Duracell Lithium Coin Battery IEC ANSI User manual

This data is subject to change. Performance information is typical. Contact Duracell for the latest information
6/08
Lithium Coin Battery
Duracell IEC ANSI Voltage Overall Ht.(MM) Overall Ht.(in.) Diameter (MM) Diameter (in.)
DL1025 - - 3.0 2.5 0.080 10 0.394
DL1216 - - 3.0 1.6 0.063 12.5 0.492
DL1616 CR1616 - 3.0 1.6 0.063 16 0.63
DL1620 CR1620 5009LC 3.0 2.0 0.079 16 0.63
DL2016 CR2016 5000LC 3.0 1.6 0.063 20 0.787
DL2025 CR2025 5003LC 3.0 2.5 0.098 20 0.787
DL2032 CR2032 5004LC 3.0 3.2 0.126 20 0.787
DL2430 CR2430 5011LC 3.0 3.0 0.118 24.5 0.965
DL2450 CR2450 5029LC 3.0 5.0 0.197 24.5 0.965
Duracell Batteries (Lithium)
Duracell Endpoint Voltage
Typical
Capacity
(MAh)
DL1025 2.0 30
DL1216 2.0 25
DL1616 2.0 55
DL1620 2.0 68
DL2016 2.0 85
DL2025 2.0 160
DL2032 2.0 230
DL2430 2.0 285
DL2450 2.0 540
Berkshire Corporate Park
Bethel, CT 06801 U.S.A.
Telephone: Toll-free 1-800-544-5454
Internet: www.duracell.com
Delivered capacity is dependent on the applied load, operating temperature and cut-off voltage.
*
