
being trimmed, the booklet will be conveyed to the belt stacker. The booklet can be ejected even
without trimming.
2) Folded paper
The booklet folded (not stapled) by the upstream unit is sent to this machine and trimmed. After
being trimmed, the booklet will be conveyed to the belt stacker. The booklet can be ejected even
without trimming.
Because the booklet is not stapled, it may not be trimmed properly if the folded paper is poorly
aligned.
3) Side and corner stapled paper (option)
The booklet side-stapled or corner-stapled by the DBM-150 is sent to the belt stacker through this
machine. The booklet cannot be trimmed.

1-3
Chapter 1 Before Operation
2. Names and Functions of Components
When using both the DBM-150 and the DBM150T, each machine is connected with each other as shown in
the gure below. When not using the DBM-150T, the belt stacker is connected to the DBM-150.
This manual describes how to use both the DBM-150 and the DBM-150T.
Note that the appearance of the belt stacker for users in the EU may be dierent from that shown in this
manual.
DBM-150 DBM-150T
Belt stacker

1-4
Chapter 1 Before Operation
2-1. DBM-150 external parts
[1] [2]
[4]
[9]
[10]
[6]
[7]
[5]
[3]
[8]

1-5
Chapter 1 Before Operation
No. Name Function
[1] Top cover Cover for ensuring user safety. This machine will not operate if
open.
[2] Control panel Use this panel to enter information to operate the machine.
(p.1-11)
[3] Folding misalignment adjustment Adjusts folding misalignment.
(p.2-17)
[4] Inlet for stacker connector Insert the connector of the belt stacker to this inlet.
[5] Stopper cover Open the cover when a paper jam occurs. This machine will not
operate if open.
(p.5-4)
[6] Manual feed guide F/B Move these guides according to a paper size when feeding paper
manually.
(p.3-15)
[7] Power switch
”1. Turning On/Off the Power” (p.2-1)
[8] Manual feed inlet/paper feed inlet When using this machine alone, insert paper into this inlet
manually.
(p.3-15)
When connected to a upstream unit, paper from the upstream unit
is conveyed through this inlet.
[9] Main power switch
”1. Turning On/Off the Power” (p.2-1)
[10] Power inlet Inlet for the power cord

1-6
Chapter 1 Before Operation
2-2. DBM-150 internal parts
[5]
[6] [7]
[7]
[6]
[12]
[9]
[11]
[9]
[13] [14] [15] [13] [12]
[5]
[8]
[2] [3]
[10]
[1] [1]
[4]

1-7
Chapter 1 Before Operation
No. Name Function
[1] Side guide Aligns the sides of paper.
(p.2-12)
When the SXS MODIFICATION KIT (option) is attached to this
machine, the shape of the side guide is dierent.
(p.3-4)
[2] Conveyance roller Conveys paper.
(p.4-1)
When the SXS MODIFICATION KIT (option) is attached to this
machine, there is no conveyance roller.
[3] Conveyance belt Conveys paper.
(p.4-1)
[4] Back guide Aligns the trail edge of paper and conveys paper.
(p.2-12)
[5] Stopper Decides the stapling position and folding position.
[6] Clincher Bends the stapler pin at.
(p.2-5)
[7] Clincher xing screw Loosen the screw when moving the clincher.
(p.2-5)
[8] Hexagonal wrench holder Holder for storing the supplied hexagonal wrench
(p.2-5)
[9] Roller gap adjustment Adjusts the gap between the folding rollers.
(p.2-10)
[10] Ejection unit Ejects a booklet folded by the folding rollers. When a paper jam
has occurred, remove the ejection unit to remove the paper.
(p.5-5)
[11] Folding roller Fold a booklet.
(p.2-10)
[12] Inlet for stapler unit connector Connector for the stapler unit.
(p.2-5)
[13] Stapler xing knob Fastens the stapler unit.
(p.2-5)
[14] Stapler unit F Staples a bunch of paper. This is attached to the operator’s side of
the machine.
(p.2-5)
[15] Stapler unit B Staples a bunch of paper. This is attached to the non-operator’s
side of the machine.
(p.2-5)

1-8
Chapter 1 Before Operation
2-3. DBM-150T
[1]
[5]
[5]
[4]
[6]
[7]
[7]
[6]
[6]
[3] [2]
No. Name Function
[1] Top cover Cover for ensuring user safety. This machine will not operate if
open.
[2] Scrap box Scrap paper of trimmed booklets is ejected to this box.
[3] Trimming stopper adjustment Adjusts the position of the trimming stopper to correct trimming
misalignment.
(p.2-19)
[4] Roller gap adjustment lever Adjusts the gap between the conveyance rollers. Adjustable to two
positions.
(p.2-18)
[5] Conveyance belt Conveys paper.
(p.4-1)
[6] Paper holder Holds paper during trimming.
[7] Trimming position stopper Determines the length of the paper.
(p.2-19)

1-9
Chapter 1 Before Operation
2-4. Belt stacker
[1]
[3]
[2]
[4]
No. Name Function
[1] Belt stacker Booklets are ejected here from the DBM-150 or the DBM-150T.
[2] Conveyance belt Conveys paper.
(p.4-1)
[3] Paper guide roller Holds a booklet as an aid for the belt stacker.
(p.2-11)(p.2-20)
[4] Ejection tray Ejected booklets are stacked on this tray.

1-10
Chapter 1 Before Operation
2-5. Accessories
[1] [2] [3]
[6][5][4]
No. Name QTY Use
[1] Manual feed guide F 1 Attach the guide to the operator's side of the manual feed inlet/paper
feed inlet with the magnet and move them according to a paper size.
(p.3-15)
[2] Manual feed guide B 1 Attach the guide to the non-operator's side of the manual feed inlet/
paper feed inlet with the magnet and move them according to a paper
size.
(p.3-15)
[3] Hexagonal wrench 1 Use to secure the position of the clinchers. Do not use this wrench for a
purpose other than handling the clincher xing screws as instructed in
this manual.
(p.2-5)
[4] Power cord for North
America
1 For 120 V
[5] Power cord for EU 1 For 220 to 240 V
[6] Instruction manual 1 This manual
